SLIDE 1
Patrik Lantto An insight into DVB
WISI ISI Ch Chameleon descrambling Hering Sndor Mini Galria TV s - - PowerPoint PPT Presentation
WISI ISI Ch Chameleon descrambling Hering Sndor Mini Galria TV s - - PowerPoint PPT Presentation
WISI ISI Ch Chameleon descrambling Hering Sndor Mini Galria TV s Antenna Kft. Dig Digital Vid Video Br Broadcasting An insight into DVB Patrik Lantto What is DVB ? https://www.dvb.org/ Founded in 1993 First standard is
SLIDE 2
SLIDE 3
Patrik Lantto An insight into DVB
- https://www.dvb.org/
- Founded in 1993
- First standard is DVB-S
- 2. generation modulation
standards since 2004
- ca 180 companies
- More than 150 industrial
standard
What is DVB ?
SLIDE 4
Patrik Lantto An insight into DVB
- First made in 2010
- Current software version 3.2.6
- Common hardware platform, service
configuration by firmware = long life headend
WISI Chameleon
SLIDE 5
Patrik Lantto An insight into DVB
GN HWUW2 Chameleon
SLIDE 6
Patrik Lantto An insight into DVB
- ASI input max payload 200 Mbit/s
- 20 → 128 IP (SPTS / MPTS), UDP multicast,
unicast
- Load 400 → 1200 Mbit/s (MFW 3.x)
- IP input bitrate 200 → 850 Mbit/s
- IP output bitrate 200 → 850 Mbit/s
- CBR, VBR
- Descrambling function
- Tight product tracking with DVB
Why Chameleon ?
SLIDE 7
Patrik Lantto An insight into DVB
Descrambling in Chameleon
Number of CI slots 2 CI slots, parallel operation Supported bit rates 55 / 62 / 72 Mbit/s Multidecryption Yes Service level decryption Yes PID level decryption Yes Compliance EN 50221
SLIDE 8
Patrik Lantto An insight into DVB
- Digi
- Telekom
- MTVA
- UPC Direct
DTH platforms
SLIDE 9
Patrik Lantto An insight into DVB
Consumer / Professional CAM
SLIDE 10
Patrik Lantto An insight into DVB
WISI local representation
SLIDE 11
Patrik Lantto An insight into DVB
WISI Communications GmbH & CO KG.
Niefern-Öschelbronn 75223 BRD
