WiredTiger Backend for OpenLDAP Open Source Solution Technology Corporation Tsukasa Hamano <hamano@osstech.co.jp> LDAPCon 2015 Edinburgh November 2015 Open Source Solution Technology Corporation 1 WiredTiger Backend for OpenLDAP About

SLIDE 1

WiredTiger Backend for OpenLDAP

Open Source Solution Technology Corporation Tsukasa Hamano <hamano@osstech.co.jp> LDAPCon 2015 Edinburgh November 2015

Open Source Solution Technology Corporation 1

SLIDE 2

WiredTiger Backend for OpenLDAP

About OSSTech

ID Management leading company in

Japan.

Storage Solution
Open Source Contribution

Open Source Solution Technology Corporation 2

SLIDE 3

WiredTiger Backend for OpenLDAP

What’s back-wt

New OpenLDAP Backend
WiredTiger Database

Open Source Solution Technology Corporation 3

SLIDE 4

WiredTiger Backend for OpenLDAP

About WiredTiger

Embedded database
High performance
High scalability

Open Source Solution Technology Corporation 4

SLIDE 5

WiredTiger Backend for OpenLDAP

Lock Free

Hazard pointer
Optimistic concurrency control

Open Source Solution Technology Corporation 5

SLIDE 6

WiredTiger Backend for OpenLDAP

Data Structure

Open Source Solution Technology Corporation 6

SLIDE 7

WiredTiger Backend for OpenLDAP

bdb_next_id()

✞ ☎

int bdb_next_id( BackendDB *be, ID *out ) { struct bdb_info *bdb=(struct bdb_info*)be->be_private; ldap_pvt_thread_mutex_lock(&bdb->bi_lastid_mutex); *out = ++bdb->bi_lastid; ldap_pvt_thread_mutex_unlock(&bdb->bi_lastid_mutex); return 0; }

✝ ✆

Open Source Solution Technology Corporation 7

SLIDE 8

WiredTiger Backend for OpenLDAP

wt_next_id()

✞ ☎

int wt_next_id(BackendDB *be, ID *out){ struct wt_info *wi = (struct wt_info *)be->be_private; *out = __sync_add_and_fetch(&wi->wi_lastid, 1); return 0; }

✝ ✆

Open Source Solution Technology Corporation 8

SLIDE 9

WiredTiger Backend for OpenLDAP

fsync(2) is slow

Open Source Solution Technology Corporation 9

SLIDE 10

WiredTiger Backend for OpenLDAP

Durability Levels

1. in-memory txn log – fastest but no

durability

2. write txn log file, no sync
3. write txn log file, sync per every

commit

Open Source Solution Technology Corporation 10

SLIDE 11

WiredTiger Backend for OpenLDAP

New Benchmark Tool - lb

SLAMD is dead
Command line interface
Written in Go

Open Source Solution Technology Corporation 11

SLIDE 12

WiredTiger Backend for OpenLDAP

Installation of lb

$ export GOPATH=~/go $ go get github.com/hamano/lb

Open Source Solution Technology Corporation 12

SLIDE 13

WiredTiger Backend for OpenLDAP

Benchmark Environment

12 Core CPU
No RAID Card
SAS Disk

Open Source Solution Technology Corporation 13

SLIDE 14

WiredTiger Backend for OpenLDAP

ADD Benchmark Script

✞ ☎

for c in 1 2 4 8 16 32 64 128 256 512; do lb add -c $c -n 10000 --uuid ldap://targethost/ done

✝ ✆

Open Source Solution Technology Corporation 14

SLIDE 15

WiredTiger Backend for OpenLDAP

ADD (nosync) Benchmarks

5000 10000 15000 20000 25000 30000 1 2 4 8 16 32 64 128 256 512 Requests per second Concurrency Level back-wt req/sec back-bdb req/sec back-mdb req/sec

Open Source Solution Technology Corporation 15

SLIDE 16

WiredTiger Backend for OpenLDAP

ADD (sync) Benchmarks

1000 2000 3000 4000 5000 6000 1 2 4 8 16 32 64 128 256 512 Requests per second Concurrency Level back-wt req/sec back-bdb req/sec back-mdb req/sec

Open Source Solution Technology Corporation 16

SLIDE 17

WiredTiger Backend for OpenLDAP

BIND Benchmark Script

✞ ☎

for c in 1 2 4 8 16 32 64 128 256 512; do lb bind -c $c -n 100000 \

D "cn=user%d,dc=example,dc=com" -w secret \
-last 10000 ldap://targethost/

done

✝ ✆

Open Source Solution Technology Corporation 17

SLIDE 18

WiredTiger Backend for OpenLDAP

BIND Benchmark Result

5000 10000 15000 20000 25000 30000 35000 40000 45000 1 2 4 8 16 32 64 128 256 512 Requests per second Concurrency Level back-wt req/sec back-bdb req/sec back-mdb req/sec

Open Source Solution Technology Corporation 18

SLIDE 19

WiredTiger Backend for OpenLDAP

SEARCH Benchmark Script

✞ ☎

for c in 1 2 4 8 16 32 64 128 256 512; do lb search -c $c -n 100000 \

a "(cn=user%d)" \
-last 10000 ldap://targethost/

done

✝ ✆

Open Source Solution Technology Corporation 19

SLIDE 20

WiredTiger Backend for OpenLDAP

SEARCH Benchmark Result

5000 10000 15000 20000 25000 30000 1 2 4 8 16 32 64 128 256 512 Requests per second Concurrency Level back-wt req/sec back-bdb req/sec back-mdb req/sec

Open Source Solution Technology Corporation 20

SLIDE 21

WiredTiger Backend for OpenLDAP

Tests

$ make -C tests wt

54 65 Succeed

Open Source Solution Technology Corporation 21

SLIDE 22

WiredTiger Backend for OpenLDAP

Tasks

Hot-backup
alias and glue entry

Open Source Solution Technology Corporation 22

SLIDE 23

WiredTiger Backend for OpenLDAP

Thank You!

Open Source Solution Technology Corporation 23
