Why Types Matter Zheng Gao CREST, UCL Russells Paradox Let R be the set of all sets that are not members of themselves. Is R a member of itself ? If so, this contradicts with R s definition If not, by definition, R should contain

slide-1
SLIDE 1

Why Types Matter

Zheng Gao CREST, UCL

slide-2
SLIDE 2

Russell’s Paradox

Let R be the set of all sets that are not members of themselves. Is R a member of itself?

  • If so, this contradicts with R’s definition
  • If not, by definition, R should contain

itself

Formalism in naïve set theory:

Let R = {x | x ∉ x}, then R ∈ R ⟺ R ∉ R

slide-3
SLIDE 3
slide-4
SLIDE 4

The Barber Paradox

There is a town with a male barber who shaves all and only those men who do not shave themselves. Who shaves the barber?

slide-5
SLIDE 5

The Barber Paradox

There is a town with a male barber who shaves all and only those men who do not shave themselves. Who shaves the barber?

  • If the barber does not shave himself, according to the

rule he must shave himself.

slide-6
SLIDE 6

The Barber Paradox

There is a town with a male barber who shaves all and only those men who do not shave themselves. Who shaves the barber?

  • If the barber does not shave himself, according to the

rule he must shave himself.

  • If he does shave himself, according to the rule he will

not shave himself.

slide-7
SLIDE 7

The Barber Paradox

There is a town with a male barber who shaves all and only those men who do not shave themselves. Who shaves the barber?

  • If the barber does not shave himself, according to the

rule he must shave himself.

  • If he does shave himself, according to the rule he will

not shave himself.

Naïve set theory contains contradiction

slide-8
SLIDE 8

Types to the Rescue

Constructs a hierarchy of types. Any object is built only from those of higher types, which prevents circular referencing.

1) a barber as a citizen of the town, who shaves himself and 2) a barber as a professional, who shaves others are of different types.

slide-9
SLIDE 9

Type Theory

An alternative to set theory as a foundation for mathematics, in which each term has a type Simply typed λ-calculus is one of the many forms of type theory, which consists of

  • Base types
  • Only one type constructor, ⟶, used to model the type
  • f functions
slide-10
SLIDE 10

The Evolution of Types

t

slide-11
SLIDE 11

The Evolution of Types

t

slide-12
SLIDE 12

The Evolution of Types

t

slide-13
SLIDE 13

The Evolution of Types

t

slide-14
SLIDE 14

The Evolution of Types

t

slide-15
SLIDE 15

The Evolution of Types

t

slide-16
SLIDE 16

Type System

A tractable method that assigns types to syntactic phrases that compose a program, and automatically checks whether the usage of these phrases comply with their types An over-approximation of the run-time behaviour of program terms

slide-17
SLIDE 17

Static & Dynamic Type Checking

Source Code Executable Compilation Execution

slide-18
SLIDE 18

Static & Dynamic Type Checking

Source Code Executable Compilation Execution Static type checking

slide-19
SLIDE 19

Static & Dynamic Type Checking

Source Code Executable Compilation Execution Static type checking Early error detection

slide-20
SLIDE 20

Static & Dynamic Type Checking

Source Code Executable Compilation Execution Static type checking Early error detection Increased run-time efficiency

slide-21
SLIDE 21

Static & Dynamic Type Checking

Source Code Executable Compilation Execution Static type checking Early error detection Increased run-time efficiency Better documentation

slide-22
SLIDE 22

Static & Dynamic Type Checking

Source Code Executable Compilation Execution Static type checking Dynamic type checking Early error detection Increased run-time efficiency Better documentation

slide-23
SLIDE 23

Static & Dynamic Type Checking

Source Code Executable Compilation Execution Static type checking Dynamic type checking Early error detection Reduced implementation

  • verhead

Increased run-time efficiency Better documentation

slide-24
SLIDE 24

Static & Dynamic Type Checking

Source Code Executable Compilation Execution Static type checking Dynamic type checking Early error detection Reduced implementation

  • verhead

Increased run-time efficiency Better documentation Better expressibility

slide-25
SLIDE 25

Why We Care

Generally, almost all real-world programming languages have type systems which offers multiple benefits. Specifically for GI/GP, type systems have the promise to guide the search and avoid the construction of invalid individuals.

slide-26
SLIDE 26

Java’s Static Type Checking

Suppose we have:

slide-27
SLIDE 27

Java’s Static Type Checking

slide-28
SLIDE 28

Java’s Static Type Checking

  • Illegal. Compiler thinks new B().me()

returns an object of class A, but at run- time, this returns an objects of class B.

slide-29
SLIDE 29

Java’s Static Type Checking

  • Illegal. Compiler thinks new B().me()

returns an object of class A, but at run- time, this returns an objects of class B. Legal.

slide-30
SLIDE 30

Java’s Static Type Checking

  • Illegal. Compiler thinks new B().me()

returns an object of class A, but at run- time, this returns an objects of class B. Legal. Legal.

slide-31
SLIDE 31

Java’s Static Type Checking

  • Illegal. Compiler thinks new B().me()

returns an object of class A, but at run- time, this returns an objects of class B. Legal. Legal.

  • Legal. But throws cast

exception at run-time.

slide-32
SLIDE 32

Hindley Milner’s Type System

One of the most famous type systems for the typed λ- calculus with parametric polymorphism:

  • A fast (nearly linear time) algorithm that

automatically infer types of the constructs from their usage

  • A set of typing rules, e.g.
slide-33
SLIDE 33

HM Example

Let us assume that we have a function myFunc of type:

myFunc : ADT ⟶ int

And we want to infer the type of a function someFunc

someFunc (x) + myFunc (x)

slide-34
SLIDE 34

Step One

someFunc (x) + myFunc (x)

slide-35
SLIDE 35

Step One

someFunc (x) + myFunc (x)

x : α

slide-36
SLIDE 36

Step Two

someFunc (x) + myFunc (x)

ADT ⟶ int x : α

slide-37
SLIDE 37

Step Two

someFunc (x) + myFunc (x)

ADT ⟶ int α = ADT x : α

slide-38
SLIDE 38

Step Two

someFunc (x) + myFunc (x)

ADT ⟶ int α = ADT x : α x : ADT

slide-39
SLIDE 39

Step Three

someFunc (x) + myFunc (x)

ADT ⟶ int x : ADT

slide-40
SLIDE 40

Step Three

someFunc (x) + myFunc (x)

ADT ⟶ int x : ADT +: int ⟶ int ⟶ int

slide-41
SLIDE 41

Step Three

someFunc (x) + myFunc (x)

ADT ⟶ int x : ADT someFunc : ADT ⟶ int +: int ⟶ int ⟶ int

slide-42
SLIDE 42

Polymorphism

The provision of a single interface to entities of different types

slide-43
SLIDE 43

Polymorphism Parametric Ad Hoc Inclusion

slide-44
SLIDE 44

Parametric Polymorphism

Rank-N polymorphic function is a function whose parameters are Rank-(N-1) polymorphic Generic programming in programming languages

slide-45
SLIDE 45

Ad Hoc Polymorphism

Function overloading in programming languages

slide-46
SLIDE 46

Inclusion Polymorphism

Inheritance creates inclusion polymorphism (subtyping)

slide-47
SLIDE 47

Inclusion Polymorphism

Inheritance creates inclusion polymorphism (subtyping) Cat < Animal Dog < Animal

slide-48
SLIDE 48

HM Limitations

  • Limited to rank 1 parametric polymorphism
  • Does not support ad hoc polymorphism
  • No notion of subtyping
slide-49
SLIDE 49

Limitation Example One

Suppose we have subtyping B < A, any function that takes arguments of type A is expected to takes arguments of type B as well.

someFunc (x) + myFunc (x)

ADT ⟶ int α = ADT ??? x : α x : ADT ???

slide-50
SLIDE 50

Limitation Example One

Suppose we have subtyping B < A, any function that takes arguments of type A is expected to takes arguments of type B as well.

someFunc (x) + myFunc (x)

ADT ⟶ int α = ADT ??? x : α x : ADT ???

slide-51
SLIDE 51

Limitation Example Two

In HM, an assumption set may contain at most one typing assumption for an construct The operator < , for example, has types:

char ⟶ char ⟶ bool int ⟶ int ⟶ bool

But it does not have the type:

∀α.α ⟶ α ⟶ bool

So any single typing is either too narrow or too wide

slide-52
SLIDE 52

Intersection Types

Allow a term to have multiple types by introducing a type constructor ⋀, a universal type ω used for untypable constructs, and the following typing rules: In practice, intersection types enable function

  • verloading.
slide-53
SLIDE 53

Union Types

The dual notion of intersection types, which introduces a type constructor ⋁ and similar typing rules. In C / C++, union types are the construct union

slide-54
SLIDE 54

Example

Consider the following code snippet in C++: The type of function foo would be: ((int ⋁ ADT) ⟶ int ⟶ void) ⋀ ((int ⋁ ADT) ⟶ float ⟶ void)

slide-55
SLIDE 55

Example

Consider the following code snippet in C++: The type of function foo would be: ((int ⋁ ADT) ⟶ int ⟶ void) ⋀ ((int ⋁ ADT) ⟶ float ⟶ void)

slide-56
SLIDE 56

Example

Consider the following code snippet in C++: The type of function foo would be: ((int ⋁ ADT) ⟶ int ⟶ void) ⋀ ((int ⋁ ADT) ⟶ float ⟶ void)

slide-57
SLIDE 57

Example

Consider the following code snippet in C++: The type of function foo would be: ((int ⋁ ADT) ⟶ int ⟶ void) ⋀ ((int ⋁ ADT) ⟶ float ⟶ void)

slide-58
SLIDE 58

Example

Consider the following code snippet in C++: The type of function foo would be: ((int ⋁ ADT) ⟶ int ⟶ void) ⋀ ((int ⋁ ADT) ⟶ float ⟶ void)

slide-59
SLIDE 59

Retype

A general tool that automatically replaces certain types, together with the corresponding operations if necessary, of a program with new ones.

slide-60
SLIDE 60

Potential Applications

Reducing energy consumption Precision tracking and improvement for FP programs New mutation operators in GI/GP Taint analysis Symbolic execution Auto-transplantation

slide-61
SLIDE 61

Intersection Types in Retype

We use intersection types to cleanly model function

  • verloading, because Retype may generate new overloads
  • f an existing operator.

Consider the following code snippet: Assumption: an external function ext_func of type int ⟶ int Objective: retype int to ADT

slide-62
SLIDE 62

Intersection Types in Retype

We use intersection types to cleanly model function

  • verloading, because Retype may generate new overloads
  • f an existing operator.

Consider the following code snippet: Assumption: an external function ext_func of type int ⟶ int Objective: retype int to ADT

Before retyping

slide-63
SLIDE 63

Intersection Types in Retype

We use intersection types to cleanly model function

  • verloading, because Retype may generate new overloads
  • f an existing operator.

Consider the following code snippet: Assumption: an external function ext_func of type int ⟶ int Objective: retype int to ADT

+: int ⟶ int ⟶ int

Before retyping

slide-64
SLIDE 64

Intersection Types in Retype

We use intersection types to cleanly model function

  • verloading, because Retype may generate new overloads
  • f an existing operator.

Consider the following code snippet: Assumption: an external function ext_func of type int ⟶ int Objective: retype int to ADT

+: int ⟶ int ⟶ int +: int ⟶ int ⟶ int

Before retyping

slide-65
SLIDE 65

Intersection Types in Retype

We use intersection types to cleanly model function

  • verloading, because Retype may generate new overloads
  • f an existing operator.

Consider the following code snippet: Assumption: an external function ext_func of type int ⟶ int Objective: retype int to ADT

+: ADT ⟶ ADT ⟶ ADT +: ADT ⟶ int ⟶ ADT

After retyping
