Why Choose The 3Z RF Vision Because It Helps Contractors and Sub-Contractors on: Ease of use Minimize time at site Eliminate site re-visits Provide quality closeout reports Reduce OPEX cost Improve Microwave

slide-1
SLIDE 1
slide-2
SLIDE 2

www.3ztelecom.com

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

2

Because It Helps Contractors and Sub-Contractors on:

  • Ease of use
  • Minimize time at site
  • Eliminate site re-visits
  • Provide quality closeout reports
  • Reduce OPEX cost
  • Improve Microwave performance degradation

Why Choose The 3Z RF Vision

slide-3
SLIDE 3

www.3ztelecom.com

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3

Optimize Time At Site With The RF Vision Alignment Tool

  • Lower OPEX cost by reducing time to align or trouble shoot a site and

guarantee accurate measurements with line of sight image reports with GEO coding.

  • Because it provides a complete report with evidence of the work done at

site, Customer will receive quality site validation right from the start.

Why Choose The 3Z RF Vision

slide-4
SLIDE 4

www.3ztelecom.com

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

4

Prepare for the future with the RF Vision Alignment Tool

With GNSS technology and visual information (see what the antenna is seeing) becomes valuable for future technologies.

Why Choose The 3Z RF Vision

slide-5
SLIDE 5

www.3ztelecom.com

3Z RF Vision Overview

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision

5

  • Built-in and Mechanically Aligned Camera
  • Built-in Impact resistant 5”Intuitive Touch-

Screen interface

  • Dual Alignment Mode: Panel or Microwave
  • Multiple satellite constellations: GPS and
  • Glonass. Beidou and Galileo will be available on

future releases

  • Small Size, Rugged Design, and IP65 Rating
  • Automatic Site Report generation with line of

sight image and GEO Coding

slide-6
SLIDE 6

www.3ztelecom.com

How it works:

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision

6

With multi constellation and dual frequency Technology the end user will receive an improvement on:

  • Accuracy
  • Multipath Rejection Signals
  • Faster Satellite Acquisition

* *

* Future Releases

slide-7
SLIDE 7

www.3ztelecom.com

How It Works:

Includes Mechanically Aligned Camera With Augmented Reality Technology

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision

7

To Facilitate The Alignment At Site And Provide More Information

For a faster more accurate alignment we have given the user sight of what the alignment tool sees and we have embedded augmented reality technology to present the antennas current values as the cross-hair and the target values as the bull's-eye. Simply the user must align the cross-hair to the bull's-eye and you got a perfect alignment

slide-8
SLIDE 8

www.3ztelecom.com

3Z RF Vision

8

Panel Antenna Alignment Mode

Optimizes The Time At Site

Panel Antenna Alignment Mode With Disactivated Camera Feature Panel Antenna Alignment Mode With Activated Camera Feature

slide-9
SLIDE 9

www.3ztelecom.com

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision

Microwave Antenna Alignment Mode Optimizes The Time At Site

9

Microwave Alignment Mode With Disactivated Camera Feature Microwave Alignment Mode With Activated Camera Feature The Tool will do the math for you and compute the Azimuth and Tilt based on the target Lat/long and Height

slide-10
SLIDE 10

www.3ztelecom.com

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

RF Vision Operation Video

10

Click to access the video:

https://3ztelecom.com/wp-content/uploads/2018/03/MOVIE-Alignment-settings.mp4

slide-11
SLIDE 11

www.3ztelecom.com

Includes Strap Bracket

3Z Telecom, Inc. I Antenna Alignment Solutions I 11

3Z RF Vision

11

Strap Bracket specs:

  • Approx. Weight:
  • 2lbs. 10 oz. (1.19 Kg)

Capabilities:

  • Antenna Panel (RAN –Cellular)
  • Microwave drum antennas 1’ (0.305m)

to 10’ (3.05m –with extended straps)

Webbing Strap Lengths and Material:

  • Two Standard 8’ Polyester webbing straps included

With the clamp. Other sizes available upon request.

slide-12
SLIDE 12

www.3ztelecom.com

Easy to attach to the antenna (MW or Panel)

3Z Telecom, Inc. I Antenna Alignment Solutions I 11

3Z RF Vision

Strap Clamp

12

slide-13
SLIDE 13

www.3ztelecom.com

RF Vision Mounting Brackets

13

(Add On) Lip Clamp Mounting Fixtures

slide-14
SLIDE 14

www.3ztelecom.com

93.3’

Bluetooth Measurement Transfer

3Z RF Vision

14

(Add On) Laser Range Finder For Additional Height Measurements

The Laser Range Finder Integrates fast, precise measurements with photo documentation. Measuring range up to 660 ft. with accuracy of ±1mm.

slide-15
SLIDE 15

www.3ztelecom.com

3Z RF Vision

15

(Add On) Laser Range Finder Ground Verification Kit

slide-16
SLIDE 16

www.3ztelecom.com

Format Reports: PDF, BMP, CSV

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision

16

slide-17
SLIDE 17

www.3ztelecom.com

Format Reports: PDF, BMP, CSV

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision

17

slide-18
SLIDE 18

www.3ztelecom.com

Kit Includes:

3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision

18

slide-19
SLIDE 19

www.3ztelecom.com

3Z RF Vision

19

slide-20
SLIDE 20

www.3ztelecom.com

jmolina@3ztelecom.com (954) 914-9804

3361 Executive Way Miramar, FL 33025
