White Matter Tractography and Human Brain Connections Using GPUs Mois es Hern andez Fern andez Istvan Reguly, Mike Giles, Stephen Smith and Stamatios N. Sotiropoulos GPU Technology Conference 2016 dMRI & Tractography Low Path

slide-1
SLIDE 1

White Matter Tractography and Human Brain Connections Using GPUs

Mois´ es Hern´ andez Fern´ andez Istvan Reguly, Mike Giles, Stephen Smith and Stamatios N. Sotiropoulos

GPU Technology Conference 2016

slide-2
SLIDE 2

dMRI & Tractography

Low Path Probability High Path Probability

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

2 / 23

slide-3
SLIDE 3

Outline

  • 1. Introduction to diffusion MRI & Tractography
  • 2. Parallelization of computational diffusion MRI using GPUs

Voxelwise Fibre Orientation Estimation on GPUs Probabilistic tractography on GPUs

  • 3. Conclusions

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

3 / 23

slide-4
SLIDE 4

diffusion MRI (dMRI)

Molecules are in constant

  • motion. We want to quantify

water diffusion within a tissue. Isotropic vs Anisotropic

  • diffusion. Different tissues: Grey

Matter vs White Matter. It is possible to estimate the principal diffusion orientations in each voxel of the brain.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

4 / 23

slide-5
SLIDE 5

diffusion MRI (dMRI)

Molecules are in constant

  • motion. We want to quantify

water diffusion within a tissue. Isotropic vs Anisotropic

  • diffusion. Different tissues: Grey

Matter vs White Matter. It is possible to estimate the principal diffusion orientations in each voxel of the brain.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

4 / 23

slide-6
SLIDE 6

diffusion MRI (dMRI)

Molecules are in constant

  • motion. We want to quantify

water diffusion within a tissue. Isotropic vs Anisotropic

  • diffusion. Different tissues: Grey

Matter vs White Matter. It is possible to estimate the principal diffusion orientations in each voxel of the brain.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

4 / 23

slide-7
SLIDE 7

Tractography

Post-mortem dissection

  • f some white matter

fibre bundles (Tracts). Tractography: The post-imaging reconstruction of fibre bundles anatomical connections in the brain. In-vivo virtual dissection.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

5 / 23

slide-8
SLIDE 8

Tractography

Post-mortem dissection

  • f some white matter

fibre bundles (Tracts). Tractography: The post-imaging reconstruction of fibre bundles anatomical connections in the brain. In-vivo virtual dissection.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

5 / 23

slide-9
SLIDE 9

dMRI &Tractography Applications

Neurosurgical Planning. Neurological and psychiatric disorders: e.g. Tracts Deterioration in Alzheimer. Brain systems wiring and network analysis.

www.humanconnectome.org.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

6 / 23

slide-10
SLIDE 10

dMRI &Tractography Applications

Jin, Yan, et al. 2015

Neurosurgical Planning. Neurological and psychiatric disorders: e.g. Tracts Deterioration in Alzheimer. Brain systems wiring and network analysis.

www.humanconnectome.org.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

6 / 23

slide-11
SLIDE 11

dMRI &Tractography Applications

Neurosurgical Planning. Neurological and psychiatric disorders: e.g. Tracts Deterioration in Alzheimer. Brain systems wiring and network analysis.

www.humanconnectome.org.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

6 / 23

slide-12
SLIDE 12

dMRI &Tractography

These tractography approaches can require very high computational resources. Computation times can be significant: Hours to Days depending on data & application. We have designed and implemented a CUDA framework to massively accelerate these estimations

  • 1. Voxelwise local modelling to estimate fibre orientations: Hundreds of

thousands model fits to estimate orientations. Quite suitable for GPUs.

  • 2. Global modelling: Integrates these orientations and estimate

long-range connections across the brain volume. Not as suitable for GPUs.

Mois´ es Hern´ andez Fern´ andez, FMRIB

  • 1. dMRI & Tractography

7 / 23

slide-13
SLIDE 13

Voxelwise Fibre Orientation Estimation

Sk = S0[(1 −

L

  • j=1

fj) exp(−bkd) +

L

  • j=1

fj exp(−bkd(gT

k vj)2)]

We want to estimate the main fibre orientations at each voxel. Input: Many diffusion-weighted measurements in each voxel Output: Orientations of fibres in each voxel. Ball & sticks model. Bayesian inference framework: P(Parameters|Data) = P(Data|Params)P(Params) P(Data) MCMC Sampling (∼5000 iters) Parameters initialized using Levenberg-Marquardt.

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 8 / 23

slide-14
SLIDE 14

Voxelwise Fibre Orientation Estimation

Sk = S0[(1 −

L

  • j=1

fj) exp(−bkd) +

L

  • j=1

fj exp(−bkd(gT

k vj)2)]

We want to estimate the main fibre orientations at each voxel. Input: Many diffusion-weighted measurements in each voxel Output: Orientations of fibres in each voxel. Ball & sticks model. Bayesian inference framework: P(Parameters|Data) = P(Data|Params)P(Params) P(Data) MCMC Sampling (∼5000 iters) Parameters initialized using Levenberg-Marquardt.

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 8 / 23

slide-15
SLIDE 15

Inferring fibre orientations on GPUs

M VOXELS N VOXELS

...

Thread Block 0

......................

Thread Block X

................................... 1 2 ................................... 1 2 Q-1 Q-2 ............................... Q-1 Q-2

Each voxel is assigned to a Thread.

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 9 / 23

slide-16
SLIDE 16

Inferring fibre orientations on GPUs

M VOXELS N VOXELS

...

Thread Block 0

......................

Thread Block MxN-1

................................... 1 2 ................................... 1 2 Q-1 Q-2 ............................... Q-1 Q-2

Each voxel is assigned to a Thread Block.

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 9 / 23

slide-17
SLIDE 17

Inferring fibre orientations on GPUs

Thread 1

g2Q+1 g1 gQ+1

Thread 0 (Leader)

g2Q g0 gQ g2 gQ+2

Thread 2 Thread Q -1

... K Gradient Directions

gQ-1

...

g2Q-1

... ...

Thread working Idle thread

TASKS:

  • 1. Propose a new Parameter
  • 2. Calculate Predicted Signal - Likelihood
  • 3. Calculate Posterior & Accept/Reject Parameter

MCMC T iterations Active Threads in a Block

. . .

Param 1

  • 1. Task 1
  • 3. Task 2
  • 2. synchronise()
  • 5. Task 3
  • 4. synchronise()

Q-2 Q-1 0 1 2 3 4 ......

...... ...... ...... ......

Param R

  • 1. Task 1
  • 3. Task 2
  • 2. synchronise()
  • 5. Task 3
  • 4. synchronise()

Q-2 Q-1 0 1 2 3 4 ......

...... ...... ...... ...... . . .

Levemberg Marquardt S iterations Active Threads in a Block

  • 1. Task 1
  • 3. Task 2
  • 2. synchronise()
  • 5. Task 3
  • 6. synchronise()
  • 7. Task 4
  • 8. synchronise()
  • 9. Task 5
  • 4. synchronise()

Q-2 Q-1 0 1 2 3 4 ......

...... ...... ...... ...... ...... ...... ...... ......

TASKS:

  • 1. Calculate Gradient
  • 2. Calculate Hessian Matrix
  • 3. Update Parameters
  • 4. Calculate Cost Function
  • 5. Check Convergence

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 10 / 23

slide-18
SLIDE 18

Fibre orientations: Speedup

Number of Fibres Time in seconds CPU GPU Directions number: 64 256 128

100 1000 10000 1000000 100000 2 3 1

1 Tesla C2050 GPU vs 1 Intel Xeon E5620 core. Speedup: 112X 102 Tesla M2090 CPU vs 102 Intel Xeon X5650. Speedup: 120X

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 11 / 23

slide-19
SLIDE 19

Fibre orientations: Speedup

Directions number: 64 256 128 Multi GPU Number of Fibres Time in seconds Multi CPU

10 100 1000 10000 100000 1 2 3

1 Tesla C2050 GPU vs 1 Intel Xeon E5620 core. Speedup: 112X 102 Tesla M2090 CPU vs 102 Intel Xeon X5650. Speedup: 120X

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 11 / 23

slide-20
SLIDE 20

Fibre Orientations: Validation

Corpus Callosum Centrum Semiovale Grey Matter

GPU CPU f1 S0 d

1 3 1 3 1 1 3 2 5 1 1 5 2 2 5 3 1 2 8 1 2 9 1 3 5 1 1 5 2 2 5 2 9 2 9 2 2 9 4 5 1 1 5 2 2 5 .4 5 .4 7 .4 9 5 1 1 5 2 2 5 3 .2 4 .2 6 .2 8 5 1 1 5 2 2 5 .0 5 .0 1 .0 1 5 4 8 1 2 1 6 2 .9 1 x 1

  • 3

1 2 3 4 5 .9 1 x 1

  • 3

5 1 1 5 2 2 5 9 .4 9 .5 x 1

  • 4

5 1 1 5 2 2 5 3 9 .6 1.1 1.1

Distribution of the estimated parameters after repeating the experiment 1000 times with CPU and GPU

Mois´ es Hern´ andez Fern´ andez, FMRIB Voxelwise application 12 / 23

slide-21
SLIDE 21

Probabilistic Tractography

High memory requirements Compute a global anatomical brain connectivity map integrating the brain fibre orientations

  • f continuous voxels.

Propagate N streamlines from seeds, choosing

  • rientations randomly.

Probability of connection between 2 regions: PAB = M/N. M: number of streamlines that go through B.

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 13 / 23

slide-22
SLIDE 22

Probabilistic Tractography

High memory requirements Compute a global anatomical brain connectivity map integrating the brain fibre orientations

  • f continuous voxels.

Propagate N streamlines from seeds, choosing

  • rientations randomly.

Probability of connection between 2 regions: PAB = M/N. M: number of streamlines that go through B.

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 13 / 23

slide-23
SLIDE 23

Probabilistic tractography on GPUs: Design

Probabilistic Tractography on GPUs

SEED 0

SL 0 SL 1 SL 2 SL 3 SL Q-4 SL Q-3 SL Q-2 SL Q-1 SL N-4 SL N-3 SL N-2 SL N-1 SL Q SL Q+1 SL Q+2 SL Q+3

Thread Block 0

................................... 1 Q-1 Q-1

Thread Block1 SEED M-1

SL 0 SL 1 SL 2 SL 3 SL N-4 SL N-3 SL N-2 SL N-1 ................................... 1 Q-1 Q-1 ................................... 1 Q-1 Q-1

Thread Block F-1

MxN streamlines (SLs) are launched from M seeds. Each SL is assigned to a thread.

This time, 1 thread per voxel is not efficient: most threads would be

  • idle. Unbalanced
  • workload. Better, one

thread per streamline. High memory requirements: Limitation

  • n the number of

parallel threads.

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 14 / 23

slide-24
SLIDE 24

Probabilistic tractography on GPUs: Design

SAMPLES ~1.5 GB

Device Memory

MASKS ~0.5 GB

X Y Z X Y Z X Y Z

...

X Y Z X Y Z X Y Z

... ...

X Y Z X Y Z X Y Z

...

X Y Z X Y Z X Y Z

... Streamlines Coordinates

This time, 1 thread per voxel is not efficient: most threads would be

  • idle. Unbalanced
  • workload. Better, one

thread per streamline. High memory requirements: Limitation

  • n the number of

parallel threads.

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 14 / 23

slide-25
SLIDE 25

Probabilistic tractography on GPUs: Design

STEP N STEP N+1 STEP N+2 STEP N+3 Segment-Triangle Intersection

  • 1. Select Sample & Jump
  • 2. Check Imposed

Anatomical Constraints (SEVERAL)

  • 3. Update Connectivity

Heavy tasks assigned to each thread: Divide tasks into several CUDA kernels. Need to Update Connectivity Matrix: 91282 x 91282 elements (∼32 GB). CPU can do

  • it. Overlap tasks using

CUDA streams. Divergences: After few steps, remove finished streamlines.

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 15 / 23

slide-26
SLIDE 26

Probabilistic tractography on GPUs: Design

GPU Kernels: Calculate paths, Check Anatomical Constraint Masks & Check connectivity between nodes. Copy Path Coordinates & Nodes Connections CPU->GPU Update Connectivity Matrix (CPU)

Heavy tasks assigned to each thread: Divide tasks into several CUDA kernels. Need to Update Connectivity Matrix: 91282 x 91282 elements (∼32 GB). CPU can do

  • it. Overlap tasks using

CUDA streams. Divergences: After few steps, remove finished streamlines.

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 15 / 23

slide-27
SLIDE 27

Probabilistic tractography on GPUs: Design

THREADS SAME WARP IDLE THREADS STEP N STEP N+1 STEP N+2 STEP N+3

Heavy tasks assigned to each thread: Divide tasks into several CUDA kernels. Need to Update Connectivity Matrix: 91282 x 91282 elements (∼32 GB). CPU can do

  • it. Overlap tasks using

CUDA streams. Divergences: After few steps, remove finished streamlines.

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 15 / 23

slide-28
SLIDE 28

Probabilistic Tractography: Speedup

2466 154 16 11816 78 151 9707 102 95 9066 55 164 44977 339 132 56578 314 180

Time & Speedup: Some major brain white maer tracts

1 10 100000 10000 1000 100

Time in seconds \ Speedup factor (Log scale)

1 Core Intel Xeon E5-2680 v3 2.50 GHz Single GPU Nvidia K80 Speedup

Corticospinal Tract Superior Thalamic Radiation Inferior Fronto-occipital Fasciculus Posterior Thalamic Radiation Forceps Minor Cingulate gyrus part of cingulum

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 16 / 23

slide-29
SLIDE 29

Probabilistic Tractography: Speedup

Time & Speedup: Brain Connecvity Matrix

1 Core Intel Xeon E5-2680 v3 2.50 GHz Single GPU Nvidia K80 Speedup

1 10 100 1000 10000 100000 1000000

68.29 10788 736720

Time in seconds \ Speedup factor (Log scale)

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 17 / 23

slide-30
SLIDE 30

Probabilistic Tractography:Performance

Global Load Throughput Global Load Efficiency Global Store Throughput Global Store Efficiency Instrucons executed per cycle (IPC)

Single-precision floang-point

  • peraons per second (FLOPS)

Single-precision floang-point instrucons per second

Integer instrucons per second

Control instrucons per second

Brain Connecvity Matrix White maer tracts

23.11 % 6.55 GB/s 12.58 % 1.07 12.25 GFLOPS 284.40 GIPS 389.30 GIPS 27.78 GB/s 51.74 GIPS 23.56 % 7.57 GB/s 12.62 % 1.15 14.88 GFLOPS 344.47 GIPS 477.80 GIPS 32.81 GB/s 61.59 GIPS

Aer few iteraons threads of the same warp access to remote memory posions (Uncoalesced): Different brain paths. Different brain paths cause divergences. A lot of other kind of instrucons.

GPU Performance Analysis

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 18 / 23

slide-31
SLIDE 31

Results: Probabilistic Tractography

Superior thalamic radiation Corticospinal tract Cingulate gyrus part of cingulum Forceps minor Posterior thalamic radiation Inferior fronto-occipital fasciculus

Coronal Sagittal Axial CPU GPU

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 19 / 23

slide-32
SLIDE 32

Results: Probabilistic Tractography

Brain Connectivity Map from a Vertex in Motor Cortex (Grey Point)

CPU GPU

Low Path Probability High Path Probability

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 20 / 23

slide-33
SLIDE 33

Probabilistic Tractography: Validation

Correlaon Coefficient and Variability (σ) for a Human Connectome (full brain connecvity map)

σ=8.95894E-06 σ=3.18924E-06

CPU-GPU CPU-CPU

0.999 0.9992 0.9994 0.9996 0.9998 1

Mois´ es Hern´ andez Fern´ andez, FMRIB Probabilistic Tractography 21 / 23

slide-34
SLIDE 34

Conclusions

Diffusion MRI uniquely allows the study of brain microstructure and long-range brain connections, non-invasively and in-vivo. The analysis of dMRI data can require high computational resources. We have designed and implemented frameworks using GPUs that reduce computational times: ∼150X These accelerations are tremendously beneficial, especially in very large recent studies such as:

The Human Connectome Project (HCP): data from 1,200 adults. The Developing Human Connectome Project (dHCP): data from 1,000 babies. The UK Biobank Project: data from 100,000 adults.

Mois´ es Hern´ andez Fern´ andez, FMRIB Conclusions 22 / 23

slide-35
SLIDE 35

Acknowledgements

Funding: Human Connectome Project (1U54MH091657-01) UK EPSRC (EP/L023067/1)

Mois´ es Hern´ andez Fern´ andez, FMRIB Acknowledgements 23 / 23
