Where I’m at now

  • University of Bath
  • Department of

Architecture & Civil Engineering (ACE)

  • BRE Centre for

Innovative Construction Materials

  • EPSRC CDT in

Decarbonisation of the Built Environment

2017-10-11 'Building out of poverty - Alastair Marsh' 3

slide-4
SLIDE 4

My team

2017-10-11 'Building out of poverty - Alastair Marsh' 4

Dept of Architecture & Civil Engineering, University of Bath Prof Andrew Heath Dr Mark Evernden Prof Pete Walker Prof Venkatarama Reddy, Indian Institute of Science Dr Pascaline Patureau, Dept of Chemistry, University of Bath

slide-5
SLIDE 5

My backstory

  • Materials Science

MEng (2009-13)

  • Graduate

Sustainability & Physics Engineer (2013-15)

  • University of Bath,

PhD (2015-18)

2017-10-11 'Building out of poverty - Alastair Marsh' 5

slide-6
SLIDE 6

My backstory

  • Construction training

charity

  • Interlocking

stabilised soil blocks (ISSB)

  • Replacement for

cement?

2017-10-11 'Building out of poverty - Alastair Marsh' 6

slide-7
SLIDE 7

Part I – the problems

  • f housing

2017-10-11 'Building out of poverty - Alastair Marsh' 7

slide-8
SLIDE 8

Draw your dream home!

  • Location?
  • Materials?
  • Type of home?
  • View?
  • Colour scheme?

2 minutes…

2017-10-11 'Building out of poverty - Alastair Marsh' 8

slide-9
SLIDE 9

Demographic context of housing

2017-10-11 'Building out of poverty - Alastair Marsh' 9

2014 population growth rates, World Bank

slide-10
SLIDE 10

Demographic context of housing

2017-10-11 'Building out of poverty - Alastair Marsh' 10

UNDESA, 2015. World Population Prospects: The 2015 Revision, Key Findings and Advance Tables. Working Paper No. ESA/P/WP.241.

slide-11
SLIDE 11

Demographic context of housing

2017-10-11 'Building out of poverty - Alastair Marsh' 11

UN-HABITAT, 2014. World Habitat Day: Background Paper. Nairobi. UNDESA, 2014. World Urbanization Prospects: The 2014 Revision, Highlights (ST/ESA/SER.A/352). UNDESA, 2015. World Population Prospects: The 2015 Revision, Key Findings and Advance Tables. Working Paper No. ESA/P/WP.241.

slide-12
SLIDE 12

Informal construction sector

  • 1. Self-building
  • 2. Stockpiling
  • 3. Materials spectrum
  • 4. Insecurity of tenure

2017-10-11 'Building out of poverty - Alastair Marsh' 12

By Claudio Allia (Own work) [CC BY-SA 3.0 (https://creativecommons.org/licenses/by-sa/3.0) or GFDL (http://www.gnu.org/copyleft/fdl.html)], via Wikimedia Commons

slide-13
SLIDE 13

Informal settlement or slum?

  • Informal settlement =

HOW it’s built

  • Slum = WHAT this

settlement is i.e. inadequate,

  • vercrowded

2017-10-11 'Building out of poverty - Alastair Marsh' 13

By Claudio Allia (Own work) [CC BY-SA 3.0 (https://creativecommons.org/licenses/by-sa/3.0) or GFDL (http://www.gnu.org/copyleft/fdl.html)], via Wikimedia Commons www.sdinet.org

Slum Dwellers International (SDI) www.sdinet.org

slide-14
SLIDE 14

Current walling materials used

2017-10-11 'Building out of poverty - Alastair Marsh' 14

UN-HABITAT, 2009. INTERLOCKING STABILISED SOIL BLOCKS: Appropriate earth technologies in Uganda. Nairobi: UN-HABITAT.

  • More durable
  • Higher social

status

  • More expensive
  • Higher impact
slide-15
SLIDE 15

Informal construction

Pros? Cons?

  • Structural quality
  • Internal environment
  • Construction safety
  • Expensive transport
  • Waste
  • Lack of materials

innovation

2017-10-11 'Building out of poverty - Alastair Marsh' 15

  • Very cheap
  • Flexible
slide-16
SLIDE 16

Respecting existing…

Attitudes Processes

2017-10-11 'Building out of poverty - Alastair Marsh' 16

Rwanda Cricket Ground design, Light Earth Designs LLP

Marsh, A. et al., 2016. A Holistic Materials Design Requirements Framework (HoMDReF) For Future Housing Materials. Integrated Design at 50: Building our Future.

slide-17
SLIDE 17

Broad research question

2017-10-11 'Building out of poverty - Alastair Marsh' 17

It’s got to be…

  • Affordable
  • Practical
  • Sustainable
  • Aspirational

Put another option on the table The best of earth and the best of concrete?

slide-18
SLIDE 18

Puzzle #1!

2017-10-11 'Building out of poverty - Alastair Marsh' 18

slide-19
SLIDE 19

Part II – geopolymers and stabilised soil materials

2017-10-11 'Building out of poverty - Alastair Marsh' 19

slide-20
SLIDE 20

What is soil?

2017-10-11 'Building out of poverty - Alastair Marsh' 20

= “uncemented or weakly cemented accumulation of mineral particles formed by the weathering of rocks as part of the rock cycle, the void space between the particles containing water and/or air.” = clay + other minerals

Knappett, J. (2012). Craig's soil mechanics. Abingdon, Abingdon : Spon. Reeves, G. M., et al. (2006). Clay materials used in construction. London, London : Geological Society.

slide-21
SLIDE 21

What are clay minerals?

  • Alumino-silicates

= mostly aluminium, silicon, oxygen and hydrogen (plus some minor others)

  • Sheet structure

2017-10-11 'Building out of poverty - Alastair Marsh' 21

Knappett, J. (2012). Craig's soil mechanics. Abingdon, Abingdon : Spon. Reeves, G. M., et al. (2006). Clay materials used in construction. London, London : Geological Society.

slide-22
SLIDE 22

Unstabilised soil materials

2017-10-11 'Building out of poverty - Alastair Marsh' 22

Shibam, Yemen By Goldzahn [CC BY-SA 3.0 (https://creativecommons.org/licenses/by-sa/3.0)], via Wikimedia Commons Hope Cove, Devon By Nilfanion (Own work) [CC BY-SA 3.0 (https://creativecommons.org/licenses/by-sa/3.0) or GFDL (http://www.gnu.org/copyleft/fdl.html)], via Wikimedia Commons

slide-23
SLIDE 23

Stabilised soil materials

How to stabilise?

2017-10-11 'Building out of poverty - Alastair Marsh' 23

  • Mechanical
  • Compaction
  • Grading
  • Chemical
  • Cement
  • Lime
  • Other…?
slide-24
SLIDE 24

Stabilised soil materials

Why stabilise soil to build with?

2017-10-11 'Building out of poverty - Alastair Marsh' 24

  • Maintenance
  • Termites
  • Lifestyle
  • Aesthetics

Images courtesy of Haileybury Youth Trust

slide-25
SLIDE 25

Geopolymers

2017-10-11 'Building out of poverty - Alastair Marsh' 25

Davidovits, J., 2011. Geopolymer chemistry and applications. 3rd ed. ed. Saint-Quentin: Saint-Quentin : Institut Geopolymere.

= amorphous, synthetic, alkali aluminosilicates

  • 2

2

slide-26
SLIDE 26

Geopolymer formation reaction

2017-10-11 'Building out of poverty - Alastair Marsh' 26

  • Four stages
  • Disassembly, then

reassembly

slide-27
SLIDE 27

Why are we interested?

Pros

  • Low temperature

reaction  low embodied energy

  • Starting materials - can

use abundant or waste materials

  • Properties
  • Strength
  • Durability
  • Fire resistance
  • Acid resistance

Cons

  • High pH solutions

required

  • Reaction still not fully

understood

2017-10-11 'Building out of poverty - Alastair Marsh' 27

slide-28
SLIDE 28

Geopolymer stabilised soil materials (GSSM)

2017-10-11 'Building out of poverty - Alastair Marsh' 28

= use geopolymer phase to stabilise soil = geopolymer reaction transforms clay in soil into a geopolymer

Could GSSM be…

  • Affordable?
  • Practical?
  • Aspirational?
  • Sustainable?
slide-29
SLIDE 29

Why are we interested?

2017-10-11 'Building out of poverty - Alastair Marsh' 29

Hischier, R., et al. (2010). Implementation of life cycle impact assessment methods. Ecoinvent Report. Hammond, G. and Jones, C. (2011). Inventory of carbon & energy (ICE). Sustainable Energy Research Team (SERT). Version, 1. Hashemi, A., Cruickshank, H. & Cheshmehzangi, A., 2015. Environmental Impacts and Embodied Energy of Construction Methods and Materials in Low-Income Tropical Housing. Sustainability, 7(6), p. 7866. Maskell, D., 2013. Development of Stabilised Extruded Earth Masonry Units.

Footprint of GSSM

  • NaOH
  • “Firing”
slide-30
SLIDE 30

Problems with GSSM

Unknowns

  • How much activating

NaOH do we need?

  • Which soils does this

reaction work on?

  • How to make the
  • ptimal ‘recipe’ for a

given soil?

2017-10-11 'Building out of poverty - Alastair Marsh' 30

slide-31
SLIDE 31

My research

Comparison of pure clay minerals’ behaviour Predict behaviour of real soil

2017-10-11 'Building out of poverty - Alastair Marsh' 31

Is this technology feasible for all soil types? Or just a small fraction?

slide-32
SLIDE 32

Manufacture

2017-10-11 'Building out of poverty - Alastair Marsh' 32

slide-33
SLIDE 33

Manufacture

2017-10-11 'Building out of poverty - Alastair Marsh' 33

slide-34
SLIDE 34

Methods

  • Which phases are

present?

  • How much of each

phase is present?

  • How are they

distributed?

2017-10-11 'Building out of poverty - Alastair Marsh' 34

1x10-1m 1x10-2m 1x10-3m 1x10-4m 1x10-5m 1x10-6m 1x10-7m 1x10-8m 1x10-9m 1x10-10m

slide-35
SLIDE 35

Magic Angle Spinning Nuclear Magnetic Resonance (MAS-NMR)

  • Uses magnetic pulses
  • Information about

atomic bonding coordination

  • Shows change from

sheet to network coordination on reaction

2017-10-11 'Building out of poverty - Alastair Marsh' 35

1x10-1m 1x10-2m 1x10-3m 1x10-4m 1x10-5m 1x10-6m 1x10-7m 1x10-8m 1x10-9m 1x10-10m

slide-36
SLIDE 36

Powder X-ray diffraction (XRD)

  • Uses single

wavelength X-ray radiation

  • Identifies crystalline

phases present

  • More difficult for

geopolymers, as these are non-crystalline.

2017-10-11 'Building out of poverty - Alastair Marsh' 36

1x10-1m 1x10-2m 1x10-3m 1x10-4m 1x10-5m 1x10-6m 1x10-7m 1x10-8m 1x10-9m 1x10-10m

slide-37
SLIDE 37

Scanning electron microscopy (SEM)

  • Like a light

microscope - but with electrons.

  • Shows microstructure

2017-10-11 'Building out of poverty - Alastair Marsh' 37

1x10-1m 1x10-2m 1x10-3m 1x10-4m 1x10-5m 1x10-6m 1x10-7m 1x10-8m 1x10-9m 1x10-10m

Clay Geopolymer- stabilised clay

slide-38
SLIDE 38

Strength and durability tests

Simple but useful!

2017-10-11 'Building out of poverty - Alastair Marsh' 38

1x10-1m 1x10-2m 1x10-3m 1x10-4m 1x10-5m 1x10-6m 1x10-7m 1x10-8m 1x10-9m 1x10-10m

slide-39
SLIDE 39

What I’ve learnt so far

  • Not just about

chemical composition – clay mineralogy very influential

  • Sensitive reaction –

no simple recipes

  • Possibly NOT

suitable for localised production?

2017-10-11 'Building out of poverty - Alastair Marsh' 39

slide-40
SLIDE 40

Puzzle #2!

2017-10-11 'Building out of poverty - Alastair Marsh' 40

slide-41
SLIDE 41

Part III – questions and conundrums

2017-10-11 'Building out of poverty - Alastair Marsh' 41

slide-42
SLIDE 42
  • 1. Research…
  • r development?

Research Product development Long term Short term Specific application Broad application

2017-10-11 'Building out of poverty - Alastair Marsh' 42

slide-43
SLIDE 43
  • 2. How to choose a

research topic?

  • Skills, interests and

priority of topic.

  • What makes an issue

a priority problem?

  • Scale
  • Neglectedness
  • Solvability
  • What are the priority

problems in engineering?

2017-10-11 'Building out of poverty - Alastair Marsh' 43

https://80000hours.org/career-guide/most-pressing-problems/ https://80000hours.org/articles/cause-selection/

slide-44
SLIDE 44

Thanks for listening! Any questions?

  • Geopolymers?
  • Soil materials?
  • Research v product

development?

  • Priority problems in

materials and engineering?

2017-10-11 'Building out of poverty - Alastair Marsh' 44

Email: a.marsh@bath.ac.uk Twitter: @AlastairMarsh
