Dominik Janzing

Max Planck Institute for Intelligent Systems T¨ ubingen, Germany 1

What does ’strong causal influence’ mean?

Joint work with David Balduzzi, Moritz Grosse-Wentrup and Bernhard Sch¨

• lkopf

X1 X2 X3 X4

¡ ¡

quantify the strength of Xi→Xj

Given:

• causally sufficient set of variables X1, . . . , Xn
• causal DAG G
• all causal conditionals P(xj|paj) even for values paj with probability zero

(more than just knowing P(X1, . . . , Xn)

Quantifying strength of an arrow:

¡ ¡

Motivation:

Z X Y W Z X Y W

Maybe, the true causal DAG is always complete if we also account for weak

• interactions. Which ones are so weak that we can neglect them?

¡ ¡

Strength of a set of arrows

Idea:

• strength of an arrow measures its relevance for understanding the behav-

ior of the system under inverventions

• strength of a set of arrows measures their relevance for understanding

the behavior of the system under interventions

• if each arrow in S is irrelevant then S could still be relevant

Z X Y W Z X Y W

¡ ¡

Note:

this picture is misleading because for a set S of arrows

• each element may have negligible strength
• but jointly they are not negligible
• ur causal strength will not be subadditive over the edges!

¡ ¡

Information theoretic approach

don’t consider approaches that involve expectations, variances, etc. (ANOVA, ACE. . . )

advantages of information theory

• variables may have different domains
• quantities are invariant under rescaling
• related to thermodynamics
• better for non-statistical generalizations

¡ ¡

Some related work

• Avin, Sphitser, Pearl: Identifiability of path-specific effects, 2005.
• Pearl: direct and indirect effects, 2001.
• Robins, Greenland: Identifiability and exchangeability of direct and indi-

rect effects, 1992.

• Holland: Causal inference, path analysis, and recursive structural equa-

tion models, 1988.

do not achieve our goal because:

• measure impact of switching X from x to x0 for one particular pair (x, x0)
• n Y when other paths are blocked
• we want an overall score of the strength of X → Y without referring to

particular pairs

¡ ¡

Axiomatic approach: Let S be a set of arrows.

• Let CS denote its strength.
• Postulate desired properties of CS.

¡ ¡

Postulate 0 Causal Markov condition:

Z X Y

S

Z X Y DAG G DAG GS

if CS = 0 then P is also Markov w.r.t. GS (after removing all arrows in S)

¡ ¡

Postulate 1 Mutual information:

X Y

for this simple DAG we postulate CX→Y = I(X; Y )

(all the dependences are due to the influence of X on Y , hence the strength of dependences can be a measure of the strength of the influence)

¡ ¡

X Y

Alternative option:

CX→Y := capacity of the information channel P(Y |do(X)) = P(Y |X) defined by maximizing I(X; Y ) over all possible input distributions Q(X)

• requires knowing P(Y |x) also for x-values that never/seldom occur
• quantifies the potential influence rather than the actual one
• nevertheless an interesting option

¡ ¡

Potential strength vs actual strength

Assume a medical study shows that

• changing cholesterol within the range of values occurring in humans has

no impact on life expectancy

• increasing it by 10 times compared to the highest observed value had a

strong impact Which statement would you prefer:

• “cholesterol has a strong impact on life expectancy”
• “cholesterol would have a strong impact on life expectancy if it was much

higher than it is”

¡ ¡

Postulate 2

Y X Z Y X Z

Z is irrelevant in both cases ξX→Y is determined by P(Y |PAY ) and P(PAY ) Locality:

¡ ¡

Postulate 3: CX→Y ≥ I(X; Y |PAX

Y )

X Y PAY

X (parents of Y without X)

X Y

Quantitative causal Markov cond: No other arrow can generate non-zero dependence I(X; Y |PAX

Y )

Idea: removing X → Y would imply I(X; Y |PAX

Y ) = 0

¡ ¡

Postulate 4: Heredity: (subsets of irrelevant sets of arrows are irrevalent) If T ⊃ S then CT = 0 ⇒ CS = 0

¡ ¡

Apart from the postulates. . . Consider a simple communication scenario for which we might agree on how C should read...

¡ ¡

• Each variable Xj consists of kj bits
• some of the bits are set uniformly at random
• the remaining ones are copied from parents

Toy model with partial copy operations: i.e. structural equation model Xj = fj(PAj, Uj) where

• every Xj and Uj is a vector of bits
• every fj is a restriction map

1 1 1

X Y

1 1

¡ ¡

• 2. Y copies some of them
• 1. X sets all its bits randomly

1 1 1

X Y

1 1 0

• 3. Y sets the remaining ones randomly

Example with X → Y

1 1 1 1

X Y

1 1 1 1 1

X Y

¡ ¡

Do we agree that. . .

. . . CX→Y should be the number of bits that Y takes from X?

(for the simple DAG X → Y this number equals I(X; Y ))

¡ ¡

X Z Y

a)

Z X Y

b)

doesn’t account for the fact that part of the dependences are due to a) the confounder Z b) the indirect influence via Z

Why I(X; Y ) is an inappropriate measure for general DAGs

¡ ¡

X Z Y

a)

Z X Y

b)

First guess: I(X; Y |Z)

• qualitatively, it behaves correctly:

screens off the path involving Z

• quantitatively wrong because. . .

¡ ¡

Fails even for a simple copy scenario

1

Z

1 1

Y X

1

Z Y X

1 1 1

Z Y X

1 1 1 1

Z Y X

1 1 1

1) 2) 3) 4)

• I(X; Y |Z) = 0 because X and Y are constants when conditioned on Z
• we would like to have CX→Y = 1

¡ ¡

X Z Y

a)

Why I(X; Y |Z) is inappropriate

b)

weakening Z → Y converts a) into b), where CX→Y = I(X; Y )

¡ ¡

Idea:

• formalized by Ay & Polani (2006) in terms of Pearl’s do-calculus
• defined family of information theoretic quantities called “Information Flow”

Measure strength of X on Y by the impact of interventions on X (while adjusting other variables)

¡ ¡

does not solve our problem

• Ay and Polani’s Information Flow measures an interesting quantity

(something related to causality)

• we don’t consider it a good measure for the strength of an arrow
• arguments follow

¡ ¡

First attempt:

X Z Y

a)

The strength of X → Y is the mutual information between I(X; Y ) in a scenario where

• X is subjected to a randomized intervention

¡ ¡

Fails because...

X Z Y

• X, Y, Z binary
• P(Z) uniform
• Y = X ⊕ Z

X and Y are independent both with respect to the

• observed distribution
• distribution obtained by randomizing X

¡ ¡

X Z Y

a)

Second attempt:

Question: X is randomized according to which distribution?

The strength of X → Y is the conditional mutual information I(X; Y |Z) in a scenario where

• X is subjected to a randomized intervention

¡ ¡

X Z Y

a)

Second attempt, Version I

The strength of X → Y is the conditional mutual information between I(X; Y |Z) in a scenario where

• X is subjected to a randomized intervention
• X distributed according to P(X|Z)

¡ ¡

Fails because. . .

X Z Y

=

If X is a copy of Z,

• given Z, X is a constant
• I(X; Y |Z) = 0 also for the post-interventional distribution

¡ ¡

X Z Y

a)

Second attempt, Version II

The strength of X → Y is the conditional mutual information between I(X; Y |Z) in a scenario where

• X is subjected to a randomized intervention
• X distributed according to P(X)

¡ ¡

X Z Y

a)

Violates Postulate 3: there is a contrived example where strength of X → Y would be smaller than I(X; Y |Z)

Z Y X

¡ ¡

Violates Postulate 3:

random bit

k bits

• randomized for Z = 1
• set to zero for Z = 0

k bits

• copied from X for Z = 1
• set to 1 for Z = 0

I(X; Y |Z) = k/2 because k bits are copied in half of the cases for X and Z independent, copying occurs only in 1/4 of the cases

¡ ¡

• Hence. . .
• defining strength of an arrow by intervention on nodes seems difficult
• we now define the strength by intervention on edges

X Z Y

P(X) P(Z)

X Z Y

S

¡ ¡

Our approach: measure impact of ‘deleting arrows’

To define the strength of S, cut every edge in S and feed the open end with an independent copy

defines new distribution PS(x, y, z) := P(x, z) P

x0,z0 P(y|x0, z0)P(x0)P(z0)

CS := D(PkPS)

X Z Y

P(X) P(Z)

¡ ¡

Idea of ‘edge deletion’

• edges are electrical wires
• attacker cuts some wires
• feeds the open ends with random input
• distribution of input chosen like observed marginal distribution
• only distribution that is locally accessible

¡ ¡

why product distribution?

X Z Y

P(X)P(Z)

X Z Y

P(X,Z)

• ur edge deletion

‘source exclusion’ by Ay & Krakauer (2006)

• not accessible to local attacker
• Postulate 4 fails

¡ ¡

X Z Y

S

1

X Z Y

S

1

X Z Y

S

D(PkPS) = number of corrupted bits (in agreement with what we expect) Applying our measure to our toy model

vaccinated

• r not

Age

infected

• r not

¡ ¡

Quantifying the impact of a vaccine

PS corresponds to an experiment where

• vaccine is randomly redistributed regardless of Age

(keeping the fraction of treated subjects)

• the random variable vaccinated is reinterpreted as

‘intention to get vaccinated’

X Z Y

a)

¡ ¡

= ⊕ P(Z) = uniform X = Z Y = X ⊕ Z XOR-Example

• Y is always 0
• Y is uniformly distributed after deleting X → Y
• Y remains independent of X
• I(X; Y ) = 0 and I(X; Y |Z) = 0
• CX→Y = 1
• Ay and Krakauer’s definition yields zero strength

E D B1 B2 B2k+1

...

= majority of Bj

= = =

¡ ¡

Failure of subadditivity redundancy code: bit E is copied to all Bj

• removing less than half of the arrows Bj → D has no impact
• each arrow has strength zero
• all arrow together have strength 1

¡ ¡

application to time series

why time series also require a new measure of causal strength

¡ ¡

Granger causality

Xt-2 Yt-2 Xt-1 Xt Xt+1 Yt-1 Yt Yt+1

...

measures

• relevance of past Xt−1, Xt−2, . . . for predicting Yt
• if past Yt−1, Yt−2, . . . is known

¡ ¡

Xt-2 Yt-2 Xt-1 Xt Xt+1 Yt-1 Yt Yt+1

...

Transfer Entropy information theoretic version I(Yt ; Xt−1, Xt−2, . . . |Yt−1, Yt−2, . . . )

¡ ¡

Criticizing Granger causality and Transfer Entropy

(Ay & Polani 2006)

Xt-2 Yt-2 Xt-1 Xt Xt+1 Yt-1 Yt Yt+1

assume perfect copy

• past of Y allows for predicting Y without X
• Granger causality and TE are zero
• interventions on X clearly change Y

¡ ¡

Xt-2 Yt-2 Xt-1 Xt Xt+1 Yt-1 Yt Yt+1

...

S

Applying our measure to time series CS quantifies effect of all X on Yt+1

(applying this to the example of Ay & Polani yields a reasonable result)

¡ ¡

Conclusions:

• none of the existing measures appeared to be conceptually right for mea-

suring strength of sets of edges

• our measure satisfies our postulates
• relies on interventions on edges
• clear operational meaning (does not refer to counterfactuals)
• definitions that rely on interventions on nodes failed although they seem

more straightforward

• replacing Transfer Entropy (Granger causality) with our measure seems

reasonable

48

Thank you for listening!

Reference:

• D. Janzing, D. Balduzzi, M. Grosse-Wentrup, B. Sch¨
• lkopf:

Quantifying causal influences, to appear in Annals of Statistics.
