Welcome to the Culobel Group

Culobel Belgium (HQ)

Hofstade (Aalst)

Culobel Czech Rep

(PV-czech)

Frýdlant n. O.

Culobel China Suzhou

CULOBEL

1 Company

3 Plants

3 Divisions

Customer request is our standard!

SUBCONTRACTING

– Sheet metal stamping

• Progressive dies
• deepdrawing

– Finishing included:

• Turning
• Surface treatments
• Spot welding
• Clinching
• Small assy

PRESSURISED

– Pressure vessels

• Cooling
• Compressed air

– Custom-made – Large series till 20L – Small series till:200L – PED/GHOST certified

ASSEMBLY

– 4 lines (CZ) +8 cells – Indoor airco-units – Domestic equipement – Purchasing parts – Sourcing in CE & CN

2

Culobel-group:

some facts and figures

Founded: 1928 Family-owned until 1991 – 3rd

generation is still in charge

Member of the VADO-group

• Financial structure
• HQ located in Eindhoven (NL)
• 40 SME- companies in different branches
• 3000 people

29-5-2013 Culobel Group. Global subcontracting solutions partner. 4

• BE plant:

– Subcontracting:

• 7.000m²

– Assy:

• 2.500m²
• CZ plant:

– Subcontracting:

• 4.000m²

– Pressurised:

• 2.500m²

– Assy:

• 2.500m²
• CN plant:

– 2500m² up to 5000m²

3

Culobel-group: Some facts and figures

• Culobel BE

– Administrative HQ – Engineering and toolmaking – Subcontracting: progressive dies; heavy deep drawing parts; parts difficult to transport

• Culobel CZ

– Main production facility

• Pressurized
• Subcontracting: deep drawing, progressive dies, spotwelding-assy
• Assy: casings & domestic appliances

– Sales-office for central European customers

• Culobel CN

– CNP:

• Pressurized
• Subcontracting: deep drawing, progressive dies, spotwelding-assy
• Sales office for Asian customers

– CNT:

• SOURCING: Procurement support to support our in-house production
• TRADING: reinforcing our position as a world-class subcontractor by offering

complementary products, produced under our supervision in China

29-5-2013 Culobel Group. Global subcontracting solutions partner. 6

Engineering & Tooling division

Own toolingshop

more than 80 years’

experience

Construction of Dies

in Europe & China

4

29-5-2013 Culobel Group. Global subcontracting solutions partner. 7

Mechanical stamping lines

Mechanical presses: – in BE: 20 – in CZ: 20 – In CN : 6 Power: up to 600 ton Coil feeding: up to

800mm width

Thickness: up to 8.5mm Maximum die table:

2000x1500mm

Culobel Subcontracting

Progressive dies

5

Culobel Subcontracting

Stamped parts

29-5-2013 Culobel Group. Global subcontracting solutions partner. 10

Hydraulic presses

Hydraulic presses: – in BE: 5 – in CZ: 7 – In CN : 2 Power: up to 600 ton Thickness: from 0.2mm

up to 10mm

Maximum die table:

3000x1500mm

6

Culobel Subcontracting

Deep drawing parts

Culobel Subcontracting

Other deep drawing parts

7

Culobel Subcontracting

Finishing & assembly of products

Culobel-group: Markets

Pumps Cooling & Heating Electronics Domestic Compressors Light industry Automotive

8

Culobel Pressurised

Customer request is our standard

Big series till 20L Small series till 200L Custom-made Test – pressure

to 65 bar

Applications:

– Cooling – Airco – Hydraulics

9

Pressurised

Our Assets:

Products made to customer’s specifications Engineering support Quality system ISO 9001 : 2000 Close co-operation with notified body : PED, mod B, C1,

D1, acc 97-23 EC Pressure Equipment Directive

Ghost certified production

10

Pressurised

Accumulators

Pressurised

Receivers 0,75L-30L

11

Assembly

Assembly for serial

products

Assembly for make to

• rder

Big/small series Sourcing in CE and CN Supply chain

management

New model

implementation

12

CULOBEL GROUP Production Plants

Culobel Belgium (HQ)

Hofstade (Aalst)

Culobel Czech Rep

(PV-czech)

Frýdlant n. O.

Culobel China Suzhou

Culobel Belgium HQ

• Located in Hofstade-Aalst Belgium
• Own engineering and sales office
• Founded in 1928
• 80 empoyees
• Mechanical & Hydraulic Presses up to 600 Ton
• Subcontrancting & Assembly

13

Culobel Czech Republic : PVCzech sro

• Located in Frydlant n.O Czech Republic ( 20

minutes from Ostrava )

• Own engineering and sales office
• Founded in 2000
• 210 empoyees
• Mechanical & Hydraulic Presses up to 600 Ton
• Assembly activites
• Production of Recievers &
• Accumulators

14

15

Culobel China CNP

• Located in Suzhou (2h from Shanghai)
• Own engineering and sales office
• Founded in 2010
• 25 empoyees
• Mechanical & Hydraulic Presses up to 400 Ton
• Milling Shop
• Subcontrancting & Assembly
• Production of Receivers & Accumulators

16

29-5-2013 Culobel Group. Global subcontracting solutions partner. 32

Culobel BELGIUM (HQ) Culobel CZECH REPUBLIC Culobel CHINA Hekkestraat 16 Sidlo: PV-Czech s.r.o. B-9308 Hofstade, Aalst

• Ul. Snozina 400 739 11 Frýdlant n. O.

Lin Jiang Road 9 Belgium Czech Republic 215122 Suzhou

• Tel. + 32 53 77 78 88
• Tel. +420 555 530 900

China Fax + 32 53 78 38 25 Fax +420 558 675 177 sales@culobel.be sales@culobel.cz sales@culobel.cn

www.culobel.com
