WELCOME AGENDA COMET GROUP COMET TRAITEMENTS PHOENIX PROCESS R&D Other developments CONCLUSION COMET GROUP COMET GROUP FIGURES 1.200.000 T/y of metal waste 2 shredders: Mons (5.2 MW) and Charleroi (2.2 MW) 350 persons

slide-1
SLIDE 1

WELCOME

slide-2
SLIDE 2

AGENDA

COMET GROUP COMET TRAITEMENTS PHOENIX PROCESS R&D – Other developments CONCLUSION

slide-3
SLIDE 3

COMET GROUP

slide-4
SLIDE 4

FIGURES

  • 1.200.000 T/y of metal waste
  • 2 shredders: Mons (5.2 MW) and

Charleroi (2.2 MW)

  • 350 persons
  • 350.000.000 € of turnover
  • Recovery rate > 95%

COMET GROUP

slide-5
SLIDE 5

COMET TRAITEMENTS

INTRODUCTION TO METAL WASTE

A MINE OF SECONDARY RAW MATERIAL

Bulk Steel Scraps… but also →

ELV WEEE (cat. 2) Ferrous % 68,5 38 Non ferrous % 8,5 28 Plastics % 16,5 19 Glass % 2,5 4 Wood %

  • 1

Fluids % 2,0

  • Other

% 2,0 10 EU

  • bjectives

% 95 (2015) 50 to 90

→

slide-6
SLIDE 6

OUR COMPANIES

DEPOLLUTION/DISMANTLING

  • Comet Services
  • Recycar
  • Terecoval (FR)
  • Recytire

METAL WASTE

  • Cometsambre
  • Recymet
  • Comet Gent
  • Comet Brussels
  • V&M Recycling
  • Ecofer
  • Comet Rouen (FR)
  • Comet Arles (FR)
  • RDN (FR)
  • SDFI Cornu (FR)
  • Gosselin Duriez (FR)

SHREDDER RESIDUE

  • Comet Traitements

COMMUNICATION, RH, IT COMET RECHERCHE COMET TRANSPORTS COMET FLUVIAL COMET TECHNIQUE

slide-7
SLIDE 7

Obourg Châtelet

LOCALISATION

slide-8
SLIDE 8

LOCALISATION

slide-9
SLIDE 9

CHÂTELET

INDUSTRIAL SITES

slide-10
SLIDE 10

INDUSTRIAL SITES

OBOURG

slide-11
SLIDE 11

Dismantling Sorting SHREDDER Air suction Magnetic separation Magnetic separation Fluids, tires, batteries, airbags, catalyst, etc Press-shears Heavy SR Light SR (fluff)

INTRODUCTION TO SHREDDER RESIDUE

A MINE OF SECONDARY RAW MATERIAL

SHREDDER RESIDUE METAL WASTES

slide-12
SLIDE 12

VMR / Comet Services

Collection / Depollution / Dismantling

VMR / COMET SERVICES

slide-13
SLIDE 13

Shredding / Magnetic separation → Mine of iron

COMET SAMBRE

slide-14
SLIDE 14

COMET TRAITEMENTS

Shredder residue Processing and Recovery

slide-15
SLIDE 15

COMET TRAITEMENTS

COMET TRAITEMENTS

COMPANY PROFILE

  • SME created in 2002
  • Activity: Shredder Residue processing and recovery
  • 7 production units (Post Shredder Technology)
  • Treatment capacity : 350 000 T/y
  • Châtelet (near Charleroi): 80.000 T/y of Light SR
  • Obourg (near Mons): 270.000 t/y of Heavy SR of which

85.000 T/y of plastics

  • Workers: 130
  • R&D team: 15 + 11 external researchers work on Comet projects
slide-16
SLIDE 16

77 % ferrous Heavy SR Input 100%

SHREDDERS

Light SR

Homogenous mix of non ferrous metals, rubber, plastics, inerts, etc. Heterogeneous mix of textiles, plastics, foam, wood and fines particles

INTRODUCTION TO SHREDDER RESIDUE

RECOVERY OF SHREDDER RESIDUE

300 000 T/y 100 000 T/y

slide-17
SLIDE 17

COMET TRAITEMENTS

Shredder residue: a mine of metals from 200 mm … … to less than 50 µm

ACTIVITIES

slide-18
SLIDE 18

Closing the loop : Ongoing R&D project with car producers to use these plastics in its manufacturing process

COMET TRAITEMENTS

from an heterogenous mix… … to pure fractions of PE/PP/ABS/PS Shredder residue: a mine of plastics

ACTIVITIES

slide-19
SLIDE 19

COMET TRAITEMENTS COMET TRAITEMENTS

Recovery steps Purification steps PP 3 Comet Regrind FPP 3 Comet Regrind PS 3 Comet Regrind (ABS – PS mixture) Waste s Landfill or RDF DrainaPlus

Density separation = 1

Rubbers & Thermoplastics concentrate Composition :

  • mixture of thermoplastics
  • foams & textils
  • wood,
  • metals,…

Sources :

  • ELV
  • Light iron scraps
  • WEEE
  • Hard Plastics from collectivity

Density separation = 1,08

Sinking Fraction :

  • Density > 1,08 plastics : PVC, PC,

PET, PA, PMMA,POM, PBT,…

  • Brominated plastics
  • PUR, rubbers & silicones

General Flowsheet

Plastics from Shredder Residues

PLASTICS RECOVERY

slide-20
SLIDE 20

Plastics from Shredder Residues : secondary process units

Current End Products Near Future End Products Upgraded plastics : High purity regrinds

Available from September 2020 : starting of a new Industrial Demonstration Unit

▪ Filled PP > 98 % ▪ PS > 95% ▪ ABS > 98 %

Ongoing R & D :

▪ PE(HD) > 95 % ▪ PP > 95 %

We guarantee :

  • Qualities
  • Volume
  • Fixed Price

PLASTICS RECOVERY

slide-21
SLIDE 21

COMET TRAITEMENTS

Shredder residue: a mine of sand Production of purified sand… … recovered as building material

ACTIVITIES

slide-22
SLIDE 22

COMET TRAITEMENTS

Shredder residue: a mine of iron From rust… … to byproduct ore

ACTIVITIES

slide-23
SLIDE 23

COMET TRAITEMENTS 16,3 % MATERIAL recovery

1,2% Ferrous metals 3,8% Non-ferrous metals 3,8% Plastics 5,2% Mineral fractions 2,3% Iron oxides

77,0 % MATERIAL recovery

Ferrous metals (magnetic fraction)

Shredder Residue INPUT 100% (ELV, metal waste,…) Final residue = 2,2 % SHREDDERS PHOENIX Organic residue (OSR)

(plastic films, textiles, foam, wood, rubber)

4,5 % ENERGY recovery

Hydrocarbon, carbon residue, (non)-ferrous metals

TOTAL Recovery = 97,8 %

EU legislation : 95% recovery rate for ELV from 2015 (European directive 2000/53/CE)

RECOVERY PROCESS

SR mainly landfilled until the 90’s R & D efforts since end of 80’s Recovery rate ~98 %

slide-24
SLIDE 24

PHOENIX PROCESS

slide-25
SLIDE 25

Catalytic cracking

Integrated process allowing the conversion of organic shredder residue into:

  • liquid fuel recoverable into cogeneration engine and
  • carbon recoverable as reducing agent for the steel industry.

PHOENIX Process

slide-26
SLIDE 26

FLOWSHEET PHOENIX

Catalytic conversion CHAR treatment CHAR

Ashes

CHAR Polymetallic concentrate Electricity Heat e-, T° Hydrocarbons Cogeneration Raw material preparation Fluff e-, T° OSR « Water » Purification Distillation Hydrocarbons

slide-27
SLIDE 27

SILOXANES

Organic Synthetic Molecules Subgroup of silicones Contraction of Silicon, Oxygen, and Alkane Used in the manufacture of many commercial products including: makeup, tooth paste, shampoo, lubricant, paint, glue, insulation, mastic, gel, etc Yearly consumption growth from 5 to 10% Thermal degradation above 200°C in small volatiles molecules

slide-28
SLIDE 28

SILOXANES

Combustion of SILOXANES→ CO2,gaz + H20vap + SiO2,sol SiO2 = main ingredient in sand SiO2 stays in the engine

slide-29
SLIDE 29

SILOXANES

slide-30
SLIDE 30

SILOXANES

PROCESS FOR REMOVING SILOXANE-BASED DERIVATIVES FROM A LIQUID ORGANIC PHASE

slide-31
SLIDE 31

PILOT PLANT

slide-32
SLIDE 32

Material balance: Energy balance: 66% recovery

1 Ton of shredder residue = 22 GJ = 50% energy density of crude oil CnHm Carbon

(+ ashes)

Water Metals Electricity Carbon Heat Phoenix process

  • 2. PHOENIX – PHOEBUS Projects

BALANCES

34% 12% 20% 34% 8% 34% 44% 14%

slide-33
SLIDE 33

FUTURE PROJECTIONS Future Projections

  • 1. Expected industrialization from 2022
  • First industrial plant located in Belgium
  • Treatment capacity:

35 000 T/y

  • Liquid fuel production:

11 000 000 liters/y

  • Gaseous fuel production:

4 000 000 m³/y of gas

  • Net electricity production:

5 MWh/h

  • Investment:

42 M€

  • Job creations:

75 persons

  • 2. Technology licensing for construction of others plants
slide-34
SLIDE 34

R&D

Other developments

slide-35
SLIDE 35

COMET TRAITEMENTS

R&D REVERSE METALLURGY - BIOLIX

Bio-leaching of polymetallic concentrates to produce copper cathodes

slide-36
SLIDE 36

R&D

2020 : First demonstration plant (4000 T/y)

REVERSE METALLURGY – BIOLIX

slide-37
SLIDE 37

R&D REVERSE METALLURGY - PICKIT

Automated sorting of metal alloys

slide-38
SLIDE 38

COMET TRAITEMENTS

R&D DIVERSIFICATION

  • Recycling of electrical and hybrid ELVs
  • Recycling of PV panels
  • Direct reduction of ferrous co-products
  • To be continued…
slide-39
SLIDE 39

CONCLUSION

slide-40
SLIDE 40

COMET TRAITEMENTS

CONCLUSION

slide-41
SLIDE 41

Thank you for your attention
