WEBRTC, MOBILE CONSIDERATIONS AND VOICE OVER IP IETF e W3C 0 c - - PowerPoint PPT Presentation
WEBRTC, MOBILE CONSIDERATIONS AND VOICE OVER IP IETF e W3C 0 c - - PowerPoint PPT Presentation
WEBRTC, MOBILE CONSIDERATIONS AND VOICE OVER IP IETF e W3C 0 c . 1 r u Google C o T s R - Microsoft n b e e p Apple W o ... 2011 2017 WebRTC (Real-Time Communications) Acquiring audio and video
SLIDE 2
SLIDE 3
SLIDE 4
SLIDE 5
WebRTC (Real-Time Communications)
- Acquiring audio and video
- Communicating audio and video
- Communicating arbitrary data
SLIDE 6
WebRTC (Real-Time Communications)
- Acquiring audio and video
- Communicating audio and video
- Communicating arbitrary data
MediaStream (aka getUserMedia) RTCPeerConnection RTCDataChannel
SLIDE 7
WebRTC (Real-Time Communications)
- Acquiring audio and video
- Communicating audio and video
- Communicating arbitrary data
MediaStream (aka getUserMedia) RTCPeerConnection RTCDataChannel
SLIDE 8
MediaStream
MediaStream MediaStreamTrack: Video MediaStreamTrack: Audio Left channel Right channel Input Output
SLIDE 9
MediaStream
MediaStream MediaStreamTrack: Video MediaStreamTrack: Audio Left channel Right channel Input Output
Constraints
- Media Type
- Resolution
- Frame rate
SLIDE 10
RTCPeerConnection
- Signal processing
- Codec handling
- Peer-to-peer connection
- Security (Encryption)
- Bandwidth management
SLIDE 11
RTCPeerConnection
- Signal processing
- Codec handling
- Peer-to-peer connection
- Security (Encryption)
- Bandwidth management
Media Peer Peer SRTP (Secure Real-Time Transport Protocol) DTLS (Datagram Transport Layer Security)
SLIDE 12
Signalling
- Exchange Session Description Object
○ Codec to use ○ Security keys ○ Network information
- Any messaging mechanism (HTTPS, Websockets, XHR, ...)
- Any messaging protocol (SIP, XMTP, JSON, ...)
SLIDE 13
SLIDE 14
RTCSessionDescription (SDP)
[OFFER] v=0
- =alice 2890844526 2890844526 IN IP4 host...
s= c=IN IP4 host.atlanta.example.com t=0 0 m=audio 49170 RTP/AVP 0 8 97 a=rtpmap:0 PCMU/8000 a=rtpmap:8 PCMA/8000 a=rtpmap:97 iLBC/8000 m=video 51372 RTP/AVP 31 32 a=rtpmap:31 H261/90000 a=rtpmap:32 MPV/90000 [ANSWER] v=0
- =bob 2808844564 2808844564 IN IP4 host…
s= c=IN IP4 host.biloxi.example.com t=0 0 m=audio 49174 RTP/AVP 0 a=rtpmap:0 PCMU/8000 m=video 49170 RTP/AVP 32 a=rtpmap:32 MPV/90000
SLIDE 15
Media Signalling Signalling Peer Peer
SLIDE 16
NAT (network address translation)
- Let multiple computers share the same IP address
- IPv4 address exhaustion
SLIDE 17
Signalling Signalling Peer Peer NAT NAT
SLIDE 18
STUN (session traversal utilities for NAT)
- What is my IP address?
- Simple server
- CHEAP
SLIDE 19
Peer Peer Signalling Signalling NAT NAT STUN STUN Media
STUN
SLIDE 20
TURN (traversal using relays around NAT)
- Cloud fallback if peer-to-peer fails
- Data sent through the server
- Ensure call works in almost any environments
- EXPENSIVE
SLIDE 21
Signalling Signalling TURN TURN Media
TURN
Peer Peer NAT NAT
SLIDE 22
Signalling Signalling
STUN + TURN
TURN TURN Media Peer Peer NAT NAT STUN STUN
SLIDE 23
ICE (interactive connectivity establishment)
- Framework for connecting peers
- Find the best path for each call
- How?
○ Gathering candidates ■ IP address + port + transport protocol
- Directly attached network interface
- Server reflexive (STUN)
- Relayed address (TURN)
○ Connectivity checks ■ Sort the candidate pairs in priority order ■ Send checks on each pairs in priority order ■ Acknowledge checks received from the agent ○ Nominating Candidate Pairs and concluding ICE
SLIDE 24
Alice Bob Media Cloud App IOs Android WebRTC SDP SDP Signalling Signalling
SLIDE 25
Architecture: Small call
SLIDE 26
Architecture: Medium call
SLIDE 27
Architecture: Big call
SLIDE 28
VoIP (Voice over Internet Protocol)
1940 2006 1970 1999 2018
PBX (Private Branch Exchange) SIP (Session Initiation Protocol)
SLIDE 29
Asterisk Phone EBC SIP Client Voice VLAN VoIP Provider PSTN
SLIDE 30
SLIDE 31
Asterisk Phone EBC SIP RTP Client Voice VLAN VoIP Provider PSTN Phone
SLIDE 32
SLIDE 33
Phone Asterisk Phone EBC SIP RTP Client Voice VLAN VoIP Provider PSTN BGW 3 2 1
SLIDE 34
WebRTC + VOIP
2006 2018 2011
- p
e n
- s
- u
r c e 2017 W e b R T C 1 . 2016 J i v e w e b
SLIDE 35
Asterisk EBC VoIP Provider PSTN Signaling Server HTTPS/WSS Browser SIP
SLIDE 36
Asterisk EBC VoIP Provider PSTN Signaling Server HTTPS/WSS Media Server (Bob) SRTP Browser (Alice) TCP SIP RTP
SLIDE 37
Asterisk EBC VoIP Provider PSTN Signaling Server HTTPS/WSS Media Server SRTP Browser TCP SIP Browser
SLIDE 38
TCP Phone Asterisk EBC VoIP Provider PSTN BGW 3 Signaling Server HTTPS/WSS Media Server SRTP Browser SIP Phone SIP Client Voice VLAN RTP
SLIDE 39
WebRTC + VOIP + Mobile
2018 2011
- p
e n
- s
- u
r c e 2017 W e b R T C 1 . 2016 J i v e w e b / m
- b
i l e 2019
SLIDE 40
PSTN Phone Oauth (PKCE) TURN Cell HTTPS/WSS SRTP TCP Signaling Server Media Server Outgoing call
SLIDE 41
PSTN Phone Oauth (PKCE) Cell PushKit pushRegistry.register(with: [.voIP]) createSession(channelID) createChannel(pushToken, encryption) EllipticCurveKeyPair Notification Service Signaling Server Media Server Register on IOs SIP
SLIDE 42
PSTN Phone Notification Service TURN Signaling Server Media Server Cell HTTPS/WSS SRTP TCP TCP APNs Incoming call Register to callkit Decrypt payload Encrypt payload voIP push Incoming call
SLIDE 43
SLIDE 44
Pitfalls
- IPv6 mobile provider
○ TURN
- IOs13
○ VoIP push must register to callkit ○ DND must be server side
- Callkit
○ No customization
- Background
○ Callkit + ConnectionService
- Bandwidth + CPU
○ Frame rate ○ Resolution ○ Pause streams ○ Batch update participants
- Android
○ Audio Routes ○ Proximity sensors
