voopIX ¡

Building ¡the ¡Educa4onal ¡ ¡ VoIP ¡Cloud ¡in ¡Croa4a ¡

¡ Branko ¡Radojević, ¡M.Sc. ¡

Deputy ¡CEO ¡ ¡

¡ ¡ ¡ September 2014.

(v 2.42)

CARNet ¡– ¡Who ¡we ¡are ¡& ¡what ¡we ¡do? ¡

• Public Institution funded from National Budget
• NREN – National Research and Education Network
• Over 20 years ISP for Educational Institutions in Croatia

(schools, universities, research institutes, ministry, agencies,

public hospitals, etc.) – 3000 locations in Croatia

• Since 2004 adding more and more services for our members:

(National Educational AA infrastructure, CMS for schools, LMS for schools,

National e-learning portal, National portal for schools, Content fjltering for schools, (many, many more), and voopIX J )

• All our services are free for our member institutions

CARNet ¡– ¡voopIX ¡goals ¡

• To interconnect all our member institutions (3000 locations) to a

single VoIP cloud and to provide to them:

• Free telephony service between institutions
• Interconnect different locations of the same institution
• Let them use legacy PBXs with our system
• Provide advanced telephony possibilities available only in VoIP PBXs
• Provide free international calls to certain destinations for free
• TRY TO BE AS TRANSPARENT TO THEM AS POSSIBLE
• Open their eyes and let them discard legacy PBXs and move to VoIP

How ¡we ¡arrived ¡to ¡this ¡idea? ¡

voopIX ¡-­‑ ¡Evolu4on ¡

• It all started at the University of Dubrovnik in 2004.

University of Dubrovnik

Telco

Legacy PBX 1x ISDN PRI Proprietary phones 1x ISDN PRI

voopIX ¡– ¡Evolu4on ¡(cont’d) ¡

• In a matter of no time ...

University of Dubrovnik

Telco

University of Dubrovnik University of Dubrovnik University of Dubrovnik University of Dubrovnik

DUNDi

voopIX ¡– ¡Next ¡Step ¡

In 2005 I’ve got married, moved to Zagreb and changed my employer to the current one J.

voopIX ¡– ¡Next ¡Step ¡(cont’d) ¡

• CARNet – my new employer already has ordered new VoIP PBX

(normal PBX functionality + Call Center), but it’s a Cisco Call Manager

• When it arrived, it took just few days to add an Asterisk to CCM

(connected with SIP trunk), and to bring up DUNDi cloud and interconnect it with the Asterisks at the University of Dubrovnik

• It proved to be reliable solution, so why don’t expand it?
• voopIX was born J

J

voopIX ¡– ¡Building ¡the ¡core ¡

ZG OS RI DU ST

• We started to build

voopIX core, based on five servers running Asterisk positioned in five of our largest POPs

• Connections shown are

logical DUNDI peering connections

• No clustering at this time

voopIX ¡– ¡Legacy ¡PBXs ¡

• Our members don’t want to throw away their working PBXs. Some
• f them were purchased recently L
• We had to fjnd a way to transparently connect them to our system.
• Obviously, we are talking about hundreds of different

combinations of PBXs, software, cards, setups, etc.

• Telco connection is also non-unifjed: from R2/MFC, ISDN BRI, ISDN

PRI and some SIP trunks (recently).

• We had to put our box between PBX and the Telco connection in
• rder to intercept calls. Our solution should be reliable.

voopIX ¡– ¡Appliance ¡(large) ¡

• Custom designed in CARNet
• Runs Linux (debian lenny) + Asterisk
• 2x or 4x ISDN PRI voice card installed
• No hard drives
• It has custom made

failover switch that can bypass the card and connect back PBX directly to Telco.

Telco PBX

Interconnec4ng ¡voopIX ¡and ¡PBX ¡

BASIC Telekom

• perator

Old phones Legacy PBX

CARNet voopIX

voopIX app.

Interconnec4ng ¡voopIX ¡and ¡PBX ¡(2) ¡

Telekom

• perator

Old phones Legacy PBX

CARNet voopIX HYBRID BASIC

voopIX app.

Interconnec4ng ¡voopIX ¡and ¡PBX(3) ¡

Telekom

• perator

Old phones Legacy PBX

CARNet voopIX HYBRID BASIC

voopIX app.

ADVANCED

voopIX ¡-­‑ ¡Appliance ¡(cont’s) ¡

voopIX ¡-­‑ ¡Appliance ¡(cont’s) ¡

FAILOVER SWITCH NETWORK VOICE CARD

voopIX ¡– ¡Appliance ¡(small) ¡

• Commercially available
• Runs Linux + Asterisk
• 1x FXS port installed
• 2 module slots available for line cards:
• 4x FXO, 4xFXS, 2xBRI, 2xGSM
• No hard drives, USB and SD Card reader included
• It has failover switch that can bypass two FXO and FXS ports

directly to Telco.

voopIX ¡– ¡Call ¡flows ¡(available ¡number) ¡

Telco

ISDN Network

Legacy PBX ISDN PRI CALL ISDN PRI DUNDi voopIX context CDR (RADIUS)/LOG Server

voopIX ¡– ¡Call ¡flows ¡(unavailable ¡number) ¡

Telco

ISDN Network

Legacy PBX ISDN PRI CALL ISDN PRI DUNDi voopIX context CDR (RADIUS)/LOG Server CALL

voopIX ¡-­‑ ¡Today ¡

• Around 110 locations

(our first target were the institutions with larger phone installations and those considered most interesting ones)

• We expect to double the

number until the end of 2014.

51 ¡ 9 ¡ 10 ¡ 6 ¡ 7 ¡ 1 ¡ 1 ¡ 4 ¡ 1 ¡ 2 ¡ 12 ¡ 1 ¡ 1 ¡ 1 ¡ 1 ¡ 1 ¡

Problems ¡we ¡encountered ¡-­‑ ¡AOC ¡ ¡

Telco

ISDN Network

Legacy PBX ISDN PRI CALL AOC-D

• AOC = Advice Of Charge (D-During, E-End)

AOC-E

Problems ¡we ¡encountered ¡– ¡AOC ¡(cont’d) ¡ ¡

Telco

ISDN Network

Legacy PBX ISDN PRI CALL AOC-D

• AOC = Advice Of Charge (D-During, E-End)

ISDN PRI CALL AOC-D AOC-E AOC-E

Asterisk Implementation Overview (Technical Details)

Node ¡becomes ¡available ¡

ZG OS RI DU ST

DUNDi voopIX context Telco

ISDN Network

Legacy PBX

Numbers: (51)-400-500 to 400-799

ISDN PRI I A X 2 p e e r i n g + r e g i s t r a t i

• n

[iax-pbx-reg] exten=> _38551400[5-7]XX _38551400[5-7]XX

Node ¡becomes ¡unavailable ¡

ZG OS RI DU ST

DUNDi voopIX context Telco

ISDN Network

Legacy PBX

Numbers: (51)-400-500 to 400-799

ISDN PRI I A X 2 p e e r i n g + r e g i s t r a t i

• n

[iax-pbx-reg] exten=> _38551400[5-7]XX _38551400[5-7]XX NAGIOS Server

Interconnection with TERENA NRENUM.net

NRENUM.net ¡

• Since the two systems (ENUM and DUNDi) are incompatible, we

had to build gateway service

• Outgoing calls are easy to implement, since Asterisk has built-in

ENUM support that we are using

• Publishing our numbers to NRENUM tree were more difficult, since
• ur system is highly dynamical, and DNS zones are more statical
• We built on top of PowerDNS software that has ability to query not
• nly its internal database, but also invoke script for subqueries. So,

for every query that we receive through ENUM, we do subquery in DUNDi and return results.

Advanced Telephony Functionality provided by voopIX

Skype ¡to ¡PBX ¡

• We allow calls from Skype to any number in our system
• Often used to place calls directly from web pages

Users ¡traveling ¡around ¡the ¡World ¡

• We provide the possibility for user traveling around the World to use

softphones which allows them to become extensions on their PBX

• It is also useful to someone working from home
• ZoIPer is a popular (and free) softphone

which is beside having SIP protocol also provides IAX2 which has much less problems traversing NATs

• Now available for Windows, MacOS,

iPad/iPhone, Android, Windows Phone

Centralized Services (logging, monitoring, confjguration, …)

Centralized ¡Services ¡ ¡

Generally, we tend to use Open Source software:

• Logging: Syslog NG
• Fault Monitoring: Nagios
• Graphs + Performance Monitoring: Munin
• Accounting: FreeRADIUS + mySQL
• Confjguration+User Mgmt.+ … : Puppet

voopIX Future ?

voopIX ¡– ¡Future? ¡

• Scalability problem - not yet seen, but may become an issue
• Web portal for members (billing, some setup, etc.)
• Solution for smaller institutions (Schools on small islands)
• Shown interest from other public/government institutions
• Try to animate institutions in other countries to start up similar

project and to peer with us - we’re ready to help

• Add more advanced functions to our system

Open Platform

Open ¡Plaborm ¡

• The idea here is to be able to create VoIP infrastructure on the

Open Platform, which doesn’t rely on a single vendor, single technology or a proprietary solution

• At any time, if there is a technology or protocol that shows up to

be superior to currently used, we can move to them without investing in new equipment or paying additional licenses

• By using central confjguration, we can switch hundreds of

appliances to new system in a matter of hours

Thank you for your time !

voopix@carnet.hr All questions and suggestions are more then welcome.
