Virginia Tech NASA USLI PDR Presentation Ishan Arora, Nicholas Corbin, William Dillingham, Valerie Hernley, Joseph Lakkis, Max Reynolds, Angelo Said 11/14/18 - 3:00 PM CST Contents Team Overview Mission Overview Launch Vehicle
Ishan Arora, Nicholas Corbin, William Dillingham, Valerie Hernley, Joseph Lakkis, Max Reynolds, Angelo Said
11/14/18 - 3:00 PM CST
a. Vehicle Layout b. Vehicle Specifications c. Airframe Materials d. Propulsion e. Recovery f. Electronics Bay g. Mission Performance Predictions h. Validity of Analyses
2
a. Mission Success Criteria b. Design Summary c. UAV Components d. Navigation e. Navigational Beacon Release f. Retention System g. Mission Performance Predictions
3
a. General b. Launch Vehicle c. Recovery d. Payload e. Safety
a. Budget b. Timeline c. Scrum
4
5
6
7
8
Mission Statement:
“Our booster will reach apogee at 4,500 feet and separate into two independent sections, each of which have both a drogue and main recovery parachute. After landing, the booster section will deploy an autonomous UAV with backup RC that delivers a navigational beacon to a Future Excursion Area.”
0) Launch 1) Booster/recovery bay separation 2) Main parachute deployment 3) Booster and recovery bay touchdown, payload deployment 4) Navigational Beacon delivery
9
0) Launch 1) Booster/recovery bay separation 2) Main parachute deployment 3) Booster and recovery bay touchdown, payload deployment 4) Navigational Beacon delivery
10
0) Launch 1) Booster/recovery bay separation 2) Main parachute deployment 3) Booster and recovery bay touchdown, payload deployment 4) Navigational Beacon delivery
11
0) Launch 1) Booster/recovery bay separation 2) Main parachute deployment 3) Booster and recovery bay touchdown, payload deployment 4) Navigational Beacon delivery
12
0) Launch 1) Booster/recovery bay separation 2) Main parachute deployment 3) Booster and recovery bay touchdown, payload deployment 4) Navigational Beacon delivery
13
14
15
Center of Gravity Center of Pressure
16
Center of Gravity Center of Pressure
17
18
Center of Gravity Center of Pressure
19
Vehicle Component Length (inches) Booster Bay 36.75 Recovery Bay 77.5 Von-Karman Nose Cone 34.5 Boat Tail Transition 5 Total Length 100 CG Location 62.3 inches from tip of nose cone CP Location 75.8 inches from tip of nose cone Static Stability Margin 2.15 Thrust-to-weight Ratio 10.04 Rail Exit Velocity 85.6 ft/sec
20
Fiberglass Carbon Fiber
○ Carbon Fiber / Soric LRC Foam Laminate ○ Expected wall thickness: 0.14 inches ○ Density: 0.23 oz/in^3 ○ Matrix Material: FibreGlast System 2000 Epoxy ○ Peak strength: 3270 lbf
○ Fabricated from aircraft grade birch plywood ○ External mounting system for easy replacement
○ COTS Fiberglass Von - Karman
○ Excellent performance in highly compressive loading scenarios ○ Lightweight materials
Carbon Fiber with sandwich core
○ High stiffness and strength to weight ratio ○ Allows for lightest possible construction ○ Application of sandwich core increases stiffness with minimal use of carbon fiber plys and increased weight
21
Motor Selection: Aerotech K-1000T Reloadable Motor Casing: Aerotech RMS-75 2560* Motor Retention:
Aluminum thrust ring, screw-cap retention system
22
*Looking into borrowing to save money, may use comparable CTI casing (Pro75 3G) with AT Crossloads
Constraints:
Aerotech produces reliable motors:
assemblies, RMS reloadable motors
thrust curve
23
Parachutes:
○ 1 ft for drogue chute ○ 5 ft for main chute
Separation Method:
○ Stratologger SL100 ○ Adafruit BMP280
○ FFFF black powder ○ BP weight determined based on volume and desired pressure
24
25 1 6 5 4 2 3
1. Power for the system is a 6600 mAh Li-Po battery (2200 mAh for Recovery Bay) 2. Arduino Battery Shield 3. Arduino Uno microcontroller 4. Arduino Ultimate GPS Logger Shield 5. 900 MHz XBee Radio 6. Adafruit BMP280 Barometric/Altitude Sensor
26
27 Data was reproduced from OpenRocket simulations.
28
29 Data was reproduced from OpenRocket simulations.
○ Designed for this specific purpose ○ Utilizes a 6-Degree Of Freedom Barrowman method for modeling ○ Supported by motor manufacturers within industry ○ Allows for customization and modeling of individual components
○ Developed based on peer approved research publications ○ Takes into account average drag coefficient, surface area, vehicle weight with and without motor, generalized thrust curve, air density, and launch rail angle
30
31
○ Retained during flight using a fail-safe retention system ○ Shall autonomously deploy from the launch vehicle upon signal ○ UAV shall deliver a 1 inch cube (navigational beacon) to FEA
○ Small enough to fit within the 6 inch diameter launch vehicle ○ The UAV shall complete the mission using autonomous flight requiring less than 1 minute of manual input ○ Range must be great enough to be able to reach an FEA regardless of vehicle landing location within the launch site
32
Launch field is about 1 square mile and will contain multiple FEA targets
and RC navigation enabled
33
* Assuming 7 mph wind
34
○ GPS coordinates ○ iNav open-source software
○ Transmitter has switch to activate in case of autonomous malfunction ○ Video with manual control can be used to fine-tune navigation/delivery
cubic inch navigational beacon to the FEA
35
arrival at the FEA
switch designated to the cube release
and release the cube
36
Cable Cutter
The fail-safe retention system provides both vertical and horizontal load support while doubling as a bay to protect the payload during separation, guiding it
Vertical Retention: Guide rods running through holes in the UAV Horizontal Retention: Cables holding down the UAV are taut until cut by cable cutters Bulkheads: Plates at the ends protect the payload during separation and from black powder charges
37
○ Constant wind speed ○ Constant thrust ○ CD & A estimated from lit review
38
Theoretical results will be validated by extensive testing to improve performance predictions
39
40
Section Requirement Verification Method Verification 1.2 The team will provide and maintain a project plan to include the following items: project milestones, budget and community support, checklists, personnel assignments, STEM engagement events, and risks and mitigations Inspection All project management documents will be available on the team's shared
management information 1.4 The team must identify all team members attending launch week activities by the Critical Design Review (CDR) Interviews, Documentation Team leads will make a list of all individuals attending launch week activities prior to CDR 1.5 The team will engage a minimum of 200 participants in educational, hands-on science, technology, engineering, and mathematics (STEM) activities prior to the submission of the CDR Documentation ESM Rocketry will turn in the STEM Engagement Activity Report 1.6 The team will establish a social media presence to inform the public about team activities Documentation Team members, and specifically the social media lead, will regularly update the social media sites and website 1.9 In every report, teams will provide a table of contents including major sections and their respective sub-sections Inspection The editor will verify a table of contents is present in every report
41
Section Requirement Verification Method Verification 2.1 The vehicle will deliver the payload to an altitude between 4,000 and 5,500 feet above ground level Inspection Altimeter data 2.3 The vehicle will carry one commercially available, barometric altimeter to record the official altitude Inspection Use of Stratologger commercially available altimeter 2.4 Each altimeter will be armed by a dedicated mechanical arming switch that is accessible from the exterior of the airframe Inspection The team plans on using commercially available switches to arm the electronics bay components while the vehicle is on the launch rail 2.5 Each altimeter will have its own dedicated power supply Inspection Altimeters will use 9V batteries 2.6 Each arming switch will be capable of being locked in the ON position for launch Inspection and Demonstration Checklist, inspection, and implementation of required devices 2.10 The launch vehicle will be capable of being prepared for flight at the launch site within 2 hours of the time the Federal Aviation Administration flight waiver opens Demonstration, Design Will design and have procedure/checklist for assembly, will perform dry-run to practice assembly
42
Section Requirement Verification Method Verification 2.11 The launch vehicle will be capable of remaining in launch-ready configuration
Demonstration, Inspection, Test, Design Testing of electronics system after checklist procedure, will perform power budget calculations 2.17 The launch vehicle will have a minimum static stability margin of 2.0 cals at the point of rail exit Analysis, Design Calculated through simulation software based on vehicle design 2.18 The launch vehicle will reach a minimum velocity of 52 fps at rail exit Demonstration, Test, Analysis Calculated using simulation software, developed code, and demonstrated during launch 2.19 All teams will successfully launch and recover a subscale model of their rocket prior to CDR Demonstration The team is planning on launching a subscale vehicle which will not be high powered 2.20 All teams will complete demonstration flights as outlined in the rulebook Demonstration, Test The team has checked with local TRA chapters to ensure they will be on schedule to launch on time and meet requirements 2.21 An FRR Addendum will be required for any team completing a Payload Demonstration Flight or NASA-required Vehicle Demonstration Re-flight after the submission of the FRR Report Demonstration, Documentation The team has checked with a local rocketry organization and will plan to fly its Payload Demonstration Flight before the submission of FRR
43
Section Requirement Verification Method Verification 3.1 The launch vehicle will deploy a drogue parachute at apogee and a main parachute is deployed at a lower altitude Design, Test The team will design the recovery system such that drogue parachutes are deployed at apogee and will use chute releases to deploy the mains at a lower altitude. This system will be tested during both the sub-scale and full-scale launches. 3.1.1 The main parachute shall be deployed no lower than 500 feet Analysis, Test This will be calculated through simulation software based on vehicle design 3.1.2 The apogee event may contain a delay of no more than 2 seconds Test Altimeter data will be analyzed post-test to verify deployment of the drogue chute within 2 seconds of hitting apogee 3.3 At landing, each independent section of the launch vehicle will have a maximum kinetic energy of 75 ft-lbf Demonstration Hand calculations are used to predict the maximum kinetic
vehicle weight information. This will be verified during post-test analysis once flight data is available. 3.6 The recovery system will contain redundant, commercially available altimeters. The term “altimeters” includes both simple altimeters and more sophisticated flight computers. Design The vehicle will contain a Stratologger SL100 and an Adafruit BMP280
44
Section Requirement Verification Method Verification 3.8 Removable shear pins will be used for both the main parachute compartment and the drogue parachute compartment. Design The recovery system is designed with removable shear pins 3.9 Recovery area will be limited to a 2,500 ft. radius from the launch pads. Design, Analysis The design choice to deploye a drogue first and then a main at lower apogee helps limit drift. Drift calculations were performed with various wind speeds. Even with 20 mph wind, the drift is less than 2000 ft. 3.10 Descent time will be limited to 90 seconds (apogee to touch down). Analysis, Test Hand calculations were used to predict descent time based on parachute size and vehicle weight. This will be verified with altimeter data after the test launches. 3.11 An electronic tracking device will be installed in the launch vehicle and will transmit the position of the tethered vehicle or any independent section to a ground receiver. Design, Test The electronic bay is designed such that each separate section contains a GPS that can be used for tracking the
during the flight tests.
45
Section Requirement Verification Method Verification 4.4.2 The UAV will be powered off until the rocket has landed on the ground and is capable of being powered on remotely after landing Design, Testing The team will design a MOSFET circuit, triggered using a radio transmitter, to remotely turn on the UAV after the vehicle has landed. This system will be tested in the lab and during the payload test flight to verify it functions properly. 4.4.3 The UAV will be retained within the vehicle utilizing a fail-safe active retention system Design, Analysis, Testing The retention system will be designed to withstand the large forces that could be experienced during flight. Analysis will be performed to estimate the force on the payload during flight. Testing will be performed to verify the payload remains secure under a variety of circumstances. 4.4.4 At landing, and under the supervision of the Remote Deployment Officer, the team will remotely activate a trigger to deploy the UAV from the rocket. Testing The team will design a MOSFET circuit, triggered using a radio transmitter, to remotely turn on the UAV after the vehicle has landed. This system will be tested in the lab and during the payload test flight to verify it functions properly.
46
Section Requirement Verification Method Verification 4.4.8 Once the UAV has reached the FEA, it will place or drop a simulated navigational beacon on the target area Test GPS will be used to autonomously navigate to the FEA. The cube release mechanism and GPS navigation will both be tested. 4.4.12 The team will abide by all applicable FAA regulations, including the FAA’s Special Rule for Model Aircraft Documentation The team will identify all applicable FAA regulations and will read them thoroughly to ensure compliance 4.4.13 Any UAV weighing more than .55 lbs will be registered with the FAA and the registration number marked on the vehicle Measurement, Documentation The final weight of the UAV will be measured and proof of registration with the FAA will be provided (if heavier than 0.55 lbs)
47
Section Requirement Verification Method Verification 5.3.2 The safety officer will implement procedures developed by the team for construction, assembly, launch, and recovery activities Documentation The safety officer will hold all team members accountable to following all procedures related to safety 5.3.4 The safety officer will assist in the writing and development of the team’s hazard analyses, failure modes analyses, and procedures Inspection The safety officer will help write and will review the hazard and failure modes analyses 5.4 During test flights, teams will abide by the rules and guidance of the local rocketry club’s RSO Documentation, Inspection The team will contact the local club's president before attending any launches. The team will abide by all safety rules and will respect the authority of the RSO. 5.5 Teams will abide by all rules set forth by the FAA Documentation The team will identify all applicable FAA regulations and will read them thoroughly to ensure compliance
48
49
○ Total: $7,153.77 ○ Current deficit: $809.19
*The team is currently pursuing corporate sponsors/VSGC Grant to cover the remaining $809.19 deficit.
○ Long-term goals
○ Taiga.io website ○ 2 week sprints ○ Organized into 3 levels: ■ Individual Tasks ■ “Epics” big-picture goals ■ “User Stories” group tasks into categories ○ Assign tasks to individual team members
50
51
52
53
54
factoring in wind speeds and launch angles
○ Autonomous navigation to FEA ○ RF control possible for fine-tuned delivery as needed ○ Cable cutter used for cube release upon arrival
