Vehicle Localization based on Lane Marking Detection Yuncong Chen UCSD HRI intern 2014 Overview Input Goal Odometry lateral localization on highway (noisy GPS / IMU for now) give correct estimate on merge / split points

slide-1
SLIDE 1

Vehicle Localization based on Lane Marking Detection

Yuncong Chen UCSD HRI intern 2014

slide-2
SLIDE 2

Overview

  • Odometry

(noisy GPS / IMU for now)

  • Monocular camera
  • Lane level map
  • lateral localization on highway
  • give correct estimate on merge

/ split points Goal Input Assumptions

  • road surface is flat
slide-3
SLIDE 3

Coordinate System

North / East / Down Longitude / Latitude local plane origin = first gps position GPS Algorithm California State Plane Map

slide-4
SLIDE 4

Map

no semantic information, interpolate

slide-5
SLIDE 5

Particle Filter

  • Motion model

current pose previous pose GPS / odometry

  • Observation model

map current image pose = (north, east, yaw) map = a set of points labeled by marking groups

slide-6
SLIDE 6

Particle Filter

propagate using motion model weight each particle by its likelihood computed from observation model resample particles according to their weights all with same weight here

slide-7
SLIDE 7

Motion Model

initial rotation noise translation noise final rotation noise

  • rotations and translation

computed from odometry

slide-8
SLIDE 8

Observation Model

project map points to bird’s-eye view Given the vehicle pose,

  • ur bird’- eye view image is expected to look

like this ...

slide-9
SLIDE 9

Observation Model

project map points to bird’s-eye view Given the vehicle pose,

  • ur bird’- eye view image is expected to look

like this ...

slide-10
SLIDE 10

Observation Model

inverse perspective transform filter Hough line fitting … while what we really observe is ...

slide-11
SLIDE 11

Observation Model

expected

  • bserved

match lines

slide-12
SLIDE 12

Maximum Bipartite Matching

  • bserved

expected

slide-13
SLIDE 13

… not so simple

  • rder must be consistent

matches cannot be too far away some map lines may not be detected in the image # candidate matchings

slide-14
SLIDE 14

Likelihood Score

map line i detected line matched to map line i distance between the line pair

  • prob. of not

detecting a map line total number

  • f map lines
slide-15
SLIDE 15

Speed Up Matching share among particles

(0,0)(1,1)(2,2)(3,3)(4,4) (0,1)(2,3)(3,4) (0,0)(1,1)(2,2)(3,3)(4,4) (0,0)(2,1)(3,2)(4,3) (0,0)(1,1)(2,2)(3,3)(4,4)

  • Sample to obtain a very small set
  • f candidate matchings
  • For the rest of the particles,
  • nly evaluate these candidate

matchings

  • Exploit spatial correlation of

matchings among nearby particles

(map, detected) (0,0)(1,1)(2,2)(3,3)(4,4) (0,0)(2,1)(3,2)(4,3) (0,1)(2,3)(3,4)

  • Preferable to sample particles

spread out in space.

slide-16
SLIDE 16

Speed Up Matching search in previous map lines’ extent

map group 16 map: ipm g16: 0 g3: 1 g7: 2, 3 g8: 2, 3 g11: 3, 4

  • Keep track of extent of every

map line

  • For a new set of detected

lines, search matchings for each map line only within its extent

  • Exploit temporal invariance of

matchings for a single particle at different times

map group 3 map group 7 map group 8 map group 11

slide-17
SLIDE 17

Process Images

inverse perspective transform filter Hough line fitting

slide-18
SLIDE 18

Inverse Perspective Mapping

pitch yaw height measured by hand

slide-19
SLIDE 19

Inverse Perspective Mapping

slide-20
SLIDE 20

Inverse Perspective Mapping

slide-21
SLIDE 21

Inverse Perspective Mapping

slide-22
SLIDE 22

Top-hat Filter

high response if one side of an edge is very dark

slide-23
SLIDE 23

Top-hat Filter

* *

threshold threshold & high response if one side of an edge is very dark more robust for detecting dark-bright-dark patterns

slide-24
SLIDE 24

Steerable Filter Second derivative of Gaussian

separable rotated to arbitrary angle

slide-25
SLIDE 25

Map-guided Filtering

SC logic OR

...

slide-26
SLIDE 26

Steerable vs. Top-hat noisy image

top-hat map-guided steerable

slide-27
SLIDE 27

Take Advantage of Map

Motion model

  • more likely to go along the current lane
  • cannot move beyond road edges

Observation model

  • map-guided image filtering
  • map-guided line fitting
slide-28
SLIDE 28

Hough Transform Line Fitting

25 line segments detected by OpenCV’s probabilistic Hough transform 6 lines remains after merging

slide-29
SLIDE 29

Experiments on straight lanes

straight avg lateral error: 0.22, max: 1.35

slide-30
SLIDE 30

Straight lanes

slide-31
SLIDE 31

Deal with Curved Lanes

curved avg lateral error: 0.25, max: 0.98

slide-32
SLIDE 32

Deal with Curved Lanes

  • detect whether

the line is a curve (i.e. residual of a linear regression is large)

  • if so, match only

the bottom segment

slide-33
SLIDE 33

Steerable vs. Top-hat straight

steerable, avg lateral error 0.23, max 1.15 top-hat, avg lateral error 0.2, max .86

slide-34
SLIDE 34

Steerable vs. Top-hat curve

steerable, avg lateral error 0.3, max 0.79 avg lon. error 0.7, max 1.55 top-hat, avg lateral error 0.47, max 1.8 avg lon. error 0.67 max 2.83

slide-35
SLIDE 35

Effect of the Number of Particles

slide-36
SLIDE 36

Issues and Extensions

  • shadows
  • more general markings (urban environment)

○ stop-lines (longitudinal correction) ○ curved lanes ○ model-free

  • investigate how number of particle affects

performance
