Vattenfall and the HYBRIT project

2018-09-13

Mikael Nordlander

…

1 Confidentiality –None (C1)

2

Fossil free within one generation

Confidentiality –None (C1)

Sweden - a good place to start 98 31 16

…% fossil free power generation …€/MWh average spot price in 2017 …TWh/yr electricity exported 2013-2017

Confidentiality –None (C1)

If you want to replace fossil fuels – it matters what you can squeeze out of a piece of land

Confidentiality –None (C1)

That’s why…we want to electrify everything

THE TRANSPORT SECTOR HEATING THE INDUSTRY

Confidentiality –None (C1)

To live up to the Paris Agreement, Swedish industry and transports need to be handled

32% 32% 9% 13% 14% Total GHG emissions 2016

Domestic transports Industry Power and heat Agriculture Other

36% 19% 16% 9% 5% 4% 2% 8% Industrial GHG emissions 2016

Iron- and steel Minerals (cement) Refineries Chemistry Pulp and paper Other metals Food Other

Source: Swedish Environmental Protection Agency

52.9 Mton 16.9 Mton

Confidentiality –None (C1)

Fossil free steel with SSAB/LKAB

Confidentiality –None (C1)

Close to complete elimination of CO2

Confidentiality –None (C1)

HYBRIT roadmap

9

2025-2035 2018-2024 2016-2017 Feasibility study phase Pilot phase Demonstration phase

2018

Pilot plant “green light” decision

2018-2020

Construction of pilot plant

2020-2024

Pilot plant trials

2016-2017

Feasibility study

2017

Joint venture formed

2017

Start of 4 year R&D program

Confidentiality –None (C1)

HYBRIT – prefeasibility conclusions

• No new major technical showstoppers identified
• However, significant development efforts required to
• vercome main challenges
• 20-30% increase in crude steel production cost
• Cost structure strongly dependent on prices of coking coal,

electricity and CO2 emission rights

• Further optimisation possible
• On the same level or better than competing alternatives
• Anticipated shift in prices and market demands make

fossil-free steel an attractive option

• Strengthened belief in the concept

 Proceed with pilot plant (decision Feb 2018)

+20-30%

Confidentiality –None (C1)

HYBRIT pilot plant - the next step

• Pre-engineering and design since January
• Location Luleå & Malmberget
• Direct reduction:

~1 ton/h DRI

• H2:

~600-700 Nm3/h (~3-4 MWe)

• Steel (EAF):

~10 ton/batch

• H2 storage:

TBD 2019

• Time schedule
• Start groundwork summer 2018
• Commissioning early 2020
• Test campaigns 2020-2024
• Total cost 2018-2024 ~150 M€
• Includes CAPEX + OPEX for whole test period
• Co-funded by Swedish Energy Agency

Direct reduction Electrolysis Steel (EAF) Pellets Malmberget Luleå Pellets

Confidentiality –None (C1)

H2 storage – an important part of the HYBRIT concept

• Underground H2 gas storage the most

cost effective storage alternative

• Salt caverns not available in Sweden
• Lined Rock Cavern (LRC) storage

promising alternative

• Natural gas LRC demo in operation in

Sweden (Skallen) since early 2000

• Main challenges are 1) the liner material

selection, and 2) rock mechanics at dynamic operation

12 Confidentiality –None (C1)

HYBRIT pilot plant – ground breaking ceremony June 20th 2018

Confidentiality –None (C1)

Thank you

mikael.nordlander@vattenfall.com

2018-10-22 Confidentiality –None (C1)

”The mind is like a parachute – it doesn’t work if it’s not open”

• Frank Zappa
