Non­Synchronous Energy Electronics, LLC

A Technical Description of a

Variable Speed Generator System

for retro­fitting RTG Cranes 94 Middlesex Rd. Merrimack, NH 03054 USA 1 (603) 546­5785

www.nonsynchronous.com

Non­Synchronous Energy Electronics

Generator Set

Engine

M

M M M M M M

Hoist Trolley Gantry

• Aux. Loads

Existing RTG Electrical System

A fuel saving Variable Speed Generator System can be incorporated into existing RTG Cranes For Existing Generator Sets, the engine speed can

• nly be governed from 47Hz to 63Hz, with an idle

speed of between 750 RPM and 900 RPM The NSEE System makes use of the idle/running toggle with trim signals to optimize performance For a 50Hz system such a Detroit Series 60 Engine, a further improvement in peak power of about 60kW can be incorporated for heavy lifts

Non­Synchronous Energy Electronics

Generator Set

Engine

M

M M M M M M

Hoist Trolley Gantry

• Aux. Loads

RTG with VSG and Bypass Switchgear

DC Boost Control

The VSG System is added, without removing any of the existing equipment. The Bypass Switchgear can be used to switch back to the

• riginal mode of fixed generator speed operation

The Engine and Alternator controls have a similar bypass mode to change when the power switchgear changes

(+) (­)

Non­Synchronous Energy Electronics

Generator Set

Battery

Engine

M

M M M M M M

Hoist Trolley Gantry

• Aux. Loads

RTG with VSG System, Energy Storage and Bypass Switchgear

The Energy Storage System is added directly to the DC Link

Smaller Generator Set

Battery

Engine

M

M M M M M M

Hoist Trolley Gantry

• Aux. Loads

RTG with Smaller Generator, VSG , Energy Storage and NO Bypass Switchgear

Once the System is proven and accepted, the bypass can be removed and a smaller generator put in place for maximum fuel savings

Non­Synchronous Energy Electronics

Field

Non­Synchronous Energy Electronics

Generator Set

Engine

AVR Throttle Control

VSG

Field Current Controller V fb PMG Speed fb

Field Current Supply Toggle idle/rated Speed Speed Trim

VSG – Generator control interface diagram

Example of similar Power Converters;

30 similar units are running on the Chicago Metro Rail system Traction Duty Construction!

Non­Synchronous Energy Electronics

NSEE has an exclusive agreement with;

Custom Power Technology Inc.

• f Menomonee Falls, Wisconsin

to supply the custom designed Power Converters for the RTG crane VSG Ststems

A VSG Power Converter rated 500kW, 300% O/L
