Utilizing STAR-CCM+ to advance the South African Power Generation Industry

The advantages of incorporating Computational Fluid Dynamics (CFD) analysis in power plant management and optimization

slide-2
SLIDE 2

Who is Aerotherm

  • Aerotherm Computational Dynamics is a well established consulting firm

with a vast amount of experience in the application of Computational Fluid Dynamics (CFD) in industry.

  • Aerotherm has been applying CFD since 1995, to solve numerous fluid

flow and heat transfer related problems to improve plant efficiency, reliability and maintainability.

  • Aerotherm is unique in that it specialises only in CAE simulation and has

therefore developed a highly specialised consulting experience in a wide variety of application areas. Our Mission Statement: To assist our clients in finding cost effective practical engineering solutions through CAE simulation of components, systems and/or entire plant.

slide-3
SLIDE 3

Focus on Coal Fired Power Plant

  • Aerotherm has in the past 16 years placed a lot of focus on fault finding

and optimization in Coal Fired Power Plants (CFPP).

  • Approximately 60% of or work experience is related to CFPP due to the

following reasons:

  • Approximately 77% of the power generated in SA is via CFPP
  • CFD was not used in the original design of any of the CFPP currently in
  • peration in SA today (not even Majuba – commissioned 1996-2001).
  • There exists large room for improvement in:
  • Air flow control and measurement
  • Coal combustion optimisation
  • Emissions reduction
  • Boiler tube leak reduction etc.
slide-4
SLIDE 4

Example application areas

  • Primary and secondary air flow measurement
  • Calibration of flow measurement devices (venturi’s / orifice plates)
  • General flow optimisation in ducting to reduce pressure drops and erosion
  • PF milling & classification process
  • PF distribution & transport
  • Air flow distribution & control
  • Gas flow in furnace and convective gas pass
  • Burner optimisation / NOx Reduction
  • Combustion Modelling – Coal quality variations
  • SOx reduction
slide-5
SLIDE 5

Holistic approach to combustion modeling

  • Input Airflow : Optimisation of the secondary air windbox which supplies

combustion air to the burners in order to evenly distribute the secondary air supply to each individual burner

  • Calibrate burners: Use mapped data from secondary air windbox model
  • n single burner sub-model and characterise burner for different swirler

settings

  • Characterise Coal: Generate a simple drop tube furnace model (DTF)

and calibrate the model to specific coal data for input to full furnace model

  • Furnace Combustion: Generate of a model of the furnace area starting

at the burner mouth and ending at the outlet of the furnace and run combustion simulations

  • Optimisation: Use the full boiler model, using mapped data and

calibrated input data from the single burner and DTF models, to evaluate the effect of different swirler settings, coal types etc.

  • Erosion Modelling: Use mapped data at outlet of furnace model in

boiler tube erosion model

slide-6
SLIDE 6

Secondary air windbox optimisation

  • Secondary air windbox supplies combustion air

to the burners

  • Optimise geometry to evenly distribute the

secondary air supply to each individual burner

slide-7
SLIDE 7

Single burner sub-model

  • Highly detailed single burner model
  • Results from the secondary air windbox model

simulations mapped as inlet boundary condition to single burner sub-model

  • The single burner sub-model is used to

characterise the burner for different swirler settings

  • The results are exported and mapped as

boundary conditions in the full boiler model

slide-8
SLIDE 8

Single burner sub-model maps

slide-9
SLIDE 9

Simple drop tube furnace model

Simplified DTF CFD Model

Cell refinement towards centre of model

slide-10
SLIDE 10

Simple drop tube furnace model

  • The DTF model is used to calibrate the CFD model to

laboratory rate data for the specific coals and test

  • conditions. (activation energy, CV, Arinius factor for

burnout rate)

  • Calibration used as input data in full burner model to

accurately model specific coals

slide-11
SLIDE 11

Full furnace model

  • The combustion models, calibrated for specific coals

using the DTF model, is applied in the full furnace model

  • The secondary air flow field, relating to specific swirler

and damper settings are extracted from the single burner sub-model solution and mapped as inlet boundary condition in the full furnace model

Input Boundary Areas Secondary Air Mapping Area Refined Burner and Furnace Section

slide-12
SLIDE 12

Full furnace model

High swirl Low swirl CO contours O2 contours Temperature contours

slide-13
SLIDE 13

Boiler tube erosion

  • Extract the solution from the full furnace model and

apply as inlet boundary condition to the boiler tube erosion/boiler aerodynamics model

  • In these analysis, all the tubes are modelled explicitly
  • A Legrangian multiphase model is used to track particles

through the domain and evaluate the resultant erosion

slide-14
SLIDE 14

Expanded metal screen Slotted Screens

Boiler tube erosion

slide-15
SLIDE 15

Boiler tube erosion

Explicit modelling (Meshing of screens)

slide-16
SLIDE 16

Boiler tube erosion

High erosion areas

slide-17
SLIDE 17

PF Milling

slide-18
SLIDE 18

PF Classification

  • Modelling of Classifiers to optimise throughput and particle size

distribution to boilers

slide-19
SLIDE 19

Other Power Plant Specific Areas

  • Fan modelling and optimisation
  • ACC modelling & performance

prediction

slide-20
SLIDE 20

Centrifugal Flow – FD & ID fans

  • Fan flow induced vibration root cause

analysis

  • Fan Stress analysis & vibration modes
slide-21
SLIDE 21

Hydro / Pumped Storage

  • Design of intakes, outlets, spillways, surge towers etc.
  • Calculation of hydrostatic and dynamic forces
  • Transient predictions of water hammers and other transient responses

Closing of valve

slide-22
SLIDE 22

Hydro / Pumped Storage

Stilling pond outlet Inlet structure Surge Tower

slide-23
SLIDE 23

Pollution control

Fabric filter plant Detailed bags are individually modelled

slide-24
SLIDE 24

Valve characterisation / Optimisation

  • Single components such as valves can be characterised and/or
  • ptimised
slide-25
SLIDE 25

Cavitation prediction

  • Many piping systems suffer

from cavitation patches which erode and eventually destroy valves and measurement equipment

slide-26
SLIDE 26

Explosion modelling

  • Evaluation of work site safety in the vicinity of high risk explosive storage

and/or systems.

slide-27
SLIDE 27

Summary

  • As can be seen there exist a multitude of applications for CFD in the

power generation industry.

  • Most existing Coal Fired Power Plants have been designed before the

advent of commercial CFD. CD-adapco’s products therefore provides an understanding of where problem areas originate and it therefore offers a unique opportunity to address the root cause for problems.

  • Evaluation of general flow systems also provides a birds eye view of

where losses occur and therefore CFD is opens the door to efficiency improvements in almost all areas of CFPP.

  • The incredible robustness, efficiency and advanced capabilities of STAR-

CCM+ has made CFD a tool that provides extremely fast turnaround times and therefore it offers a cost effective route for problem solving, design and optimisation.
