Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions Using the SAL technique for ensemble forecast verification Sabine Radanovics Until March 2017: LSCE/ESTIMR, now: CNRM/GMME/MICADO May 10, 2017 1 / 19 Why

slide-1
SLIDE 1

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Using the SAL technique for ensemble forecast verification

Sabine Radanovics

Until March 2017: LSCE/ESTIMR, now: CNRM/GMME/MICADO

May 10, 2017

1 / 19

slide-2
SLIDE 2

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Why was spatial verification invented?

2 / 19

slide-3
SLIDE 3

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Why was spatial verification invented?

2 / 19

Forecaster Paul

COSMO2 VERA CLEPS 44 46 48 50 2007062100 5 10 15 5 10 15 5 10 15 10 20 30 40 prec

slide-4
SLIDE 4

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Why was spatial verification invented?

2 / 19

Forecaster Paul

COSMO2 VERA CLEPS 44 46 48 50 2007062100 5 10 15 5 10 15 5 10 15 10 20 30 40 prec

slide-5
SLIDE 5

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Why was spatial verification invented?

3 / 19

Model developer Cate

COSMO2 VERA CLEPS 44 46 48 50 2007062100 5 10 15 5 10 15 5 10 15 10 20 30 40 prec

slide-6
SLIDE 6

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Why was spatial verification invented?

3 / 19

Model developer Cate

COSMO2 VERA CLEPS 44 46 48 50 2007062100 5 10 15 5 10 15 5 10 15 10 20 30 40 prec

RMSE = 452.02 RMSE = 352.03

slide-7
SLIDE 7

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Why was spatial verification invented?

3 / 19

Model developer Cate

COSMO2 VERA CLEPS 44 46 48 50 2007062100 5 10 15 5 10 15 5 10 15 10 20 30 40 prec

RMSE = 452.02 RMSE = 352.03 → Need to develop verification that gives credit to the attributes Paul appreciates

slide-8
SLIDE 8

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

SAL - Structure, Amplitude, Location

Amplitude component A

4 / 19

(Wernli et al., 2008)

  • bs

fc 4 8 12 16 4 8 12 16 4 8 12 16

x y

1 2 3 4 5 6 precip

S = 0 A = 0.667 L = 0

Doubled precipitation → relative Amplitude error A

slide-9
SLIDE 9

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

SAL - Structure, Amplitude, Location

Location component L

5 / 19

  • bs

fc 4 8 12 16 4 8 12 16 4 8 12 16

x y

1 2 3 precip

S = 0 A = 0 L = 0.442

Shifted feature → location error of center of mass relative to domain size L

slide-10
SLIDE 10

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

SAL - Structure, Amplitude, Location

Structure component S

6 / 19

  • bs

fc 4 8 12 16 4 8 12 16 4 8 12 16

x y

1 2 3 precip

S = 0.4 A = 0 L = 0

Flatten feature → structure error in terms of scaled feature volumes S

slide-11
SLIDE 11

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

SAL verification

7 / 19

COSMO2 VERA CLEPS

  • 44

46 48 50 2007062100 5 10 15 5 10 15 5 10 15 10 20 30 40 prec

RMSE = 452.02 S = -0.32 A = -0.22 L = 0.11 RMSE = 352.03 S = 0.55 A = -0.69 L = 0.38

slide-12
SLIDE 12

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Questions

  • 1. Ensemble verification with SAL?
  • 2. What is the effect of observation uncertainty?

8 / 19

slide-13
SLIDE 13

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Ensemble verification with SAL?

9 / 19

slide-14
SLIDE 14

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Ensemble verification with SAL?

9 / 19

Option 1

Calculate the scores for every ensemble member combination → study spread of scores

slide-15
SLIDE 15

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Ensemble verification with SAL?

9 / 19

Option 1

Calculate the scores for every ensemble member combination → study spread of scores

Option 2

Calculate one score for the whole ensemble → allows comparison with deterministic model

slide-16
SLIDE 16

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Ensemble SAL

Standard SAL Ensemble SAL A =

rrmod−rrobs 0.5[rrmod+rrobs]

A =

rrmod−rrobs 0.5[rrmod+rrobs]

L1 = |x(rrmod)−x(rrobs)|

d

L1 = |x(rrmod)−x(rrobs)|

d

L2 = 2

  • |r(mod)

d

− r(obs)

d

|

  • L2 = 2 × CRPS
  • P

r(mod)

d

  • , P

r(obs)

d

  • r =
  • i rri|xi−x|
  • i rri

S =

V (mod)−V (obs) 0.5[V (mod)+V (obs)]

S =

V (mod)−V (obs) 0.5[V (mod)+V (obs)]

V =

  • i rri

rri rrmax i

  • i rri

rr domain average precipitation. x center of mass of the precipitation field d largest distance between two domain borders. xi the center of mass of the ith feature rri is the sum of precipitation over all grid cells in feature i rr max

i

maximum precipitation of the ith feature.

10 / 19

slide-17
SLIDE 17

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

MesoVICT project core case 20-22 June 2007

(Mesoscale Verification In Complex Terrain)

11 / 19

3-hourly precipitation Ensembles CLEPS ensemble forecast (16 members) (Marsigli et al., 2005) VERA analysis ensemble (50 members) [VERAens]

(Gorgas and Dorninger, 2012)

Deterministic COSMO2 forecasts

(Ament and Arpagaus, 2009)

VERA analysis

(Steinacker et al., 2000)

slide-18
SLIDE 18

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

MesoVICT project core case 20-22 June 2007

(Mesoscale Verification In Complex Terrain)

11 / 19

3-hourly precipitation Ensembles CLEPS ensemble forecast (16 members) (Marsigli et al., 2005) VERA analysis ensemble (50 members) [VERAens]

(Gorgas and Dorninger, 2012)

Deterministic COSMO2 forecasts

(Ament and Arpagaus, 2009)

VERA analysis

(Steinacker et al., 2000)

slide-19
SLIDE 19

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

CLEPS-VERAens 16×50 SAL scores

3-hourly precipitation, 20-22 June 2007 3h-24h lead times (depending on the hour of the day)

S A L −1 1 −1 1 0.00 0.25 0.50 0.75 1.00 Jun 20 00:00 Jun 20 12:00 Jun 21 00:00 Jun 21 12:00 Jun 22 00:00 Jun 22 12:00 Jun 23 00:00 Jun 20 00:00 Jun 20 12:00 Jun 21 00:00 Jun 21 12:00 Jun 22 00:00 Jun 22 12:00 Jun 23 00:00 Jun 20 00:00 Jun 20 12:00 Jun 21 00:00 Jun 21 12:00 Jun 22 00:00 Jun 22 12:00 Jun 23 00:00

large spreads in scores, especially S

12 / 19

slide-20
SLIDE 20

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

CLEPS-VERAens Ensemble SAL vs. median of 800 x standard SAL

S A L −1.0 −0.5 0.0 0.5 1 0.0 0.2 0.4 0.6 Jun 20 00:00 Jun 20 12:00 Jun 21 00:00 Jun 21 12:00 Jun 22 00:00 Jun 22 12:00 Jun 23 00:00 Jun 20 00:00 Jun 20 12:00 Jun 21 00:00 Jun 21 12:00 Jun 22 00:00 Jun 22 12:00 Jun 23 00:00 Jun 20 00:00 Jun 20 12:00 Jun 21 00:00 Jun 21 12:00 Jun 22 00:00 Jun 22 12:00 Jun 23 00:00

sal

Ensemble SAL Median of standard SAL

Similar for 2-sided scores A and S Ensemble L tends to be smaller than median of standard L

13 / 19

slide-21
SLIDE 21

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Compare models - SAL diagrams

14 / 19

VERA VERA ensemble

  • −2

−1 1 2 −2 −1 1 2 COSMO2 CLEPS −2 −1 1 2 −2 −1 1 2

S A

0.1 0.2 0.3 0.4 0.5

L

slide-22
SLIDE 22

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Compare models - SAL diagrams

14 / 19

VERA VERA ensemble

  • −2

−1 1 2 −2 −1 1 2 COSMO2 CLEPS −2 −1 1 2 −2 −1 1 2

S A

0.1 0.2 0.3 0.4 0.5

L

difference between VERA and VERAens bigger than difference between forecasts

slide-23
SLIDE 23

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Compare models - SAL diagrams

14 / 19

VERA VERA ensemble

  • −2

−1 1 2 −2 −1 1 2 COSMO2 CLEPS −2 −1 1 2 −2 −1 1 2

S A

0.1 0.2 0.3 0.4 0.5

L

difference between VERA and VERAens bigger than difference between forecasts

Why?

slide-24
SLIDE 24

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Compare models - SAL diagrams

14 / 19

VERA VERA ensemble

  • −2

−1 1 2 −2 −1 1 2 COSMO2 CLEPS −2 −1 1 2 −2 −1 1 2

S A

0.1 0.2 0.3 0.4 0.5

L

difference between VERA and VERAens bigger than difference between forecasts

Why?

Forecasts very similar due to short lead times VERAens very different from VERA

slide-25
SLIDE 25

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

VERAens vs. VERA

  • hourly

3−hourly −2 −1 1 2 −2 −1 1 2 −2 −1 1 2

S A

0.1 0.2 0.3 0.4

L

Total precipitation A systematically higher in VERAens S spans the whole range of values, majority negative S for hourly large values of L, same order of magnitude as forecasts

15 / 19

slide-26
SLIDE 26

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

What is known for VERAens

Gorgas and Dorninger (2012) found that

  • 1. the quality control procedure to remove unrealistic values like

from the perturbed analysis fields tends to remove more of the negative perturbations than from the positive ones → high bias in the VERA ensemble.

  • 2. the standard deviations are on average increased due to the

perturbations, but this varies strongly with the ensemble member

Increased standard deviation → smaller/more peaked objects → negative S dominates. What if the standard deviation due to the perturbations does not only vary with the ensemble member but also over different time steps? This would partly explain the wide range

  • f S values.

16 / 19

slide-27
SLIDE 27

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions

Conclusions

The behaviour of the ensemble SAL seems comparable to the standard SAL + less computation than 800 standard SAL – loose information on spread SAL is very sensitive to small differences in the analysis (or the forecasts) (see also Weniger and Friederichs (2016)) → may be useful to highlight subtle differences and as a rather qualitative diagnostic in model development → probably less useful for ranking models There might be an issue with a too large verification domain for L and S. → domain size sensitivity experiments needed, in particular with complex terrain

17 / 19

slide-28
SLIDE 28

Why spatial verification? SAL Ensemble SAL MesoVICT data Results Conclusions 18 / 19

Thank you!

slide-29
SLIDE 29

References I

Ament, F. and Arpagaus, M. (2009). dphase cosmoch2: Cosmo model forecasts (2.2 km) run by meteoswiss for the map d-phase project. Gorgas, T. and Dorninger, M. (2012). Concepts for a pattern-oriented analysis ensemble based on observational uncertainties. Quarterly Journal of the Royal Meteorological Society, 138(664):769–784. Marsigli, C., Boccanera, F., Montani, A., and Paccagnella, T. (2005). The cosmo-leps mesoscale ensemble system: validation of the methodology and verification. Nonlinear Processes in Geophysics, 12(4):527–536. Steinacker, R., H¨ aberli, C., and P¨

  • ttschacher, W. (2000). A transparent method for

the analysis and quality evaluation of irregularly distributed and noisy observational

  • data. Monthly Weather Review, 128(7):2303–2316.

Weniger, M. and Friederichs, P. (2016). Using the sal technique for spatial verification

  • f cloud processes: A sensitivity analysis. Journal of Applied Meteorology and

Climatology, 55(9):2091–2108. Wernli, H., Paulat, M., Hagen, M., and Frei, C. (2008). SAL–a novel quality measure for the verification of quantitative precipitation forecasts. Monthly Weather Review, 136(11):4470–4487.

19 / 19
