Using LLVM to guarantee program integrity

Simon Cook

Background

• Compiling for security is becoming increasingly important
• Finding bugs through AddressSanitizer, MemorySanitizer, etc.
• Research programs such as LADA
• Use of security-enhancing hardware can added to existing

programs by extending their use in the compiler

Topics to Discuss

• Hardware
• C attributes
• Clang/Sema, Clang/Codegen
• LLVM Optimization Tweaks
• Instruction Lowering/Selection
• AsmPrinting
• Creating post-link tools using MC

What are we trying to protect?

• Instruction integrity
• Detection of any modification to program code at runtime
• Control flow integrity
• Ensuring that calls/branches only go to known locations and that

return values are correct

• If either of these are invalid the hardware should trap as

soon as possible

Encoding Instructions: Hardware

Each instruction becomes dependent on the previous one Given an instruction 𝐽", and internal state 𝑇$, we can produce the encoded instruction 𝐹" and output state 𝑇"

𝑓𝑜𝑑𝑝𝑒𝑓 , → ,

𝐽" 𝑇$ 𝐹" 𝑇"

𝑒𝑓𝑑𝑝𝑒𝑓 , → ,

𝐹" 𝑇$ 𝐽" 𝑇"

add r0, r1 0xbeef

At run time, the hardware can use the same state, and using the encoded instruction, reproduce the original instruction

0xbeef add r0, r1

Encoding a Function

lsli $r10, $r2, 2 919a 4000 andi $r13, $r3, 5 5d87 4002 add $r2, $r13, $r10 aa82 0900 jmp $r0 0050 int foo(int x, int y) { return (4*x) + (y&5); }

𝐽" 𝐽. 𝐽/ 𝐽0

lsli 0001 0203 andi 0405 0607 add 0809 0a0b jmp 0c0d 𝑓 , → 𝑓 , → 𝑓 , → 𝑓 , →

𝐽" 𝑇$ 𝐹" 𝐽. 𝑇" 𝐹. 𝐽/ 𝑇. 𝐹/ 𝐽0 𝑇/ 𝐹0

Encoding Branches

; BB#0: movi $r10, 0 809e 4000 bne .LBB0_2, $r4, $r10 e2c6 0100 ; BB#1: mov $r2, $r3 9812 .LBB0_2: jmp $r0 0050 int foo(int x, int y, bool z) { return z ? x : y; }

𝐽" 𝐽. 𝐽/ 𝐽0

𝑓 , → 𝑓 , →

𝐽0 𝑇/ 𝐹0 𝐽0 𝑇2 𝐹0

For two cases, this may be solvable, but not for blocks with many direct predecessors

Encoding Branches

; BB#0: movi $r10, 0 809e 4000 bne .LBB0_2, $r4, $r10 e2c6 0100 _correction_value_ .... ; BB#1: mov $r2, $r3 9812 .LBB0_2: jmp $r0 0050 int foo(int x, int y, bool z) { return z ? x : y; }

𝐽" 𝐽. 𝐷 𝐽/ 𝐽0

𝑓 , → 𝑓 , →

𝐽0 𝑇/ 𝐹0 𝐽0 𝐷 𝐹0

𝑓 , → 𝑓 , →

𝐽. 𝑇" 𝐹. 𝐷 𝑇" 𝐹3

Function Calls

int foo(int x) { return bar(x+2); } subi $r1, $r1, 2 4a16 stw [$r1, 0], $r0 4038 addi $r2, $r2, 2 9214 bal bar, $r0 00c2 0000 ldw $r0, [$r1, 0] 0828 addi $r1, $r1, 2 4a14 jmp $r0 0050

𝐽" 𝐽. 𝐽/ 𝐽0 𝐽4 𝐽5 𝐽6

• Calling bar pushes state to the encoding stack
• Returning pops this value, so calls can be treated as part of same BB

𝑇0

Scaling up to an entire program

foo.c bar.c baz.c

Clang: -mencode-instructions?

Pros

• Easy to enable, one flag

enables system for entire CU

Cons

• ABI break, flag required

across entire project

• Only affects C, assembly still

needs patching

• Potential concerns about code

size

In the end we decided not to go down this route

Clang: __attribute__((protected))

Pros

• Per function granularity
• Lower cost overhead for

“non-secure” functions

• ABI change is limited to those

functions it was requested for

Cons

• Only affects C, assembly still

needs patching

• Risk of user neglecting to add

attribute to all declarations of a function

Clang Function Attribute

• Added as a TypeAttr
• We want to add error checking as pointers to protected functions are

not the same as to unprotected

• Extend FunctionType to support having protected as a property
• For calls, add protected as bit in ExtInfo
• This is not the same as a different calling convention, as we use

different CCs and want to turn this on independently

• For CodeGen, we map this down to a LLVM function attribute

“protected”

int (*__attribute__((protected)))()

• Function pointers present a challenge
• We need to know what 𝑇$ the target function is expecting
• If 𝑇$ based on address of function, we have no problem…
• … otherwise we need to calculate it
• Could use same for each function? Defeats security benefits.
• Calculate all possible call targets? Not necessarily possible.
• User should know, let’s ask them!
• Attribute becomes __attribute__((protected("somestring")))

Changes to Middle-End LLVM

• None, really…
• … except one small change to the inliner
• Avoid inlining secure functions into non-secure
• Merging non-secure into secure is generally safe

Instruction Selection

• Update call target nodes with custom flag field
• Flag field contains:
• Bit indicating whether function expects security
• 16-bit representation of group name

let isCall = 1 in def JAL : Inst_rrr <0x2, 0x9, (outs), (ins i64imm:$ i64imm:$flags flags, GR64:$rD, GR64:$rB), "jal\t $rD, $rB”, [(AAPcall timm timm:$ :$flags flags, GR64:$rD, GR64:$rB)]>;

Encoding Control Flow I

• Just before emission, SecurityAnalysisPass:
• Prepares a function for annotation
• Builds lists of branches/calls/jump tables
• Adds placeholders for correction values
• Generates report on code size impact

===--- CF encoding statistics for 'main' ---=== Bytes added: 10 Words added: 5 NOP gaps added: 3 Enable/Disable insns added: 1

.debug_secure Record Format

• Start function:
• End function:
• Direct Call:
• Jump Table:

1 Function Start Address Group 2 Function End Address 6 Call Site Call Target 11 Count Target 1 Target 2

Encoding Control Flow II

• AsmPrinterHandler – Adds hooks to assembly printing
• Used by us for adding labels/emitting encoding at end of module
• beginInstruction
• endInstruction
• beginFunction
• endFunction
• endModule

Resolving Values

• 1. Reconstruct the control flow graph of all secure functions
• 2. Assign correction values/𝑇$ to all functions/groups
• 3. Encode each basic block, noting state of each reloc
• 4. Validate all values are known
• 5. Fill in relocations
• 6. Writeback

End result

simon@shadowfax$ llvm-objdump -d a.out a.out: file format ELF32-aap Disassembly of section .text: Section has correction values, printing real instructions foo: 8000000: [8f39] 91 9a 40 00 lsli $r10, $r2, 2 8000004: [81ca] 5d 87 40 02 andi $r13, $r3, 5 8000008: [053b] aa 82 09 00 add $r2, $r13, $r10 800000c: [93e4] 00 50 jmp $r0

Thank you
