SLIDE 1

Useful info on SNT workflows

Nick Amin

slide-2
SLIDE 2

⚫ Two main parts

  • Data/metadata retrieval
  • people usually use DAS
  • many of us use DIS
  • metadata about SNT samples (i.e., CMS4)
  • Job submission
  • people usually use CRAB
  • many of us use local condor (and Metis)

⚫ Also advertising how to retrieve this information and how to

  • ptimally request CMS4 samples :)

Overview

2

slide-3
SLIDE 3

⚫ Many CMS services to deal with data bookkeeping ⚫ DAS (Data Aggregation Service) deals with many but not all

  • It’s old and slow

⚫ "Can I get the cmsRun configuration for the GENSIM used to make this MC sample?"

  • Surprise — Can’t use DAS
  • Surprise — even using McM, that’s 10-30 clicks the first time and then 4-5 clicks
  • nce you know which ICONS are relevant

Where do I get my data?

3 user DAS DBS Phedex Other stuff PmP McM dataset/file info dataset/file location campaign progress MC configurations minor stuff nobody uses CMS4 CMS4 information

Skype with Nick, or ls /hadoop/...

👥

slide-4
SLIDE 4

⚫ DIS alleviates this issue by querying services directly

  • Faster, so you find out where that WJets sample is before retirement

⚫ Drops some DAS things that we don’t use daily ⚫ Adds some things that combine multiple sources ⚫ Adds CMS4 bookkeeping ⚫ You don’t need a proxy/cert for anything, only the person running the DIS server

Where do I get my data?

4 user DIS DBS Phedex PmP McM dataset/file info dataset/file location campaign progress MC configurations CMS4 CMS4 information

👥

slide-5
SLIDE 5

A DAS query

5 processing time: 8.1s …not to mention it times out sometimes, and there’s also this kind of page:

slide-6
SLIDE 6

A DIS query

6 processing time: 2.2s

⚫ If DIS talks to DBS directly, and DAS talks to DBS for the same data, then how is

DAS 4x slower? 🤸

⚫ dasgoclient (CLI) written by DAS author to bypass DAS and query DBS directly

  • But it’s not a website, and doesn’t (nicely) do all the things we want

⚫ http://uaf-8.t2.ucsd.edu/~namin/dis/?query=%2FEGamma%2FRun2018D-22Jan2019-

v2%2FMINIAOD&type=files&short=short

slide-7
SLIDE 7

DIS knobs

7 what kind of info do you want? "short" output? if unchecked, display more details

query (almost always just a dataset name)

slide-8
SLIDE 8

⚫ Basic

DIS options (1)

8

⚫ Files — by default, shows only 10 files (uncheck short option to see all)

slide-9
SLIDE 9

⚫ Sites — where is my data?

DIS options (2)

9 If you put in a dataset, you get fractional T2 presence If you put in a file, you get info about that file/block

slide-10
SLIDE 10

⚫ Chain

  • returns McM info (fragment, driver, CMSSW version, gridpack)
  • … for all steps from GENSIM to NANOAODSIM

DIS options (3)

10

slide-11
SLIDE 11

⚫ Pick (pickevents)

  • Put in a dataset, then comma separated list of run:lumi:event
  • Gives you the command to run to get a single root file

DIS options (4)

11

⚫ Pick_cms4 (pickevents to CMS4 level)

  • Or, just skip the middle and print out which CMS4 files have the

events

slide-12
SLIDE 12

⚫ SNT (search CMS4 samples)

  • Two entries here, because there’s two CMS4 tags

DIS options (5)

12

slide-13
SLIDE 13

⚫ How can we summarize lots of output? ⚫ "What’s the total event count of all /TTTT* samples?"

  • Any list of json-like stuff can be piped into "grep"
  • Print out some statistics with "stats"

How to summarize data?

13

slide-14
SLIDE 14

⚫ Additionally, for SNT queries, put restrictions as comma

separated list after dataset pattern

⚫ Print out hadoop path and dataset name for Prompt 2018 data

processed with the CMS4_V10-02-04 tag

How to select data?

14

slide-15
SLIDE 15

⚫ Python command line client has exact same syntax as webpage (just

give -t <type>), and you can make nice tables too

  • https://github.com/aminnj/dis/blob/master/dis_client.py
  • dis_client.py -t snt "/MET/Run2018*Prompt*/

MINIAOD,cms3tag=CMS4_V10-02-04 | grep dataset_name,gtag,nevents_in" --table

Python CLI client

15

dataset_name gtag nevents_in /MET/Run2018A-PromptReco-v2/MINIAOD 102X_dataRun2_Prompt_v11 5980578 /MET/Run2018A-PromptReco-v1/MINIAOD 102X_dataRun2_Prompt_v11 30172992 /MET/Run2018B-PromptReco-v1/MINIAOD 102X_dataRun2_Prompt_v11 28012780 /MET/Run2018C-PromptReco-v1/MINIAOD 102X_dataRun2_Prompt_v11 1986935 /MET/Run2018B-PromptReco-v2/MINIAOD 102X_dataRun2_Prompt_v11 1739672 /MET/Run2018A-PromptReco-v3/MINIAOD 102X_dataRun2_Prompt_v11 17175066 /MET/Run2018D-PromptReco-v2/MINIAOD 102X_dataRun2_Prompt_v11 162272551 /MET/Run2018C-PromptReco-v2/MINIAOD 102X_dataRun2_Prompt_v11 14698298 /MET/Run2018C-PromptReco-v3/MINIAOD 102X_dataRun2_Prompt_v11 14586790

slide-16
SLIDE 16

DIS (misc)

16

⚫ Other features

  • See readme of repo
slide-17
SLIDE 17

⚫ "CRAB mostly works when it works, but it mostly doesn’t work"

  • CRAB has a lightheavyweight server between you and your jobs

⚫ Luckily we have local condor submission and running lots of cmsRun isn’t that

complicated

⚫ Almost all data processing we do is based on dataset in → files out

  • Can be organized into "tasks" that take a "sample" (supplier of events) and

produce files with events

  • CRAB takes a dataset, PSet, CMSSW code, and some other info in a

configuration file

⚫ Metis (https://github.com/aminnj/ProjectMetis) makes it more functional

  • The tarfile contains CMSSW source to eventually ship to condor worker nodes

ProjectMetis

17

task = CMSSWTask( sample = DBSSample(dataset="/ZeroBias6/Run2017A-PromptReco-v2/MINIAOD"), events_per_output = 450e3,

  • utput_name = "merged_ntuple.root",

tag = "CMS4_V00-00-03", pset = "pset_test.py", pset_args = "data=True prompt=True", cmssw_version = "CMSSW_9_2_1", tarfile = "/nfs-7/userdata/libCMS3/lib_CMS4_V00-00-03_workaround.tar.gz", is_data = True, )

slide-18
SLIDE 18

ProjectMetis (submitting)

18

def main(): task = CMSSWTask( sample = DBSSample(dataset="/ZeroBias6/Run2017A-PromptReco-v2/MINIAOD"), events_per_output = 450e3,

  • utput_name = "merged_ntuple.root",

tag = "CMS4_V00-00-03", pset = "pset_test.py", pset_args = "data=True prompt=True", cmssw_version = "CMSSW_9_2_1", tarfile = "/nfs-7/userdata/libCMS3/lib_CMS4_V00-00-03_workaround.tar.gz", is_data = True, ) task.process() StatsParser(data=total_summary, webdir="~/public_html/dump/metis_test/").do() if __name__ == "__main__": # Do stuff, sleep, do stuff, sleep, etc. for i in range(100): main() time.sleep(1.*3600) # Since everything is backed up, totally OK to Ctrl+C and pick up later

⚫ Process a task

  • get list of inputs
  • make list of outputs
  • submit jobs
  • resubmit failed jobs

⚫ Make a summary of

jobs and put it on a dashboard

⚫ Easily extendible to a

loop over datasets

slide-19
SLIDE 19

ProjectMetis (chaining)

19

tag = "v1" total_summary = {} for _ in range(10000): gen = CMSSWTask( sample = DummySample(N=1, dataset="/WH_HtoRhoGammaPhiGamma/privateMC_102x/GENSIM"), events_per_output = 1000, total_nevents = 1000000, pset = "gensim_cfg.py", cmssw_version = "CMSSW_10_2_5", scram_arch = "slc6_amd64_gcc700", tag = tag, split_within_files = True, ) raw = CMSSWTask( sample = DirectorySample( location = gen.get_outputdir(), dataset = gen.get_sample().get_datasetname().replace("GENSIM","RAWSIM"), ),

  • pen_dataset = True,

files_per_output = 1, pset = "rawsim_cfg.py", cmssw_version = "CMSSW_10_2_5", scram_arch = "slc6_amd64_gcc700", tag = tag, ) aod = CMSSWTask( sample = DirectorySample( location = raw.get_outputdir(), dataset = raw.get_sample().get_datasetname().replace("RAWSIM","AODSIM"), ),

  • pen_dataset = True,

files_per_output = 5, pset = "aodsim_cfg.py", cmssw_version = "CMSSW_10_2_5", scram_arch = "slc6_amd64_gcc700", tag = tag, ) miniaod = CMSSWTask( sample = DirectorySample( location = aod.get_outputdir(), dataset = aod.get_sample().get_datasetname().replace("AODSIM","MINIAODSIM"), ),

  • pen_dataset = True,

flush = True, files_per_output = 5, pset = "miniaodsim_cfg.py", cmssw_version = "CMSSW_10_2_5", scram_arch = "slc6_amd64_gcc700", tag = tag, ) cms4 = CMSSWTask( sample = DirectorySample( location = miniaod.get_outputdir(), dataset = miniaod.get_sample().get_datasetname().replace("MINIAODSIM","CMS4"), ),

  • pen_dataset = True,

flush = True, files_per_output = 1,

  • utput_name = "merged_ntuple.root",

pset = "psets_cms4/main_pset_V10-02-04.py", pset_args = "data=False year=2018", global_tag = "102X_upgrade2018_realistic_v12", cmssw_version = "CMSSW_10_2_5", scram_arch = "slc6_amd64_gcc700", tag = tag, tarfile = "/nfs-7/userdata/libCMS3/lib_CMS4_V10-02-04_1025.tar.xz", ) tasks = [gen,raw,aod,miniaod,cms4] for task in tasks: task.process() summary = task.get_task_summary() total_summary[task.get_sample().get_datasetname()] = summary StatsParser(data=total_summary, webdir="~/public_html/dump/metis/").do() time.sleep(30*60)

⚫ Can chain together tasks

  • Input of one is the output
  • f the previous task

⚫ Allows one to make a

GEN→CMS4 workflow in one script

  • Make 5 tasks
  • Loop through tasks and

process them all

  • As tasks complete, the

inputs for the subsequent

  • nes become available
  • parallel in a sense
slide-20
SLIDE 20

ProjectMetis (misc)

20

⚫ Also has other Task objects (CondorTask) that can be used to make

babies from CMS4

⚫ Many examples in

  • https://github.com/aminnj/ProjectMetis/tree/master/examples

⚫ Other Metis features

  • See readme of repo

⚫ Monitoring page for central instance of Metis that submits SNT

samples

  • http://uaf-8.t2.ucsd.edu/~namin/dump/metis/
slide-21
SLIDE 21

bigly.py

21

⚫ https://github.com/cmstas/NtupleTools/blob/master/MetisScripts/

bigly.py

  • Well-organized script that uses ProjectMetis to submit CMS4 jobs

for >500 datasets (currently)

⚫ Procedure to get more CMS4

  • Make a commit that adds samples in the appropriate place in this

file, e.g.,

  • format is datasetname|xsec|kfactor|filterefficiency (though only the

product of xsec, kfactor, filtereff really matters)

  • Skype Nick after to pull this file and submit the samples
  • Too dangerous to fully automate this part…

"/QCD_HT100to200_TuneCP5_13TeV-madgraphMLM-pythia8/RunIIAutumn18MiniAOD-102X_upgrade2018_realistic_v15-v1/MINIAODSIM|19380000|1|1", "/QCD_HT200to300_TuneCP5_13TeV-madgraphMLM-pythia8/RunIIAutumn18MiniAOD-102X_upgrade2018_realistic_v15-v1/MINIAODSIM|1559000|1.0|1.0", "/QCD_HT300to500_TuneCP5_13TeV-madgraphMLM-pythia8/RunIIAutumn18MiniAOD-102X_upgrade2018_realistic_v15-v1/MINIAODSIM|323300|1.0|1.0", "/QCD_HT500to700_TuneCP5_13TeV-madgraphMLM-pythia8/RunIIAutumn18MiniAOD-102X_upgrade2018_realistic_v15-v1/MINIAODSIM|30000|1.0|1.0", …
