Uplift Need Small Flights of Stairs Avoid ramps Independence Vision Vision $40 Product Benchmarking 40$ Product Contract 40$ 2 ideas Concept 1: Bottom Attachment Easy attachment Weight directly beneath leg Walker leg Cannot
SLIDE 2
SLIDE 3
Vision
SLIDE 4
Vision
$40
SLIDE 5
40$
Product Benchmarking
SLIDE 6
40$
Product Contract
SLIDE 7
2 ideas
Concept 1: Bottom Attachment
Easy attachment Weight directly beneath leg Cannot accommodate wheels/gliders
Extendable leg Walker leg Spring
SLIDE 8
2 ideas
Concept 2: Side Attachment
Needs to be weight bearing Larger Accommodates wheels/gliders
Extendable leg Walker leg
SLIDE 9
Components
Extendable leg Walker leg Casing Pin & Spring Handle
SLIDE 10
User Interface
Stair Climbing
SLIDE 11
Simple lever pull Easy access at hands
User Interface
SLIDE 12
Safety
Raise wheels and gliders Sturdy trip up the stairs 4 points of balance
SLIDE 13
Works with most walkers Does not hinder existing leg
Compatibility
Side Attachment
SLIDE 14
Lessons Learned
Rotation of leg causes pin and hole to misalign Friction of the pin
SLIDE 15
Next Steps
Lightweight Fail Safe Mode Aesthetics
