SLIDE 1
Understanding GPU performance
How to get peak FLOPS (GPU version)
Kenjiro Taura
1 / 7
Contents
1 Data Access Performance
2 / 7
Understanding GPU performance How to get peak FLOPS (GPU version) - - PowerPoint PPT Presentation
Understanding GPU performance How to get peak FLOPS (GPU version) - - PowerPoint PPT Presentation
Understanding GPU performance How to get peak FLOPS (GPU version) Kenjiro Taura 1 / 7 Contents 1 Data Access Performance 2 / 7 Contents 1 Data Access Performance 3 / 7 Data access performance data access performance is important in GPU too
SLIDE 2
SLIDE 3
Contents
1 Data Access Performance
3 / 7
SLIDE 4
Data access performance
data access performance is important in GPU too
4 / 7
SLIDE 5
Memory organization
Pascal (P100)
level line size capacity associativity L1 32B 24KB/SM ? L2 32B 4MB/device ? Global Memory 12/16GB N/A Shared Memory 64KB (∗) N/A
Volta (V100)
level line size capacity associativity L1 32B 32-128 KB/SM (∗) ? L2 32B 6MB/device ? Global Memory 16GB N/A Shared Memory ≤96KB (∗) N/A
∗ : 128KB is split between L1 and Shared Memory (configurable) source: https://arxiv.org/abs/1804.06826
5 / 7
SLIDE 6
Global vs. Shared Memory
global memory and L1/L2 cache are the ordinary memory that make a hierarchy
cudaMalloc returns a global memory accesses to global memory are transparently cached into L1/L2 caches
shared memory is an explicitly-managed scratch memory
latency shorter than L1 (esp. on Pascal) you explicitly move between global and shared memory data shared only within a thread block programming interface is covered shortly
6 / 7
SLIDE 7
Latency measurement
the same pointer chasing experiment as we did on CPU
✞
1
for (N times) {
2
p = p->next;
3
} cache line size next pointers N elements (link all elements in a random order)
7 / 7
SLIDE 8
Data size vs. latency
even L1 cache hit takes 30 (Volta) - 100 (Pascal) cycles
100 200 300 400 500 600 700 1024 4096 16384 65536 262144 1.04858 × 106 4.1943 × 106 1.67772 × 107 6.71089 × 107 latency/load (GPU cycles) size of the region (bytes) latency per load in a random list traversal p 8 v 8
8 / 7
SLIDE 9
Shared memory
9 / 7
