Undergraduate Research at the US Coast Guard Academy Dr. Susan Swithenbank SNAME Philadelphia April 20, 2011 Recent Research Scaling Effects of a 100 ft tow tank Stern Flaps on the 378 Cutter Resistance of Bow Bulbs Marine Bio

slide-1
SLIDE 1

Undergraduate Research at the US Coast Guard Academy

  • Dr. Susan Swithenbank

SNAME Philadelphia April 20, 2011

slide-2
SLIDE 2

Recent Research

  • Scaling Effects of a 100 ft tow tank
  • Stern Flaps on the 378’ Cutter
  • Resistance of Bow Bulbs
  • Marine Bio‐Fouling of 110’ CG Cutters
  • Simplified Stability Tests
  • Corrosion
slide-3
SLIDE 3

Tow Tank Scaling Effects

slide-4
SLIDE 4

Stern Flaps on 378’ Cutters

Morgenthau Flap Flap 2 Flap 3 Flap 4 16 kts 7.24% 15.60% ‐7.84% ‐4.87% 17 kts 13.93% 16.58% ‐0.79% 2.15% 18 kts 12.85% 18.69% 3.10% 3.24% Percent Reduction in EHP overBare Hull

slide-5
SLIDE 5

Rendering of hull and bulb in Rhinoceros 4.0

Resistance of Bow Bulbs

Total Cost ($) 427315 Savings per patrol ($) 43627 Patrols per year (180 days) 4 Years to Pay Off 2.4 Bulb 2 (12.3 ft)

Economic Viability:

slide-6
SLIDE 6

Marine Bio‐Fouling of Cutters

slide-7
SLIDE 7

Simplified Stability Testing

  • Vessels must
  • btain at least 10

foot-degrees of Righting Energy.

  • Vessels must have at

least 15 degrees of heel until Downflood.

slide-8
SLIDE 8

Corrosion Background

  • Current corrosion Issues

– Exhaust tube corrosion – Buoy deck crack corrosion – Bilge Corrosion – Cavitation errosion corrosion – Stern Tube Corrosion – Slot weld corrosion

slide-9
SLIDE 9

Research Team

  • 3 current students

– One 1/C Cadet (Senior) – Two 2/C Cadets (Junior)

  • One from USCGA
  • One from USNA
  • Two professors from

chemistry, Dr Joshua Gray and LT Jody Maisano

slide-10
SLIDE 10

Experiments

  • Mass loss versus dimensional measurements of

corrosion

  • Corrosion rates versus salinity of water
  • Different commercially available coatings to

reduce the rate of corrosion

  • Different methods of simulating the bilge

environment (stir bars versus rotating tables)

  • Different inhibiters to reduce corrosion rate
  • Using sacrificial anodes inside the bilge
slide-11
SLIDE 11

Questions?

slide-12
SLIDE 12

Corrosion Acknowledgements

  • Dr Joshua Gray and LT Jody Maisano of USCGA
  • CAPT Paul Roden, CDR John Gage, Larry

Wilkerson, Mark Dust, Gary Peters, and John Kerns of the Coast Guard Surface Force Logistics Center

  • Dr. Glen Frysinger, LCDR Greg Hall, and Dr Todd

Taylor of the USCGA for their support of the project

  • Rich Grassia and NSWCCD Philadelphia for their

help and expertise
