UD8400U

MITSUBISHI UD8400U

Feature highlights

• Technology: 0.67" 1-Chip DMD
• Resolution: 1920x1200
• Brightness: 6500 ANSI Lumens
• Contrast: 2000:1 (Full ON, Full OFF)
• Weight: 35.3 lbs
• Noise: 28dba (low mode)
• Lamp Life: Estimated up to 4000 hours (low mode)
• Dual-Lamp Projection
• Super Resolution Technology
• Continuous 24/7 Operability
• Edge Blending
• Geometric Correction
• Crestron RoomView™, AMX Device Discovery
• Automated Self-Cleaning Reusable Filter design
• SDI Input (3G-SDI/HD-SDI / SD-SDI)
• Advanced Cooling with Heat Pipe Cooling Technology
• Swappable Color Wheel (optional accessory)
• 360° Installation (vertical)
• Optional Lenses (5 options)
• Motorized Lens Shift & Zoom & Focus

Recommended Use

• Auditoriums
• Lecture Halls
• Conference Rooms

UD8400U High Brightness

The high brightness of 6500 lumens ensures that clear & sharp images can be reproduced even in large & bright environments such as auditoriums and conference halls. Powerful images can be projected onto big screens.

UD8400U Continuous Operation

The dual lamp system and sophisticated Lamp-Relay function enable continuous operation with high reliability. Also, dust resistance and cooling performance are greatly improved by the automatic cleaning filter and heat pipe cooling system. The combination of these advanced technologies provide high durability even at continuous operation use for monitoring and other critical applications.

Automatic cleaning filter

Continuous Continuous Operati Operation

• n

2 Lamps + Relay Function 2 Lamps 2 Lamps + + Relay Function Relay Function

Heat pipe cooling system

UD8400U Lamp Relay Function

With the lamp relay function, the lamps can be rested (turned off) alternately during long-term use, ensuring that images are continuously projected. Additionally, in single lamp mode, if the lamp goes out, the automatic back-up function activates the other lamp, thus enabling continuous projection without interruption.

B

Week 1 Week 2 Week 3

1st day 2nd 3rd 4th 5th 6th 7th 8th 9th 10th 11th 12th 13th 14th 15th 16th

Dual

Short-term

• peration mode

(1-lamp operation for 1 hour during each 24-hour period) [Initial setting] Lamp

Single

Lamp selection Lamp relay function

1h 1h 1h 2h 2 days 1 week 1 day 1 week

(1) (2) (3) (4)

Short-term

• peration mode

(Lamps switched every 24 hours) [Initial setting] Long-term

• peration mode

(1-lamp operation for 2 hours during each 1-week period) Long-term

• peration mode

(Lamps switched every week)

A B A B A B A

UD8400U Estimated Lamp Life Rating

6,000 hours

Equipped with a long-life lamp (up to 4,000 hours at low mode), significantly reducing both running costs and replacement frequency.

3000-hour lamp 4000-hour lamp

3,000 hours 4,000 hours

Factory-installed lamp First lamp replacement

Second lamp replacement

Factory-installed lamp First lamp replacement

Lamp Life Comparison

Lower Lower running running costs costs

8,000 hours 6,000 hours

3000-hour lamp 4000-hour lamp

3,000 hours 4,000 hours

Second lamp replacement

First lamp replacement Factory-installed lamp Factory-installed lamp B Factory-installed lamp A

Lamp Life Comparison

Lower Lower running running costs costs

8,000 hours

Plus, when used in single-lamp mode…

UD8400U Super Resolution

The SUPER RESOLUTION technology with a Mitsubishi unique Algorithm, enables you to enjoy super sharp picture quality even when enlarging low-resolution images for big screen

• projection. This technology has already been utilized in Mitsubishi TVs & display monitors,

and the 8000 Series are the first Mitsubishi projectors to employ it.

Estimation of digitally well-scaled data

Enlarged image (original) Low-resolution image Image processed by SUPER RESOLUTION High resolution data that does not exist in the enlarged image is estimated by MitsubishiÊs proprietary image processing algorithm.

Estimate & Correct Enlargement

UD8400U Automatic Cleaning Filter

Utilizing the reliable mechanism from the proven Mitsubishi air-conditioners, our unique automatic cleaning filter automatically prevents dust from building up in the radiator of the heat-pipe cooling unit. Also, the transparent structure provides clear visibility with convenience for periodic maintenance.

Automatic cleaning filter

UD8400U Heat Pipe Cooling System

No power supply required No power supply required No moving parts No moving parts Simple mechanism Simple mechanism Sealed structure Sealed structure Energy-saving Energy-saving Quiet operation Quiet operation Compact design Compact design No concern of liquid-leakage No concern of liquid-leakage

Benefits of Heat pipe Cooling System

When compared with the conventional liquid cooling system, the heat pipe system ensures highly reliable and effective cooling with exceptional energy-savings.

Radiant heat is Radiant heat is drawn from the drawn from the fins by a fan. fins by a fan.

Heat flow Heat pipe Fins Heat flow Heat pipe DMD heat

UD8400U Optional Swappable Color Wheel

Segment Brightness-emphasized color wheel (standard equipment) Color-emphasized color wheel (CW-FC2, optional)

The color wheel can be interchanged to either a brightness-emphasized type (factory standard) or a color-emphasized type (optional) to suit the type of images projected. An ideal option for customers who wish to optimize image quality.

UD8400U Geometric Correction

Keystone Correction

Both vertical and horizontal Keystone correction is available, correcting trapezoidal image distortion for installation flexibility

Projection on a curved surface

Correcting image distortion when projecting on a curved surface greatly expands the creative flexibility for applications such as event venues and digital signage

Cornerstone Correction

Positioning of the 4 image corners is adjustable, enabling projector stacking

UD8400U Edge Blending Technology

Edge blending

When projecting from multiple adjacent projectors, the brightness at the edges between screens can be adjusted to achieve a seamless, multi-image display

Color matching

This function corrects differences in color reproduction between projectors, ensuring uniform colors for a seamless multi-display

Color matching functions Mitsubishi Falcon Series projector Edge blending function

With edge blending Without edge blending

Noticeable “seam” where images

• verlap

UD8400U CRESTRON and AMX Compatibility

LAN

Compatibility with the Network protocols of popular controller manufacturers, CRESTRON & AMX, enables you to control the projectors easily from a PC. Also, HDMI connectivity

• ffers greater system flexibility with HDMI compatible switchers.

Control PC Control box

S c h

• l

y a r d r

• u

n d u p

Room A

Schoolyard roundup

Room B

Schoolyard roundup

Room C

Schoolyard roundup

UD8400U 360-Degree Installation

Installation is possible at any angle, a full 360 degrees, in the perpendicular direction (except when used in high-altitude mode). Images can be projected on the ceiling or floor on demand, greatly expanding creative flexibility.

Installation example

UD8400U Natural Color Matrix

The color wheel can be changed to either a brightness- emphasized type (standard equipment) or a color- emphasized type (optional) to suit the type of images

• projected. An ideal option for customers who wish to
• ptimize image quality.

R (Red) G (Green) B (Blue) Original image

UD8400U Optional Lenses

<Throw Ratio> FR SZ Fixed Std. LZ TZ UZ FR SZ Fixed Std. LZ TZ UZ FR SZ Fixed Std. LZ TZ UZ 4 5 6 7 UD8400U 9 XD8000U XD8100U WD8200U 1 2 3 8

Fixed Rear projection lens OL-XD2000FR Short throw lens OL-XD2000SZ Long throw lens OL-XD2000LZ Telescopic lens OL-XD2000TZ Ultra-telescopic lens OL-XD8000UZ

NEW NEW

Besides the short throw, long throw, telescopic throw, and fixed rear focal point lenses, a newly developed ultra-telescopic lens has been added to the optional lens lineup for much wider coverage of throw distance demand.

4.7 – 9.0

UD8400U Other Features and Functions

• Mechanical shutter
• Direct power off
• Lamp side replacement
• Closed captions
• High-altitude mode (2,000 to 2,700 m)
• OSD menu multi-language compatibility (19 languages)
• Standby power < 0.3W (when network is off)
• Non-painted cabinet
• Motorized Lens-shift & Zoom
• 2-Screen mode (PinP UD8400U)
• Test pattern pre-set

Installation flexibility Convenience Environmental

UD8400U Quiet Operation

Mitsubishi’s unique Sirocco fan technology, provides super quiet operation (28dBA when used in low mode), eliminating annoying noise for a more comfortable conference or lecture environment.

Examples of Noise Levels 20dBA : 30dBA : 40dBA :

28dBA

Rustling leaves, the ticking of a wall clock (from 1 m in front) A whisper, a suburban area very late at night A quiet neighborhood, small birds chirping

UD8400U ID-Compatible Remote Control

ID-compatible remote control

IDs for up to 63 projectors can be programmed. When multiple projectors are installed, each individual projector can be independently controlled by setting the ID’s

Control Projector from Remote Location

Control operations remotely up to 30m from the projector when using the wireless remote controller (must be standing in front of the projector). When using the wired remote controller, projector operation is possible at a distance of up to 100m*. These options give the presenter the ability to move more freely at big venues, such as a large meeting rooms or auditoriums

IDs can be set for up to 63 projectors. *Dependent on cable performance

UD8400U Terminal Cover

Connection cables and terminals are hidden by the terminal cover for a neat and attractive appearance. The white color and center lens design also contribute to a more aesthetic appearance.
