Turning Data from Online Sensors into information Data - Information - Knowledge - Understanding - Wisdom Snow & Flow Monitoring Water Quality Monitoring Sommer GmbH Sommer offers more than 20 years of experience in developing and
Sommer offers more than 20 years of experience in developing and producing high quality measure equipment for hydrology and meteorology in environmental engineering. Sommer is a family owned company with 35 people and located in Koblach/ Austria, close to the Suisse and German border.
2 General Product Presentation, M. Kaufmann 2013
3
Our core competences are: » Engineering and construction of turnkey measurement systems for hydrology, meteorology and geotechnical application. » Distribution of our sensors and devices. » Research and development: data logger,
custom build sensors Main Products are: » Radar Systems » Tracer » Snow Measurement Equipment
General Product Presentation, M. Kaufmann 2013
4
Sommer radar systems for contact free measurement of level, velocity and discharge. RL-15/35 » Contact free level sensor RG-30 » Contact free velocity sensor RQ-30 » Contact free discharge measurement RQ-30 Compact » Contact free discharge measurement with integrated data logger and GPRS/GSM data modem RP-30 » Mobile and contact free radar measurement of surface velocity
General Product Presentation, M. Kaufmann 2013
Contact free radar level sensor » Maintenance free » Measurement range 15 m / 35 m (RL-15/35) » Near blanking zone 0.5 m » High accuracy +/- 2 mm » Compact design » Non sensitive against environmental disturbances » Easy integration into existing systems
5 General Product Presentation, M. Kaufmann 2013
Contact free radar velocity sensor » Maintenance free » Measurement range from +/-0.3 to +/-15m/s » Detection of flow direction » Non-contact and fast measurement » Programmable measurement interval or externally triggered measurement » Non sensitive against environmental disturbances » Easy integration into existing systems
6 General Product Presentation, M. Kaufmann 2013
Contact free radar discharge measurement device for open channels and rivers » Maintenance free » Measurement range from +/-0.3 to +/-15m/s » Detection of flow direction » Measurement in vegetal invasion, back water situation and tide influenced rivers » Recognition of hysteresis effects » Non sensitive against environmental disturbances » Easy integration into existing systems » Optional analog output 4-20 mA
7 General Product Presentation, M. Kaufmann 2013
In addition to the RQ-30 the RQ-30 compact offers following features: » integrated data logger » GSM/GPRS data modem for remote access and read
» integrated battery for independent power supply »
8 General Product Presentation, M. Kaufmann 2013
Mobile and contact free measurement of surface velocity profile of rivers, especially in flood conditions. » Portable mobile measurement system » For use on cable ways, bridge railings or tripods » For flood conditions and high flow velocities » No danger from flotsam and debris » Calculation of discharge with known water level and cross section profile » Easy user interface and handling » Wireless data transmission via Bluetooth » Measurement range from 0.30 to 15 m/s
9 General Product Presentation, M. Kaufmann 2013
10
Mobile discharge measurement fluorescent tracer » Calculation of discharge by measuring the change of fluorescence due to dilution of tracer material » Uranine or Rhodamine tracer, typical insertion 1 g/m³ » Discharge measurement unlimited » Easy and quick mobile discharge measurement » Discharge quantity immediately available » Data read out via Bluetooth with notebook, PDA or smartphone (Windows Mobile) » Online visualisation of results » Simultaneous measurement with up to 4 sensors for increased accuracy and validation of results » Application with conductivity and fluorescence sensors » Independent of the cross section » Optimal for high velocities and turbulent rivers with high discharge
General Product Presentation, M. Kaufmann 2013
General Product Presentation, M. Kaufmann 2013 11
Mobile discharge measurement system with salt tracer » Calculation of discharge by measuring the change of conductivity due to dilution of salt (NaCl) in the river » Salt tracer, typical insertion ~5 kg/m³ » Discharge measurement up to 10 m³/s » Easy and quick mobile discharge measurement » Discharge quantity immediately available » Data read out via Bluetooth with notebook, PDA or smartphone (Windows Mobile) » Online visualisation of results » Simultaneous measurement with up to 4 sensors for increased accuracy and validation of results » Independent of the cross section » Optimal for high velocities and turbulent river
12
USH-8 » Ultrasonic snow depth sensor SSG » Snow scale for measuring the snow water equivalent SMA » Snow melt analyser SPA » Snowpack analysing system
General Product Presentation, M. Kaufmann 2013
» Continuous and non-contact ultrasonic snow depth measurement » Reliable sensor for extreme conditions » Robust sealed ceramic membrane » Correct measurement during snowfall and snow drift » Protective shield against ice and snow hangings » Integrated lightning protection » High measuring accuracy » Integrated temperature compensation » Energy-saving sensor operation » Ideal for solar-powered stations » Simple sensor integration » Analogue and digital interface » Parameterisation via hyper terminal
13 General Product Presentation, M. Kaufmann 2013
The Sommer Snow Scale SSG is a precise device for measuring the Snow Water Equivalent (SWE). » Continuous measurement of Snow-Water-Equivalent (SWE) » Minimisation of ice bridging effects » Optimised thermal flow between sensor and ground for high accuracy during the melting process » Robust and long life aluminum construction » Measure up to 200 / 500 / 1.000 / 2000 mm of SWE » No antifreeze liquid required » Simple system integration » Only little preparation of the measuring site required
14 General Product Presentation, M. Kaufmann 2013
Snowmelt Analyser appropriate for flood prediction and water management. » Registration of the snow parameters:
» Snow water equivalent (SWE) » Contents of liquid water and ice
» Prediction of snowmelt from the snow pack » Early recognition of increase of liquid content in snow pack » Simple and easy installation and set up » No calibration required » Low power consumption
15 General Product Presentation, M. Kaufmann 2013
Snow Pack Analysing system is a unique device for automatic and continuous measurement of all relevant snow parameters. » Registration of the snow parameters:
» Snow depth » Snow density » Snow water equivalent (SWE) » Content of liquid water and ice
» Automatic and continuous measurement » Energy-saving sensor operation
» „Standby“ between the measuring phases » Optimised for solar-panel
» No measurement errors caused by ice layers » Possible installation at hillsides » Information about
» the whole snowpack » a specific snow depth level
16 General Product Presentation, M. Kaufmann 2013
Designer and manufacturer of a full range sensors and specialized software for water quality measurement based in Vienna, Austria, since 1999 Subsidiaries in the USA, China and France Serving the whole water industry from drinking water over environmental monitoring to industrial waste waters Established online Spectrometry as an accepted method for many parameters in many countries By far world leader in online UV spectrometry with > 4.000 Systems sold World leader in Water Protection Systems and EDS software
s::can Messtecknik GmbH Established 1999 University Spin-Off Based in Vienna, Austria Family-owned company 3 subsidiaries in USA, China and France Worldwide distribution network Aaxis and Techspan in India Consistent focus on R & D and developing solutions for emerging markets
University of Natural Resources and Life Sciences, Vienna
Intelligent All s::can sensors are intelligent, they are digital and have the controller, the brain, built in. They check their health every second and can communicate with the operator. Optical If possible, we always use optical methods, since they are just better, more reliable, simpler and more accurate. If no optical method is suitable, we choose the next best alternative. Online We make nothing for laboratories, nothing that consumes reagents, nothing with moving parts. s::can is the only real „on-line“ company in the industry that offer an almost complete range of sensors and parameters, and nothing else.
The measurements make use of the specific absorption signals caused by (groups of) substances
Latest generation of s::can operator terminal High-performance, power efficient industrial PC based on newest Intel Atom technology Highly intuitive use because of wide screen color graphical display (7”) and touch screen Extended input options (e.g. also SDI12 interface) for almost any sensor, analyzer and other analogue or digital I/Os Worldwide network connectivity thanks to quad-band WCDMA and dual-band network connection technology Easy data transfer via automatic file transfer utilizing FTP
Real Time Continuous Water Quality Monitoring Stations at the Ganga Basin
Remote water monitoring station in Allahabad (monitored parameters: TSS, COD, BOD, EC, pH, Temp, NH4, DO, Chloride, NO3-N
The remote stations are field operational and tolerant to extreme environmental conditions in India, in high or low temperatures, high humidity coastal conditions and high temperature desert conditions.
Real Time Continuous Water Quality Monitoring Stations at the Ganga Basin
Monitoring stations in Kannauj, Wazirabad and Patna
Measurement results from Okhla: Continuous results every 10 minutes, automatic file transfer of: NTU, COD, BOD, NO3, DO, pH, NH4-N, EC, Cl-, Temp
Real Time Continuous Water Quality Monitoring Stations at the Ganga Basin
systems for large monitoring applications (rivers, lakes, etc) interconnection of multiple s::can monitoring systems
automatic data transfer via GPRS/UMTS automatized data handling on FTP server display and evaluation of spectral data visualization and control of data GIS-system delta spectrometry
central database
