Turbo HD SEASONAL PROMOTION International Product and Solution Center CONTENTS Product Family Part.01 Spotlight Products Part.02 Upgrade Information Part.03 Turbo HD Camera Product Family Turbo HD DVR Product System--Camera

slide-1
SLIDE 1

Turbo HD SEASONAL

PROMOTION

International Product and Solution Center

slide-2
SLIDE 2

CONTENTS

Part.01

Product Family

Part.02 Part.03

Spotlight Products

Upgrade Information

slide-3
SLIDE 3

Product Family

 Turbo HD Camera  Turbo HD DVR

slide-4
SLIDE 4

720p 1080p 5 MP 4K

Value Pro Ultra IoT

C0T

D0T H0T U1T U7T U8T D0T-PIRL(O) H0T-PIRL(O) D3T DFT H8T D8T D9T

Special

C8T-PH D8T-PH H1T-FITS C5T C2T

D8T-PIRL(O) HFT Balun models Audio models DFT-PIRXOF D0T-PIRXF

Product System--Camera

Turbo HD X

slide-5
SLIDE 5

1080p lite & 720p 1080p 5 MP 4K

Value Pro Ultra

71HQ-K 71HU-K 72HU-K 73HU-K 72HQ-K 73HQ-K 72HG-F 72HT-K 73HT-K 81HQ-K 81HT-K 90HT-K 81HU-K 90HU-K 72HG-K iDS-72HU-K iDS-72HQ-K iDS-73HU-K iDS-90HU-K 7104HG-F

Special

iDS-72HQ-M iDS-72HU-M 72HG-F/N 7108/16HG-F/N

ATM DVR

Education sharing system

71 - 1 HDD 72 - 1/2 HDD 73 - 4 HDD 81/90 - 8 HDD

Product System--DVR

2nd Generation AcuSense Balun models Audio models

slide-6
SLIDE 6

Spotlight Products

 Turbo HD X Solution  AcuSense DVRs  ColorVu Cameras  New EXIR D0T Cameras  SSD DVR  Coaxial Audio Series

slide-7
SLIDE 7

Rethink Security, Making Your Everyday Life Safer!

slide-8
SLIDE 8

Rethink Security, Making Your Everyday Life Safer!

Warning the intruders

Active light & sound alarms

CAMERA DVR HIK-CONNECT

Alerting Security

Real-time notification

Remote Alarm

Real-time remote monitoring and management

slide-9
SLIDE 9

Sample available Smart motion detection

VCA

✘ All moving targets trigger alarms.

200+

 Not influenced by shaking leaves, wind or light.

PIR + MD

200+

✘ Targets whose temperature is similar with human may trigger alarms.

✘

100+ 100+

✔

Sample available  Human/vehicle targets  Other target types won’t trigger alarms.

AcuSense

✔

1

✘

200+

Deep-learning algorithm

How to get the accurate alarm?

slide-10
SLIDE 10

Recommended Alarm Camera

5 MP

H0T-PIRL H0T-PIRLO D8T-PIRL

1080p

D0T-PIRL D8T-PIRLO D0T-PIRLO D0T-PIRXF DFT-PIRXOF

PIR detection Strobe light alarm PIR detection Strobe light alarm Alarm output PIR detection

Siren alarm

PIR detection

Siren alarm Alarm output

DVR

AcuSense DVR

Accurate alarm Focus on Human & Vehicle

(AI analysis channels)

K series DVR

Sensitive to living targets PIR & motion detection

(PIR channels)

Sensitive to living targets PIR & motion detection

(PIR channels)

slide-11
SLIDE 11

DS-2CE12DFT-PIRXOF DS-2CE72DFT-PIRXOF DS-2CE12D0T-PIRXF DS-2CE72D0T-PIRXF

  • HD 1080p
  • 2.8/3.6/6 mm
  • ColorVu
  • PIR detection
  • Siren alarm (light & sound)
  • Alarm output

PIR Siren Camera

  • HD 1080p
  • 2.8/3.6/6 mm
  • PIR detection
  • Siren alarm (light & sound)

Product Family

ColorVu PIR Siren Camera

slide-12
SLIDE 12

Product Family

2nd Generation AcuSense DVR iDS-7204/08/16HQHI-M1/S iDS-7208/16HQHI-M2/S iDS-7204/08HUHI-M1/S iDS-7204/08HUHI-M2/S

Accurate alarms with human/vehicle Quick target search Face detection Alarm types of camera flexible Arming/disarming setting by App

V4.21.000 - New Version for ALL K series DVRs

slide-13
SLIDE 13

2nd Generation DVR

iDS-7204HQHI-M1/FA iDS-7208HQHI-M1/FA iDS-7216HQHI-M1/FA Face Library Customizing Facial Recognition (1-ch)

  • Up to 80 MB (about 2000 pictures)
  • Maximum 16 face libraries

Release

  • “The targets” recognition
  • “Non-targets” recognition
  • Searching by picture
  • Supports receiving facial recognition alarms
  • Supports uploading/checking/deleting face

library

Hik-Connect linkage iDS-72xxHUHI-Mx/FA

Release

slide-14
SLIDE 14

HFT Cameras

DS-2CE12HFT-F

Bullet: WL 40 m

0.0005 lux Friendly lighting 130 dB WDR IP67, 4 in 1 2.8/3.6/6 mm

5 MP

DFT Cameras

DS-2CE72HFT-F

Turret: WL 20 m

DS-2CE10HFT-F

Mini Bullet: WL 20 m

2 MP

DS-2CE10DFT-F DS-2CE10DFT-PF

Mini Bullet: WL 20 m

DS-2CE72DFT-F

Turret: WL 20 m

DS-2CE12DFT-F

Bullet: WL 40 m

New Design: Universal Joint Bracket

slide-15
SLIDE 15

0.0005 lux Friendly lighting 130 dB WDR IP67, 4 in 1 2.8/3.6/6 mm

(2.8 mm in September)

slide-16
SLIDE 16

DFT-C Cameras

DS-2CE72DFT-FC

Turret: WL 20 m

DS-2CE10DFT-FC

Mini Bullet: WL 20 m

DS-2CE10DFT-PFC DS-2CE12DFT-FC

Bullet: WL 40 m

  • 0.0008 lux
  • 120 dB WDR
  • 2 MP
  • Friendly lighting
  • 2.8/3.6/6 mm
  • IP67, 4 in 1

24/7 colorful imaging

slide-17
SLIDE 17

DFT-C Performance

DFT DFT-C DFT DFT-C

Outdoor

iPhone 8

Indoor

slide-18
SLIDE 18

Conventional IR Camera

A RED car with clear plate; A man wearing GREEN coat You can find the targets but without clear details

ColorVu camera has high quality night images which offers more colorful and clearer target details.

Night Performance

Note: testing with supplemental light OFF Note: testing with IR light ON

slide-19
SLIDE 19

Night Performance

Raining Snowing

ColorVu will not suffer from reflection in bad weather so that you can get clear night vision.

slide-20
SLIDE 20

For MOST general scenarios

DFT

1239 1230

Resolution

2 MP 2 MP 2 MP

Aperture

F1.0

F1.6 F1.6

Min Illumination

0.0005 lux 0.005 lux 0.005 lux

Supplement al Light

Warm Light White Light IR Light

WDR

130 dB DWDR DWDR F1.6 1239

Not every camera with white supplementary lights is FULL TIME COLOR camera!

Necessary to open white light!

No need for white light!

Note: Testing with light OFF

F1.0,

ColorVu

What makes a full-time color camera?

Starlight Only different from supplementary light

slide-21
SLIDE 21

DWDR 2 MP 0.01 lux EXIR 2.0 4 in 1

DS-2CE16D0T-ITF DS-2CE16D0T-ITPF IR 30 m

Released

IR 25 m DS-2CE76D0T-ITMF DS-2CE76D0T-ITPF IR 30 m IR 20 m

Release

New EXIR D0T Cameras

Universal joint bracket 3-axis adjustment

2D DNR

slide-22
SLIDE 22

SSD DVR

DS-7204HQHI-K1/SSD

Comes with SSD SSD, capacity 512GB or 1TB

  • Compact design
  • Noise free (without fans)
  • Shock resistance
  • Low-power consumption

2019.9 Release

  • H.265 Pro+
  • 1080p / 4 MP lite @ 15 fps
  • GUI 4.0
slide-23
SLIDE 23

Coaxial Audio Series

Before New

Outside pick up Audio adaptor Audio cabling Covert and tidy Saving manpower Video Part: Camera & Accessories

Audio Part：Pick up & Adaptor & Cable

Camera & Accessories

Video & Audio part

slide-24
SLIDE 24

Coaxial Audio Series

DS-2CE16D0T-ITPFS DS-2CE76D0T-ITMFS DS-2CE78D0T-IT3FS DS-2CE76D0T-ITPFS DS-2CE16D0T-ITFS

1080p

DS-7104/08/16HQHI-K1 (S) DS-7204/08/16HQHI-K1 (S) DS-7208/16/24/32HQHI-K2 (S) DS-2CE16H0T-ITPFS DS-2CE76H0T-ITMFS DS-2CE78H0T-IT3FS DS-2CE76H0T-ITPFS DS-2CE16H0T-ITFS

5 MP

DS-7104/08HUHI-K1 (S) DS-7204/08HUHI-K1 (S) DS-7204/08/16HUHI-K2 (S)

Product Showcase

DS-7204HTHI-K1 (S) DS-7204/08HTHI-K2 (S)

D0T-S H0T-S HQ-K HU-K HT-K

Note:24/32-ch will be released 2020

Built-in mic Up to 300 m transmission Broadcast quality

slide-25
SLIDE 25

Coaxial Audio Series

Product Showcase

slide-26
SLIDE 26

Upgrade Information

 D0T/H0T Series  PIR Cameras  Coaxial Cable

slide-27
SLIDE 27

25 m

20 m

D0T/H0T Series

Universal Joint Bracket  Integration of Sun Shield

Image Performance

 Saving Storage Costs  Saving Transportation Costs

Universal joint bracket 3-axis adjustment

Easy to install and adjust

 Universal Joint Bracket

More exquisite appearance

Structural Upgrade Compact Package

New Old

Available models: D0T/H0T fixed bullets Available models: D0T/H0T IT1/3/5 bullets

Less cameras More cameras

New A single product package A bulk package Old

 Enhanced Infrared Capability

IR distance extended by 5 ~10 m

30 m

20 m

D0T-IR(F) D0T-IRM(F) D0T-IT1(F) H0T-ITPF H0T-ITF H0T-IT1F H0T-ITMF

Checklist of models with IR distance upgrades

slide-28
SLIDE 28

New Design New Function Increased light brightness, enhanced warning effect.

Supplement Light Mode

The white light can always be on.

Upgrade in PIR Cameras

*Available models: 71-PIRL turret and 11-PIRL bullet.

slide-29
SLIDE 29

D0T/H0T Series

Checklist of models with IR distance upgrades

Old models IR distance (old) New models - (C) version IR distance (new)

D0T Series

DS-2CE16D0T-IRF 20 m DS-2CE16D0T-IRF(C) 25 m DS-2CE16D0T-IT1F 20 m DS-2CE16D0T-IT1F(C) 30 m DS-2CE56D0T-IRMF 20 m DS-2CE56D0T-IRMF(C) 25 m DS-2CE56D0T-IT1F 20 m DS-2CE78D0T-IT1F(C) 30 m

H0T Series

DS-2CE16H0T-ITPF 20 m DS-2CE16H0T-ITPF(C) 25 m DS-2CE16H0T-ITF 20 m DS-2CE16H0T-ITF(C) 30 m DS-2CE16H0T-IT1F 20 m DS-2CE16H0T-IT1F(C) 30 m DS-2CE56H0T-ITMF 20 m DS-2CE76H0T-ITMF(C) 30 m DS-2CE56H0T-IT1F 20 m DS-2CE78H0T-IT1F(C) 30 m

Return

slide-30
SLIDE 30

2 4 5 3 3 5 Monitoring center

  • Stable video recording
  • Accurate & real-time alarm
  • Easy-to-use system

Shop owner

Hik-Connect

  • Receiving real-time alarm
  • Remote monitoring and control

6 1

Retail Protection Demo

1 Entrance

  • 24/7 Monitoring;
  • Working as guardians especially when closed.
  • Powerful alarms warn off intruders.

Warehouse 4 3 Goods area

  • 24/7 Monitoring;
  • Clear images, good night vision

HD camera Active alarm camera DVR

6

2 Cashier

slide-31
SLIDE 31

Product Introduction

Coaxial cable component

Conductor Dielectric insulator Aluminum Foil Braiding Plastic sheath

Power Cable：

 Conductor ：0.38mm *7 copper wires  Voltage : MAX AC/DC 300V  Current : MAX 7A

1 2

Coaxial Cable with power cable

2 1

Two types:

Coaxial Cable ( No power cable)

slide-32
SLIDE 32

Product Highlights

Conductor

Conductor

HIKVISION: Conductor is oxygen free copper(OFC), higher purity than bare copper , whose diameter exactly meet the standard 0.81mm RG59. (Bare copper market price around 8200USD per ton) Small Manufacturers: Conductor is generally CCA material, whose diameter maybe only 0.4mm or smaller. (Aluminum market price around 2200USD per ton, 26.8% of bare copper)

slide-33
SLIDE 33

Product Highlights

Braiding Density & Aluminum Foil

HIKVISION Braiding density reaches to 95% Small manufacturers braiding density reaches to 60- 75%

Braiding Density & Aluminum Foil

Braiding density of HIKVISION coaxial cable reaches to 95% but small manufacturers may only reach to 60-75%. Aluminum foil provides HIKVISION cable high shielding performance but small manufacturers are often without aluminum foil. HIKVISION with Aluminum Foil Small manufacturers without Aluminum Foil

slide-34
SLIDE 34

Product Highlights

Flame Resistance

HIKVISION Coaxial Cable Small Manufacturer Coaxial Cable

Flame Resistance

Up to VW-1 Rating(Part of UL), globally applied for fire-prevention standard. Essential element to value cable safety.

slide-35
SLIDE 35

Product Highlights

High Anti-interference High Anti-interference

Centre ntre Condu nduct ctor

  • r

Braidi aiding Dens nsity ity Alum uminum num Foil il Oxygen Free Copper (OFC) Reaches to 95% Copper-clad Aluminum wire (CCA) W/ Aluminum Foil CCA or Other Inferior Materials Reaches to 60-75% W/O Aluminum Foil

HIKVISION Small Manufacturer

slide-36
SLIDE 36

Product Highlights

Power cable Power Cable

HIKVISION: HIKVISION power cable always use OFC material. Small manufacturer: Power cable may use CCA material with higher resistance, leading to its instability and fire risk.

slide-37
SLIDE 37

Product Highlights

Product Models Product Models

DS-1LC1SCA2C-200B RG59 Coaxial Cable with power cable DS-1LC1SCA-200B RG59 Coaxial Cable

HIKVISION

slide-38
SLIDE 38

THANKS
