SLIDE 1

Tree Improvement and cuttings production of Eucalyptus globulus at Albany Forestry Research Centre

Nigel England

Oji Paper Co.

SLIDE 2

Time points

1992 APFL planting began
2001 Start of Phenotypic tree selection
2003 Albany Forestry Research Centre
pened
2004 First field trial planted (2ha)
2005 Trials and 10ha of cuttings planted
2006 Trials and 80ha of cuttings planted
2007 Planting of 100ha projected

Oji Paper Co.

SLIDE 3

Phenotypic Tree Selection

In plantations of 6-10

yrs

Immediate neighbours

must be alive

Straight without forks
Measure surrounding

25 trees

DBH > plot mean+1.5sd

Oji Paper Co.

SLIDE 4

Phenotypic Tree Selection

X X X Dead X X X X Dead X X X X Dead X

Candidate Tree

X X X X X X Dead X X X Dead X X X

Example of typical phenotypic tree selection plot Oji Paper Co.

SLIDE 5

Wood sampling

Whole tree sample based on

discs at 10, 30, 50, 70, and 90% of ht to 5cm DOB

Wood tested for:

Basic density Pulp Yield Alkali consumption Fibre length

Cores also taken at BH
NIR analysis (with ENSIS)

SLIDE 6

Propagation by cuttings from coppice

Coppice in field Cuttings from coppice after 8 weeks (4 clones chosen at random)

SLIDE 7

Population distribution of root strike

Total of 321 clones

Total sample size of 321

10 20 30 40 50 60 1-20 21-40 41-60 61-80 81-100

Rooting % group

% of clones Based on 343 clones Tested over 4 seasons

SLIDE 8

Root strike from coppice and nursery grown stock-plants

10 20 30 40 50 60 70 80 90 10 20 30 40 50 60 70 80 90

Rooting % from coppice Rooting % from nursery stockplants

R sq= 0.54

SLIDE 9

Mother plant systems

Outside Potted stock-plants Continuous Flow Hydroponics And Flood and Drain Hydroponics Oji Paper Co.

SLIDE 10

Root strike from different systems

10 20 30 40 50 60 70 80 90 Potted Stock Cont Flow Hydros F&D Hydros Root % (8 weeks) December Jan Mean

Data from 4 clones in Dec 2006, 2 clones in Jan 07 , Total 37 000 cuttings

SLIDE 11

Photos of cuttings

Oji Paper Co. Production cuttings after 5 weeks

SLIDE 12

Relationships between Rooting and Wood properties

Rooting % v Wood Basic Density

450 500 550 600 650 700 10 20 30 40 50 60 70 80 90 100

Rooting ability (%) B a s ic D e n s ity (k g m -3 )

Rooting v Screened Pulp Yield

45 47 49 51 53 55 57 59 20 40 60 80 100

Rooting (%) SPY at K appa 18 (%)

Rooting v Kajanni Fibre Length

0.65 0.7 0.75 0.8 0.85 0.9 0.95 1 20 40 60 80 100

Rooting (%) K F L (m m )

SLIDE 13

Clone trials

STP, 5TP, and 72TP designs

depending on plants available

60 clones in trials of at least 8

plants

Range of sites tested within

APFL planting limit of 120km of Albany

Improved seedling controls in

all trials

Joint trials with other

companies

Oji Paper Co.

SLIDE 14

Clone trial results

0.00 1.00 2.00 3.00 4.00 5.00 6.00 5 10 15 20 25 Time from planting (months) Height (m) T12 T15 T17 T33 Unimp seed Imp Seed 1 Imp Seed 2

Data: 4 x 72 tree plots on 1 site

Oji Paper Co.

SLIDE 15

Developing a breeding population

All clones are being

planted in a Breeding Arboretum and being

ut-crossed
Progeny trials will be

planted with this seed

Combination crosses

are also being made of good growing and good rooting clones

Germ-plasm exchange

with other companies

SLIDE 16

Acknowledgements ‘Tom’ Tsurumi Shin Sukeno Karen Seward Keiji Tomita Allie Muneri Troy Brown

Oji Paper Co.
