Cours 10 : Neural networks (1) Tim Van de Cruys & Philippe Muller 2016—2017

Introduction

Machine learning for NLP

• Standard approach: linear model trained over high-dimensional

but very sparse feature vectors

• Recently: non-linear neural networks over dense input vectors

Neural Network Architectures

Feed-forward neural networks

• Best known, standard neural network approach
• Fully connected layers
• Can be used as drop-in replacement for typical NLP classifiers

Feature representation

Dense vs. one hot

• One hot: each feature is its own dimension
• Dimensionality vector is same as number of features
• Each feature is completely independent from one another
• Dense: each feature is a d-dimensional vector
• Dimensionality is d
• Similar features have similar vectors

Feature representation

Feature combinations

• Traditional NLP: specify interactions of features
• E.g. features like ’word is jump, tag is V and previous word is

they’

• Non-linear network: only specify core features
• Non-linearity of network takes care of finding indicative feature

combinations

Feature representation

Why dense?

• Discrete approach often works surprisingly well for NLP tasks
• n-gram language models
• POS-tagging, parsing
• sentiment analysis
• Still, a very poor representation of word meaning
• No notion of similarity
• Limited inference

Feature representation

Why dense?

• Discrete approach often works surprisingly well for NLP tasks
• n-gram language models
• POS-tagging, parsing
• sentiment analysis
• Still, a very poor representation of word meaning
• No notion of similarity
• Limited inference

[ 0 0 0 0 0 0 0 0 0 0 0 0 0 0 01 0 0 0 0 ]

Feature representation

Why dense?

• Discrete approach often works surprisingly well for NLP tasks
• n-gram language models
• POS-tagging, parsing
• sentiment analysis
• Still, a very poor representation of word meaning
• No notion of similarity
• Limited inference

[ 0 0 0 0 0 0 0 0 0 0 0 0 0 0 01 0 0 0 0 ] [ 0 0 0 0 0 01 0 0 0 0 0 0 0 0 0 0 0 0 0 ]

Feature representation

Why dense?

Feature representation

Why dense?

Feature representation

Why dense?

Feed-forward

Architecture

Multi-layer perceptron with 2 hidden layers NNMLP2(x) = y (1) h1 = g(xW1 + b1) (2) h2 = g(h1W2 + b2) (3) y = h2W3 (4) x: vector of size din = 3 y: vector of size dout = 2 h1, h2: vectors of size dhidden = 4

Feed-forward

Architecture

Multi-layer perceptron with 2 hidden layers NNMLP2(x) = y (1) h1 = g(xW1 + b1) (2) h2 = g(h1W2 + b2) (3) y = h2W3 (4) W1, W2, W3: matrices of size [3 × 4], [4 × 4], [4 × 2] b1, b2: ’bias’ vectors of size dhidden = 4 g(·): non-linear activation function (elementwise)

Feed-forward

Architecture

Multi-layer perceptron with 2 hidden layers NNMLP2(x) = y (1) h1 = g(xW1 + b1) (2) h2 = g(h1W2 + b2) (3) y = h2W3 (4) W1, W2, W3, b1, b2 = parameters of the network (θ) Use of multiple hidden layers: deep learning

Feed-forward

Non-linear activation functions

Sigmoid (logistic) function σ(x) =

1 1+e−x

0.5 1 −6 −4 −2 2 4 6

Feed-forward

Non-linear activation functions

Hyperbolic tangent (tanh) function tanh(x) = e2x−1

e2x+1

Feed-forward

Non-linear activation functions

Rectified linear unit (ReLU) ReLU(x) = max(0, x)

Feed-forward

Output transformation function

Softmax function x = x1 . . . xk softmax(xi) =

exi k

j=1 exj

Feed-forward

Input vector

• Embedding lookup from embedding matrix
• concatenate or sum embeddings

Feed-forward

Loss functions

• L(ˆ

y, y) - the loss of predicting ˆ y when true output is y

• Set parameters θ in order to minimize loss across different

training examples

• Compute gradient of parameters with regard to loss function

to find minimum, take steps in right direction

Feed-forward

Loss functions

• Hinge loss (binary and multi-class)
• classify correct class over incorrect class(es) with margin of at

least 1

• Categorical cross-entropy loss (negative log-likelihood)
• Measure difference between true class distribution y and

predicted class distribution ˆ y

• Use with softmax output
• Ranking loss
• In unsupervised setting: rank attested examples over

unattested, corrupted ones with margin of at least 1

Training

Stochastic gradient descent

• Goal: minimize total loss n

i=1 L(f(xi; θ), yi)

• Estimating gradient over entire training set before taking step is

computationally heavy

• Compute gradient for small batch of samples from training set

→ estimate of gradient: stochastic

• Learning rate λ: size of step in right direction
• Improvements: momentum, adaptive learning rate

Training

Stochastic gradient descent

• Size mini-batch: balance between better estimate and faster

convergence

• Gradients over different parameters (weight matrices, bias

terms, embeddings, ...) efficiently calculated using backpropagation algorithm

• No need to carry out derivations yourself: automatic tools for

gradient computation using computational graphs

Training

Initialization

• Parameters of network are initialized randomly
• Magnitude of random samples has effect on training success
• effective initialization schemes exist

Training

Misc

• Shuffling: shuffle training set with each epoch
• Learning rate: balance between proper convergence and fast

convergence

• Minibatch: balance speed/proper estimate; efficient using GPU

Training

Regularization

• Neural networks have many parameters: risk of overfitting
• Solution: regularization
• L2: extend loss function with squared penalty on parameters,

i.e. λ

2 ||θ||2

• Dropout: Randomly dropping (setting to zero) half of the

neurons in the network for each training sample

Word embeddings

• Each word i is represented by a small, dense vector vi ∈ Rd
• d is typically in the range 50–1000
• Matrix of size V (vocabulary size) × d (embedding size)
• words are ‘embedded’ in a real-valued, low-dimensional space
• Similar words have similar embeddings

Word embeddings

• Each word i is represented by a small, dense vector vi ∈ Rd
• d is typically in the range 50–1000
• Matrix of size V (vocabulary size) × d (embedding size)
• words are ‘embedded’ in a real-valued, low-dimensional space
• Similar words have similar embeddings

d1 d2 d3 . . . apple –2.34 –1.01 0.33 pear –2.28 –1.20 0.11 car –0.20 1.02 2.44 . . .

Word embeddings

• Each word i is represented by a small, dense vector vi ∈ Rd
• d is typically in the range 50–1000
• Matrix of size V (vocabulary size) × d (embedding size)
• words are ‘embedded’ in a real-valued, low-dimensional space
• Similar words have similar embeddings

Neural word embeddings

• Word embeddings have been around for quite some time
• The term ‘embedding’ was coined within the neural network

community, along with new methods to learn them

• Idea: Let’s allocate a number of parameters for each word and

allow the neural network to automatically learn what the useful values should be

• Prediction-based: learn to predict the next word

Embeddings through language modeling

• Predict the next word in a

sequence, based on the previous word

• One non-linear hidden layer,
• ne softmax layer for

classification

• Choose parameters that
• ptimize probability of

correct word

Embeddings through language modeling

• Predict the next word in a

sequence, based on the previous word

• One non-linear hidden layer,
• ne softmax layer for

classification

• Choose parameters that
• ptimize probability of

correct word

Embeddings through error detection

• Take a correct sentence and

create a corrupted counterpart

• Train the network to assign a

higher score to the correct version of each sentence

Embeddings through error detection

• Take a correct sentence and

create a corrupted counterpart

• Train the network to assign a

higher score to the correct version of each sentence

Word2vec

• Neural network approaches work well, but large number of

parameters makes them computationally heavy

• Popular, light-weight approach with less parameters:

word2vec

• No hidden layer, only softmax classifier
• Two different models
• Continuous bag of words (CBOW): predict current word based
• n surrounding words
• Skip-gram: predict surrounding words based on context words

CBOW

• Current word wt is predicted

from context words

• Prediction is made from the

sum of context embeddings

Skip-gram

• Each context word is

predicted from current word

• Parameters for each

softmax classifier are shared

Negative sampling

• Computation of full

softmax classifier is still rather expensive

• Only compute score for

correct context, and a number of wrong contexts

• Maximize correct

contexts and minimize wrong ones

Word similarity

france j´ esus rouge peinture grande-bretagne christ jaune sculpture belgique j´ esus-christ bleu gravure espagne mo¨ ıse vert dessin angleterre dieu blanc photographie pologne proph` ete noir peintures bretagne r´ esurrection bleue toile su` ede mahomet gris c´ eramique italie abraham verte po´ esie roumanie saints blanche peintre tunisie anges noire art

Word similarity

Word similarity

Word similarity

Word similarity

Word similarity

Computing analogies

• Questions in the form:

a is to b as c is to d

• The system is given a, b, and c; it needs to compute d. For

example: apple is to apples as car is to ? man is to woman as king is to ?

Computing analogies

• task: a is to b as c is to d
• idea: direction of the

relation should remain the same a − b ≈ c − d man − woman ≈ king − queen queen ≈ king − man + woman dw = arg max

d′

w∈V

cos(d′, c − a + b)

Computing analogies

Computing analogies

Computing analogies

Computing analogies

Computing analogies

Computing analogies

Relationship Example 1 Example 2 Example 3 France - Paris Italy: Rome Japan: Tokyo Florida: Tallahassee big - bigger small: larger cold: colder quick: quicker Sarkozy - France Berlusconi: Italy Merkel: Germany Koizumi: Japan copper - Cu zinc: Zn gold: Au uranium: plutonium Japan - sushi Germany: bratwurst France: tapas USA: pizza

Computing analogies

a is to b as c is to d homme roi : femme reine autriche vienne : allemagne berlin ´ ecrivain livre : po` ete po` eme france nicolas sarkozy : ´ etats- unis bush droite ump : gauche ps droite front national : gauche pcf

Prediction-based vs. count-based

• Count-based: extract co-occurrence frequencies from corpus
• Prediction-based: induce parameters based on prediction of

correct word

• Initially seen as two different methods, where prediction-based

approach works better

• Later, emerging evidence and proof that they are actually

equivalent or quite similar

Word Embeddings

unsupervised pre-training: parameters

• Training objective
• Choice of contexts (bag of words, syntax, parallel corpus)
• Window size (small, sentence, paragraph), dynamic, ...
• Directed
• Lemmatization, normalization, stop words, ...
• Character-based, sub-word models

Word embeddings in practice

• Word embeddings are often used for pretraining
• Unsupervised: only requires plain text, so can be trained on a

lot of data

• Fast algorithms available
• It helps a model start from an informed position
• Model is initialized with pretrained word embeddings, and then

finetuned depending on task

Word embeddings in practice

Beyond words

• Embeddings are not restricted to words
• Can equally be computed for sentences, paragraphs,

documents

• Different methods
• word2vec-alike method (paragraph vector)
• Convolutional neural network
• Recurrent neural network (sequence-to-sequence learning)
• Current research trend in NLP with applications in machine

translation, paraphrase detection, etc.

Neural Network Architectures

Convolutional neural networks

• Type of feedforward neural network
• Certain layers are not fully connected (convolutional layers,

pooling layers)

• local cues appear in different places in input (cfr. vision)

Neural Network Architectures

Recurrent (+ recursive) neural networks

• Handle structured data of arbitrary sizes
• Recurrent networks for sequences
• Recursive networks for trees

Convolutional layers

Introduction

How to represent variable number of features, e.g. words in a sentence, document?

• Continuous Bag of Words (CBOW): sum embedding vectors of

corresponding features

• no ordering info (”not good quite bad” = ”not bad quite good”)
• Convolutional layer
• ’Sliding window’ approach that takes local structure into account
• Combine individual windows to create vector of fixed size

Feature representation

Variable number of features

• Feed-forward network assume fixed dimensional input
• How to represent variable number of features, e.g. words in a

sentence, document?

• Continuous Bag of Words (CBOW): sum embedding vectors of

corresponding features

Convolutional layers

Basic convolution + pooling

• Goal: identify indicative local features (n-grams) in large

structure, combine them into fixed size vector

• Convolution: apply filter to each window (linear transformation

+ non-linear activation)

• Pooling: combine by taking maximum

Convolutional layers

Narrow vs. wide convolution

• Whether or not to include padding elements to beginning and

end

• E.g. ”the quick brown fox”, convolution of size 2
• Narrow: [the quick], [quick brown], [brown fox]
• Wide: [ the], [the quick], [quick brown], [brown fox], [fox ]

Convolutional layers

Variations

• Dynamic: divide sentence/document in different regions, do

pooling over each region

• Hierarchical: succession of convolution and pooling layers
• K-max pooling: Keep top-k values when pooling

Recurrent neural network

Introduction

• CBOW: no ordering, no structure
• CNN: improvement, but mostly local patterns
• RNN: represent arbitrarily sized structured input as fixed-size

vectors, paying attention to structured properties

Recurrent neural network

Model

• x1: input layer (current word)
• a1: hidden layer of current timestep
• a0: hidden layer of previous timestep
• U, W and V: weights matrices
• f(·): element-wise activation function (sigmoid)
• g(·): softmax function to ensure probability distribution

a1 = f(Ux1 + Wa0) (5) y1 = g(Va1) (6)

Recurrent neural network

Graphical representation

Recurrent neural network

Training

• Consider recurrent neural network as very deep neural network

with shared parameters across computation

• Backpropagation through time
• What kind of supervision?
• Acceptor: based on final state
• Transducer: an output for each input (e.g. language modeling)
• Encoder-decoder: one RNN to encode sequence into vector

representation, another RNN to decode into sequence (e.g. machine translation)

Recurrent neural network

Training: graphical representation

Recurrent neural network

Multi-layer RNN

• multiple layers of RNNs
• input of next layer is output of RNN layer below it
• Empirically shown to work better

Recurrent neural network

Bi-directional RNN

• Input sequence both forward and backward to different RNNs
• Representation is concatenation of forward and backward state

(A & A’)

• Represent both history and future

Concrete RNN architectures

Simple RNN

Concrete RNN architectures

LSTM

• Long short term memory networks
• In practice, simple RNNs only able to remember narrow context

(vanishing gradient)

• LSTM: complex architecture able to capture long-term

dependencies

Concrete RNN architectures

LSTM

Concrete RNN architectures

LSTM

Concrete RNN architectures

LSTM

Concrete RNN architectures

LSTM

Concrete RNN architectures

LSTM

Concrete RNN architectures

LSTM

Concrete RNN architectures

GRU

• LSTM: effective, but complex, computationally expensive
• GRU: cheaper alternative that works well in practice

Concrete RNN architectures

GRU

• reset gate (r): how much information from previous hidden

state needs to be included (reset with current information?)

• upgate gate (z): controls updates to hidden state (how much

does hidden state need to be updated with current information?)

Recursive neural networks

Introduction

• Generalization of RNNs from sequences to (binary) trees
• Linear transformation + non-linear activation function applied

recursively throughout a tree

• Useful for parsing

Software

• Tensorflow
• Python, C++
• http://www.tensorflow.org
• Theano
• Python
• http://deeplearning.net/software/theano/
• Keras
• Theano/tensorflow-based modular deep learning library
• Lasagne
• Theano-based deep learning library
