Towards Machine Learning for Quantification

Mikoláš Janota AITP, 28 March 2018

IST/INESC-ID, University of Lisbon, Portugal

Janota Towards Machine Learning for Quantification 1 / 28

Outline

Intro: QBF, Expansion, Games, Careful expansion Solving QBF Learning in QBF Bernays–Schönfinkel (“Effectively Propositional Logic”) — Finite Models

Janota Towards Machine Learning for Quantification 2 / 28

Intro: QBF, Expansion, Games, Careful expansion

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example:

x 1 y x y x y

• QBF — for a Quantified Boolean formula
• Example:

x y x y

• Quantifications as shorthands for connectives

( , ) Example:

(1) x y x y (2) x x x 1 (3) 1 1 1 1 (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example:

x y x y

• Quantifications as shorthands for connectives

( , ) Example:

(1) x y x y (2) x x x 1 (3) 1 1 1 1 (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example:

x y x y

• Quantifications as shorthands for connectives

( , ) Example:

(1) x y x y (2) x x x 1 (3) 1 1 1 1 (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example: ∀x∃y. (x ↔ y)
• Quantifications as shorthands for connectives

( , ) Example:

(1) x y x y (2) x x x 1 (3) 1 1 1 1 (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example: ∀x∃y. (x ↔ y)
• Quantifications as shorthands for connectives

(∀ = ∧, ∃ = ∨) Example:

(1) x y x y (2) x x x 1 (3) 1 1 1 1 (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example: ∀x∃y. (x ↔ y)
• Quantifications as shorthands for connectives

(∀ = ∧, ∃ = ∨) Example:

(1) ∀x∃y. (x ↔ y) (2) x x x 1 (3) 1 1 1 1 (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example: ∀x∃y. (x ↔ y)
• Quantifications as shorthands for connectives

(∀ = ∧, ∃ = ∨) Example:

(1) ∀x∃y. (x ↔ y) (2) ∀x. (x ↔ 0) ∨ (x ↔ 1) (3) 1 1 1 1 (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example: ∀x∃y. (x ↔ y)
• Quantifications as shorthands for connectives

(∀ = ∧, ∃ = ∨) Example:

(1) ∀x∃y. (x ↔ y) (2) ∀x. (x ↔ 0) ∨ (x ↔ 1) (3) ((0 ↔ 0) ∨ (0 ↔ 1)) ∧ ((1 ↔ 0) ∨ (1 ↔ 1)) (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

SAT and QBF

• SAT — for a Boolean formula, determine if it is satisfiable
• Example: {x = 1, y = 0} |

= (x ∨ y) ∧ (x ∨ ¬y)

• QBF — for a Quantified Boolean formula
• Example: ∀x∃y. (x ↔ y)
• Quantifications as shorthands for connectives

(∀ = ∧, ∃ = ∨) Example:

(1) ∀x∃y. (x ↔ y) (2) ∀x. (x ↔ 0) ∨ (x ↔ 1) (3) ((0 ↔ 0) ∨ (0 ↔ 1)) ∧ ((1 ↔ 0) ∨ (1 ↔ 1)) (4) 1 (True)

Janota Towards Machine Learning for Quantification 3 / 28

QBF is a strict subset of Bernays–Schönfinkel (EPR)

• Consider the QBF:

∀u∃e. u ↔ e

• 1. Introduce a predicate for truth,
• 2. each existential variable replace by a predicate,
• 3. universal variables wrapped by the truth predicate:

is-true t is-true f Xu is-true Xu pe Xu

• Alternatively, use equality:

t f Xu Xu t pe Xu

Janota Towards Machine Learning for Quantification 4 / 28

QBF is a strict subset of Bernays–Schönfinkel (EPR)

• Consider the QBF:

∀u∃e. u ↔ e

• 1. Introduce a predicate for truth,
• 2. each existential variable replace by a predicate,
• 3. universal variables wrapped by the truth predicate:

is-true t is-true f Xu is-true Xu pe Xu

• Alternatively, use equality:

t f Xu Xu t pe Xu

Janota Towards Machine Learning for Quantification 4 / 28

QBF is a strict subset of Bernays–Schönfinkel (EPR)

• Consider the QBF:

∀u∃e. u ↔ e

• 1. Introduce a predicate for truth,
• 2. each existential variable replace by a predicate,
• 3. universal variables wrapped by the truth predicate:

is-true t is-true f Xu is-true Xu pe Xu

• Alternatively, use equality:

t f Xu Xu t pe Xu

Janota Towards Machine Learning for Quantification 4 / 28

QBF is a strict subset of Bernays–Schönfinkel (EPR)

• Consider the QBF:

∀u∃e. u ↔ e

• 1. Introduce a predicate for truth,
• 2. each existential variable replace by a predicate,
• 3. universal variables wrapped by the truth predicate:

is-true(t) ∧ ¬is-true(f) ∧ (∀Xu. is-true(Xu) ↔ pe(Xu))

• Alternatively, use equality:

t f Xu Xu t pe Xu

Janota Towards Machine Learning for Quantification 4 / 28

QBF is a strict subset of Bernays–Schönfinkel (EPR)

• Consider the QBF:

∀u∃e. u ↔ e

• 1. Introduce a predicate for truth,
• 2. each existential variable replace by a predicate,
• 3. universal variables wrapped by the truth predicate:

is-true(t) ∧ ¬is-true(f) ∧ (∀Xu. is-true(Xu) ↔ pe(Xu))

• Alternatively, use equality:

t ̸= f ∧ (∀Xu. (Xu = t) ↔ pe(Xu))

Janota Towards Machine Learning for Quantification 4 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example u1u2 e1e2 u1 e1 u2 e2

• A QBF represents a two-player game between

and .

• wins a game if the matrix becomes false.
• wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for

.

• A QBF is true iff there exists a winning strategy for

. Example u e u e

• player wins by playing e

u.

Janota Towards Machine Learning for Quantification 5 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example ∀u1u2∃e1e2. (¬u1 ∨ e1) ∧ (u2 ∨ ¬e2)

• A QBF represents a two-player game between

and .

• wins a game if the matrix becomes false.
• wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for

.

• A QBF is true iff there exists a winning strategy for

. Example u e u e

• player wins by playing e

u.

Janota Towards Machine Learning for Quantification 5 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example ∀u1u2∃e1e2. (¬u1 ∨ e1) ∧ (u2 ∨ ¬e2)

• A QBF represents a two-player game between ∀ and ∃.
• wins a game if the matrix becomes false.
• wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for

.

• A QBF is true iff there exists a winning strategy for

. Example u e u e

• player wins by playing e

u.

Janota Towards Machine Learning for Quantification 5 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example ∀u1u2∃e1e2. (¬u1 ∨ e1) ∧ (u2 ∨ ¬e2)

• A QBF represents a two-player game between ∀ and ∃.
• ∀ wins a game if the matrix becomes false.
• wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for

.

• A QBF is true iff there exists a winning strategy for

. Example u e u e

• player wins by playing e

u.

Janota Towards Machine Learning for Quantification 5 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example ∀u1u2∃e1e2. (¬u1 ∨ e1) ∧ (u2 ∨ ¬e2)

• A QBF represents a two-player game between ∀ and ∃.
• ∀ wins a game if the matrix becomes false.
• ∃ wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for

.

• A QBF is true iff there exists a winning strategy for

. Example u e u e

• player wins by playing e

u.

Janota Towards Machine Learning for Quantification 5 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example ∀u1u2∃e1e2. (¬u1 ∨ e1) ∧ (u2 ∨ ¬e2)

• A QBF represents a two-player game between ∀ and ∃.
• ∀ wins a game if the matrix becomes false.
• ∃ wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for ∀.
• A QBF is true iff there exists a winning strategy for

. Example u e u e

• player wins by playing e

u.

Janota Towards Machine Learning for Quantification 5 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example ∀u1u2∃e1e2. (¬u1 ∨ e1) ∧ (u2 ∨ ¬e2)

• A QBF represents a two-player game between ∀ and ∃.
• ∀ wins a game if the matrix becomes false.
• ∃ wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for ∀.
• A QBF is true iff there exists a winning strategy for ∃.

Example u e u e

• player wins by playing e

u.

Janota Towards Machine Learning for Quantification 5 / 28

Quantification and Two-player Games

• In this talk we consider prenex form:

Quantifier-prefix. Matrix Example ∀u1u2∃e1e2. (¬u1 ∨ e1) ∧ (u2 ∨ ¬e2)

• A QBF represents a two-player game between ∀ and ∃.
• ∀ wins a game if the matrix becomes false.
• ∃ wins a game if the matrix becomes true.
• A QBF is false iff there exists a winning strategy for ∀.
• A QBF is true iff there exists a winning strategy for ∃.

Example ∀u∃e. (u ↔ e) ∃-player wins by playing e u.

Janota Towards Machine Learning for Quantification 5 / 28

Solving QBF

Solving by CEGAR Expansion

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Can be solved by SAT

2

. Impractical! Observe:

2

for some 2

What is a good ?

Janota Towards Machine Learning for Quantification 6 / 28

Solving by CEGAR Expansion

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Can be solved by SAT (∧

µ∈2U φ[µ]

) . Impractical! Observe:

2

for some 2

What is a good ?

Janota Towards Machine Learning for Quantification 6 / 28

Solving by CEGAR Expansion

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Can be solved by SAT (∧

µ∈2U φ[µ]

) . Impractical! Observe:

∃E. ∧

µ∈2U φ[µ] ⇒ ∃E. ∧ µ∈ω φ[µ]

for some ω ⊆ 2U

What is a good ω?

Janota Towards Machine Learning for Quantification 6 / 28

Solving by CEGAR Expansion Contd.

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Expand gradually instead: [Janota and Marques-Silva, 2011]

• Pick τ0 arbitrary assignment to E
• SAT

0 assignment to

• SAT

1 assignment to

• SAT

1 2 assignment to

• SAT

1 2 assignment to

• After n iterations

i 1 n i

Janota Towards Machine Learning for Quantification 7 / 28

Solving by CEGAR Expansion Contd.

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Expand gradually instead: [Janota and Marques-Silva, 2011]

• Pick τ0 arbitrary assignment to E
• SAT(¬φ[τ0]) = µ0 assignment to U
• SAT

1 assignment to

• SAT

1 2 assignment to

• SAT

1 2 assignment to

• After n iterations

i 1 n i

Janota Towards Machine Learning for Quantification 7 / 28

Solving by CEGAR Expansion Contd.

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Expand gradually instead: [Janota and Marques-Silva, 2011]

• Pick τ0 arbitrary assignment to E
• SAT(¬φ[τ0]) = µ0 assignment to U
• SAT(φ[µ0]) = τ1 assignment to E
• SAT

1 2 assignment to

• SAT

1 2 assignment to

• After n iterations

i 1 n i

Janota Towards Machine Learning for Quantification 7 / 28

Solving by CEGAR Expansion Contd.

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Expand gradually instead: [Janota and Marques-Silva, 2011]

• Pick τ0 arbitrary assignment to E
• SAT(¬φ[τ0]) = µ0 assignment to U
• SAT(φ[µ0]) = τ1 assignment to E
• SAT(¬φ[τ1]) = µ2 assignment to U
• SAT

1 2 assignment to

• After n iterations

i 1 n i

Janota Towards Machine Learning for Quantification 7 / 28

Solving by CEGAR Expansion Contd.

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Expand gradually instead: [Janota and Marques-Silva, 2011]

• Pick τ0 arbitrary assignment to E
• SAT(¬φ[τ0]) = µ0 assignment to U
• SAT(φ[µ0]) = τ1 assignment to E
• SAT(¬φ[τ1]) = µ2 assignment to U
• SAT(φ[µ0] ∧ φ[µ1]) = τ2 assignment to E
• After n iterations

i 1 n i

Janota Towards Machine Learning for Quantification 7 / 28

Solving by CEGAR Expansion Contd.

∃E ∀U. φ ≡ ∃E. ∧

µ∈2U φ[µ]

Expand gradually instead: [Janota and Marques-Silva, 2011]

• Pick τ0 arbitrary assignment to E
• SAT(¬φ[τ0]) = µ0 assignment to U
• SAT(φ[µ0]) = τ1 assignment to E
• SAT(¬φ[τ1]) = µ2 assignment to U
• SAT(φ[µ0] ∧ φ[µ1]) = τ2 assignment to E
• After n iterations

∃E. ∧

i∈1..n φ[τi]

Janota Towards Machine Learning for Quantification 7 / 28

Abstraction-Based Algorithm for a Winning Move

Algorithm for ∃∀. Generalize to arbitrary number of alternations using recursion. [Janota et al., 2012].

1 Function Solve(∃X∀Y. φ) 2 α ← true

// start with an empty abstraction

3 while true do 4

τ ← SAT(α) // find a candidate

5

if τ = ⊥ then return ⊥

6

µ ← Solve(¬φ[X ← τ]) // find a countermove

7

if µ = ⊥ then return τ

8

α ← α ∧ φ[Y ← µ] // refine abstraction

Janota Towards Machine Learning for Quantification 8 / 28

Results, QBF-Gallery ’14, Application Track

Janota Towards Machine Learning for Quantification 9 / 28

Careful Expansion: Good Example

∃x . . . ∀y . . . . φ ∧ y

Setting countermove y ← 0 yields false. Stop.

x y x

Setting candidate x 1 yields true (impossible to falsify). Stop.

Janota Towards Machine Learning for Quantification 10 / 28

Careful Expansion: Good Example

∃x . . . ∀y . . . . φ ∧ y

Setting countermove y ← 0 yields false. Stop.

∃x . . . ∀y . . . . x ∨ φ

Setting candidate x ← 1 yields true (impossible to falsify). Stop.

Janota Towards Machine Learning for Quantification 10 / 28

Careful Expansion: Bad Example

∃x∀y. x ⇔ y

• 1. x ← 1

candidate

• 2. SAT

1 y y countermove

• 3. SAT x

x candidate

• 4. SAT

y y 1 countermove

• 5. SAT x

x 1 UNSAT Stop

Janota Towards Machine Learning for Quantification 11 / 28

Careful Expansion: Bad Example

∃x∀y. x ⇔ y

• 1. x ← 1

candidate

• 2. SAT(¬(1 ⇔ y)) . . . y ← 0

countermove

• 3. SAT x

x candidate

• 4. SAT

y y 1 countermove

• 5. SAT x

x 1 UNSAT Stop

Janota Towards Machine Learning for Quantification 11 / 28

Careful Expansion: Bad Example

∃x∀y. x ⇔ y

• 1. x ← 1

candidate

• 2. SAT(¬(1 ⇔ y)) . . . y ← 0

countermove

• 3. SAT(x ⇔ 0) . . . x ← 0

candidate

• 4. SAT

y y 1 countermove

• 5. SAT x

x 1 UNSAT Stop

Janota Towards Machine Learning for Quantification 11 / 28

Careful Expansion: Bad Example

∃x∀y. x ⇔ y

• 1. x ← 1

candidate

• 2. SAT(¬(1 ⇔ y)) . . . y ← 0

countermove

• 3. SAT(x ⇔ 0) . . . x ← 0

candidate

• 4. SAT(¬(0 ⇔ y)) . . . y ← 1

countermove

• 5. SAT x

x 1 UNSAT Stop

Janota Towards Machine Learning for Quantification 11 / 28

Careful Expansion: Bad Example

∃x∀y. x ⇔ y

• 1. x ← 1

candidate

• 2. SAT(¬(1 ⇔ y)) . . . y ← 0

countermove

• 3. SAT(x ⇔ 0) . . . x ← 0

candidate

• 4. SAT(¬(0 ⇔ y)) . . . y ← 1

countermove

• 5. SAT(x ⇔ 0 ∧ x ⇔ 1) . . . UNSAT

Stop

Janota Towards Machine Learning for Quantification 11 / 28

Careful Expansion: Ugly Example

∃x1x2∀y1y2. x1 ⇔ y1 ∨ x2 ⇔ y2

• 1. x1, x2 ← 0, 0
• 2. SAT

y1 y2 y1 1 y2 1

• 3. SAT x1

1 x2 1 x1 x2 0 1

• 4. SAT

y1 1 y2 y1 1 y2

• 5. SAT

x1 1 x2 1 x1 1 x2 6.

Janota Towards Machine Learning for Quantification 12 / 28

Careful Expansion: Ugly Example

∃x1x2∀y1y2. x1 ⇔ y1 ∨ x2 ⇔ y2

• 1. x1, x2 ← 0, 0
• 2. SAT(¬(0 ⇔ y1 ∨ ¬0 ⇔ y2)) . . . y1 ← 1, y2 ← 1
• 3. SAT x1

1 x2 1 x1 x2 0 1

• 4. SAT

y1 1 y2 y1 1 y2

• 5. SAT

x1 1 x2 1 x1 1 x2 6.

Janota Towards Machine Learning for Quantification 12 / 28

Careful Expansion: Ugly Example

∃x1x2∀y1y2. x1 ⇔ y1 ∨ x2 ⇔ y2

• 1. x1, x2 ← 0, 0
• 2. SAT(¬(0 ⇔ y1 ∨ ¬0 ⇔ y2)) . . . y1 ← 1, y2 ← 1
• 3. SAT(x1 ⇔ 1 ∨ x2 ⇔ 1) . . . x1, x2 ← 0, 1
• 4. SAT

y1 1 y2 y1 1 y2

• 5. SAT

x1 1 x2 1 x1 1 x2 6.

Janota Towards Machine Learning for Quantification 12 / 28

Careful Expansion: Ugly Example

∃x1x2∀y1y2. x1 ⇔ y1 ∨ x2 ⇔ y2

• 1. x1, x2 ← 0, 0
• 2. SAT(¬(0 ⇔ y1 ∨ ¬0 ⇔ y2)) . . . y1 ← 1, y2 ← 1
• 3. SAT(x1 ⇔ 1 ∨ x2 ⇔ 1) . . . x1, x2 ← 0, 1
• 4. SAT(¬(0 ⇔ y1 ∨ 1 ⇔ y2)) . . . y1 ← 1, y2 ← 0
• 5. SAT

x1 1 x2 1 x1 1 x2 6.

Janota Towards Machine Learning for Quantification 12 / 28

Careful Expansion: Ugly Example

∃x1x2∀y1y2. x1 ⇔ y1 ∨ x2 ⇔ y2

• 1. x1, x2 ← 0, 0
• 2. SAT(¬(0 ⇔ y1 ∨ ¬0 ⇔ y2)) . . . y1 ← 1, y2 ← 1
• 3. SAT(x1 ⇔ 1 ∨ x2 ⇔ 1) . . . x1, x2 ← 0, 1
• 4. SAT(¬(0 ⇔ y1 ∨ 1 ⇔ y2)) . . . y1 ← 1, y2 ← 0
• 5. SAT

( (x1 ⇔ 1 ∨ x2 ⇔ 1) ∧ (x1 ⇔ 1 ∨ x2 ⇔ 0) ) . . . 6.

Janota Towards Machine Learning for Quantification 12 / 28

Careful Expansion: Ugly Example

∃x1x2∀y1y2. x1 ⇔ y1 ∨ x2 ⇔ y2

• 1. x1, x2 ← 0, 0
• 2. SAT(¬(0 ⇔ y1 ∨ ¬0 ⇔ y2)) . . . y1 ← 1, y2 ← 1
• 3. SAT(x1 ⇔ 1 ∨ x2 ⇔ 1) . . . x1, x2 ← 0, 1
• 4. SAT(¬(0 ⇔ y1 ∨ 1 ⇔ y2)) . . . y1 ← 1, y2 ← 0
• 5. SAT

( (x1 ⇔ 1 ∨ x2 ⇔ 1) ∧ (x1 ⇔ 1 ∨ x2 ⇔ 0) ) . . .

• 6. . . .

Janota Towards Machine Learning for Quantification 12 / 28

Learning in QBF

Issue

• CEGAR requires 2n SAT calls for the formula

∃x1 . . . xn∀y1 . . . yn. ∨

i∈1..n

xi ⇔ yi

• BUT: We know that the formula is immediately false if we

set yi xi. x1 xn y1 yn

i 1 n

xi xi x1 xn 0

• Idea: instead of plugging in constants, plug in functions.
• Where do we get the functions?

Janota Towards Machine Learning for Quantification 13 / 28

Issue

• CEGAR requires 2n SAT calls for the formula

∃x1 . . . xn∀y1 . . . yn. ∨

i∈1..n

xi ⇔ yi

• BUT: We know that the formula is immediately false if we

set yi ← ¬xi. ( ∃x1 . . . xn∀y1 . . . yn. ∨

i∈1..n

xi ⇔ ¬xi ) ≡ ( ∃x1 . . . xn. 0 )

• Idea: instead of plugging in constants, plug in functions.
• Where do we get the functions?

Janota Towards Machine Learning for Quantification 13 / 28

Issue

• CEGAR requires 2n SAT calls for the formula

∃x1 . . . xn∀y1 . . . yn. ∨

i∈1..n

xi ⇔ yi

• BUT: We know that the formula is immediately false if we

set yi ← ¬xi. ( ∃x1 . . . xn∀y1 . . . yn. ∨

i∈1..n

xi ⇔ ¬xi ) ≡ ( ∃x1 . . . xn. 0 )

• Idea: instead of plugging in constants, plug in functions.
• Where do we get the functions?

Janota Towards Machine Learning for Quantification 13 / 28

Issue

• CEGAR requires 2n SAT calls for the formula

∃x1 . . . xn∀y1 . . . yn. ∨

i∈1..n

xi ⇔ yi

• BUT: We know that the formula is immediately false if we

set yi ← ¬xi. ( ∃x1 . . . xn∀y1 . . . yn. ∨

i∈1..n

xi ⇔ ¬xi ) ≡ ( ∃x1 . . . xn. 0 )

• Idea: instead of plugging in constants, plug in functions.
• Where do we get the functions?

Janota Towards Machine Learning for Quantification 13 / 28

Use Machine Learning

[Janota, 2018]

• 1. Enumerate some number of candidate–countermove

pairs.

• 2. Run a machine learning algorithm to learn a Boolean

function for each variable in the inner quantifier.

• 3. Strengthen abstraction with the functions.
• 4. Repeat.
• 5. Additional heuristic: If a learned function still works, keep
• it. “Don’t fix what ain’t broke.”

Janota Towards Machine Learning for Quantification 14 / 28

Use Machine Learning

[Janota, 2018]

• 1. Enumerate some number of candidate–countermove

pairs.

• 2. Run a machine learning algorithm to learn a Boolean

function for each variable in the inner quantifier.

• 3. Strengthen abstraction with the functions.
• 4. Repeat.
• 5. Additional heuristic: If a learned function still works, keep
• it. “Don’t fix what ain’t broke.”

Janota Towards Machine Learning for Quantification 14 / 28

Use Machine Learning

[Janota, 2018]

• 1. Enumerate some number of candidate–countermove

pairs.

• 2. Run a machine learning algorithm to learn a Boolean

function for each variable in the inner quantifier.

• 3. Strengthen abstraction with the functions.
• 4. Repeat.
• 5. Additional heuristic: If a learned function still works, keep
• it. “Don’t fix what ain’t broke.”

Janota Towards Machine Learning for Quantification 14 / 28

Use Machine Learning

[Janota, 2018]

• 1. Enumerate some number of candidate–countermove

pairs.

• 2. Run a machine learning algorithm to learn a Boolean

function for each variable in the inner quantifier.

• 3. Strengthen abstraction with the functions.
• 4. Repeat.
• 5. Additional heuristic: If a learned function still works, keep
• it. “Don’t fix what ain’t broke.”

Janota Towards Machine Learning for Quantification 14 / 28

Use Machine Learning

[Janota, 2018]

• 1. Enumerate some number of candidate–countermove

pairs.

• 2. Run a machine learning algorithm to learn a Boolean

function for each variable in the inner quantifier.

• 3. Strengthen abstraction with the functions.
• 4. Repeat.
• 5. Additional heuristic: If a learned function still works, keep
• it. “Don’t fix what ain’t broke.”

Janota Towards Machine Learning for Quantification 14 / 28

Machine Learning Example

x1 x2 . . . xn y1 y2 . . . yn . . . 1 1 . . . 1 1 . . . 1 . . . 1 . . . 1 1 1 . . . 1 . . . 1 1 . . .

Janota Towards Machine Learning for Quantification 15 / 28

Machine Learning Example

x1 x2 . . . xn y1 y2 . . . yn . . . 1 1 . . . 1 1 . . . 1 . . . 1 . . . 1 1 1 . . . 1 . . . 1 1 . . .

• After 2 steps: y1 ← ¬x1, yi ← 1 for i ∈ 2..n.
• SAT x1

x1

i 2 n x2

1

• After 4 steps: y1

x1 y2 x2

• Eventually we learn the right functions.

Janota Towards Machine Learning for Quantification 15 / 28

Machine Learning Example

x1 x2 . . . xn y1 y2 . . . yn . . . 1 1 . . . 1 1 . . . 1 . . . 1 . . . 1 1 1 . . . 1 . . . 1 1 . . .

• After 2 steps: y1 ← ¬x1, yi ← 1 for i ∈ 2..n.
• SAT(x1 ⇔ ¬x1 ∨ ∨

i∈2..n x2 ⇔ 1)

• After 4 steps: y1

x1 y2 x2

• Eventually we learn the right functions.

Janota Towards Machine Learning for Quantification 15 / 28

Machine Learning Example

x1 x2 . . . xn y1 y2 . . . yn . . . 1 1 . . . 1 1 . . . 1 . . . 1 . . . 1 1 1 . . . 1 . . . 1 1 . . .

• After 2 steps: y1 ← ¬x1, yi ← 1 for i ∈ 2..n.
• SAT(x1 ⇔ ¬x1 ∨ ∨

i∈2..n x2 ⇔ 1)

• After 4 steps: y1 ← ¬x1 y2 ← ¬x2 . . .
• Eventually we learn the right functions.

Janota Towards Machine Learning for Quantification 15 / 28

Machine Learning Example

x1 x2 . . . xn y1 y2 . . . yn . . . 1 1 . . . 1 1 . . . 1 . . . 1 . . . 1 1 1 . . . 1 . . . 1 1 . . .

• After 2 steps: y1 ← ¬x1, yi ← 1 for i ∈ 2..n.
• SAT(x1 ⇔ ¬x1 ∨ ∨

i∈2..n x2 ⇔ 1)

• After 4 steps: y1 ← ¬x1 y2 ← ¬x2 . . .
• Eventually we learn the right functions.

Janota Towards Machine Learning for Quantification 15 / 28

Current Implementation

• Use CEGAR as before.
• Recursion to generalize to multiple levels as before.
• Refinement as before.
• Every K refinements, learn new functions from last K
• samples. Refine with them.
• Learning using decision trees by ID3 algorithm.

Janota Towards Machine Learning for Quantification 16 / 28

Current Implementation

• Use CEGAR as before.
• Recursion to generalize to multiple levels as before.
• Refinement as before.
• Every K refinements, learn new functions from last K
• samples. Refine with them.
• Learning using decision trees by ID3 algorithm.

Janota Towards Machine Learning for Quantification 16 / 28

Current Implementation

• Use CEGAR as before.
• Recursion to generalize to multiple levels as before.
• Refinement as before.
• Every K refinements, learn new functions from last K
• samples. Refine with them.
• Learning using decision trees by ID3 algorithm.

Janota Towards Machine Learning for Quantification 16 / 28

Current Implementation

• Use CEGAR as before.
• Recursion to generalize to multiple levels as before.
• Refinement as before.
• Every K refinements, learn new functions from last K
• samples. Refine with them.
• Learning using decision trees by ID3 algorithm.

Janota Towards Machine Learning for Quantification 16 / 28

Current Implementation

• Use CEGAR as before.
• Recursion to generalize to multiple levels as before.
• Refinement as before.
• Every K refinements, learn new functions from last K
• samples. Refine with them.
• Learning using decision trees by ID3 algorithm.

Janota Towards Machine Learning for Quantification 16 / 28

Current Implementation: Experiments

100 200 300 400 500 600 700 800 20 40 60 80 100 120 CPU time (s) instances qfun-64 qfun-128 rareqs qfun-64-f quabs gq

Janota Towards Machine Learning for Quantification 17 / 28

Bernays–Schönfinkel (“Effectively Propositional Logic”) — Finite Models

Bernays–Schönfinkel (EPR)

∀X. φ

• φ has no further quantifiers and no functions (just

predicates and constants)

• uses predicates p1

pm and constants c1 cn.

• Finite model property: formulas has a model iff it has a

model of size n.

• Therefore we can look for a model with the universe

1 n , n

n.

Janota Towards Machine Learning for Quantification 18 / 28

Bernays–Schönfinkel (EPR)

∀X. φ

• φ has no further quantifiers and no functions (just

predicates and constants)

• φ uses predicates p1, . . . , pm and constants c1, . . . , cn.
• Finite model property: formulas has a model iff it has a

model of size n.

• Therefore we can look for a model with the universe

1 n , n

n.

Janota Towards Machine Learning for Quantification 18 / 28

Bernays–Schönfinkel (EPR)

∀X. φ

• φ has no further quantifiers and no functions (just

predicates and constants)

• φ uses predicates p1, . . . , pm and constants c1, . . . , cn.
• Finite model property: formulas has a model iff it has a

model of size ≤ n.

• Therefore we can look for a model with the universe

1 n , n

n.

Janota Towards Machine Learning for Quantification 18 / 28

Bernays–Schönfinkel (EPR)

∀X. φ

• φ has no further quantifiers and no functions (just

predicates and constants)

• φ uses predicates p1, . . . , pm and constants c1, . . . , cn.
• Finite model property: formulas has a model iff it has a

model of size ≤ n.

• Therefore we can look for a model with the universe

∗1, . . . , ∗n′, n′ ≤ n.

Janota Towards Machine Learning for Quantification 18 / 28

CEGAR for Finite Models

∃p1 . . . pm∃c1 . . . cn∀X. φ pi predicates, ci constants, X variables

• 1. α ← true
• 2. Find interpretation for

: SAT

• 3. Test interpretation:

SAT X

• 4. If no counterexample, formula is true. STOP.
• 5. Strengthen abstraction:

X

• 6. GOTO 2

Janota Towards Machine Learning for Quantification 19 / 28

CEGAR for Finite Models

∃p1 . . . pm∃c1 . . . cn∀X. φ pi predicates, ci constants, X variables

• 1. α ← true
• 2. Find interpretation for α: I ← SAT(α)
• 3. Test interpretation:

SAT X

• 4. If no counterexample, formula is true. STOP.
• 5. Strengthen abstraction:

X

• 6. GOTO 2

Janota Towards Machine Learning for Quantification 19 / 28

CEGAR for Finite Models

∃p1 . . . pm∃c1 . . . cn∀X. φ pi predicates, ci constants, X variables

• 1. α ← true
• 2. Find interpretation for α: I ← SAT(α)
• 3. Test interpretation: µ ← SAT(∃X. ¬φ[I])
• 4. If no counterexample, formula is true. STOP.
• 5. Strengthen abstraction:

X

• 6. GOTO 2

Janota Towards Machine Learning for Quantification 19 / 28

CEGAR for Finite Models

∃p1 . . . pm∃c1 . . . cn∀X. φ pi predicates, ci constants, X variables

• 1. α ← true
• 2. Find interpretation for α: I ← SAT(α)
• 3. Test interpretation: µ ← SAT(∃X. ¬φ[I])
• 4. If no counterexample, formula is true. STOP.
• 5. Strengthen abstraction:

X

• 6. GOTO 2

Janota Towards Machine Learning for Quantification 19 / 28

CEGAR for Finite Models

∃p1 . . . pm∃c1 . . . cn∀X. φ pi predicates, ci constants, X variables

• 1. α ← true
• 2. Find interpretation for α: I ← SAT(α)
• 3. Test interpretation: µ ← SAT(∃X. ¬φ[I])
• 4. If no counterexample, formula is true. STOP.
• 5. Strengthen abstraction: α ← α ∧ φ[µ/X]
• 6. GOTO 2

Janota Towards Machine Learning for Quantification 19 / 28

CEGAR for Finite Models

∃p1 . . . pm∃c1 . . . cn∀X. φ pi predicates, ci constants, X variables

• 1. α ← true
• 2. Find interpretation for α: I ← SAT(α)
• 3. Test interpretation: µ ← SAT(∃X. ¬φ[I])
• 4. If no counterexample, formula is true. STOP.
• 5. Strengthen abstraction: α ← α ∧ φ[µ/X]
• 6. GOTO 2

Janota Towards Machine Learning for Quantification 19 / 28

Learning in Finite Models’ CEGAR

• 1. Consider some finite grounding:

∃p1 . . . pm∃c1 . . . cn ∧

µ∈ω . φ[µ]

pi predicates, ci constants,

• 2. Calculate interpretation by e.g. Ackermanization.
• 3. The interpretation only matters on the existing ground

terms.

• 4. Learn entire interpretation from observing values of

existing terms.

Janota Towards Machine Learning for Quantification 20 / 28

Learning in Finite Models’ CEGAR

• 1. Consider some finite grounding:

∃p1 . . . pm∃c1 . . . cn ∧

µ∈ω . φ[µ]

pi predicates, ci constants,

• 2. Calculate interpretation by e.g. Ackermanization.
• 3. The interpretation only matters on the existing ground

terms.

• 4. Learn entire interpretation from observing values of

existing terms.

Janota Towards Machine Learning for Quantification 20 / 28

Learning in Finite Models’ CEGAR

• 1. Consider some finite grounding:

∃p1 . . . pm∃c1 . . . cn ∧

µ∈ω . φ[µ]

pi predicates, ci constants,

• 2. Calculate interpretation by e.g. Ackermanization.
• 3. The interpretation only matters on the existing ground

terms.

• 4. Learn entire interpretation from observing values of

existing terms.

Janota Towards Machine Learning for Quantification 20 / 28

Learning in Finite Models’ CEGAR

• 1. Consider some finite grounding:

∃p1 . . . pm∃c1 . . . cn ∧

µ∈ω . φ[µ]

pi predicates, ci constants,

• 2. Calculate interpretation by e.g. Ackermanization.
• 3. The interpretation only matters on the existing ground

terms.

• 4. Learn entire interpretation from observing values of

existing terms.

Janota Towards Machine Learning for Quantification 20 / 28

Learning in Finite Models’ CEGAR, Example

• 1. ∀X. p(X1, . . . , Xn) ⇔ (X1 = t)
• 2. Ground by Xi

and X1

1 X1

Xn

0 :

3. p t p

1 1

t

• 4. Partial interpretation:

t

1 p

False p

1

True

• 5. Learn: t

1, p X1

Xn X1

1 ,

Janota Towards Machine Learning for Quantification 21 / 28

Learning in Finite Models’ CEGAR, Example

• 1. ∀X. p(X1, . . . , Xn) ⇔ (X1 = t)
• 2. Ground by {Xi ∗0} and {X1 ∗1, X1 ∗0 . . . Xn ∗0}:

3. p t p

1 1

t

• 4. Partial interpretation:

t

1 p

False p

1

True

• 5. Learn: t

1, p X1

Xn X1

1 ,

Janota Towards Machine Learning for Quantification 21 / 28

Learning in Finite Models’ CEGAR, Example

• 1. ∀X. p(X1, . . . , Xn) ⇔ (X1 = t)
• 2. Ground by {Xi ∗0} and {X1 ∗1, X1 ∗0 . . . Xn ∗0}:
• 3. (p(∗0, . . . , ∗0) ⇔ ∗0 = t) ∧ (p(∗1, . . . , ∗0) ⇔ ∗1 = t)
• 4. Partial interpretation:

t

1 p

False p

1

True

• 5. Learn: t

1, p X1

Xn X1

1 ,

Janota Towards Machine Learning for Quantification 21 / 28

Learning in Finite Models’ CEGAR, Example

• 1. ∀X. p(X1, . . . , Xn) ⇔ (X1 = t)
• 2. Ground by {Xi ∗0} and {X1 ∗1, X1 ∗0 . . . Xn ∗0}:
• 3. (p(∗0, . . . , ∗0) ⇔ ∗0 = t) ∧ (p(∗1, . . . , ∗0) ⇔ ∗1 = t)
• 4. Partial interpretation:

t ∗1, p(∗0 . . . , ∗0) False, p(∗1 . . . , ∗0) True

• 5. Learn: t

1, p X1

Xn X1

1 ,

Janota Towards Machine Learning for Quantification 21 / 28

Learning in Finite Models’ CEGAR, Example

• 1. ∀X. p(X1, . . . , Xn) ⇔ (X1 = t)
• 2. Ground by {Xi ∗0} and {X1 ∗1, X1 ∗0 . . . Xn ∗0}:
• 3. (p(∗0, . . . , ∗0) ⇔ ∗0 = t) ∧ (p(∗1, . . . , ∗0) ⇔ ∗1 = t)
• 4. Partial interpretation:

t ∗1, p(∗0 . . . , ∗0) False, p(∗1 . . . , ∗0) True

• 5. Learn: t ∗1, p(X1, . . . , Xn) (X1 = ∗1),

Janota Towards Machine Learning for Quantification 21 / 28

Preliminary Results

100 200 300 400 500 600 100 200 300 400 500 600 CPU time (s) instances iprover vam-fm cegar+learn cegar expand cvc4

Janota Towards Machine Learning for Quantification 22 / 28

Preliminary Results

100 200 300 400 500 600 50 100 150 200 250 300 350 400 CPU time (s) instances cegar+learn cegar expand

Janota Towards Machine Learning for Quantification 23 / 28

Preliminary Results (Hard) - more then 1 sec

100 200 300 400 500 600 10 20 30 40 50 60 70 80 CPU time (s) instances cegar+learn cegar expand

Janota Towards Machine Learning for Quantification 24 / 28

Learn vs. CEGAR, Iterations

1 10 100 1000 10000 100000 1 10 100 1000 10000 100000 cegar+learn (its) cegar (its)

Janota Towards Machine Learning for Quantification 25 / 28

Learn vs. CEGAR, Iterations — Only True

1 10 100 1000 10000 1 10 100 1000 10000 cegar+learn (its) cegar (its)

Janota Towards Machine Learning for Quantification 26 / 28

Summary and Future

• Observing a formula while solving, learn from that.
• Learning objects in the considered theory. (rather than

strategies, etc.)

• Learning from Booleans:

For

n m

, learning

n

• Learning interpretations in finite models from partial

interpretations: For D1 Dk F1 Fl , learning D1 Dk

• How can we learn strategies based on functions?
• Infinite domains?
• Learning in the presence of theories?

Janota Towards Machine Learning for Quantification 27 / 28

Summary and Future

• Observing a formula while solving, learn from that.
• Learning objects in the considered theory. (rather than

strategies, etc.)

• Learning from Booleans:

For

n m

, learning

n

• Learning interpretations in finite models from partial

interpretations: For D1 Dk F1 Fl , learning D1 Dk

• How can we learn strategies based on functions?
• Infinite domains?
• Learning in the presence of theories?

Janota Towards Machine Learning for Quantification 27 / 28

Summary and Future

• Observing a formula while solving, learn from that.
• Learning objects in the considered theory. (rather than

strategies, etc.)

• Learning from Booleans:

For . . . ∃Bn∀Bm . . . , learning Bn → B

• Learning interpretations in finite models from partial

interpretations: For D1 Dk F1 Fl , learning D1 Dk

• How can we learn strategies based on functions?
• Infinite domains?
• Learning in the presence of theories?

Janota Towards Machine Learning for Quantification 27 / 28

Summary and Future

• Observing a formula while solving, learn from that.
• Learning objects in the considered theory. (rather than

strategies, etc.)

• Learning from Booleans:

For . . . ∃Bn∀Bm . . . , learning Bn → B

• Learning interpretations in finite models from partial

interpretations: For ∃(D1 × · · · × Dk → B)∀F1 × · · · × Fl . . . , learning D1 × · · · × Dk → B

• How can we learn strategies based on functions?
• Infinite domains?
• Learning in the presence of theories?

Janota Towards Machine Learning for Quantification 27 / 28

Summary and Future

• Observing a formula while solving, learn from that.
• Learning objects in the considered theory. (rather than

strategies, etc.)

• Learning from Booleans:

For . . . ∃Bn∀Bm . . . , learning Bn → B

• Learning interpretations in finite models from partial

interpretations: For ∃(D1 × · · · × Dk → B)∀F1 × · · · × Fl . . . , learning D1 × · · · × Dk → B

• How can we learn strategies based on functions?
• Infinite domains?
• Learning in the presence of theories?

Janota Towards Machine Learning for Quantification 27 / 28

Summary and Future

• Observing a formula while solving, learn from that.
• Learning objects in the considered theory. (rather than

strategies, etc.)

• Learning from Booleans:

For . . . ∃Bn∀Bm . . . , learning Bn → B

• Learning interpretations in finite models from partial

interpretations: For ∃(D1 × · · · × Dk → B)∀F1 × · · · × Fl . . . , learning D1 × · · · × Dk → B

• How can we learn strategies based on functions?
• Infinite domains?
• Learning in the presence of theories?

Janota Towards Machine Learning for Quantification 27 / 28

Summary and Future

• Observing a formula while solving, learn from that.
• Learning objects in the considered theory. (rather than

strategies, etc.)

• Learning from Booleans:

For . . . ∃Bn∀Bm . . . , learning Bn → B

• Learning interpretations in finite models from partial

interpretations: For ∃(D1 × · · · × Dk → B)∀F1 × · · · × Fl . . . , learning D1 × · · · × Dk → B

• How can we learn strategies based on functions?
• Infinite domains?
• Learning in the presence of theories?

Janota Towards Machine Learning for Quantification 27 / 28

Thank You for Your Attention! Questions?

Janota Towards Machine Learning for Quantification 28 / 28

Janota, M. (2018). Towards generalization in QBF solving via machine learning. In AAAI Conference on Artificial Intelligence. Janota, M., Klieber, W., Marques-Silva, J., and Clarke, E. M. (2012). Solving QBF with counterexample guided refinement. In SAT, pages 114–128. Janota, M. and Marques-Silva, J. (2011). Abstraction-based algorithm for 2QBF. In SAT.

Janota Towards Machine Learning for Quantification 28 / 28
