Toward full ACID distributed transaction support with Foreign Data Wrapper

Masahiko Sawada

https://www.2ndQuadrant.com

PGCon 2020

What is Foreign Data Wrapper

• Implementation of the SQL/MED
• Access data that resides outside PostgreSQL

using regular SQL queries

• Foreign tables
• Pluggable architecture
• https://wiki.postgresql.org/wiki/Foreign_data_wrapper
• Writable at 9.3 or later

https://www.2ndQuadrant.com

PGCon 2020

Foreign Data Wrapper

PostgreSQL

MySQL Oracle Database PostgreSQL Client mysql_fdw postgres_fdw

• racle_fdw

https://www.2ndQuadrant.com

PGCon 2020

Current Status

• FDW plugin is responsible for transaction

management on the remote nodes (foreign transaction)

• begin, commit, rollback and savepoint
• Foreign transaction termination can use

XactCallback, which is called BEFORE committing the local transaction

https://www.2ndQuadrant.com

PGCon 2020

postgres_fdw’s Transaction Managements

• Open a foreign transaction when FDW access the

remote first time within the local transaction

• Foreign transaction uses SERIALIZABLE when the

local transaction has SERIALIZABLE.

• Otherwise use REPEATABLE READ
• This ensures that if a query performs multiple table

scans on the remote server, it will get snapshot- consistent results for all the scans

https://www.2ndQuadrant.com

PGCon 2020

Two Major Limitations

• Atomic Commit
• Read Issues

https://www.2ndQuadrant.com

PGCon 2020

Atomic Commit Problem

• Foreign transactions are committed one by one

before the local transaction commits

• If a remote server crashes during the commit,

some transactions are committed whereas other are not (it’s the same when the local node crashes)

• There is no guarantee that all servers (including

local) are committed or rollbacked

https://www.2ndQuadrant.com

PGCon 2020

Transaction Commit w/ FDW

L

COMMIT COMMIT COMMIT OK COMMIT OK OK

R1 R2

https://www.2ndQuadrant.com

PGCon 2020

Transaction Commit w/ FDW

L

COMMIT COMMIT ROLL BACK Rollbacked OK NG!!

R1 R2

COMMIT

https://www.2ndQuadrant.com

PGCon 2020

Two-Phase Commit Protocol

• A type of atomic commitment protocol
• Blocking protocol
• Consists of two phases: prepare phase and commit phase

1.Coordinator sends PREPARE request to all participants 2.Coordinator sends COMMIT request to all participants if and only if all participants sent OK in prepare phase 3.Otherwise coordinator sends ROLLBACK request to all participants

https://www.2ndQuadrant.com

PGCon 2020

2PC for FDW

• First proposal at 2015
• “Transactions involving multiple postgres foreign servers,

take 2” by Masahiko Sawada and Ashutosh Bapat

• The core manages remote transactions
• Introduces new FDW APIs for transaction

managements

• Commit, Rollback, Prepare and GetPrepareId

https://www.2ndQuadrant.com

PGCon 2020

2PC for FDW - Commit

Transaction involving foreign transactions implements commit via following steps: 1.Prepare all foreign transactions 2.Commit locally 3.Commit all foreign transaction

https://www.2ndQuadrant.com

PGCon 2020

2PC for FDW

• The core persists information about foreign

transactions to disk via WAL records so that these can be recovered after restart

• Introduce a new background process called

Transaction Resolver

• Executing COMMIT PREPARED in-progress foreign

transactions

• Resolving recovered or in-doubt foreign transactions

https://www.2ndQuadrant.com

PGCon 2020

FDW transaction with 2PC

L

Prepare Prepare Commit Ok Commit Commit Prepared Commit Prepared

TR

R1 R2

https://www.2ndQuadrant.com

PGCon 2020

Scenario-1: A participant crashes before commit

L

Prepare Prepare Rollback NG Commit NG!! Rollback Prepared

R1 R2

https://www.2ndQuadrant.com

PGCon 2020

Scenario-2: Local node crashes after commit

L

Prepare Prepare Commit Commit Commit Prepared Commit Prepared

TR

L

Foreign transaction information is recovered during the recovery.

R1 R2

https://www.2ndQuadrant.com

PGCon 2020

Interruptions

L

Prepare Prepare Commit Ok Commit Commit Prepared Commit Prepared

TR

R1 R2

https://www.2ndQuadrant.com

PGCon 2020

Interruptions

L

Prepare Prepare Commit Ok, committed. But we leaves transactions. Commit Commit Prepared

TR

Cancel Commit Prepared

R1 R2 R2

https://www.2ndQuadrant.com

PGCon 2020

Atomic Visibility

Either all or none of each transaction’s updates are observed by other transaction

https://www.2ndQuadrant.com

PGCon 2020

Atomic Visibility - uncertain period

L R1

Prepare Prepare Commit Commit Prepared Commit Prepared

TR

A transaction starts in this period will be able to see only one committed data

R2

https://www.2ndQuadrant.com

PGCon 2020

Read Issues

• One of the most important goals of FDW is that

if the client uses PostgreSQL with the foreign server then it needs to function the same way as a single PostgreSQL server would do

• Unfortunately, current FDW doesn’t work even if

a transaction involves only one remote node

https://www.2ndQuadrant.com

PGCon 2020

Transaction Isolation Levels (ANSI/ISO)

Dirty read Non-repeatable Read Phantom Read Read Uncommitted

(*1)

May occur May occur May occur Read Committed Don’t occur May occur May occur Repeatable Read Don’t occur Don’t occur May occur

(*2)

Serializable Don’t occur Don’t occur Don’t occur

(*1) : PostgreSQL doesn’t support Read Uncommitted transaction isolation level. (*2) : Don’t occur in PostgreSQL

https://www.2ndQuadrant.com

PGCon 2020

Example 1: two clients access the same foreign table

L R

100 rows SELECT count(*) DELETE 10 rows and COMMIT SELECT count(*) 100 rows Begin RC Tx Begin RR Tx Read data with the same snapshot

https://www.2ndQuadrant.com

PGCon 2020

Example 2: two clients access the different foreign table

L

100 rows SELECT tbl1 DELETE 10 rows from tbl2 and COMMIT SELECT tbl2 90 rows Begin RR Tx Begin RR Tx

R1 R2

https://www.2ndQuadrant.com

PGCon 2020

Summary

• In both case, the client gets the different result

than when using single PostgreSQL server

• There is not guarantee that the cluster return

the consistent result among all foreign servers even when there is only one foreign table.

https://www.2ndQuadrant.com

PGCon 2020

Global Snapshots

• Provide globally consistent snapshots
• Global snapshots could be PostgreSQL

snapshots (xmin, xmax and in-progress xids), CSN, timestamp etc

https://www.2ndQuadrant.com

PGCon 2020

Central Transaction Manager

• Postgres-XL has a dedicated global transaction manager node (GTM

node)

• All coordinators have to access GTM to get a global consistent

snapshot

• GTM provides PostgreSQL snapshot consistent across all data nodes
• Google Percolator has similar concept: Timestamp Oracle
• Which can produce timestamps in a strictly increasing order
• Timestamps coming from the timestamp oracle are used as the time

when read/write operation happens

• But.. SPOF issues with GTMs

https://www.2ndQuadrant.com

PGCon 2020

Clock-SI

• Jiaqing Du et al., “Clock-SI: Snapshot Isolation for

Partitioned Data Stores Using Loosely Synchronized Clocks”, 2013 IEEE 32nd International Symposium on Reliable Distributed Systems, 2013.

• Use physical time as CSN
• Address clock skew problem
• A patch which implements Clock-SI paper was proposed at

2018

• “Global Snapshots” by Stas Kelvich

https://www.2ndQuadrant.com

PGCon 2020

Clock Skew

t t Tx1: start Tx1: read(x) t’ Delay until timestamp-t Read(x)

A B

https://www.2ndQuadrant.com

PGCon 2020

Summary

• Foreign Data Wrapper is the powerful feature to

access the distributed data across heterogenous data stores

• A big missing pieces is transaction management
• Several ideas are proposed
• 2PC over FDW
• Clock-SI

https://www.2ndQuadrant.com

PGCon 2020

Thank you
