Lumada IoT Architecture Today and Tomorrow

Rob Tiffany

CTO and Global Product Manager/Lumada IoT 9/18/2017

Session Objectives: ▪ Discover the baseline architecture found in most IoT platforms. ▪ Learn about Lumada’s high-performance architecture that integrates with a customer’s existing systems. ▪ Get a glimpse of the highly-distributed, global future of Lumada. Key Takeaway: You should be able to describe a secure, global IoT system designed to deliver customer value at unprecedented scale.

Session Objectives and Takeaways

Common IoT Architectures

Generic IoT Platform Architecture

IoT Device SDK Auth IoT Cloud Gateway Message Queue

Do

IoT Device Registry

Unique Device ID Security Token Something

Let’s Build it in the Cloud!

Cloud Gateway Device Registry Analytics Thing Thing Thing Thing Thing Thing Thing Thing Thing Thing

Lumada Architecture

Lumada at a Glance

Core

Data Collection Asset Management Asset Avatar

Foundry

Intelligent Composable Secure Flexible

IT Systems Business Data OT Systems Machine Data Human Data

Analytics

Batch / Stream Analytics Artificial Intelligence Data Blending / Orchestration

Studio

Alerts / Notifications Dashboard Application Enablement

Edge

Edge Analytics Real time Control Asset Integration Data Caching / Filtering

▪ An asset avatar type is a digital blueprint for a class of physical assets

• f the same type.

First We Start with an Asset Avatar Type

▪ Asset avatars are an instance of an asset avatar type and inherit a subset of properties and metadata.

Asset Avatar Type Asset Asset Asset Asset Avatar Asset Avatar Asset Avatar

Asset Avatar Asset Avatar

▪ An asset avatar is a digital representation of a physical asset.

Then We Derive Asset Avatars

▪ It serves as a digital proxy for physical assets with continuously updated sensor values to meet the needs of data consumers.

Asset Avatar Asset Avatar Asset Avatar

Sensor State

Asset

Physical Digital

Sensor Sensor Sensor Sensor Sensor Sensor Sensor Value Sensor Value Sensor Value Sensor Value Sensor Value Sensor Value

Data Query Service

▪ Not all of our Industrial IoT customers are prepared to move their data and operations to the cloud, so Lumada runs everywhere.

Portability to Meet Customers Where They Are

Assets Edge Core

▪ Lumada runs fully on-prem, in a hybrid on-prem to cloud configuration

• r completely in the cloud as needed.

Assets Edge Assets Core Core Assets Assets Assets

▪ Many customers have already made a sizable investment in their own apps, analytics, data management and visualization systems. ▪ Customers can integrate with Lumada via the asset avatar data query service, the real-time data consumer queue and data integration connectors.

Flexibility to Work with Customer Systems

Asset Avatar Data Query Service Data Integration Connectors

Visualization Alerts Apps Analytics Data Consumer Message Queue Cloud Databases CRM ERP Real Time Subscription

Lumada 2.0 Architecture

Real Time Telemetry

Assets OT Data

Serialization of Sensor Values

Edge

Edge SDK for Securable IP Edge Devices w/ Compute + Storage

Analytics

Batch File Telemetry MQTT AMQP HTTP/REST Security Token TLS

IT Data

Business Data Cloud Data CRM ERP CSV JSON

Studio

Interactive Dashboards Reporting Enterprise Integration Initiate Actions in Customer Business Systems via Data Integration Connectors Real-Time Alerts via SMS, Email and Mobile Push Notifications Data Blending Streaming Analytics Data Pipelines Workflow Engine Machine Learning Python, R, Weka Spark Execution Engines

Core

Asset Registry Assets + Gateways + People Security Tokens Producer Message Queue Asset Avatars Properties + State + History KPIs + Thresholds + Rules Consumer Message Queue Unstructured Storage Data Lake

APIs

Data Integration Connectors

Private or Public Cloud (IaaS)

Active Directory Update Avatars Update Queue Data Replay

Foundry

Microservices + Clustering + SSO + Authentication Authorization + Multi-Cloud Deployment + Logging

Data Producers Data Consumers

Solution Cores

Queue Subscription Asset Avatar Data Query Service Data Sink

Asset SDK for Securable IP Endpoint Devices w/ Compute + Storage Protocol Adapter Framework

OPC UA HTTP CAN Bus. Proprietary TCP UDP APIs

The Future of Lumada

The Future of Asset Avatar Types

Asset Avatar Type

Baseline metadata about this type of asset Names, data types, and units of measure for every sensor and actuator exposed by the asset User-defined KPIs, thresholds, and rate of change velocity per sampling for each sensor Asset configuration information including network interface, protocols, data formats, parsing and data transformation information required to initiate telemetry ingestion Code to be executed against incoming telemetry since data structure is known in advance Analytic engines or runtimes used to execute code New or updated metadata contributed by one asset avatar to be shared with all asset avatars of the same type If it’s a Child of a complex Parent Asset Avatar Type, it will also contain the Unique ID

• f the Parent Asset Avatar Type to maintain the Parent/Child relationship

Latest versions of Software and firmware plus the path to retrieve updates

The Future of Asset Avatars

Asset Avatar

Baseline metadata about this particular asset Names of every asset sensor along with current and historical values Names of every asset actuator to receive commands from authorized services and relay them to the actual asset New or updated metadata to be shared with the Asset Avatar Type it’s derived from If it’s a Child of a complex Parent Asset Avatar, it will also contain the Unique ID of the Parent Asset Avatar to maintain the Parent/Child relationship The Unique ID of the Asset Avatar Type it is derived from Ongoing maintenance records The Unique IDs of one or more groups the asset belongs to Current version of Software and firmware to compare with Asset Avatar Type version URL of authoritative upstream server node Location (GPS or other) Activated + Retired Flag + associated dates and data retention policy

▪ Lumada will move to a distributed, global cloud model that looks like the Internet using data replication services that work like the Internet Domain Name Servers (DNS). ▪ Administrators can create and maintain groups, roles, asset avatars, analytics, ML models, and global instances of Core, Fog, Edge and Assets with a single SaaS system. ▪ Hitachi and partners will connect Assets to Edge and Fog infrastructure. Hitachi and partner domain experts will create Asset Avatar Types. Hitachi and partner data scientists will pick Machine Learning algorithms and create/train models. Hitachi, partners or the customer will manage and monitor the entire environment from a single cloud location.

Moving to a Global Offering

Global Company Japan

Assembly Line One Assembly Line Two

Factory Two Factory One

Tokyo Kyoto

Machine One

Factory Three

Solving for Global Scale

Assembly Line Three

Machine Two Machine Three Machine Four Machine Five

Osaka

Japan Core

ML Model Training Identity Avatars Sec APIs

Fog Fog Smart Connected Assets Edge Edge

Identity Avatars Sec APIs Identity Avatars Sec APIs

EMEA Core ASIA Core

Identity Avatars Sec APIs

Americas Core

ML Model Training ML Model Training ML Model Training Identity Avatars Sec APIs Sync Sync Identity Avatars Sec APIs Identity Avatars Sec APIs

Fog Fog Edge Edge

Consumer Producer Identity Avatars Sec APIs Consumer Producer Identity Avatars Sec APIs Consumer Producer Identity Avatars Sec APIs Consumer Producer Sec APIs Identity Avatars Sec APIs Identity Avatars

Smart Connected Assets Smart Connected Assets Smart Connected Assets

Studio Analytics Analytics Analytics Analytics Analytics Analytics Analytics Analytics Studio Studio Studio

Sync Sync Sync Sync Sync Sync

Data Sync

Session Objectives: ▪ Discover the baseline architecture found in most IoT platforms. ▪ Learn about Lumada’s high-performance architecture that integrates with a customer’s existing systems. ▪ Get a glimpse of the highly-distributed, global future of Lumada. Key Takeaway: You should be able to describe a secure, global IoT system designed to deliver customer value at unprecedented scale.

In Review: Session Objectives and Takeaways

Q & A

Thank You
