Hazards associated with Clostridium perfringens in particular reference to predictive models applicable to cooling of cooked meat and poultry products

Vijay K. Juneja, DVM, MS, Ph.D.

Eastern Regional Research Center ARS - USDA 600 East Mermaid Lane Wyndmoor, Pennsylvania 19038 Phone: 215-233-6500 Fax: 215-233-6697 e-mail: vjuneja@arserrc.gov

Clostridium perfringens

• Anaerobic
• Gram-positive
• Spore-forming
• Rod-shaped
• Non-motile bacterium

Clostridium perfringens

• Implicated in 248,520 cases of foodborne illnesses every

year in the United States with 41 hospitalizations and 7 deaths (Mead et al. 2000).

• Illnesses estimated at $123 million in North America

(Anonymous, 1995).

• Inadequate cooling practices.

Nature of Problem

• Clostridium perfringens is a spore-

forming bacterium

• It grows under anaerobic conditions
• It is distributed widely in the

environment – Exits in the intestines of humans and animals – Persists in soil, sediments, and areas where fecal contamination can occur

• It survives well in the world

Perfringens Food Poisoning

• It is usually caused by consumption of large number of

vegetative cells (> 108)

• It is associated with production of C. perfringens toxins

– Cells producing toxins in the intestine – Foods containing toxins

• It can cause intense abdominal cramps and diarrhea with

8 - 22 h

• It is usually over in less than 24 h

Why Is It So Important?

• Spores – normal cooking temperatures cannot kill them
• During cooking – spores activated by heat and then

germinate, outgrow and multiply rapidly if cooling rate is slow

• Note: Growth is rapid when temperature is between 30 –

50°C.

Temperature Abuse

Temperature time

Dt1 Dt2

Danger Zone

DT

What Types of Foods?

• Foods are cooked, but not canned
• Allowed to cool slowly
• Kept warm

– Large pieces of cooked meats – A big pot of soup

Who, When, Where, and How?

• Institutional feeding - school cafeteria, hospitals, prisons,

and nursing homes where large quantities of foods are prepared

• Malfunctioned cooling systems during manufacturing of

cooked meats

• The young and elderly are always victims

For Prepared Food Manufacturers

Cooling! Cooling! Cooling!

Federal Regulation

USDA Food Safety and Inspection Services Guideline 130 – 80°F (54.4 – 26.6°C) ≤ 1.5 h 80 – 40°F (26.6 – 4.4°C) ≤ 5 h

In the event of process deviation or temperature abuse, manufacturers must prove that growth of C. perfringens < 1 log

Federal Register, Vol. 64, No. 3; Jan 6, 1999

Internal temperature should not remain between 130 and 80 F for > 1.5 h nor between 80 and 40 for > 5 h

Option I

• Cooling should begin 90 min from the end of cooking

cycle

• Product chilled from 120 to 55 F in < 6 h; Chilling

should continue until the product reaches 40 F;

• Product shall not be shipped until it reaches 40 F

Option II

• Product chilled from 130 to 80 F in 5 h; and 80 to 45

F in 10 h

RTE meat and poultry cured with nitrite (min 100 ppm) Option III

Narrow margin of safety In case of cooling deviation, assume the process has exceeded performance standard for C. perfringens Therefore, Use PMP Option III…

Stabilization Performance Standards

• All RTE products must be processed so as to prevent

multiplication of toxigenic microorganisms such as C. botulinum and allow no more than 1-log10 multiplication

• f C. perfringens within the product (USDA-FSIS,

2001).

• Determined using our PMP

– If computer modeling suggests > 1 log CFU/g increase in C. perfringens, there is a hazard – Therefore, re-cook the product

Cooling Deviations….

• USDA/FSIS: Compliance Guidelines for Cooling Heat-

Treated Meat and Poultry Products (Stabilization)

– “In the event that a cooling deviation does occur, the product

may often be salvaged if the results of computer modeling and/or sampling can ensure product safety. Because of a lack of information concerning the distribution of C. perfringens in product, sampling may not be the best recourse for determining the disposition of product following cooling deviations. However, computer modeling can be a useful tool in assessing the severity of a cooling deviation. While computer modeling cannot provide an exact determination of the possible amount clostridial growth, it can provide a useful estimate. “

Cooling Requirements

Safe cooling rates for cooked products (Objectives)

Develop models to predict the relative growth of Clostridium perfringens from spores at temperatures applicable to the cooling of cooked beef, pork and chicken.

Clostridium perfringens (Accomplishments)

• Cooling models:

»Beef Gravy »cured and uncured beef »cured and uncured chicken »cured and uncured pork

• Model for growth of C. perfringens:

Temperature, sodium chloride and sodium pyrophosphate, sodium nitrite

Mathematical Models

• Modified Gompertz Model
• Logistic Model
• Baranyi Model

Primary models

Growth Equation based on Baranyi Model

μ = specific exponential growth rate. q affects the lag phase duration. m = ln of maximum population density, M.

( ) ( (0))

1 ( ) (0) ( ) ln(1 ) ( )

A t m n

e n t n A t t e



 



     

) 1 ln( ) (

1

q q e t t A

ut

   

 



Modeling Growth of C. perfringens In Cooked Beef Under Isothermal Conditions

1 2 3 4 5 6 7 8 9 10 20 30 40 50 t (h) log(CFU/g) 25°C 30°C 36°C 45°C 47°C 50°C

1 2 3 4 5 6 7 8 9 20 40 60 80 100 120 140 160 180 200 t (h) log(CFU/g)

Secondary model

T is temperature in C. a, b, Tmin, Tmax are parameter values

EGR1/2 = a(T-Tmin)[1-exp(b(T-Tmax))]1/2 (Ratowsky Equation)

EGR times Lag is a function of q – reflecting the physiological state

• f the cells (Baranyi). Often assumed constant for modeling.

Consider quantity. ζ = ln(EGR x LAG)

Plot of estimated EGR versus temperature, for uncured chicken

10 20 30 40 50 Temp C 0.0 0.5 1.0 1.5 2.0 2.5 EGR All Rep = 1 Rep = 2 Deleted

Differential equations describing dynamic growth,

mo(t) = cells in lag phase mD(t) = cells in exponential phase h(t) = λ(t) = the hazard function for lag to exponential phase

• )

( ) ( ) ( t m t h dt t dm

O O

  ) ) ( ) ( 1 )( ( ) ( ) ( ) ( ) ( M t m t m t m t t m t h dt t dm

D O D O D

    

Clostridium perfringens Growth in Beef

(Dynamic Cooling Scenarios)

Time (h) between 54.4 and 27 C Time (h) between 27 and 4 C Initial level log10 Observed log10 increase Predicted log10 increase Logistic model Baranyi model Linear model 1.5 0.0 2.87 0.66 1.11 1.07 1.11 1.5 0.0 1.07

• 0.24

1.11 1.07 1.11 3.0 0.0 2.97 2.45 3.66 3.56 3.54 3.0 0.0 0.81 1.44 3.66 3.58 3.56 4.5 0.0 3.03 4.37 6.02 4.94 4.94 4.5 0.0 0.82 4.03 6.02 6.07 6.00 6.0 0.0 2.84 6.20 6.95 5.16 5.16 6.0 0.0 0.73 5.35 6.95 7.26 7.25

Clostridium perfringens Growth in Beef

(Dynamic Cooling Scenarios)

Time (h) between 54.4 and 27 C Time (h) between 27 and 4 C Initial level log10 Observed log10 increase Predicted log10 increase Logistic model Baranyi model Linear model 1.5 12.5 2.64 2.73 3.24 3.24 3.21 1.5 15.0 2.77 3.62 3.74 3.67 3.63 3.0 12.5 2.98 4.30 5.77 4.94 4.93 3.0 12.5 0.85 1.72 5.77 5.75 5.67 3.0 15.0 0.47 0.86 6.06 6.20 6.10

Clostridium perfringens Growth in Beef

(Dynamic Cooling Scenarios)

Hours from 54.4 to 27 °C Hours from 27 to 4 °C Log10 relative growth Observed Predicted log10 relative growth for exponential model Δ = 0 h Δ = 0.25 h Δ = 0.5 h Function 1.5 0.66 (0.33) 1.11 0.95 0.80 1.00 1.5 12.5 2.73 (0.24) 3.21 3.09 2.98 3.31 1.5 15 3.62 (0.04) 3.63 3.51 3.41 3.73 3.0 2.45 (0.09) 3.54 3.40 3.25 3.37

* Δ = 1-EGR/(8ln(10)), so that Δ ranged from 0.26 to 1.

Conclusions

The Traditional Method: May lead to slight

• verestimation of C. perfringens growth in uncured

chicken and beef meats during dynamic cooling. Use of Memory: The predicted values improved to within ± 0.5 log10 of the mean of the observed values for the cooling scenarios.

Predictive Microbiology Information Portal

Regulations Models Useful Links

• Final Rule on Listeria

monocytogenes in RTE Meat and Poultry Products

• “Zero Tolerance” Policy

USDA Pathogen Modeling Program Download at www.ars.usda.gov/naa/errc/mfsru/pmp

Pathogen Modeling Program (PMP) 7.0

The PMP is a repository of models that estimate the behavior of bacterial pathogens in specific environments. Through a user interface, information is provided about the effects of environmental factors on:

• growth
• inactivation (thermal and non-thermal)
• toxin production

PMP

• The PMP 7.0 currently contains:
• 40 models
• 15 food and 25 broth models
• static and dynamic temperature models
• Used by ~50% of FSIS-inspected companies
• >7,000 downloads per year

Thermal Inactivation of Foodborne Pathogens

• The models:

– Develop HACCP Plans – Validate HACCP Plans, or – The effects of process deviations – Determine the relative severity of a problem – Finally, plan for corrective actions

Practical Scenario --

Cooling Deviation

Cooling/Growth Models

• Scenario #1:
• Cooked roast beef plant has a cooling Critical Control Point (CCP)

Confidence Limit:

• Product’s internal temperature –

– between 130 F and 80 F for not more than 1.5 and then between 80 F and 40 F for not more than 5 hours.

• For this cooling deviation, the product cooled

– between 130 F and 80 F in 2 hours and then between 80 F and 40 F in another 6 hours

Cooling / Growth Models

• Clostridium perfringens – Cooling Cured Beef
• Clostridium perfringens in Beef

Broth

• Proteolytic Clostridium botulinum in Beef Broth -Clostridium perfringens – Cooling

Cured Chicken

Cooling/Growth Models

• Scenario #1 - Results from PMP 7.0

– Clostridium perfringens

• Mean Net Growth = 0.18
• LCL Net Growth = 0.12
• UCL Net Growth = 0.25

– Clostridium botulinum

• Mean Net Growth = 0.00
• LCL Net Growth = - 0.01
• UCL Net Growth = 0.01

Cooling/Growth Models

• Scenario #1 - Product Disposition

– Product would be released without any further action because:

• The UCL net growth for Clostridium perfringens is 0.25 which

meets the Agency performance standard/policy of no more than 1.0 log increase for the pathogen; and

• The UCL net growth for Clostridium botulinum is 0.01 which is not

more a 0.3 log increase indicating there was no multiplication of the pathogen thus meeting the Agency performance standard/policy

Cooling/Growth Models

• Scenario #2:
• Cooked roast beef plant has a cooling Critical Control Point (CCP)

Confidence Limit:

• Product’s internal temperature –

– between 130 F and 80 F for not more than 1.5 and then between 80 F and 40 F for not more than 5 hours.

• For this cooling deviation, the product cooled

– between 130 F and 80 F in 4.5 hours and then between 80 F and 40 F in another 10.5 hours

Cooling / Growth Models

• Clostridium perfringens – Cooling Cured Beef
• Clostridium perfringens in Beef

Broth

• Proteolytic Clostridium botulinum in Beef Broth
• Clostridium perfringens – Cooling

Cured Chicken-

Cooling/Growth Models

• Scenario #2 - Results from PMP 7.0

– Clostridium perfringens

• Mean Net Growth = 1.40
• LCL Net Growth = 1.07
• UCL Net Growth = 1.73

– Clostridium botulinum

• Mean Net Growth = 0.47
• LCL Net Growth = - 0.33
• UCL Net Growth = 0.61

Cooling/Growth Models

• Scenario #2 - Product Disposition

– Product should be destroyed because:

• The Mean, LCL and UCL net growth for Clostridium perfringens

are 1.07, 1.40, and 1.73, respectively, which exceeds the Agency performance standard/policy of no more than 1.0 log increase for the pathogen; and

• The Mean, LCL and UCL net growth for Clostridium botulinum

is 0.47, 0.33, and 0.61, respectively, which is more than a 0.3 log increase, indicating there was multiplication of the pathogen thus not meeting the Agency performance standard/policy of no growth of toxigenic microorganisms.

Center of Excellence in Microbial Modeling & Informatics

DO YOU HAVE ANY QUESTIONS? THANK YOU!
