TISSUE FREEZING METHODS FOR CRYOSTAT SECTIONING

Basic Tissue Freezing Methods

Preparing Tissue for Freezing Then a quick overview of MHPL Cryostat sectioning Techniques: Using The Brush; Using The Anti-Roll Plate;

Speaker: Donna J. Emge, HT-ASCP, MHPL Manager

Preparing Tissue For Freezing

Tissue for freezing should be frozen or fixed as promptly as possible after cessation of circulation to avoid morphological distortions and damage due to:

• Tissue drying artifact.
• Autolysis - The destruction of tissues or cells by

the action of substances, such as enzymes, that are produced within the organism. Also called self-digestion.

• Putrefaction - Decomposition by microorganisms.

WHY SNAP FREEZE OR FIX AND CRYOPROTECT FOR FREEZING?

Slow freezing can cause distortion of tissue due to ice crystal formation that replaces the architecture with a “Swiss Cheese” effect.

The object is to freeze so rapidly that water does not have time to form crystals and remains in a vitreous form that does not expand when solidified.

Freezing artifact in sections of Brain, Muscle, and Spleen Brain Skeletal Muscle

SHORT ARTICLE ON THE SUBJECT OF WATER CRYSTAL FORMATION: “FREEZING BIOLOGICAL SAMPLES”

Charles W. Scouten & Miles Cunningham

http://www.myneurolab.com/global/Manuals/Tips%20an d%20Techniques%20Freezing%20Artifact.pdf

METHODS OF TISSUE FREEZING

• 1. Fresh tissue freezing – Tissue is in OCT and flash

frozen fresh.

• 2. 4% PFA fixed, sucrose cryoprotected tissue freezing –

Tissue is in OCT and may be frozen using dry ice or the flash frozen method.

• 3. Enzyme study tissue freezing – Often used for fresh

muscle tissue. A fresh frozen method with no OCT

• matrix. Tissue protrudes from a Tragacanth or other

support medium.

MHPL Protocols for these methods are included in your workshop folder.

WHY NOT JUST USE LIQUID NITROGEN?

• It Boils – this creates a vapor barrier that causes

freezing in a slower, unpredictable pattern.

• Tissue and OCT often cracks – due to this

unpredictable freezing pattern.

AFTER ALL: “Liquid nitrogen is one of the coldest liquids routinely available and it does not mix with tissue.”

Review the article: “FREEZING BIOLOGICAL SAMPLES” Charles W. Scouten & Miles Cunningham http://www.myneurolab.com/global/Manuals/Tips%20and%20Techniques%20Freezing% 20Artifact.pdf

GETTING STARTED:

Before you dissect the animal - organize and set-up:

Before you dissect the animal -

• rganization and set-up:
• Choose appropriate freezing method - and depending on the

method prepare liquid nitrogen, isopentane, dry ice.

• Label ahead of time - cryo molds, aluminum foil, specimen bags

while at room temperature.

• Covered Foam cooler with crushed dry ice –

to temporarily hold frozen samples as you work.

• Tools & other supplies - OCT, or Tragacanth,

forceps, small labeled weigh boats or small labeled petri dishes.

FRESH TISSUE FREEZING

Pros

• Fastest of all methods.
• Excellent for IHC, IF, ISH. No antigen retrieval

required since no cross-linking fixative.

• Often easiest to section – depending upon tissue.

Cons

• Poorest morphology.
• Prone to freezing artifact – must be snap frozen.
• ISH integrity – extreme clean techniques required
• r RNA will be rapidly and easily degraded.

PREPARING FRESH TISSUE FOR FREEZING

(Not for enzyme study method)

• Acclimate tissue to OCT - cover freshly dissected tissue for a few minutes

in OCT in a labeled small petri dish or small weigh boat.

• Transfer and orientate in fresh OCT in a labeled Cryomold – with just

enough OCT to cover the tissue.

• Avoid bubbles in the OCT – especially near the tissue.
• Sectioning surface - is the bottom of the Cryomold.
• Begin freezing.

Fresh Tissue Freezing Procedure:

• A metal beaker is filled 2/3 with Isopentane and placed in a Dewar of Liquid

Nitrogen enough to come up to about 1/3 of the metal beaker. Prepare at least 10 minutes before freezing sample.

• With 12 inch forceps freeze the cryo mold prepared sample in the clear portion
• f isopentane – do not fully submerge.
• Avoid block cracking - when there is still a small drop size of unfrozen OCT

transfer sample to covered foam cooler of dry ice while continuing on to other samples.

Temporarily store frozen samples in a covered foam cooler of dry ice while continuing to freeze other samples Wrap individual samples in labeled foil, seal in a plastic bag, place in a freezer box . Store at -80° C.

4% PFA FIXED, SUCROSE CRYOPROTECTED TISSUE FREEZING

Pros

• Excellent morphology compared to other methods.
• May use a slower freeze in crushed powder dry ice

alone, slush of dry ice and 100% alcohol, or in a beaker of isopentane surrounded by dry ice - without incurring freezing artifact or block cracking.

• Any of the freezing methods discussed can be used.
• Good for most IHC, IF and ISH.

Cons

• Time consuming
• Most IHC will require antigen retrieval.
• Although the fixative cross-linking is protective for ISH

techniques there is some RNA degradation.

PREPARING FIXED, SUCROSE CRYOPROTECTED TISSUE

• 4% PFA transcardial perfuse animal.
• Drop fix in 4% PFA for a few hours to O/N.
• 15% sucrose in 1XPBS until tissue sinks.
• 30% sucrose in 1XPBS until tissue sinks.

SUCROSE CRYOPROTECTED TISSUE FREEZING

(Not for enzyme study method)

• Acclimate tissue to OCT - cover freshly dissected tissue

for a few minutes in OCT in a labeled small petri dish or small weigh boat.

• Transfer and orientate in fresh OCT in a labeled

Cryomold – with just enough OCT to cover the tissue.

• Avoid bubbles in the OCT – especially near the tissue.
• Sectioning surface - is the bottom of the Cryomold.
• Begin freezing.

• A metal beaker is ½ filled with isopentane, placed in a foam cooler or laboratory ice

bucket and surround with crushed dry ice. Add a few pieces of dry ice to the isopentane and wait until boiling stops. Add more isopentane if necessary.

• With 12 inch forceps freeze the cryo mold prepared sample in the isopentane – do not

fully submerge.

• Alternatively: Freeze cryomold prepared sample by surrounding it in finely powder

crushed dry ice alone, or in a dry ice methanol or 100% Ethanol slurry.

• Transfer frozen sample to a covered foam cooler of dry ice while continuing on to other

samples.

• Wrap all samples in labeled foil, place in a bag sealed bag, in a freezer box.
• Store at -80

FIXED, SUCROSE CRYOPROTECTED TISSUE FREEZING

ENZYME STUDY TISSUE FREEZING

Pros

• Excellent for Enzyme histochemistry and

Immunohistochemistry studies.

• Best method for muscle tissue.

Cons

• Advanced skill needed for sectioning – no supportive

OCT matrix. Anti-roll plate better than brush technique.

• Time and technique skill to prepare.
• Extremely susceptible to any freeze thaw – leading to

loss of morphologic detail in muscle or brain tissue.

ENZYME STUDY METHOD TISSUE PREP FOR FREEZING

Organize and set up:

ENZYME STUDY METHOD PREP FOR TISSUE FREEZING

• Prepare a small pyramid of

thick Tragacanth paste on a small piece of cork.

• Make a small hole in the

Tragacanth paste pyramid.

ENZYME STUDY METHOD PREP FOR TISSUE FREEZING

• Gently remove any surface

moisture from tissue with fresh tissue wipe.

• Place 1/8 to ¼ of the tissue in a hole

at top of pyramid, leaving the rest stick out above the tragacanth.

• Seal edges of tragacanth to the

tissue.

ENZYME STUDY TISSUE FREEZING

Procedure:

• A metal beaker is filled 2/3 with Isopentane and placed in a Dewar of

Liquid Nitrogen enough to come up to about 1/3 to ½ of the metal beaker. Prepare at least 10 minutes before freezing sample.

• Hold the cork/tragacanth/sample with 12” forceps and submerge sample

side down completely into the isopentane for 10 to 20 seconds.

ENZYME STUDY TISSUE FREEZING

• Transfer sample to covered foam cooler of crushed dry ice or

immediately to a -80 freezer.

• Rapidly wrap all samples in pre-cooled, labeled foil, and place in a

pre-cooled plastic bag, in a freezer box.

• Store at -80°C.

CRYOSECTIONING PREP

• Remove the frozen block from the -70°C freezer and

allow it to equilibrate in the cryostat chamber temperature for approximately 30 minutes.

• The optimal temperature for cryostat sectioning

depends on the nature of the tissue and on whether the tissues have been freshly frozen or pre-fixed with subsequent cryoprotection.

• Note the reference chart for temperature setting

guidelines for tissue types in your folder.

MHPL CRYOSTAT SECTIONING TECHNIQUES

• Using The Brush
• Using The Anti-Roll Plate

CRYOSTAT SECTIONING BRUSH TECHNIQUE The purpose of the brush is to grab and maneuver the section

across the stage.

You can buy a 1/4 inch, #2 flat, or bright brushes from an art supply store for about $3 and cut them at an angle. With this angled tip, the brush meets the tissue flat like a broom because the brush is held at an angle.

Stephen R Peters M.D. Pathology Innovations, LLC http://www.pathologyinnovations.com/frozen_section_technique.htm

CRYOSTAT SECTIONING BRUSH TECHNIQUE

CRYOSTAT SECTIONING BRUSH TECHNIQUE

CRYOSTAT SECTIONING ANTI-ROLL PLATE

Used to prevent frozen sections from curling upwards, after sectioning. The device is made of coated glass or plastic and is aligned parallel to the knife edge, a little above it. The following points are to be considered:

• a. Correct height to knife edge
• b. Correct angle to knife
• c. Top edge not damaged
• d. At cabinet temperature

CRYOSTAT SECTIONING ANTI-ROLL PLATE

CRYOSTAT SECTIONING ANTI-ROLL PLATE

TRAGACANTH SUSPENDED TISSUE

EXCELLENT PAPER:

Evaluation of the Value of Frozen Tissue Section Used as “Gold Standard” for Immunohistochemistry

Shan-Rong Shi, MD, Cheng Liu, Llana Pootrakul, PhD, Laurie Tang, MS, Andrew Young, Ryan Chen,Richard J. Cote, MD, and Clive R. Taylor, MD, PhD Am J Clin Pathol 2008;129:358-366 DOI: 10.1309/7CXUYXT23E5AL8KQ http://ajcp.ascpjournals.org/content/129/3/358.full.pdf

CARE AND HANDLING OF FROZEN SECTION SLIDES

EXAMINES:

• The use of acetone- or ethanol-fixed

frozen tissue sections as the “gold standard” for immunohistochemical analysis

• Frozen sections fixed by 6 protocols:

acetone, ethanol, NBF (2 durations), and NBF + calcium chloride (2 durations). With and without AR.
