Time- -Domain Measurement Method to Domain Measurement Method to - - PowerPoint PPT Presentation

Time Time-

• Domain Measurement Method to

Domain Measurement Method to Guard Against Preamplifier Saturation Guard Against Preamplifier Saturation

April 10, 2012 Matthew Jackson

2012

2

Outline

• Background
• Amplifier Saturation
• 1 dB Compression Point
• Testing with a Preamplifier
• Saturation Analysis Methods

– Attenuator Check – Band-pass Filter

• Time-Domain Measurement Method
• Conclusion
• Questions

2012

3

• Ambient noise requirements

– 6 dB below limit (CISPR 2008)

• Problems:

– Stringent limit – Large AF/cable loss – Noisy measuring instrument

• Solutions:

– Quieter measuring instrument – More efficient antenna – Shorter cable or low-loss cable

Use a low noise preamplifier

Background

2012

4

Amplifier Saturation

• Amplifier linear dynamic range
• Max output voltage limited by supply voltage
• 1
• 0.8
• 0.6
• 0.4
• 0.2

0.2 0.4 0.6 0.8 1

Amp Input Amp Output

Clipping

To avoid saturation, the input signal to the amplifier must be low enough to keep the amplifier in its linear dynamic range.

Pout (dB) = Pin (dB) + Linear Gain (dB)

2012

5

1 dB Compression Point

1dB Compression: 1 MHz

• 15
• 10
• 5

5 10 15 20

• 40 -39 -38 -37 -36 -35 -34 -33 -32 -31 -30 -29 -28 -27 -26 -25 -24 -23 -22 -21 -20 -19 -18 -17 -16 -15 -14 -13 -12 -11 -10

Pin (dBm) Pout (dBm) Amplifer Output Theoretical 1dB Down

Gain = 27 dB Pout 1 dB = Pin 1 dB + Linear Gain – 1 dB

1 dB Compression Point

2012

6

Testing with a Preamplifier

• Gain (G) used as a correction factor
• Preamplifier saturation = nonlinear gain
• Nonlinear gain < G
• Control SW corrects Vf

with G

• Report lower emission levels!

Ef = Vf + AF + C1 + C2 + C3 – G

2012

7

Saturation Analysis Methods

• Attenuator Check

– Consecutive scans w/ different input attenuation – Compare magnitude responses – Difficult to evaluate BB disturbances

• Band-pass Filter

– Install at preamplifier input – Remove out-of-band content – Need to know when/where to use – Drawbacks

• Impedance matching
• Insertion loss

f f1 f2 f3

• f1
• f2
• f3

Band-pass Filter

2012

8

TD Measurement Method

• Signal Propagation
• E-Field Incident Wave Voltage

f f1 … fN

• fN … -f1

α0 α1 αN α1

*

αN

*

N k e A

k

j k k

, ... , 1 , 2 1 = =

φ

α A = α

Saturation is not always caused by one dominate signal; many small signals can combine to produce a large v(t)

∑

=

+ + =

N k k k k

t f A A t v

1

) 2 cos( ) ( φ π

2012

9

TD Measurement Method

• Step 1: Calculate Pin (dBm)
• Where:

Pin = Max input (in dBm) that will not saturate the preamplifier Pout 1 dB = Rated output power at 1 dB compression G = Rated gain (in dB) Scf = Saturation correction factor

• Miteq AM-1300 Example
• Pout

1 dB = 8 dBm

• G = 27
• Pin

= 8 – 27 + 1 – Scf = -18 – Scf

Pin = Pout 1 dB – G + 1 – Scf

Input (dBm) Output (dBm)

• 18

8 Scf Pin

2012

10

TD Measurement Method

• Step 2: Convert Pin

to a peak voltage (Vpk )

• Where:

Vpk = Max input (in Volts) that will not saturate the preamplifier Pin = Max input (in dBm) that will not saturate the preamplifier Z = Preamplifier input impedance

• Miteq AM-1300 Example
• Pin

= -18 – Scf Let: Z = 50 Ω; Scf = 3 dB = -21

• Vpk

= ± 19.9 mV

( )( )

( )⎟

⎠ ⎞ ⎜ ⎝ ⎛ ± =

10

10 001 .

in

P pk

Z V

2012

11

TD Measurement Method

• Step 3: Correct for cable loss
• Equation:

( ) ( )

20

3 2

10

C C pk limit

V V

+

=

Where:

Vlimit = Adjusted max voltage limit C2 , C3 = Max cable loss (in dB)

2012

12

TD Measurement Method

• Step 4: Select an oscilloscope

– Input sensitivity of at least 1 mV/div – BW equal to upper frequency of preamplifier range – Sampling rate: fs > 2∗fmax

• Step 5: Adjust oscilloscope

1. Set input impedance to 50 Ω 2. Turn ON max and min measurements 3. Turn ON measurement statistics 4. Trigger on rising and falling edges 5. Turn ON infinite persistence 6. Limit input bandwidth (optional)

2012

13

TD Measurement Method

• Step 6: Setup equipment & measure emissions
• Adjust scope horizontal/vertical scales to monitor v(t)
• Measure for 5-10 minutes, or until no higher levels
• Repeat for each antenna and antenna polarization
• Repeat for each DUT orientation and DUT mode

2012

14

TD Measurement Method

Tektronix DPO7254, 2.5 GHz, 40 GS/s

2012

15

TD Measurement Method

• Step 7: Compare measurement to Vlimit

Max/Min > Vlimit ? Preamplifier will saturate Preamplifier will NOT saturate No Yes

2012

16

• TD Measurement Method

– Preamplifiers have a max input voltage – Exceeding the max input voltage → saturation – Find the max permissible input voltage – Use an o-scope, and measure the input voltage – Verify the input voltage < max input voltage

• Advantages

– Theoretically sound – Eliminates BB disturbance uncertainty – Comprehensive check – Conservative evaluation – Simple setup

Conclusion

2012

17

Questions
