REVOLUTIONIZING SATELLITE COMMUNICATIONS THROUGH EXPANDABLE ANTENNAS

This presentation is NSLComm proprietary and is confidential

Our Mission

Develop, manufacture and sell antenna technologies that will significantly increase satellite communications bandwidth Main Benefits:

• Significantly reduce antenna cost
• Improving satellite efficiency and industry

competitiveness

• Add flexibility and reuse of satellite resources by

controlling satellite footprint

2

This presentation is NSLComm proprietary and is confidential

• Mr. Danny Spirtus

Co Founder & CTO

25 Years of experience RF, Communications And customer driven startups Gilat, Raysat danny@nslcomm.com

• Mr. Daniel K. Rockberger

Co Founder & Chief Engineer

19 Years of experience Designer of Nano-Satellites and Communication Satellites Israel Aerospace Industries daniel@nslcomm.com

• Dr. Raz Itzhaki Tamir

Co Founder & CEO

24 Years of experience Nano-Satellite Department Manager Israel Aerospace Industries raz@nslcomm.com

Our Team

3

• Mr. Michael Pollack

VP North America

23 Years of experience Business Development, International Sales and Marketing Hughes, UltiSat, Advantech Satellite Networks

4

This presentation is NSLComm proprietary and is confidential

The Problem

High throughput satellites, providing large bandwidth, require large antennas with a very high surface accuracy

• Complexity: Difficult to launch to space
• Weight: Satellite launchers limit current antenna sizes to ~3m
• Accuracy: Expandable antennas are less accurate than rigid ones

Current Status

• Solutions for large VHTS satellites are complex,

heavy and very expensive

5

This presentation is NSLComm proprietary and is confidential

Our Solution

A large diameter expandable antenna technology with an adaptive corrective and pattern shaping sub reflector

This technology transforms the efficiency of communications services and may disrupt the entire communications industry.

• Performance: Up to 10X (GEO) and 100x (LEO) the throughput of

current solutions

• Cost reduction: Highly cost effective, as opposed to current solutions
• Flexibility: In-orbit footprint control
• Capable of providing communications for wide range of frequencies

1 Gigabit / sec Nano-Satellite

6

This presentation is NSLComm proprietary and is confidential

Our Product

Large Expandable Antennas for VHTS

Correctable antennas for high frequencies with active, in-orbit footprint control

FlexoSub

Unique error correction adaptive system

Main Reflector

Shape memory composites

* Technology is protected by patents

7

This presentation is NSLComm proprietary and is confidential

8

This presentation is NSLComm proprietary and is confidential

How does it work?

• Main reflector is compacted during launch and orbit raising
• After Main reflector is deployed, calibration is performed to

achieve required performance

• An onboard measurement system measures main reflector

surface errors due to thermal variations and aging

• The Flexosub shape is changed to compensate for any surface error
• Flexosub is used in order to control the footprint

9

This presentation is NSLComm proprietary and is confidential

5m VHTS Antenna Main Characteristics

• Surface accuracy better than 0.2 mm RMS
• Designed for Multi Beam configuration
• Life span equivalent to rigid antennas
• Allows for adaptive footprint control
• On Board calibration capabilities
• Cost target up to 25% of existing solutions

10

This presentation is NSLComm proprietary and is confidential

60 cm LEO antenna solution

• 1 Gigabit / sec for LEO satellite
• Stowed volume < 2U (2 liters)
• Applicable for any LEO satellite
• Adheres to the Nano-Satellite (cubesat) standard
• Optimal for LEO constellations
• Can be used for inter-satellite link
• Can be used for LEO2GEO communication

11

Click to see how it works

12

This presentation is NSLComm proprietary and is confidential

Application Example

13

1

This presentation is NSLComm proprietary and is confidential

Application Example

14

2

This presentation is NSLComm proprietary and is confidential

Application Example

15

3

This presentation is NSLComm proprietary and is confidential

Product Key Benefits

• Provides up to 10X (GEO) and 100X (LEO) the throughput
• Significant cost reduction due to FlexoSub approach
• Allows for adaptive footprint control
• Space qualified materials and processes
• Significantly lower stowed mass and volume

16

Thank You
