THERMAL ABLATION TATO SYSTEM Laura Sarti Product Specialist 1 Definition Thermal Ablation (TA) is the use of extreme hiperthermic temperatures to destroy diseased tissues. T.A. is performed in Interventional Radiology as an alternative to the

slide-1
SLIDE 1

1

THERMAL ABLATION TATO SYSTEM

Laura Sarti Product Specialist

slide-2
SLIDE 2

Definition

Thermal Ablation (TA) is the use of extreme hiperthermic temperatures to destroy diseased tissues. T.A. is performed in Interventional Radiology as an alternative to the surgical treatment of tumors in:

2

slide-3
SLIDE 3

Different TA technologies

  • Radiofrequency
  • Microwaves
  • Laser
  • Cryoablation

33

3

slide-4
SLIDE 4

RF Current Flow

  • RF Currents that goes through the tissue from the tip of

the applicator to the ground pad. Side effect: skin burning.

4

4

slide-5
SLIDE 5

MW Energy

Microwaves radiate only near the tip of the applicator. An applied MW field causes water molecules to rotate bilions of time per second , which leads to heat generation.

5

slide-6
SLIDE 6

Comparison between RF and MW thermal ablation

6

  • Heat sink effect
  • Ground pad required
  • Difficult to control the increase
  • f ablation
  • Less influenced by veins
  • Ground pad is not required
  • Predictable and controllable ablation
  • Compatible with pacemaker
slide-7
SLIDE 7

7

TATO : Multiprobe microwave thermal ablation System

  • Rev. 09 del 27.10.2016
slide-8
SLIDE 8

8

Main features of the system

1

  • No cooling system

2

  • Ergonomic and easily

transportable

3

  • Multi-probes with detachable

cable

slide-9
SLIDE 9
  • 1. No cooling system

The NIC (Not Internally Cooled) coax needles have a high energy efficiency that allows operating with less MW power for treatment up to 15 minutes.

Cooling system not needed

Less complexity Higher reliability Greater safety Better applicator handling Reducing procedure dead time Easy control of the procedure

9

slide-10
SLIDE 10

10

Switch Unit Roll Stand

2.Ergonomic and easily transportable

Main Unit- Microwave generator Articulated Arm extendable up to 1,5 m

Tato cart version Tato travel version

Switch Unit Roll Stand

slide-11
SLIDE 11

11

Main unit

Handle On/off button Touchscreen 7,1 inch Yellow Led: lighting indicates that MWs are ON Red Led: when lighting up, it indicates a fault 2,45 GHz 120 W total power IEC standards compliant USB port

slide-12
SLIDE 12

Extendable arm and switch cover

12

Extendable up to 1.5 m Sterile cover for arm

  • Total power 120 W
  • 1 to 4 power outputs
slide-13
SLIDE 13

TATO1 vs TATO2

13

FEATURE TURES TATO1 O1 TATO2 O2 TOTAL POWER 100W 120W DATA LOGGING  DATA DOWNLOAD  TRACK ABLATION PROTOCOL  REFLECTED POWER MONITORING  SELECTION NEEDLE GAUGE 

slide-14
SLIDE 14

14

11 G 14 G 17 G 18 G

Multi-Gauge

slide-15
SLIDE 15

15

DIAMETER G mm 3 mm 2,1 mm 1,5 mm 1,2 mm

11 G 14 G 17 G 18 G

The thinnest applicator currently available in the world market

slide-16
SLIDE 16

Version with infusion tip

Holes 0,3 mm Ø

16

  • 14 G and 17 G version
  • Applicator with 4 micro-holes in the tip for fluid infusion
  • A syringe can be used to inject fluids during the treatment
slide-17
SLIDE 17

17

  • Simple radiating monopole
  • High efficiency
  • Lightweight

(~35g w/o cable, 50g w/cable)

  • Detachable feeding cable:

advantage under CT scan

Main structural features

slide-18
SLIDE 18

Massa - Patient with HCC

 Usability of TATO under CT-scan  Extendable arm

18

slide-19
SLIDE 19

19

Echogenic needle

slide-20
SLIDE 20

Video of needle insertion

20

slide-21
SLIDE 21
  • All steel tips are tested with an applied force of 5kg.
  • No fragile ceramic parts are used
  • All probes are Teflon covered, non-sticky.
  • Available in different lengths from 10 up to 50 cm.
  • Centimeter marked cannula

21

Main structural features

slide-22
SLIDE 22

How to insert the needle

22

E

Lesion Ablation

E

Insert the tip of the needle into the lesion and use length E parameter (indicated in the chart) as reference.

slide-23
SLIDE 23

23

Control of increasing ablation volume : By employing lower MW power, the procedure’ s safety is increased, thus eliminating a lot of bubble gas and ensuring a better control under ultrasound. Gauge ge Max power er W 11 11 60 14 14 40 17 17 30 18 18 15

Main functional features

In order to operate safely, antennas must be used respecting the assigned power limits:

slide-24
SLIDE 24

Increasing ablation

24

slide-25
SLIDE 25

TATO 2 HMI

25

slide-26
SLIDE 26

26

TATO2 HMI Home Screen

slide-27
SLIDE 27

Setting

27

Language Date and time LOG Download Services

Output mating cycles : 1 4 3 2

slide-28
SLIDE 28

28

TATO2 Home Screen

slide-29
SLIDE 29

Possibility to insert Patient ID, Physician ID and note

29

slide-30
SLIDE 30

Needle choice

30

slide-31
SLIDE 31

Therapy Setting

31

slide-32
SLIDE 32

Therapy summary

32

slide-33
SLIDE 33

Therapy running

33

REFLECTED POWER COEFFICIENT OK : NEEDLE IS WORKING WELL AIR : NEEDLE IS IN THE AIR MISMATCH : NON-OPTIMAL FUNCTIONING OF NEEDLE NOT CONNECTED : NEDDLE IS NOT CONNECTED

slide-34
SLIDE 34

Therapy ended - Summary

34

TRACK ABLATION

slide-35
SLIDE 35

Track Ablation

35

slide-36
SLIDE 36

Video for Track ablation

  • 14 G, 60 W, 25 sec

36

slide-37
SLIDE 37

Ex – vivo and in – vivo charts

  • f Tato System

37

slide-38
SLIDE 38

CHARTS TATO2

38 ABLATION ZONE EXAMPLES* – 1 APPLICATOR Ex – vivo Bovine Liver

11 G 60 W Duration (min) 10:00 15:00 L (cm) 6,0 7,0 D( cm) 4,3 5,0 E (cm) 1,3 1,5 14 G 40 W Duration (min) 5:00 10:00 15:00 L (cm) 5,0 5,4 6,2 D( cm) 2,6 4,0 4,5 E (cm) 0,9 1,0 1,1 17 G 30 W Duration (min) 5:00 10:00 15:00 L (cm) 4,6 5,0 5,6 D( cm) 2,5 3,4 3,8 E (cm) 0,8 1,0 1,2 18 G 10 W 15 W Duration (min) 5:00 10:00 5:00 10:00 L (cm) 2,0 2,6 2,3 3,3 D( cm) 1,4 1,7 1,5 2,3 E (cm) 0,4 0,6 0,6 0,6

slide-39
SLIDE 39

CHARTS TATO2

39

slide-40
SLIDE 40

CHARTS TATO2

40

slide-41
SLIDE 41

CHARTS TATO2

41

slide-42
SLIDE 42

E.g. HCC or liver metastasis

  • Examples of MW applications in different liver tumors with

same values of watt and time.

  • HCC : «oven effect» due to the tissue’s consistency that is rich

in water and to the encapsulated tumor’s morphology . The result is a bigger ablation.

  • Metastasis: no «oven effect» because of the tissue has less

water content and is not encapsulated. The result is a smaller ablation.

42

slide-43
SLIDE 43

Frequently used parameters

In vivo most frequently used values of power (W) and time (min)

  • D = diameter

43

Diamet eter er

  • f tumor

0,5 <D<1 1<D<2 2<D<2,8 2,8 <D<4 D>4 Gauge 11 11 60 60 W Open surgery

1 needle 10 min 2 needles 15 min

14 14 40 40 W

1 needle 10 min 1 needle 15 min 2 needles 15 min 3 needles 15min 4 needles 10 min

17 17 30 30 W

1 needle 10 min 2 needles 15 min

18 18 15W 15W

1 needle 10 min

slide-44
SLIDE 44

Microwave ablation system Cross- reference

44

slide-45
SLIDE 45

Padova – TATO use in laparoscopy

  • Lesion: 7 cm
  • 2 x 14 G, 35 W, 15 min
  • And Repositioning 1 x 14G, 35 W, 4.5 min

45

slide-46
SLIDE 46

46

Treatment on HCC (percutaneous)

Dimension of the tumor 5 X 3 cm Used 2 x 17G

slide-47
SLIDE 47

Padova – Open surgery

47

9 tumors in total RESECTION AND ABLATION

Data of the first 4 ablations: 18 mm, 35W, 10min 19 mm, 35W, 2.3min and 40W, 1.30min 20 mm, 40W, 6min 18 mm, 40W, 6.2min

slide-48
SLIDE 48

Osteoid osteoma

48

Osteoid osteoma in vertebra

18G, 10W, 6min

slide-49
SLIDE 49

Aarau - Patient with kidney tumor Multi-probe case

Tumor size: 2.4 x 2.2 cm (+2 cm margin) Number of antennas: 4 x 14G Power: 100W total Time: 15min

49

slide-50
SLIDE 50
