SLIDE 1
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Table of Contents
The Biology The Model and the Math Lithium in the Model Lithium Treatment
2 / 38
The Treatment of Bipolar Disorder: Modeling Lithiums Effect on - - PowerPoint PPT Presentation
The Treatment of Bipolar Disorder: Modeling Lithiums Effect on - - PowerPoint PPT Presentation
The Treatment of Bipolar Disorder: Modeling Lithiums Effect on Neuronal Bursting Rosa Rossi-Goldthorpe Bowdoin College January 27th, 2019 NCUWM 2019 The Biology The Model and the Math Lithium in the Model Lithium Treatment Table of
SLIDE 2
SLIDE 3
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Table of Contents
The Biology The Model and the Math Lithium in the Model Lithium Treatment
3 / 38
SLIDE 4
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Bipolar Disorder
- Mental illness characterized by “unusual shifts in
mood, energy, activity levels, and the ability to carry
- ut day-to-day tasks” (NIMH)
- Extreme mood “episodes” tend to be between two
extreme mood-states: mania and depression (NIMH)
- The transition between extreme moods is not cyclical;
both internal and environmental stressors can trigger a mood swing
4 / 38
SLIDE 5
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Lithium as a Mood Stabilizer
- Lithium is the most commonly prescribed drug for
bipolar disorder, the only widely used mood-stabilizer
- Newer mood stabilizers are not typically as effective
(Thies-Flechtner, 1996)
- Competing hypotheses about biological mechanism
- f bipolar and how lithium corrects it
- Lithium treatment tailored to individual
5 / 38
SLIDE 6
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Proposed Mechanism
Potential Genetic Mechanism Gene Mutation High IP3 Excess Ca2+ High NT Release
Gene mutation associated with high risk of bipolar disorder causes elevated Ca2+ levels(Psychiatric Genomics Consortium, 2011)
Proposed Lithium Mechanism Lithium Inhibits IP3R action Lowers Ca2+ Decrease NT
6 / 38
SLIDE 7
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Neurons and Neurotransmitters (NT)
Neurons:
- Type of cell in the nervous system
- Carries information throughout the nervous system by
chemical and electrical signals (NINDS)
- Electrical impulse to chemical signal to electrical
impulse
Neurotransmitters:
- Chemical messengers that transmit information to a
neuron
- Norepinephrine implicated in euphoria/grandiosity,
defining characteristics of mania (Goodwin, 1974)
7 / 38
SLIDE 8
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Action Potentials (AP)
- APs are electrical impulses caused by membrane
depolarization (Bear, 84)
- Arrival of AP in terminal triggers release of NT(Bear,
122)
8 / 38
SLIDE 9
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Model Hypothesis
- Burst-frequency determines amount of NT released
(Wilkins, 232)
Assume high NT release causes mania. And lithium treat- ment works by lowering intracellular calcium which lowers burst frequency. This decreases NT release which stabi- lizes mood. Lithium Lowers Ca2+ Decrease burst freq. Decrease NT ?
9 / 38
SLIDE 10
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Table of Contents
The Biology The Model and the Math Lithium in the Model Lithium Treatment
10 / 38
SLIDE 11
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Morris-Lecar Model
dV dt = 1 C
5
(I − gcaM∞(V − Vca) − gkW(V − Vk) − gl(V − Vl))
6
dW dt = φ(W∞ − W) τW M∞(V) = 1 2
5
1 + tanh
3V − V1
V2
46
W∞(V) = 1 2
5
1 + tanh
3V − V3
V4
46
11 / 38
SLIDE 12
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Bursting in 2-D ML Model
What is a“burst”?
- “a rapid cluster of action potentials followed by a brief
pause” (Bear, 106)
- 2-D model, every action potential represents a burst
(Williams, 2013)
1
1Hayashi, 2016. Orange by Rosa 12 / 38
SLIDE 13
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Nernst Equation for Calcium
ICa = gCaM∞(V − VCa) Reversal potential is the membrane voltage at electochemical equilibrium (Bear, 68) VCa = RT 2F ln
3[Ca2+]out
[Ca2+]in
4
So, if intracellular Ca2+ concentration, [Ca2+]in, increases, the VCa would decrease
13 / 38
SLIDE 14
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Table of Contents
The Biology The Model and the Math Lithium in the Model Lithium Treatment
14 / 38
SLIDE 15
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Lithium Addition to Morris-Lecar Model
How does the addition of lithium change the model? Lithium Lowers Ca2+ Decrease burst freq. Decrease NT ? If bipolar disorder is caused by abnormal intracellular lev- els of calcium, where intracellular calcium is elevated, we would expect the reversal potential of calcium, VCa, to be lower than the average value.
SLIDE 16
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Lithium Addition to Morris-Lecar Model
How does the addition of lithium change the model? Lithium Lowers Ca2+ Decrease burst freq. Decrease NT ? Increase VCa ? If bipolar disorder is caused by abnormal intracellular lev- els of calcium, where intracellular calcium is elevated, we would expect the reversal potential of calcium, VCa, to be lower than the average value.
15 / 38
SLIDE 17
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Bifurcations
Using Vca as the bifurcation parameter
16 / 38
SLIDE 18
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Bifurcations
Emergence of Limit Cycles, VCa = 85.6 T ≈ 73.85; f ≈ .0135, for stable LC
17 / 38
SLIDE 19
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Frequency of Limit Cycle
20 40 60 80 100 120 140 160 180 200 0.011 0.0115 0.012 0.0125 0.013 0.0135 0.014 0.0145 0.015
18 / 38
SLIDE 20
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Response Function for Lithium to Vca
Vca = α tanh(.003(L(t) − 1000)) + β; α and β are scaling factors to account for physiological differences
200 400 600 800 1000 1200 1400 1600 1800 2000 60 70 80 90 100 110 120 130
19 / 38
SLIDE 21
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Table of Contents
The Biology The Model and the Math Lithium in the Model Lithium Treatment
20 / 38
SLIDE 22
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Lithium Concentration in Bloodstream
Differential equation for exponential decay: dL dt = −αL L(0) = L0 α = ln(2) 36 Solution Flow: φt(L0) = L0e−αt Ln = φτ(Ln−1) + κ
21 / 38
SLIDE 23
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Equilibrium for Lithium Concentration
FDA has the standard lithium dosage at 300 mg every 8 hours (τ = 8, κ = 300):
2 4 6 8 10 12 108 200 400 600 800 1000 1200 1400 1600 1800 2000 2200 L* t *
Where (L∗) and when (t∗) does L stabilize?
22 / 38
SLIDE 24
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Equilibrium for Lithium Concentration
FDA has the standard lithium dosage at 300 mg every 8 hours (τ = 8, κ = 300): L∗ ≈ 2097.1 mg t∗ ≈ 13 days
2 4 6 8 10 12 108 200 400 600 800 1000 1200 1400 1600 1800 2000 2200 L* t *
23 / 38
SLIDE 25
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
First 36 hours of Lithium, 5 doses
2 4 6 8 10 12 14 16 18 107 200 400 600 800 1000 1200 1400
24 / 38
SLIDE 26
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
100 200 300 400 500 600 700 800 900 1000
t
- 40
- 30
- 20
- 10
10 20
V 25 / 38
SLIDE 27
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
2 4 6 8 10 12 14 16 18 107 200 400 600 800 1000 1200 1400
26 / 38
SLIDE 28
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
100 200 300 400 500 600 700 800 900 1000
t
- 40
- 30
- 20
- 10
10 20
V 27 / 38
SLIDE 29
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
2 4 6 8 10 12 14 16 18 107 200 400 600 800 1000 1200 1400
28 / 38
SLIDE 30
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
100 200 300 400 500 600 700 800 900 1000 t
- 50
- 40
- 30
- 20
- 10
10 20 30 40 V
- 50
- 40
- 30
- 20
- 10
10 20 30 40 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5
29 / 38
SLIDE 31
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
16 days of Lithium treatment
2 4 6 8 10 12 14 108 200 400 600 800 1000 1200 1400 1600 1800 2000 2200
30 / 38
SLIDE 32
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Numerical Simulations
- 50
- 40
- 30
- 20
- 10
10 20 30 40 50 0.1 0.2 0.3 0.4 0.5 0.6 100 200 300 400 500 600 700 800 900 1000 t
- 50
- 40
- 30
- 20
- 10
10 20 30 40 50 V
31 / 38
SLIDE 33
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Frequency Plots
90 100 110 120 130 140 150 160 170 0.009 0.01 0.011 0.012 0.013 0.014 0.015 90 100 110 120 130 140 150 160 170 0.009 0.01 0.011 0.012 0.013 0.014 0.015
32 / 38
SLIDE 34
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Mood Quantification
90 100 110 120 130 140 150 160 170 0.009 0.01 0.011 0.012 0.013 0.014 0.015
33 / 38
Mania
Lithium equilibrium
SLIDE 35
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Conclusion
- Model lithium decreases the burst frequency in the
physiological ‘typical’ range by increasing the calcium reversal potential
- This decreases the amount of neurotransmitter
released by the neuron, reducing symptoms of mania
Lithium Lowers Ca2+ Decrease burst freq. Decrease NT X Increase VCa X
34 / 38
SLIDE 36
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Future Work
- Sensitivity analysis of parameters
- Determining an ‘optimal’ dosage for stability
35 / 38
SLIDE 37
The Biology The Model and the Math Lithium in the Model Lithium Treatment
References
- Bear, Mark F., Barry W. Connors, and Michael A. Paradiso. Neuroscience: Exploring the Brain. 4th ed.
Philadelphia: Wolters Kluwer, 2016.
- Dubovsky, Steven L., J. Murphy, Marshall R. Thomas, and Jonella Rademacher. ”Abnormal Intracellular
Calcium Ion Concentration in Platelets and Lymphocytes of Bipolar Patients.” American Journal of Psychiatry 149, no. 1 (1992): 118-20. doi:10.1176/ajp.149.1.118.
- El-Mallakh, Rif S. ”Ion Homeostasis and the Mechanism of Action of Lithium.” Clinical Neuroscience
Research 4, no. 3-4 (2004): 227-31. doi:10.1016/j.cnr.2004.09.014.
- FDA. Lithium Prescription Label. PDF. Federal Drug Administration, October 2016.
- Goodwin, F. K., and R. L. Sack. ”Central Dopamine Function in Affective Illness: Evidence from Precursors,
Enzyme Inhibitors, and Studies of Central Dopamine Turnover.” Advances in Biochemical Psychopharmacology 12 (1974): 261-79. https://www.ncbi.nlm.nih.gov/pubmed/4608958.
- Hayashi, Hatsuo. ”Dynamical Features of Neurons and the Brain: Chaos, Synchronization, and
Propagation.” Neuroinformatics: Dynamical Features of Neurons and the Brain. August 2016. https://dynamicbrain.neuroinf.jp/modules/mediawiki/index.php/Dynamicalfeaturesofneuronsandthebrain:Chaos,synchronization,andpropagation.
- Marmol, Frederic. ”Lithium: Bipolar Disorder and Neurodegenerative Diseases Possible Cellular
Mechanisms of the Therapeutic Effects of Lithium.” Progress in Neuro-Psychopharmacology and Biological Psychiatry 32, no. 8 (2008): 1761-771. doi:10.1016/j.pnpbp.2008.08.012.
- McCobb, David P
., and Mary Lou Zeeman. ”Bridging Between Experiments and Equations: A Tutorial on Modeling Excitability.” In Computational Neuroendocrinology. John Wiley & Sons, 2016.
- Morris, C., and H. Lecar. ”Voltage Oscillations in the Barnacle Giant Muscle Fiber.” Biophysical Journal 35,
- no. 1 (1981): 193-213. doi:10.1016/s0006-3495(81)84782-0.
36 / 38
SLIDE 38
The Biology The Model and the Math Lithium in the Model Lithium Treatment
References
- National Institute of Mental Health. ”Bipolar Disorder.” NIMH. April 2016.
https://www.nimh.nih.gov/health/topics/bipolar-disorder/index.shtml.
- National Institute of Neurological Disorders and Stroke. ”Brain Basics: The Life and Death of a Neuron.”
- NIH. November 2018.
https://www.ninds.nih.gov/Disorders/Patient-Caregiver-Education/life-and-death-neuron.
- Psychiatric GWAS Consortium Bipolar Disorder Working Group. ”Large-scale Genome-wide Association
Analysis of Bipolar Disorder Identifies a New Susceptibility Locus near ODZ4.” Nature Genetics 43 (September 2011): 977-83. https://www.nature.com/articles/ng.943.
- Thies-Flechtner, K., B. Muller-Oerlinghausen, W. Seibert, A. Walther, and W. Greil. ”Effect of Prophylactic
Treatment on Suicide Risk in Patients with Major Affective Disorders.” Pharmacopsychiatry 29, no. 03 (1996): 103-07. doi:10.1055/s-2007-979553.
- Williams, Alex H., Molly A. Kwiatkowski, Adam L. Mortimer, Eve Marder, Mary Lou Zeeman, and Patsy S.
- Dickinson. ”Animal-to-animal Variability in the Phasing of the Crustacean Cardiac Motor Pattern: An
Experimental and Computational Analysis.” Journal of Neurophysiology 109, no. 10 (2013): 2451-465. doi:10.1152/jn.01010.2012.
- Wilkins, Robert. Oxford Handbook of Medical Sciences. Oxford: Oxford Univ. Press, 2011.
37 / 38
SLIDE 39
The Biology The Model and the Math Lithium in the Model Lithium Treatment
Acknowledgments
Thank you to Mary Lou Zeeman for being the best advisor ever (even across the ocean), to the members of the Resilience group of the Mathematical Climate Research Network, and to Professor Levy and Professor Chong for their help on the project. This project was funded by NSF grant CCS-1521672, NSF grant DMS-1722578 and the Grua/O’Connell Research Fellowship.
38 / 38
