The Periprosthetic Fracture: When and How I Fix Michael B. Cross, - - PowerPoint PPT Presentation

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

The Periprosthetic Fracture: When and How I Fix

Michael B. Cross, MD Assistant Attending Orthopaedic Surgeon

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Disclosures

• Consultant:
• Smith & Nephew
• Link Orthopaedics
• Exactech Inc.
• Intellijoint
• Acelity
• Theravance Biopharma
• Zimmer Biomet
• Honorarium
• Acelity
• Editorial Board
• Techniques in Orthopaedics
• Bone and Joint Journal 360
• Journal of Orthopaedics and Traumatology

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Periprosthetic FX of the Femur after THA

• Incidence increasing
• Intraoperative Fx: Technical errors
• Postoperative Fx: Technical Errors, Loosening

and/or Osteolysis

3

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Intraoperative Periprosthetic Fracture

• More common in uncemented THA, especially

during revision THA

• Vary from 3% to 20% after uncemented hip

replacement

• Usually occur around the trochanteric/calcar

area – Single cerclage wire around the calcar – WBAT

• Distal Fx: long stem bypass and cables

4

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

The Early Postop Periprosthetic FX

• Early Postoperative fx on the rise!

Cementless implants Desire to get a tight press fit

• Rush Experience

5,313 THA over 10 years 32 Early postop fx that required surgery (0.6%) 21 Vancouver B2 fractures

Sheth, Della Valle et. al J Arthroplasty 2012

5

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Risk Factors for Early Fx

• Fractures associated with

Increasing age (6% increased risk per year) Female Sex Flat wedge taper cementless stems Dx of DDH vs. OA

6

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Intra-Operative Prevention

• Appropriate exposure!

Increased risk with “MIS” exposures Particularly in the “learning curve”

• Stop hitting the broach when it fails to advance
• Be VERY wary if the implant goes past broach

7

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Treatment for the Early Periprosthetic FX

• Cable around the calcar
• WBAT
• If not good stable fixation

with wire in place switch to diaphyseal engaging stem

• However…higher risk of

complications/reoperation – Infection – Nutrition – Skin – Brooker III/IV HO – Prevent with XRT or NSAIDs

8

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

The Late Periprosthetic FX

• 3 features of fracture classification:

 Location of fracture  Integrity of fixation  Quality of bone

9

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Type A

Fracture of the trochanter Typically associated w/ osteolysis or early post-op

10

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

“Rigid” fixation + Bearing surface exchange

Type A

11

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

• Fracture around the

prosthesis

• Stem well fixed
• Rare (be wary)
• Most common mistake is

classifying a B1 incorrectly!

Type B1

12

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Typically treated with locked plating

Type B1

13

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

 15 synthetic femurs with simulated Vancouver B1 periprosthetic FXs  3 proximal fixation methods used: (1) Bicortical screws, (2) Unicortical screws

with cables, & (3) 3 cables through plate

 Conclusion:

– Bicortical screw placement achieved the highest load to failure and the highest torsional/sagittal bending stiffness – Additional unicortical screws improved axial stiffness when using cable fixation – Lateral bending stiffness was not different between the 3 fixation groups

Ideal Construct for B1?

14

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Do you need a strut?

 Biomechanical analysis using 15 Synthetic femurs  3 constructs:

– Lateral plate only – Lateral plate and medial strut – Lateral plate and anterior strut

 Conclusion: A combination of a plate with a medial strut allograft

provides more mechanical stability on periprosthetic femoral fractures near the tip of a total hip arthroplasty

15

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Do you need a strut?

• Meta analysis of 37 manuscripts with 687 B1 fractures treated with or

without a strut allograft

• Results:

 Percent union was similar for Vancouver B1 fractures treated with or

without an allograft strut (90.7% vs. 91.5%)

 Time to union (4.4 vs. 6.6 months) and deep infection (3.8% vs. 8.3%)

were increased with use of allograft struts

• Conclusion: due to increased infection and time to union, allograft struts

should be used cautiously during operative treatment of Vancouver B1 factures

16

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

How far distal do you go?

• Moloney GB et al, 2014

 N = 58 patients with Vancouver B1  36 short plates, 21 long plates to femoral condyle  No nonunions in long plate group  3 nonunions with plate failure and reoperation in short plate group

17

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Stem is loose and must be revised

Type B2

18

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

If you don’t revise the loose stem…

Type B2

The Periprosthetic Fracture: When and How I Fix

19

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Revise with a cementless stem that bypass fx

Type B2

20

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Extended Trochanteric Osteotomy

“Why would I want to take something that is broken and create more pieces?”

• Facilitates:

 Exposure  Component and/or

cement removal

 Component insertion

21

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

• ETO to fracture site

Distal fixation achieved Fracture/Osteotomy fragments wrapped around the stem Prophylactic cerclage wire distal to osteotomy/fracture site PRIOR to reaming and stem insertion Modularity helps!

ETO for Vancouver B2

E T O

Prophylactic Cerclage

Levine et. Al, J Arthroplasty 2006

22

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

• Poor bone stock
• Little isthmus for distal

fixation

Type B3

23

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

• The majority addressed

with a modular taper

• However good results also

reported with fully porous coated monoblock stems

Paprosky 2001 Garcia CORR 2013

Occasionally consider proximal femoral replacement in elderly

Type B3

24

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Type B3 Treatment: PFR

The Periprosthetic Fracture: When and How I Fix

25

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Modular Tapered Stems for B2/B3

• Stem survival at 54 months = 96%
• No difference in survival between B2 and B3

fractures

• Tapered stems are a useful option in revision for

femoral fracture across the spectrum of femoral bone deficiency

26

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Fracture distal to stem

Type C: Locked Plates

27

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

Beware…

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

• Vancouver Classification helps guide treatment
• Be wary of the B1 (rare)
• B2 fractures are most commonly encountered

Extended osteotomy facilitates management Diaphyseal fitting stem to bypass the fracture

• B3 commonly managed with a modular taper vs

proximal femoral replacement

Conclusions

30

ADULT RECONSTRUCTION AND JOINT REPLACEMENT

THANK YOU
