The Nose in OSA Soup to Nuts Edward M. Weaver, MD, MPH University of Washington Harborview Medical Center Seattle VA Medical Center Acknowledgments This material is the result of work supported in part by resources from the VA Puget

slide-1
SLIDE 1

The Nose in OSA – Soup to Nuts

Edward M. Weaver, MD, MPH

University of Washington Harborview Medical Center Seattle VA Medical Center

slide-2
SLIDE 2

Acknowledgments

  • This material is the result of work supported in

part by resources from the VA Puget Sound Health Care System, Seattle, Washington.

  • Dr. Weaver is a staff physician, surgery service

line, Dept of Veterans Affairs Medical Center, Seattle, Washington.

slide-3
SLIDE 3

Disclosures

  • No industry disclosures
  • No off label therapies
slide-4
SLIDE 4

Notes

  • Adults
  • Split audience:

– Otolaryngologists – Others

slide-5
SLIDE 5

Topics

  • Significance of nasal obstruction and

treatment in OSA

  • Nasal evaluations, findings, therapies
slide-6
SLIDE 6

Upper Airway Anatomy

slide-7
SLIDE 7

Nasal Obstruction à Mouth Opening à

slide-8
SLIDE 8

Nasal Obstruction & CPAP Use

Nasal obstruction â CPAP use. Nasal treatment á CPAP use.

slide-9
SLIDE 9

r = 0.34 p < 0.01

Figure 5 Nasal Minimum Cross-sectional Area (cm2)

CPAP Use (hrs/nt)

Li, Sleep 2005; 28:1554-9

slide-10
SLIDE 10

Camacho, Sleep 2015; 38:279-86

Outcome Pre-Nasal Post-Nasal Pressure (cm) 11.6 ± 2.2 9.5 ± 2.0 Acceptance 39% 90% Use (hr/nt) 3.0 ± 3.1 5.5 ± 2.0 All p<0.001 *Beware *

slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13

Topics

  • Significance of nasal obstruction and

treatment in SDB

  • Nasal evaluations, findings, therapies
slide-14
SLIDE 14
  • 1. Subjective
slide-15
SLIDE 15

Subjective Instruments

  • Nasal Obstruction Symptom

Evaluation (NOSE) Scale

  • Nasal Obstruction VAS

Stewart, OtoHNS 2004; 130:157-63 Stewart, OtoHNS 2004; 130:283-90

slide-16
SLIDE 16
  • 2. Nasal Valve
slide-17
SLIDE 17
  • Point of greatest resistance

– Regulates airflow – Valve disorders important

Nasal Valve

slide-18
SLIDE 18

Nasal Valve

Septum Turbinate Upper lateral cartilage

slide-19
SLIDE 19

Rhee, OtoHNS 2010; 143:48-59

slide-20
SLIDE 20

Nasal Valve Collapse

slide-21
SLIDE 21

Cottle Test

slide-22
SLIDE 22

Nasal Pillows

slide-23
SLIDE 23

Nasal Dilator Strip

slide-24
SLIDE 24

Nasal Dilator Insert

slide-25
SLIDE 25

Nasal Medication

  • Treat intranasal congestion
  • ↑ nasal caliber → ↓ neg force

– Bernoulli’s Law

  • Indirect effect on valve collapse
slide-26
SLIDE 26

Otolaryngology Consultation

  • Nasal airway evaluation
  • Surgery evaluation
slide-27
SLIDE 27
  • 3. Nasal Cavity
slide-28
SLIDE 28

Nasal Cavity Exam

  • Speculum & headlight
  • Septum
  • Turbinates*
  • Allergy*
  • Polyps*

*Medically treatable (partial)

slide-29
SLIDE 29
slide-30
SLIDE 30

Nasal Valve Septum

slide-31
SLIDE 31

Septum Treatment

  • Surgical: Septoplasty
slide-32
SLIDE 32

Pre-Op Post-Op Septoplasty

slide-33
SLIDE 33

Turbinate Valve

slide-34
SLIDE 34

Turbinate Treatment

  • Irritant avoidance
  • Elevate head of bed
  • CPAP heated humidity
  • Nasal saline
  • Medications:

– Nasal steroid – Anti-histamine – Oral decongestant – Nasal decongestant

  • Surgery: Turbinate reduction
slide-35
SLIDE 35

Turbinate Reduction

slide-36
SLIDE 36

Turbinate Reduction

slide-37
SLIDE 37

Poiseuille’s Law

Radius4

Flow = ———— x η Length

slide-38
SLIDE 38

Allergy Treatment

  • Allergen avoidance
  • Nasal saline
  • Medications:

– Nasal steroid – Oral anti-histamine – Nasal anti-histamine – Nasal leukotriene modifiers

  • Desensitization therapy
slide-39
SLIDE 39
slide-40
SLIDE 40

Polyp Treatment

  • Allergy treatment
  • Oral steroid
  • Surgery:

– Endoscopic Polypectomy

slide-41
SLIDE 41
slide-42
SLIDE 42
  • 4. Nasal Structure
slide-43
SLIDE 43

Nasal Deformity Treatment

  • Surgical
slide-44
SLIDE 44

Columellar Reduction

Pre-Op

slide-45
SLIDE 45

Columellar Reduction

Post-Op

slide-46
SLIDE 46

Men 22 ± 2 mm Women 21 ± 2 mm

Erdem, Am J Rhinol 2004; 18:57-62

slide-47
SLIDE 47

Aperture Widening

slide-48
SLIDE 48

Weaver, Op Tech Oto 2012; 23:67-71

Nasal Valve Stabilization

slide-49
SLIDE 49

Topics

  • Nasal airway significant
  • Nasal evaluation

– Everyone can do basic evaluation – Otolaryngology for advanced eval

  • Nasal therapy

– Medications safe & available – Often helpful – Surgical treatment backup

slide-50
SLIDE 50

The Nose and OSA – Soup to Nuts

REFERENCES 1. Lee SH, Choi JH, Shin C, Lee HM, Kwon SY, Lee SH. How does open-mouth breathing influence upper airway anatomy? Laryngoscope 2007;117(6):1102-6. 2. Li HY, Engleman H, Hsu CY, et al. Acoustic reflection for nasal airway measurement in patients with obstructive sleep apnea- hypopnea syndrome. Sleep 2005;28(12):1554-9. 3. Camacho M, Riaz M, Capasso R, et al. The effect of nasal surgery on continuous positive airway pressure device use and therapeutic treatment pressures: A systematic review and meta-analysis. Sleep 2015;38(2):279-86. 4. Stewart MG, Witsell DL, Smith TL, Weaver EM, Yueh B, Hannley MT. Development and validation of the Nasal Obstruction Symptom Evaluation (NOSE) Scale. Otolaryngology-Head & Neck Surgery 2004;130(2):157-63. 5. Stewart MG, Smith TL, Weaver EM, et al. Outcomes after nasal septoplasty: Results from the Nasal Obstruction Septoplasty Effectiveness (NOSE) study. Otolaryngol Head Neck Surg 2004;130(3):283-90. 6. Rhee JS, Weaver EM, Park SS, et al. Clinical consensus statement: Diagnosis and management of nasal valve compromise. Otolaryngol Head Neck Surg 2010;143:48-59. 7. Erdem T, Ozturan O, Erdem G, Akarcay M, Miman MC. Nasal pyriform aperture stenosis in adults. Am J Rhinol 2004;18(1):57-62. 8. Weaver EM. Nasal valve stabilization. Operative Techniques in Oto 2012;23:67-71.
