The Explosive Lives of Stars: Producing Elements in the Cauldrons of the Cosmos Catherine M. Deibel Department of Physics & Astronomy Louisiana State University Conference for Women in Undergraduate Physics 01/18/14 1 13.7 Billion

slide-1
SLIDE 1

01/18/14 Conference for Women in Undergraduate Physics

The Explosive Lives of Stars:

Producing Elements in the Cauldrons of the Cosmos

Catherine M. Deibel Department of Physics & Astronomy Louisiana State University

1

slide-2
SLIDE 2

01/18/14 Conference for Women in Undergraduate Physics 2

13.7 Billion (13,700,000,000) years ago the universe began with

THE BIG BANG

slide-3
SLIDE 3

01/18/14 Conference for Women in Undergraduate Physics

The first atoms

  • A fraction (1/10,000,000,000,000,000,000,000,000,000,000)
  • f a second after the BIG BANG electrons are created

3

slide-4
SLIDE 4

01/18/14 Conference for Women in Undergraduate Physics

The first atoms

  • One millionth of a second (.000001 seconds) after the

BIG BANG protons and neutrons are formed

4

slide-5
SLIDE 5

01/18/14 Conference for Women in Undergraduate Physics

The first atoms

  • 3 minutes after the BIG BANG the first atoms form

5

slide-6
SLIDE 6

01/18/14 Conference for Women in Undergraduate Physics

After the Big Bang

6

slide-7
SLIDE 7

01/18/14 Conference for Women in Undergraduate Physics 7

Aluminum (Al) Gold (Au) Calcium (Ca) Sodium (Na) Oxygen (O) in water (H2O)

What about everything else?

slide-8
SLIDE 8

01/18/14 Conference for Women in Undergraduate Physics

Where does the rest of the Periodic Table come from?

8

slide-9
SLIDE 9
  • Adding or subtracting neutrons makes different isotopes
  • A hydrogen nucleus is one proton

– Adding one neutron to hydrogen makes the isotope deuterium – Then adding one proton makes the isotope 3He – Then adding one neutron makes the isotope 4He

  • Total number of protons (“atomic number”) = Z
  • Total number of neutrons = N
  • N + Z = A, “atomic mass number” or number of nucleons

01/18/14 Conference for Women in Undergraduate Physics 9

Beyond the Periodic Table . . .

1H

slide-10
SLIDE 10
  • Adding or subtracting neutrons makes different isotopes
  • A hydrogen nucleus is one proton

– Adding one neutron to hydrogen makes the isotope deuterium – Then adding one proton makes the isotope 3He – Then adding one neutron makes the isotope 4He

  • Total number of protons (“atomic number”) = Z
  • Total number of neutrons = N
  • N + Z = A, “atomic mass number” or number of nucleons

01/18/14 Conference for Women in Undergraduate Physics 9

H

2

Beyond the Periodic Table . . .

1H

slide-11
SLIDE 11
  • Adding or subtracting neutrons makes different isotopes
  • A hydrogen nucleus is one proton

– Adding one neutron to hydrogen makes the isotope deuterium – Then adding one proton makes the isotope 3He – Then adding one neutron makes the isotope 4He

  • Total number of protons (“atomic number”) = Z
  • Total number of neutrons = N
  • N + Z = A, “atomic mass number” or number of nucleons

01/18/14 Conference for Women in Undergraduate Physics 9

H

2

He

3

Beyond the Periodic Table . . .

1H

slide-12
SLIDE 12
  • Adding or subtracting neutrons makes different isotopes
  • A hydrogen nucleus is one proton

– Adding one neutron to hydrogen makes the isotope deuterium – Then adding one proton makes the isotope 3He – Then adding one neutron makes the isotope 4He

  • Total number of protons (“atomic number”) = Z
  • Total number of neutrons = N
  • N + Z = A, “atomic mass number” or number of nucleons

01/18/14 Conference for Women in Undergraduate Physics 9

H

2

He

3

Beyond the Periodic Table . . .

1H

He

4

protons + neutrons

AX or Z AX

slide-13
SLIDE 13

01/18/14 Conference for Women in Undergraduate Physics

  • Keep adding protons and neutrons to make

thousands of isotopes

10

Beyond the Periodic Table . . .

slide-14
SLIDE 14

01/18/14 Conference for Women in Undergraduate Physics

Where does the rest of the Periodic Table come from?

11

slide-15
SLIDE 15

01/18/14 Conference for Women in Undergraduate Physics

Where does the rest of the Periodic Table come from?

11

slide-16
SLIDE 16

01/18/14 Conference for Women in Undergraduate Physics 12

Different Nuclei are produced in different stars

slide-17
SLIDE 17

01/18/14 Conference for Women in Undergraduate Physics

!" D.K. Galloway et al., ApJ 601 466 (2004).

slide-18
SLIDE 18

01/18/14 Conference for Women in Undergraduate Physics

Neutron Stars

  • Neutron stars are extremely compact,

dense objects (! ~ 1014 g/cm2)

14

slide-19
SLIDE 19

01/18/14 Conference for Women in Undergraduate Physics

Neutron Stars

  • Neutron stars are extremely compact,

dense objects (! ~ 1014 g/cm2)

14

slide-20
SLIDE 20

01/18/14 Conference for Women in Undergraduate Physics

!# D.K. Galloway et al., ApJ 601 466 (2004).

slide-21
SLIDE 21

01/18/14 Conference for Women in Undergraduate Physics

X-Ray Burst Nucleosynthesis

18

Z N Z-1 N Z-1 N+1 Z N+1 Z+1 N+1 Z+2 N+1 Z+1 N Z+2 N Z N+2 Z+1 N+2 Z+2 N+2 Proton decay: (γ,p) Alpha capture: Proton capture: (p,γ) Beta decay: (β+) (α,p) (α,γ)

slide-22
SLIDE 22

01/18/14 Conference for Women in Undergraduate Physics

X-Ray Burst Nucleosynthesis

19

www.jinaweb.org

slide-23
SLIDE 23

01/18/14 Conference for Women in Undergraduate Physics

How do nuclei react?

  • $%&'()*(a reaction rate?

(i.e. What is the probability of two nuclei reacting in the stellar plasma?)

  • Thermal distribution of nuclei in

stellar plasma: Maxwell-Boltzmann distribution

  • The probability of the interaction

between two nuclei: nuclear cross section

  • Temperature dependent - difgerent

temperatures in stars probe difgerent energies in nucleus

20

slide-24
SLIDE 24

01/18/14 Conference for Women in Undergraduate Physics

Reaction Rates

  • !"#$%&'()*+(!"#$%&&'()&*+,"--./01*20345)-(%&(,%)*()*+(
  • 46&%"2.62)11.1%65)-..'%-+.()*+(2%"65)-.2"*%
  • !"/(/+."&0&)(/+012"&(/0)+.3
  • ! exp(-E)
  • ! nuclear spin, J
  • ! nuclear widths, "
  • 4,"(,05.()"(.)6$5(/+012"&.(/0)+.(0&$(1/"..(.+12"&.3
  • 7%/+1)#58(9+0.6/%&'()*+(/+012"&(/0)+(%).+#:
  • ;&$%/+1)#58($+)+/9%&%&'($%<+/+&)(1"9="&+&).(":()*+(

/+012"&(/0)+

  • +>'>("+?(@!A=B""C#

21

30S 34Ar 33Cl

α p0,1,2

g.s. g.s. g.s. Ex, J

slide-25
SLIDE 25
  • Using accelerators with different types of detectors we can

measure what nuclear reactions happen in stars

  • A particle beam is accelerated and impinges on a target
  • Outgoing particles are detected

01/18/14 Conference for Women in Undergraduate Physics 22

Studying Nuclear Reactions in the Laboratory

DETECTOR beam " target

slide-26
SLIDE 26

01/18/14 Conference for Women in Undergraduate Physics 23

Studying Nuclear Reactions in the Laboratory

  • Charged particles can be manipulated

by magnetic fields and separated by

– charge – mass – energy

  • Detected using

– ionization chambers – silicon detectors – CsI detectors – gamma detectors

slide-27
SLIDE 27

Prototype Si array Si array Recoil Detector Target fan Beam

01/18/14 Conference for Women in Undergraduate Physics

HELIcal Orbit Spectrometer

  • Beam of radioactive nuclei directed

through center of solenoid

  • Impinges on a target of light nuclei (e.g.

hydrogen, helium, etc.)

  • Reaction products measured by detectors
  • Reaction products tell us:

– excitation energy levels – spins of levels – reaction rate information

24

Excited States in 18O (MeV)

States in 18O from

14O(6Li,d)18O

slide-28
SLIDE 28

01/18/14 Conference for Women in Undergraduate Physics

33Cl(p,!)30S

Measurement

25 Rotatable arm

slide-29
SLIDE 29

(!,p)-process waiting points:

30S(!,p)33Cl Measurement

01/18/14 Conference for Women in Undergraduate Physics 101 100 102 4 5 6

  • c. m. Energy (MeV)

Cross Section (mb) (!0,p) NON-SMOKER converted (!0,p0) data (b)

  • (!,p) reactions on waiting points

(22Mg, 26Si, 30S, and 34Ar) may have significant effects on type I X-ray bursts

– final elemental abundances – energy generation – double-peaked luminosity profiles

  • Measured cross sections

(probability of reacting) larger than theoretical predictions:

– reaction rate is bigger!

26

C.M. Deibel ett al, submitted (2011).

30S(!0,p)33Cl

J.L. Fisker et al.,ApJ 608, L61 (2004).

slide-30
SLIDE 30

01/18/14 Conference for Women in Undergraduate Physics

Experiments for X-ray bursts

27

Up to 1300 cm2 of 1-mm-thick Si backed with 2-cm-thick CsI Annular array for forward/ backward angles Annular gas proportional counter surrounds beam axis Active target+detector Up to 3 rings of 12 modules in barrel formation

ANASEN IC

Array for Nuclear Astrophysics Studies with Exotic Nuclei (ANASEN)

slide-31
SLIDE 31

01/18/14 Conference for Women in Undergraduate Physics 28

slide-32
SLIDE 32
  • Supernova models don’t explode
  • We don’t know where all the heavy

elements are made

  • Most reactions that happen in stars

have not been studied

01/18/14 Conference for Women in Undergraduate Physics

Embarrassing truths about NA

a.k.a. why we stay employed

29

Cowan & Sneden, Nature 440 (2006) 1151.

Z>55 pattern matches solar

slide-33
SLIDE 33

01/18/14 Conference for Women in Undergraduate Physics

  • Supernova models don’t explode
  • We don’t know where all the heavy

elements are made

  • Most reactions that happen in stars

have not been studied

  • But the future is bright . . .

30

Embarrassing truths about NA

a.k.a. why we stay employed

slide-34
SLIDE 34

01/18/14 Conference for Women in Undergraduate Physics

  • Supernova models don’t explode
  • We don’t know where all the heavy

elements are made

  • Most reactions that happen in stars

have not been studied

  • But the future is bright . . .

30

Embarrassing truths about NA

a.k.a. why we stay employed

slide-35
SLIDE 35

01/18/14 Conference for Women in Undergraduate Physics

Thanks!

Blackmon Rascoe Zganjar Lai Williams Macon Lauer Afanasieva Linhardt

Gardiner
