The Energy Sciences Network BESAC August 2004 William E. Johnston, - - PowerPoint PPT Presentation

1

The Energy Sciences Network BESAC August 2004

William E. Johnston, ESnet Dept. Head and Senior Scientist

• R. P. Singh, Federal Project Manager

Michael S. Collins, Stan Kluz, Joseph Burrescia, and James V. Gagliardi, ESnet Leads Gizella Kapus, Resource Manager and the ESnet Team Lawrence Berkeley National Laboratory Mary Anne Scott Program Manager Advanced Scientific Computing Research Office of Science Department of Energy

2

What is ESnet?

• Mission:
• Provide, interoperable, effective and reliable

communications infrastructure and leading-edge network services that support missions of the Department of Energy, especially the Office of Science

• Vision:
• Provide seamless and ubiquitous access, via shared

collaborative information and computational environments, to the facilities, data, and colleagues needed to accomplish their goals.

• Role:
• A component of the Office of Science infrastructure critical

to the success of its research programs (program funded through ASCR/MICS; managed and operated by ESnet staff at LBNL).

3

Why is ESnet important?

• Enables thousands of DOE, university and industry

scientists and collaborators worldwide to make effective use of unique DOE research facilities and computing resources independent of time and geographic location

• Direct connections to all major DOE sites
• Access to the global Internet (managing 150,000 routes at 10

commercial peering points)

• User demand has grown by a factor of more than 10,000 since

its inception in the mid 1990’s—a 100 percent increase every year since 1990

• Capabilities not available through commercial networks
• Architected to move huge amounts of data between a small

number of sites

• High bandwidth peering to provide access to US, European, Asia-

Pacific, and other research and education networks.

Objective: Support scientific research Support scientific research by providing seamless and ubiquitous access to the facilities, data, and colleagues

4

How is ESnet Managed?

• A community endeavor
• Strategic guidance from the OSC programs
• Energy Science Network Steering Committee (ESSC)

– BES represented by Nestor Zaluzec, ANL and Jeff Nichols, ORNL

• Network operation is a shared activity with the community
• ESnet Site Coordinators Committee
• Ensures the right operational “sociology” for success
• Complex and specialized – both in the network

engineering and the network management – in order to provide its services to the laboratories in an integrated support environment

• Extremely reliable in several dimensions

Taken together these points make ESnet a unique

facility supporting DOE science that is quite different from a commercial ISP or University network

5

…what now???

VISION - A scalable, secure, integrated network network environment environment for ultra-scale distributed science is being developed to make it possible to combine resources and expertise to address complex questions that no single institution could manage alone.

• Network Strategy

Production network

• Base TCP/IP services; +99.9% reliable

High-impact network

• Increments of 10 Gbps; switched lambdas (other solutions); 99%

reliable

Research network

• Interfaces with production, high-impact and other research

networks; start electronic and advance towards optical switching; very flexible [UltraScience Net]

• Revisit governance model
• SC-wide coordination
• Advisory Committee involvement

6

Where do you come in?

• Early identification of requirements
• Evolving programs
• New facilities
• Participation in management activities
• Interaction with BES representatives on ESSC
• Next ESSC meeting on Oct 13-15 in DC area

7

What Does ESnet Provide?

• A network connecting DOE Labs and their collaborators that

is critical to the future process of science

• An architecture tailored to accommodate DOE’s large-scale

science

• move huge amounts of data between a small number of sites
• High bandwidth access to DOE’s primary science

collaborators: Research and Education institutions in the US, Europe, Asia Pacific, and elsewhere

• Full access to the global Internet for DOE Labs
• Comprehensive user support, including “owning” all trouble

tickets involving ESnet users (including problems at the far end of an ESnet connection) until they are resolved – 24x7 coverage

• Grid middleware and collaboration services supporting

collaborative science

• trust, persistence, and science oriented policy

8

What is ESnet Today?

• ESnet builds a comprehensive IP network

infrastructure (routing, IPv6, and IP multicast) on commercial circuits

• ESnet purchases telecommunications services ranging

from T1 (1 Mb/s) to OC192 SONET (10 Gb/s) and uses these to connect core routers and sites to form the ESnet IP network

• ESnet purchases peering access to commercial networks

to provide full Internet connectivity

• Essentially all of the national data traffic supporting

US science is carried by two networks – ESnet and Internet-2 / Abilene (which plays a similar role for the university community)

9

How Do Networks Work?

• Accessing a service, Grid or otherwise, such as a

Web server, FTP server, etc., from a client computer and client application (e.g. a Web browser_ involves

• Target host names
• Host addresses
• Service identification
• Routing

10

How Do Networks Work?

LBNL Google, Inc. ESnet (Core network) Big ISP (e.g. SprintLink)

gateway router router router router router router core router router peering router core router border router

border/gateway routers

• implement separate site and network

provider policy (including site firewall policy) peering routers Exchange reachability information (“routes”)

• implement/enforce

routing policy for each provider

• provide cyberdefense

router router

core routers

• focus on high-

speed packet forwarding

peering router DNS

11

ESnet Core is a High-Speed Optical Network

10GE 10GE

RTR RTR

• ptical

fiber ring Wave division multiplexing

• today typically 64 x 10 Gb/s
• ptical channels per fiber
• channels (referred to as

“lambdas”) are usually used in bi-directional pairs

Lambda channels are converted to electrical channels

• usually SONET data framing
• r Ethernet data framing
• can be clear digital channels

(no framing – e.g. for digital HDTV)

ESnet IP router Site IP router Site – ESnet network policy demarcation (“DMZ”) site LAN ESnet site ESnet hub ESnet core

RTR RTR RTR RTR

A ring topology network is inherently reliable – all single point failures are mitigated by routing traffic in the other direction around the ring.

TWC JGI

SNLL LBNL SLAC

YUCCA MT

BECHTEL

PNNL

LIGO INEEL

LANL SNLA

Allied Signal

PANTEX

ARM KCP NOAA OSTI ORAU SRS

ORNL JLAB PPPL

ANL-DC INEEL-DC ORAU-DC

LLNL/LANL-DC

MIT ANL BNL FNAL AMES

4xLAB-DC

NERSC

NREL

ALB HUB

LLNL

GA

DOE-ALB SDSC

Japan

GTN&NNSA

International (high speed) OC192 (10G/s optical) OC48 (2.5 Gb/s optical) Gigabit Ethernet (1 Gb/s) OC12 ATM (622 Mb/s) OC12 OC3 (155 Mb/s) T3 (45 Mb/s) T1-T3 T1 (1 Mb/s)

Office Of Science Sponsored (22) NNSA Sponsored (12) Joint Sponsored (3) Other Sponsored (NSF LIGO, NOAA) Laboratory Sponsored (6)

QWEST ATM

42 end user sites

ESnet IP

GEANT

• Germany
• France
• Italy
• UK
• etc

Sinet (Japan) Japan – Russia(BINP) CA*net4 MREN Netherlands Russia StarTap Taiwan (ASCC) CA*net4 KDDI (Japan) France Switzerland Taiwan (TANet2) Australia CA*net4 Taiwan (TANet2) Singaren

ESnet core: Packet over SONET Optical Ring and Hubs

ELP HUB S N V H U B C H I H U B NYC HUB

ATL HUB

D C H U B

peering points

MAE-E S t a r l i g h t Chi NAP Fix-W PAIX-W MAE-W NY-NAP PAIX-E Euqinix

P N W G

S E A H U B

ESnet Provides Full Internet Service to DOE Facilities and Collaborators with High-Speed Access to all Major Science Collaborators

hubs

S N V H U B

Abilene Abilene

high-speed peering points

Abilene Abilene M A N L A N A b i l e n e

CERN

STARLIGHT

MAE-E

NY-NAP

PAIX-E GA LBNL

ESnet’s Peering Infrastructure Connects the DOE Community With its Collaborators

ESnet Peering (connections to

• ther networks)

NYC HUBS SEA HUB Japan SNV HUB MAE-W FIX-W PAIX-W 26 PEERS CA*net4

CERN

MREN Netherlands Russia StarTap Taiwan (ASCC) Abilene + 7 Universities 22 PEERS MAX GPOP GEANT

• Germany
• France
• Italy
• UK
• etc

SInet (Japan) KEK Japan – Russia (BINP) Australia CA*net4 Taiwan (TANet2) Singaren 20 PEERS 3 PEERS LANL TECHnet 2 PEERS 39 PEERS CENIC SDSC PNW-GPOP CalREN2

C H I N A P

Distributed 6TAP 19 Peers 2 PEERS KDDI (Japan) France EQX-ASH 1 PEER 1 PEER 5 PEERS

ESnet provides access to all of the Internet by managing the full complement of Global Internet routes (about 150,000) at 10 general/commercial peering points + high-speed peerings w/ Abilene and the international R&E networks. This is a lot

• f work, and is very visible, but provides full access for DOE.

ATL HUB

University International Commercial Abilene

EQX-SJ

Abilene

6 PEERS

Abilene

14

AS routes peer 1239 701 209 3356 3561 7018 2914 3549 5511 174 6461 7473

3491

11537 5400 4323 4200 6395 2828 7132 SPRINTLINK 63384 51685 47063 41440 35980 28728 19723 17369 8190 5492 5032 4429 3529 3327 3321 2774 2475 2408 2383 UUNET- ALTERNET QWEST LEVEL3 CABLE- WIRELESS ATT-WORLDNET VERIO GLOBALCENTER OPENTRANSIT COGENTCO ABOVENET SINGTEL CAIS ABILENE BT TWTELECOM ALERON BROADWING XO 1961 SBC

What is Peering?

• Peering points

exchange routing information that says “which packets I can get closer to their destination”

• ESnet daily peering

report (top 20 of about 100)

• This is a lot of work

peering with this outfit is not random, it carries routes that ESnet needs (e.g. to the Russian Backbone Net)

15

What is Peering?

• Why so many routes?

So that when I want to get to someplace out of the ordinary, I can get there. For example: http://www-sbras.nsc.ru/eng/sbras/copan/microel_main.html (Technological Design Institute of Applied Microelectronics, Novosibirsk, Russia)

Peering routers Start: 134.55.209.5 134.55.209.90 63.218.6.65 63.218.6.38 63.216.0.53 63.216.0.30 63.218.12.37 63.218.13.134 195.209.14.29 195.209.14.153 195.209.14.206 Finish: 194.226.160.10 ESnet core snv-lbl-oc48.es.net snvrt1-ge0-snvcr1.es.net pos3-0.cr01.sjo01.pccwbtn.net pos5-1.cr01.chc01.pccwbtn.net pos6-1.cr01.vna01.pccwbtn.net pos5-3.cr02.nyc02.pccwbtn.net pos6-0.cr01.ldn01.pccwbtn.net rbnet.pos4-1.cr01.ldn01.pccwbtn.net MSK-M9-RBNet-5.RBNet.ru MSK-M9-RBNet-1.RBNet.ru NSK-RBNet-2.RBNet.ru ESnet peering at Sunnyvale AS3491 CAIS Internet “ “ “ “ “ “ “ “ AS3491->AS5568 (Russian Backbone Network) peering point Russian Backbone Network “ “ “ “ Novosibirsk-NSC-RBNet.nsc.ru RBN to AS 5387 (NSCNET-2)

16

Organized by Office

• f Science

Mary Anne Scott, Chair Dave Bader Steve Eckstrand Marvin Frazier Dale Koelling Vicky White

Workshop Panel Chairs

Ray Bair and Deb Agarwal Bill Johnston and Mike Wilde Rick Stevens Ian Foster and Dennis Gannon Linda Winkler and Brian Tierney Sandy Merola and Charlie Catlett

August 13-15, 2002

Predictive Drivers for the Evolution of ESnet

• The network and middleware requirements to support DOE

science were developed by the OSC science community representing major DOE science disciplines

• Climate
• Spallation Neutron Source
• Macromolecular Crystallography
• High Energy Physics
• Magnetic Fusion Energy Sciences
• Chemical Sciences
• Bioinformatics

Available at www.es.net/#research

The network is needed for:

• long term (final stage) data analysis
• “control loop” data analysis (influence an

experiment in progress)

• distributed, multidisciplinary simulation

17

The Analysis was Driven by the Evolving Process of Science

Feature Requirements Discipline Characteristics that Motivate High Speed Nets

• A few data repositories, many

distributed computing sites

• NCAR - 20 TBy
• NERSC - 40 TBy
• ORNL - 40 TBy
• Add many simulation

elements/components as understanding increases

• 100 TBy / 100 yr generated

simulation data, 1-5 PBy / yr (just at NCAR)

• Distribute large chunks of data

to major users for post- simulation analysis

• 5-10 PBy/yr (at NCAR)
• Add many diverse simulation

elements/components, including from other disciplines - this must be done with distributed, multidisciplinary simulation

• Virtualized data to reduce storage

load Networking

Climate

(near term) Analysis of model data by selected communities that have high speed networking (e.g. NCAR and NERSC)

• Authenticated data

streams for easier site access through firewalls

• Server side data

processing (computing and cache embedded in the net)

• Information servers for

global data catalogues

• Reliable data/file

transfer (across system / network failures) Middleware

• Quality of service

guarantees for distributed, simulations

• Virtual data catalogues

and work planners for reconstituting the data

• n demand

Climate

(5 yr) Enable the analysis of model data by all of the collaborating community

• Robust access to

large quantities of data

Climate

(5-10 yr) Integrated climate simulation that includes all high-impact factors

• Robust networks

supporting distributed simulation - adequate bandwidth and latency for remote analysis and visualization of massive datasets

Vision for the Future Process of Science

analysis was driven by

18

Evolving Quantitative Science Requirements for Networks

Science Areas Today End2End Throughput 5 years End2End Throughput 5-10 Years End2End Throughput Remarks High Energy Physics 0.5 Gb/s 100 Gb/s 1000 Gb/s high bulk throughput Climate (Data & Computation) 0.5 Gb/s 160-200 Gb/s N x 1000 Gb/s high bulk throughput SNS NanoScience Not yet started 1 Gb/s 1000 Gb/s + QoS for control channel remote control and time critical throughput Fusion Energy 0.066 Gb/s (500 MB/s burst) 0.198 Gb/s (500MB/ 20 sec. burst) N x 1000 Gb/s time critical throughput Astrophysics 0.013 Gb/s (1 TBy/week) N*N multicast 1000 Gb/s computational steering and collaborations Genomics Data & Computation 0.091 Gb/s (1 TBy/day) 100s of users 1000 Gb/s + QoS for control channel high throughput and steering

19

Observed Drivers for ESnet Evolution

• Are we seeing the predictions of two years ago

come true?

• Yes!

20

50 100 150 200 250 300 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004

OSC Traffic Increases by 1.9-2.0 X Annually

Annual growth in the past five years has increased from 1.7x annually to just

• ver 2.0x annually.

TBytes/Month ESnet is currently transporting about 250 terabytes/mo. (250,000,000 MBy/mo.) ESnet Monthly Accepted Traffic

21

Fermilab (US) → CERN SLAC (US) → IN2P3 (FR) 1 Terabyte/day SLAC (US) → INFN Padva (IT)

Fermilab (US) → U. Chicago (US) CEBAF (US) → IN2P3 (FR) INFN Padva (IT) → SLAC (US)

• U. Toronto (CA) → Fermilab (US)

Helmholtz-Karlsruhe (DE)→ SLAC (US) DOE Lab → DOE Lab DOE Lab → DOE Lab SLAC (US) → JANET (UK) Fermilab (US) → JANET (UK) Argonne (US) → Level3 (US) Argonne → SURFnet (NL) IN2P3 (FR) → SLAC (US)

Fermilab (US) → INFN Padva (IT)

A small number

• f science users

account for a significant fraction of all ESnet traffic

Since BaBar data analysis started, the top 20 ESnet flows have consistently accounted for > 50% of ESnet’s monthly total traffic (~130 of 250 TBy/mo)

ESnet Top 20 Data Flows, 24 hr. avg., 2004-04-20

ESnet is Engineered to Move a Lot of Data

FNAL (US) → IN2P3 (FR) 2.2 Terabytes

SLAC (US) → INFN Padua (IT) 5.9 Terabytes

• U. Toronto (CA) → Fermilab (US)

0.9 Terabytes SLAC (US)→ Helmholtz-Karlsruhe (DE) 0.9 Terabytes SLAC (US) → IN2P3 (FR) 5.3 Terabytes

CERN → FNAL (US) 1.3 Terabytes FNAL (US) → U. Nijmegen (NL) 1.0 Terabytes

FNAL (US)→ Helmholtz-Karlsruhe (DE) 0.6 Terabytes

FNAL (US)→ SDSC (US) 0.6 Terabytes

• U. Wisc. (US)→ FNAL (US

0.6 Terabytes

The traffic is not transient: Daily and weekly averages are about the same. SLAC is a prototype for what will happen when Climate, Fusion, SNS, Astrophysics, etc., start to ramp up the next generation science

ESnet Top 10 Data Flows, 1 week avg., 2004-07-01

23

ESnet is a Critical Element of Large-Scale Science

• ESnet is a critical part of the large-scale science

infrastructure of high energy physics experiments, climate modeling, magnetic fusion experiments, astrophysics data analysis, etc.

• As other large-scale facilities – such as SNS – turn
• n, this will be true across DOE

24

Science Mission Critical Infrastructure

• ESnet is a visible and critical piece of general DOE science

infrastructure

• if ESnet fails, tens of thousands of DOE and University users know it

within minutes if not seconds

• Requires high reliability and high operational security in the
• network operations, and
• ESnet infrastructure support – the systems that support the operation

and management of the network and services

• Secure and redundant mail and Web systems are central to the operation

and security of ESnet

– trouble tickets are by email – engineering communication by email – engineering database interface is via Web

• Secure network access to Hub equipment
• Backup secure telephony access to all routers
• 24x7 help desk (joint w/ NERSC) and 24x7 on-call network engineers

Automated, real-time monitoring of traffic levels and operating state of some 4400 network entities is the primary network

• perational and diagnosis tool

Network Configuration OSPF Metrics (routing and connectivity) Performance SecureNet IBGP Mesh (routing and connectivity) Hardware Configuration

26

ESnet’s Physical Infrastructure

Picture detail

Equipment rack detail at NYC Hub, 32 Avenue of the Americas (one

• f ESnet’s

core optical ring sites)

27 Cisco 7206 AOA-AR1 (low speed links to MIT & PPPL) ($38,150 list) Juniper M20 AOA-PR1 (peering RTR) ($353,000 list)

Juniper T320 AOA-CR1 (Core router) ($1,133,000 list)

Juniper OC192 Optical Ring Interface (the AOA end of the OC192 to CHI ($195,000 list) Juniper OC48 Optical Ring Interface (the AOA end of the OC48 to DC-HUB ($65,000 list)

AOA Performance Tester ($4800 list) Qwest DS3 DCX DC / AC Converter ($2200 list) Lightwave Secure Terminal Server ($4800 list)

ESnet core equipment @ Qwest 32 AofA HUB NYC, NY (~$1.8M, list)

Sentry power 48v 30/60 amp panel ($3900 list) Sentry power 48v 10/25 amp panel ($3350 list)

Typical Equipment of an ESnet Core Network Hub

28 LBNL PPPL BNL AMES

Remote Engineer

• partial duplicate

infrastructure

DNS

Remote Engineer

• partial duplicate

infrastructure

TWC

Remote Engineer

Disaster Recovery and Stability

• The network must be kept available even if, e.g., the West Coast

is disabled by a massive earthquake, etc.

ATL HUB

SEA HUB ALB HUB

NYC HUBS DC HUB E L P H U B CHI HUB SNV HUB

Duplicate Infrastructure Currently deploying full replication of the NOC databases and servers and Science Services databases in the NYC Qwest carrier hub Engineers, 24x7 Network Operations Center, generator backed power

• Spectrum (net mgmt system)
• DNS (name – IP address

translation)

• Eng database
• Load database
• Config database
• Public and private Web
• E-mail (server and archive)
• PKI cert. repository and

revocation lists

• collaboratory authorization

service

Reliable operation of the network involves

• remote NOCs
• replicated support infrastructure
• generator backed UPS power at all critical

network and infrastructure locations

• non-interruptible core - ESnet core
• perated without interruption through
• N. Calif. Power blackout of 2000
• the 9/11/2001 attacks, and
• the Sept., 2003 NE States power blackout

29

ESnet WAN Security and Cyberattack Defense

• Cyber defense is a new dimension of ESnet security
• Security is now inherently a global problem
• As the entity with a global view of the network, ESnet has an

important role in overall security

30 minutes after the Sapphire/Slammer worm was released, 75,000 hosts running Microsoft's SQL Server (port 1434) were infected.

(“The Spread of the Sapphire/Slammer Worm,” David Moore (CAIDA & UCSD CSE), Vern Paxson (ICIR & LBNL), Stefan Savage (UCSD CSE), Colleen Shannon (CAIDA), Stuart Staniford (Silicon Defense), Nicholas Weaver (Silicon Defense & UC Berkeley EECS) http://www.cs.berkeley.edu/~nweaver/sapphire ) Jan., 2003

30

ESnet and Cyberattack Defense

Sapphire/Slammer worm infection hits creating almost a full Gb/s (1000 megabit/sec.) traffic spike on the ESnet backbone

31

Cyberattack Defense LBNL ESnet

router router border router

X

peering router

Lab Lab

gateway router

ESnet second response – filter traffic from outside of ESnet Lab first response – filter incoming traffic at their ESnet gateway router ESnet third response – shut down the main peering paths and provide only limited bandwidth paths for specific “lifeline” services

X

peering router gateway router border router router attack traffic

X

ESnet first response – filters to assist a site

Sapphire/Slammer worm infection created a Gb/s of traffic on the ESnet core until filters were put in place (both into and out of sites) to damp it out.

Science Services: Support for Shared, Collaborative Science Environments

• X.509 identity certificates and Public Key

Infrastructure provides the basis of secure, cross- site authentication of people and systems (www.doegrids.org)

• ESnet negotiates the cross-site, cross-organization, and

international trust relationships to provide policies that are tailored to collaborative science in order to permit sharing computing and data resources, and other Grid services

• Certification Authority (CA) issues certificates after

validating request against policy

• This service was the basis of the first routine sharing of

HEP computing resources between US and Europe

33

Science Services: Public Key Infrastructure

* Report as of July 15,2004

34

Voice, Video, and Data Tele-Collaboration Service

• Another highly successful ESnet Science Service is

the audio, video, and data teleconferencing service to support human collaboration

• Seamless voice, video, and data teleconferencing is

important for geographically dispersed scientific collaborators

• ESnet currently provides to more than a thousand DOE

researchers and collaborators worldwide

• H.323 (IP) videoconferences (4000 port hours per month and rising)
• audio conferencing (2500 port hours per month) (constant)
• data conferencing (150 port hours per month)
• Web-based, automated registration and scheduling for all of these

services

• Huge cost savings for the Labs

35

ESnet’s Evolution over the Next 10-20 Years

• Upgrading ESnet to accommodate the anticipated increase

from the current 100%/yr traffic growth to 300%/yr over the next 5-10 years is priority number 7 out of 20 in DOE’s “Facilities for the Future of Science – A Twenty Year Outlook”

• Based on the requirements of the OSC Network Workshops,

ESnet must address

• Capable, scalable, and reliable production IP networking
• University and international collaborator connectivity
• Scalable, reliable, and high bandwidth site connectivity
• Network support of high-impact science
• provisioned circuits with guaranteed quality of service

(e.g. dedicated bandwidth)

• Science Services to support Grids, collaboratories, etc

36

New ESnet Architecture to Accommodate OSC

• The future requirements cannot be met with the

current, telecom provided, hub and spoke architecture of ESnet

• The core ring has good capacity and resiliency

against single point failures, but the point-to-point tail circuits are neither reliable nor scalable to the required bandwidth

ESnet Core

New York (AOA) C h i c a g

• (

C H I ) Sunnyvale (SNV) Atlanta (ATL) Washington, DC (DC) El Paso (ELP) DOE sites

37

S C I C&C

instrument compute storage cache & compute

Evolving Requirements for DOE Science Network Infrastructure

C S C C S I C S C C S I C S C C S I

C&C C&C C&C C&C C&C C&C

C S C C S I

C&C C&C C&C C&C C&C C&C

1-40 Gb/s, end-to-end

guaranteed bandwidth paths

100-200 Gb/s, end-to-end

• In the near term applications

need higher bandwidth

• high bandwidth
• QoS
• high bandwidth and QoS
• network resident cache and compute

elements

• robust bandwidth (multiple paths)
• high bandwidth and QoS
• network resident cache and compute

elements

1-3 yr Requirements 3-5 yr Requirements 2-4 yr Requirements 4-7 yr Requirements

38

A New Architecture

• With the current architecture ESnet cannot address
• the increasing reliability requirements
• the long-term bandwidth needs

(incrementally increasing tail circuit bandwidth is too expensive – it will not scale to what OSC needs)

• LHC will need dedicated 10 Gb/s into and out of FNAL and BNL
• ESnet can benefit from
• Engaging the research and education networking

community for advanced technology

• Leveraging the R&E community investment in fiber and

networks

39

A New Architecture

• ESnet new architecture goals: full redundant

connectivity for every site and high-speed access for every site (at least 10 Gb/s)

• Three part strategy

1) MAN rings provide dual site connectivity and much higher site-to-core bandwidth 2) A second core will provide

• multiply connected MAN rings for protection against hub failure
• extra core capacity
• a platform for provisioned, guaranteed bandwidth circuits
• alternate path for production IP traffic
• carrier neutral hubs

3) a high-reliability IP core (like the current ESnet core)

40

A New ESnet Architecture

Europe Asia- Pacific

ESnet Existing Core

New York (AOA) C h i c a g

• (

C H I ) Sunnyvale (SNV) Washington, DC (DC) El Paso (ELP) DOE/OSC Labs New hubs Existing hubs

2nd Core (e.g. NLR)

Possible new hubs Atlanta (ATL)

Metropolitan Area Rings

41

ESnet Beyond FY07

DEN DEN ELP ELP ALB ALB ATL ATL

MANs High-speed cross connects with Internet2/Abilene Major DOE Office of Science Sites

Japan CERN Europe SDG SDG AsiaPac SEA SEA

NLR – ESnet hubs Qwest – ESnet hubs

SNV SNV Europe

10Gb/s 30Bg/s 40Gb/s

Japan CHI CHI

High-impact science core Lab supplied Major international 2.5 Gbs 10 Gbs Future phases Production IP ESnet core

DC DC Japan NYC NYC

42

Conclusions

• ESnet is an infrastructure that is critical to DOE’s

science mission

• Focused on the Office of Science Labs, but serves

many other parts of DOE

• ESnet is working hard to meet the current and future

networking need of DOE mission science in several ways:

• Evolving a new high speed, high reliability, leveraged

architecture

• Championing several new initiatives which will keep

ESnet’s contributions relevant to the needs of our community

43

Reference -- Planning Workshops

• High Performance Network Planning Workshop, August 2002

http://www.doecollaboratory.org/meetings/hpnpw

• DOE Workshop on Ultra High-Speed Transport Protocols and Network

Provisioning for Large-Scale Science Applications, April 2003

http://www.csm.ornl.gov/ghpn/wk2003

• Science Case for Large Scale Simulation, June 2003

http://www.pnl.gov/scales/

• DOE Science Networking Roadmap Meeting, June 2003

http://www.es.net/hypertext/welcome/pr/Roadmap/index.html

• Workshop on the Road Map for the Revitalization of High End

Computing, June 2003

http://www.cra.org/Activities/workshops/nitrd http://www.sc.doe.gov/ascr/20040510_hecrtf.pdf (public report)

• ASCR Strategic Planning Workshop, July 2003

http://www.fp-mcs.anl.gov/ascr-july03spw

• Planning Workshops-Office of Science Data-Management Strategy,

March & May 2004

• http://www-conf.slac.stanford.edu/dmw2004 (report coming soon)
