The EGI AAI “CheckIn” Service

Kostas Koumantaros- GRNET

On behalf of EGI-Engage JRA1.1

2

EGI CheckIn Goals

EGI Services EGI CheckIn IdP Attribute Authority EGI UID First name, last name email affiliation Mandatory Attributes

3

EGI AAI CheckIn Service

• May 2015: Introduction of the EGI AAI Roadmap and Architecture

4

Why Proxy?

• All EGI SPs can have one statically configured IdP.
• No need to run an IdP Discovery Service on each EGI SP.
• Connected SPs get consistent/harmonised user identifiers and

accompanying attribute sets from one or more AAs that can be interpreted in a uniform way for authZ purposes.

• External IdPs only deal with a single EGI SP proxy.
• In a nutshell: EGI services will not have to deal with the complexity of

multiple IdPs/Federations/Attribute Authorities/technologies. This complexity will be handled centrally by the proxy.

5

EGI CheckIn Service Today

• Available via eduGAIN
• IdP Discovery
• User Enrolment
• User Consent
• Support for LoA
• Attribute Aggregation
• SAML2.0 Attribute Query,

REST, LDAP, SQL

• Support for OIDC/OAuth2 IdPs
• Google, Facebook, LinkedIn,

ORCID

• Support for OIDC/OAuth2 SPs
• Experimental support for eIDAS

Production

Ready for production Alpha

6

Levels of Assurance

• LoA: 0
• This category groups the credentials with basically no LoA associated.

Examples are social-identity credentials with no vetting and no uniqueness of the ID guaranteed.

• LoA: 1
• This category groups the credentials that are usable in a federated

environment, but may require additional attributes to be used in all applications.

Proposal under discussion

7

Levels of Assurance

• LoA: 2
• This category groups the credentials that have a level of assurance that

is considered aligned with all the EGI policies and allows to access all EGI services.

• LoA: 3
• This category groups credentials with an higher LoA for both the

authentication and the attributes distributed in the assertion.

Proposal under discussion

8

Use cases for the LoA in EGI

• Allow an IdP to advertise those LoAs for which it is able to

meet the associated requirements.

• Allow an IdP to indicate the actual LoA in its responses.
• Allow a SP to express its expectations for the LoA at

which a user should be authenticated.

9

EGI Unique Identifier requirements

The EGI User ID should be:

• personal - used by a single person.
• persistent - used for an extended period of time across multiple sessions.
• non-reassignable - assigned exclusively to a specific person, and never reassigned to

another individual.

• non-targeted - not intended for a specific relying party (or parties), i.e. should be shared.
• globally unique - unique beyond the namespace of the IdP and the namespace of the

SP(s) with which the ID is shared.

• paque - should (by itself) provide no information about the user, i.e. should be

privacy-preserving.

EGI User Identifier

10

EGI User Identifier implementation

• EGI User ID is created by the CheckIn service at the moment of the user’s first

connection

• The IdP/SP Proxy adds (or replaces) the eduPersonUniqueId attribute, based on

the first non-empty value from this attribute list: ○ ePUID, ePPN, ePTID

• The selected attribute value, combined with the entityID of the authN authority, is

hashed and the “egi.eu” scope portion is added to the generated ePUID, e.g.:

EGI Unique User Id Generation

ef72285491ffe53c39b75bdcef46689f5d26ddfa00312365cc4fb5ce97e9ca87@egi.eu

11

IdP/SP Proxy technical architecture and deployment

• High Availability & Load Balancing.
• SimpleSAMLphp caches user sessions in Memcached, an in-memory

key-value store for small chunks of arbitrary data.

• COmanage maintains EGI user profile information in PostgreSQL DB cluster:

○ Data are synced between master (read/write) and hot standby slave (read-only queries).

• Sessions are distributed and replicated among different Memcached servers,

enabling load-balancing and failover.

• User requests are load balanced among multiple SimpleSAMLphp web

front-ends that use the back-end matrix of Memcached servers.

12

IdP/SP Proxy: Integrated IdPs

IdPs:

• EGI SSO
• ELIXIR research

infrastructure AAI

• ORCID
• Virtual Home Organization

(VHO)

• eduGAIN
• Social networks:

○ Google ○ Facebook ○ Linkedin

13

Integration with attribute authorities

• Connection with Perun - DONE
• Connection with GOCDB - DONE
• Connection with COmanage - DONE
• Connection with the new OpenConnext Attribute Aggregator:

Pilot in collaboration with AARC project

14

Attribute aggregation

• The EGI CheckIn supports attribute aggregation through:

○ SAML 2.0 AttributeQuery Attribute Aggregator (SimpleSAMLphp module) ■ Enables SSP to issue SAML 2.0 attribute queries to Attribute Authorities that support SAML 2.0 SOAP binding ○ LDAP Attribute Aggregator (SimpleSAMLphp module) ■ Allows SSP to issue LDAP queries for retrieving attributes ○ REST Attribute Aggregator (SimpleSAMLphp module) ■ Allows SSP to retrieve attributes from a RESTful web service ○ OpenConext attribute aggregation (Java application) ■ Handles attribute aggregation and provides REST API for accessing attribute information

15

CoCo & R&S compliance

• CheckIn compliances

○ Compliant with R&S ○ Not compliant with CoCo but this will happen soon as the needed policies are put in place

• Identifiers

○ eduPersonUniqueId ○ eduPersonPrincipalName ○ eduPersonTargetedID

• Mail attribute

○ mail

• Name attributes

○ displayName ○ givenName ○ sn (surname)

• Authorization attribute

○ eduPersonScopedAffiliation

16

Token Translation: CILogon + RC Auth

17

User Enrollment

EGI CheckIn supports different user enrollment flows depending on the attributes released by the user’s Home Identity Provider:

• Self-service Sign Up: Allows joining the EGI User Community without

approval by an administrator if all the information below is asserted by the Home Organisation: ○ at least one of the following unique user identifiers: ■ pseudonymous, non-reassignable identifier (eduPersonUniqueId attribute); ■ name-based identifier (eduPersonPrincipalName attribute); ■ pseudonymous identifier (eduPersonTargetedID attribute or SAML persistent identifier) ○ first name (givenName attribute) and surname (sn attribute) ○ email address (mail attribute) ○ role (affiliation) at Home Organisation (eduPersonScopedAffiliation attribute)

18

User Enrollment

• Sign Up: If any of the required information cannot be released by the Home

Organisation: ○ user needs to self-assert the values of the missing attributes ○ request must then be approved by an EGI User Sponsor

• Identity linking: Allows access to EGI resources with a single personal EGI ID,

using any of the linked login credentials → organisational or social

19

OpenID Connect Support

• Service Providers can connect to the EGI AAI using OpenID Connect (OIDC)

as an alternative to SAML2

• EGI AAI OIDC Provider allows users to sign in using any of the supported

backend authentication mechanisms, i.e institutional IdPs (eduGAIN) or Social Providers

• Easy OIDC client registration through Client Management UI:

○ Obtain OAuth 2.0 credentials ○ Register one or more redirect URIs ○ Register required scopes (e.g. openid, profile, email)

www.egi.eu

Thank you for your attention.

Questions?

This work by Parties of the EGI-Engage Consortium is licensed under a Creative Commons Attribution 4.0 International License.

21

AARC Blueprint Architecture

22

IdP/SP Proxy technical architecture

• SimpleSAMLphp caches user sessions in Memcached, an in-memory key-value store for

small chunks of arbitrary data

• COmanage maintains EGI user profile information in PostgreSQL DB cluster; Data are

synced between master (read/write) and hot standby slave (read-only queries)

• Sessions are distributed and replicated among different Memcached servers, enabling

load-balancing and fail-over

• User requests are load balanced among multiple SimpleSAMLphp web front-ends that

use the back-end matrix

• f

Memcached servers

High Availability & Load Balancing

23

User Enrollment

EGI CheckIn supports different user enrollment flows depending on the attributes released by the user’s Home Identity Provider: Self-service Sign Up: Allows joining the EGI User Community without approval by an administrator if all the information below is asserted by the Home Organisation: at least one of the following unique user identifiers: pseudonymous, non-reassignable identifier (eduPersonUniqueId attribute); name-based identifier (eduPersonPrincipalName attribute); pseudonymous identifier (eduPersonTargetedID attribute or SAML persistent identifier) first name (givenName attribute) and surname (sn attribute) email address (mail attribute) role (affiliation) at Home Organisation (eduPersonScopedAffiliation attribute)

24

IdP/SP Proxy: SP integration flow

EGI SP:

• Central/Core service
• IaaS fedCloud
• ...

Register SP Development instance https://aai-dev.egi.eu/oidc/ EGI SP:

• Central/Core service
• IaaS fedCloud
• ...

Register SP Production instance https://aai.egi.eu/oidc/ IF OK
