THEBES: KYT project investigating bentonite 1 st THEBES workshop, Aalto University 11 th December 2015 The behaviour of bentonite based materials: insight into nano and micro-structure Pierre Delage Ecole Nationale des Ponts et Chausses, Paris

slide-1
SLIDE 1

The behaviour of bentonite based materials: insight into nano and micro-structure

Pierre Delage Ecole Nationale des Ponts et Chaussées, Paris Laboratoire Navier/CERMES THEBES: KYT project investigating bentonite 1st THEBES workshop, Aalto University 11th December 2015

slide-2
SLIDE 2

2

Outline of the presentation

  • Bentonite materials in nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
  • Nanostructure issues during hydration
  • Consequences on water retention
  • Consequences on water transfer
  • Consequences on technological voids
  • Conclusions
slide-3
SLIDE 3

3

Outline of the presentation

  • Bentonite materials in nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
  • Nanostructure issues during hydration
  • Consequences on water retention
  • Consequences on water transfer
  • Consequences on technological voids
  • Conclusions
slide-4
SLIDE 4

4

Role of the disposal

  • To impede water circulation

– Canister – Engineered barrier – Geological barrier – Structure of the disposal

  • To immobilise radionuclides into the canisters
  • To delay and attenuate the migration of

radionuclides (> 500 000 y.) Multibarrier concept including engineered barrier and host rock

ANDRA 2005

slide-5
SLIDE 5

5

Multi-barrier system (vertical deposit)

SKB

slide-6
SLIDE 6

6

SKB concept

SKB, Posiva

slide-7
SLIDE 7

7

Swiss concept

Opalinus clay Compacted bentonite High Level Waste Intermediate Level Waste

slide-8
SLIDE 8

Deep geological disposal: French concept

ANDRA 2005

(EDZ)

Saturation

slide-9
SLIDE 9

COx Claystone

Ø Stable geological context (155 Ma) Ø Very low permeability: 10-20 10-21 m2 Ø Good ability for radionuclides retention Ø Porosity : 14 – 19% Ø Clay fraction: 48-50% at 490 m

Photo ANDRA

slide-10
SLIDE 10

10

Blocks of compacted bentonite

FEBEX project (1996), Grimsel URL FEBEX project (2005)

Technological voids Closed after 9 years hydration

slide-11
SLIDE 11

11

Pellets

Posiva

slide-12
SLIDE 12

12

NAGRA Concept

Bentonite blocks Bentonite pellets

Nagra

slide-13
SLIDE 13

13

HE-E experiment (Nagra)

slide-14
SLIDE 14

14

Outline of the presentation

  • Bentonite materials in nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

slide-15
SLIDE 15

15

Clay FoCa7 clay (F) Kunigel (J) MX 80 (US) Mineralogy Kaolinite- smectite 64% Na smectite 85% Na - Ca smectite wL (%) 112 474 520 wP (%) 50 27 62 IP 62 447 458 ρs 2.67 Mg/m3 2.79 Mg/m3 2.65 Mg/m3 Activity 0.78 6.9 5.4 Specific surface 300 m2/g 687 m2/g 700 m2/g Cation Exchange Capacity 54 mEq/100 g 73,2 mEq/100 g 68 mEq/100 g

Some typical characteristics of bentonites

Tessier et al. (1998), Komine & Ogata (1992), Pusch (1992)

slide-16
SLIDE 16

16

SEM Photo, Compacted Kunigel clay

5 µm 2 µm

Cui et al. (2002)

Clay aggregates Inter-aggregates DRY pores ρ = 2 Mg/m3 w = 8% s = 57 MPa Cui, Loiseau and Delage 2002

slide-17
SLIDE 17

17

Sand (35%) - MX80 (65%) mixture

20 40 60 80 100 0.0001 0.001 0.01 0.1 1 10

Grain size (mm) Percentage passing (%)

Sand grains Bentonite grains Deflocculated bentonite (hydrometer)

Sand Bentonite grains Deflocculated bentonite

Saba, Delage et al. Eng. Geol 2014

slide-18
SLIDE 18

0.01 0.1 1 10 100 0.00 0.01 0.1 1 10 100 0.0 0.1 0.2 0.3 0.4

b

Porosity Entrance pore diameter (µm)

Laplace’s law : Cylindrical pore : r1 = r2 Higher Hg (non wetting) pressure penetrates smaller pores

⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ + =

2 1

1 1 r r cos p θ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ 1 =

1

2 r cos p θ

in smaller and smaller pores

increasing Hg pressure

200 MPa 3.5 nm

Mercury intrusion pore size distribution

Hg penetrating

slide-19
SLIDE 19

19

Mercury intrusion pore size distribution

0.01 0.1 1 10 100 0.00 0.05 0.10 0.15

dV/d(logD)

a

0.01 0.1 1 10 100 0.0 0.1 0.2 0.3 0.4

b

Porosity Entrance pore diameter (µm)

Not intruded < 3.5 nm s = 75.5 MPa

Saba, Delage et al. Eng. Geol 2014

Sand-bentonite compacted powder ρd = 1.8 Mg/m3 , w = 10%, Sr = 55%, s = 75.5 MPa

slide-20
SLIDE 20

Simona SABA - PhD Defense – 9 Dec 2013 20 /48

0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.001 0.01 0.1 1 10 100 1000 Entrance pore diameter D (µm) dV/d(logD) 0.019 µm 22 µm

Micropores: intra-granular Macropores: inter-grains

2- Microstructure at initial state

Micropores

Grain Platelet

Macropores

Pore size distribution curve

Sand-bentonite compacted powder ρd = 1.8 Mg/m3 , w = 10%, Sr = 55%, s = 75.5 MPa

Saba, Delage et al. Eng. Geol 2014

slide-21
SLIDE 21

21

Microfocus X-Ray Computed Tomography (µCT)

http://navier.enpc.fr

Imager/Detector X-Ray Source Sample Rotation disk Translation rails

Saba, Delage et al. Eng. Geol 2014

slide-22
SLIDE 22

Simona SABA - PhD Defense – 9 Dec 2013 22 /48

10 mm 50 mm 4 mm

2- Microstructure at initial state

Saba, Delage et al. Eng. Geol 2014

Sand-bentonite compacted powder

30 µm voxel size

65% MX80 bentonite, 35% sand, ρd = 1.8 Mg/m3, s = 76 MPa, Sr = 55%

slide-23
SLIDE 23

Simona SABA - PhD Defense – 9 Dec 2013 23 /48

Horizontal µCT cross section

50 mm

Bentonite Sand Pore Well defined bentonite grains Aggregation of bentonite grains

2- Microstructure at initial state

Saba, Delage et al. Eng. Geol 2014

slide-24
SLIDE 24

Simona SABA - PhD Defense – 9 Dec 2013 24 /48

Image analysis (ImageJ)

▌ Segmentation

73 Logarithmic Linear 73 Logarithmic Linear

3D Median filter (2x2x2 vox) Threshold Segmented image 73 Image histogram « Mixture Modelling» function

2- Microstructure at initial state

Saba, Delage et al. Eng. Geol 2014

slide-25
SLIDE 25

Simona SABA - PhD Defense – 9 Dec 2013 25 /48

5 10 15 20 25 30 0.00 0.01 0.02 0.03 0.04 0.05 0.06 0.07

Porosity (> 30 µm) Distance fron centre (mm)

Heterogeneity in porosity

Mean value = 0.016 Pores > 30 µm (voxel size)

2- Microstructure at initial state

0.05 0.1 0.15 0.2 0.25 0.3 0.001 0.01 0.1 1 10 100 1000 Entrance pore diameter D (µm) Cumulative porosity

30 µm 0.026

1 3 4 5 2

Saba, Delage et al. Eng. Geol 2014

slide-26
SLIDE 26

26

Outline of the presentation

  • Bentonite materials in nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
slide-27
SLIDE 27

27

Sand-bentonite mixture PSD

0.01 0.1 1 10 100 0.00 0.05 0.10 0.15

dV/d(logD)

a

0.01 0.1 1 10 100 0.0 0.1 0.2 0.3 0.4

b

Porosity Entrance pore diameter (µm)

Not intruded < 3.5 nm s = 75.5 MPa

slide-28
SLIDE 28

0.001 0.01 0.1 1 10 Porous radius (µm) 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 Intruded mercury void ratio, em 0.597 0.812 0.293 0.230 w = 12.5 % w = 28.5 % e = 1.008

Effect of water content

MX 80 clay ρ = 2 Mg/m3 w = 12.5%, s = 30 MPa w = 28.5% s = 2 MPa

Delage et al., Géot. 2006

SAMPLE AT HIGHER WATER CONTENT AND LOWER SUCTION HAS MORE WATER LOCATED IN VERY SMALL PORES (< 35 nm)

slide-29
SLIDE 29

As compacted Calcigel

Agus and Schanz, 2005

ρd = 2 Mg/m3, w = 9%, s = 22.7 MPa Total pore volume

slide-30
SLIDE 30

Oven drying, Calcigel clay

Agus and Schanz, 2005

Oven-dried,w = 0%, s = 1 GPa OVEN-DRYING (s from 22 MPa to 1GPa) HAS LITTLE EFFECT ON MICROSTRUCTURE AND NANOPORES

slide-31
SLIDE 31

Hydration – swelling, Calcigel clay

Agus and Schanz, 2005

Hydrated and swollen w = 19%, s = 0 MPa SWELLING CONCERNS BOTH NANO PORES (< 3.5 nm) AND LARGE PORES (around 1 µm)

slide-32
SLIDE 32

32

Outline of the presentation

  • High level nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
  • Nanostructure issues during hydration
slide-33
SLIDE 33

Saturated intra-aggregates swelling mechanisms

Saiyouri, Hicher & Tessier (2000), using Pons et al. (1981)

  • X ray scattering at low angles
  • Probabilistic analysis

Interlayer distances as a function of decreased suction

slide-34
SLIDE 34

Sayiouri, Hicher & Tessier (2000)

Water adsorption along smectites

  • 4 layers : 20.6 Å
slide-35
SLIDE 35
  • Adsorption of water vs suction, MX 80

inside the saturated aggregates

50 MPa

18.6 Å 15.6 Å 12.6 Å

7 MPa Sayiouri, Hicher & Tessier (2000)

slide-36
SLIDE 36

Hydration from a dry state

Sayiouri, Hicher & Tessier (2000)

inside the saturated aggregates

high suction (> 50 MPa) 100 layers low suction (< 7 MPa) 10 layers possible double layer

slide-37
SLIDE 37

Hydration from a dry state, MX80

  • 50 MPa

7 MPa 18.6 Å 15.6 Å 12.6 Å

Sayiouri, Hicher & Tessier (2000)

slide-38
SLIDE 38

Hydration from a dry state

Suction (MPa)

inside the saturated aggregates

7 MPa 50 MPa

inter particles water, between 20 and 100 Å 0.001 0.01 0.1 1 10 100

Sayiouri, Hicher & Tessier (2000)

slide-39
SLIDE 39
  • Laplace’s law :
  • Planar pores : r2 = ∞

The same pressure corresponds to a twice smaller radius

Mercury intrusion in planar pore

⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ + =

2 1

1 1 r r cos p θ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ 1 =

1

r cos p θ

slide-40
SLIDE 40

Planar pores in particles

4 layers = 20.6 Å : 2d = 11 Å, d = 5.5 Å 3 layers = 18.6 Å : 2d = 9 Å, d = 4.5 Å 2 layers = 15.6 Å : 2d = 6 Å, d = 3 Å 1 layers = 12.6 Å : 2d = 3 Å, d = 1.5 Å

  • 4 layers : 20.6 Å
slide-41
SLIDE 41

0.001 0.01 0.1 1 10 Porous radius (µm) 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 Intruded mercury void ratio, em 0.597 0.812 0.293 0.230 w = 12.5 % w = 28.5 % e = 1.008 9 Å 3 layers 1.5 Å : 1 layer

inter particles water, between 20 and 100 Å

Compacted MX80

slide-42
SLIDE 42

42

Outline of the presentation

  • Bentonite materials in nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
  • Nanostructure issues in compacted bentonites

during hydration

  • Consequences on water retention
slide-43
SLIDE 43

Water retention curve, FoCa clay

10 20 30 40 50

Gravimetric water content (%)

0.1 1 10 100 1000

Suction (MPa)

Compacted samples Powder samples 50 MPa 7 MPa si

1 layer 2 layers 3 layers

slide-44
SLIDE 44

44

Water retention with swelling impeded

Wang et al., Soils and Found. 2013

slide-45
SLIDE 45

Water retention curve, constant volume

10 20 30 40 50

Gravimetric water content (%)

0.1 1 10 100 1000

Suction (MPa)

Free swelling condition Prevented swelling condition

50 MPa 7 MPa si

1 layer 2 layers 3 layers ? Constant volume Free swelling 3 layers

slide-46
SLIDE 46

Kunigel (70%) – sand (30%) mixture

4 6 8 10 12 14

w (%)

0.1 1 10 100

s (MPa)

7 MPa

3 layers ? Constant volume

Cui et al., Phys. Chem. Earth 2008

slide-47
SLIDE 47

Compacted MX80 and powder

  • 7 MPa

3 layers ? Constant volume

Delage et al., Géot. 2006

slide-48
SLIDE 48

Swelling

FoCa clay

0.1 1 10 100 1000

Suction (MPa)

0.4 0.8 1.2 1.6

Void ratio

Various suction cycles under no stress : Reversibility

50 MPa 7 MPa Si = 116 MPa

1 layer Less thicker particles 2 layers 3 layers, Many more thinner particles

slide-49
SLIDE 49

Simona SABA - PhD 49 /48

50 mm

Sand Empty inter-grains pores containing water Exfoliation Gel around hydrated bentonite grains Bentonite

70% bentonite and 30% sand ρdb = 0.94 Mg/m3 , Sr = 85%

4- Swelling pressure anisotropy

Hydrated sand-bentonite mixture

Saba 2013

slide-50
SLIDE 50

50

Hydrated Pellet-bentonite mixture - µtomo

Van Geet et al. App. Clay Sc. 2005 Two weeks One month Two months (5 bars) Dry

slide-51
SLIDE 51

51

Investigation of gel formation

Pressure measurements Pressure measurements Flow/Hydration/Gel Flow/Hydration/Gel Inflow, 2 MPa Planar free space Marcial, Delage & Cui, Geomech. Geoeng. 2006

slide-52
SLIDE 52

52

Pressure build up

2000 4000 6000 Time (mn) 300 600 900 1200 1500 1800 2100 p (kPa)

pp sp1 sp2 sp3

33h 66h 99h Time (h) Pressure (kPa)

Marcial, Delage & Cui, Geomech. Geoeng. 2006

slide-53
SLIDE 53

53

Outline of the presentation

  • Bentonite materials in nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
  • Nanostructure issues in compacted bentonites

during hydration

  • Consequences on water retention
  • Consequences on water transfer
slide-54
SLIDE 54

Unsaturated permeability

Instantaneous profile method suction (MPa) Curve slopes give hydraulic gradient i at various suctions

lower gradient Water infiltration in a column Water retention curve determined Suction monitoring along column

Daniel 1984

slide-55
SLIDE 55

Corresponding water contents given by water retention curve Changes in water content with time provide water unit flow q Unsaturated permeability K given by :

A is the sectional area

t dx dx A q

L x t L x t t

i i

Δ θ θ

Δ

∫ ∫

− =

+

( )

t t t

i i 5 , q A 1 K

Δ +

+ − =

Daniel 1984

slide-56
SLIDE 56

56

Instantaneous profile method, Kunigel

10 20 30 40 50 60 s ( MPa) 50 100 150 200 250 h (mm) t = 0 h t = 200 h t = 400 h t = 600 h t = 800 h t = 1000 h t = 1200 h t = 1400 h t = 1600 h t = 1800 h t = 2000 h t = 2200 h

Suction (MPa)

Infiltration constant volume

Cui et al., Phys. Chem. Earth 2008

slide-57
SLIDE 57

57

Darcy’s law?

20000 40000 60000

i (-)

0.0x100 4.0x10-13 8.0x10-13 1.2x10-12 1.6x10-12 2.0x10-12

q (m3/s)

s = 45 MPa s = 43 MPa s = 41 MPa s = 39 MPa s = 37 MPa s = 35 MPa

Cui et al., Phys. Chem. Earth 2008

slide-58
SLIDE 58

58

Unsaturated permeability (2)

10 20 30 40 50 60 s (MPa) 0.0x10 4.0x10

  • 14

8.0x10

  • 14

1.2x10

  • 13

k (m/s) h = 50 mm h = 100 mm h = 150 mm h = 200 mm T01

Suction (MPa) Permeability (m/s)

Cui et al., Phys. Chem. Earth 2008

slide-59
SLIDE 59

59

Outline of the presentation

  • Bentonite materials in nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
  • Nanostructure issues in compacted bentonites

during hydration

  • Consequences on water retention
  • Consequences on water transfer
  • Consequence on technological voids
slide-60
SLIDE 60

60

Effects of technological voids

Technological voids Closed after 9 years hydration Estimated 6.6% in FEBEX, 9% in the French concept (ANDRA) and 14% in the Sealex test (IRSN, France)

slide-61
SLIDE 61

61

Technological voids

Wang et al. Sand Found. 2013

slide-62
SLIDE 62

62

Swelling pressure development

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 10 20 30 40 Time (h) Vertical stress (MPa)

SP-01 SP-02 SP-03 SP-04

ρd = 1.93 Mg/m3 ρd = 1.96 Mg/m3 ρd = 1.96 Mg/m3 ρd = 1.98 Mg/m3

σ

Water escaping Gel formation Clogging Wang et al. Sand Found. 2013

slide-63
SLIDE 63

63

Final swelling pressure vs saturated density

0.01 0.1 1 10 100 1 2 3 4 Bentonite void ratio (-) Vertical stress (MPa)

Mixture 70/30 (Present work) Mixture 70/30 (Karnland et al., 2008) Pure bentonite (Karnland et al., 2008) Pure bentonite (Dixon et al., 1996) Pure bentonite (Komine et al., 2009) Pure bentonite (Borgesson et al., 1996)

Initial technical void

Wang et al. Sand Found. 2013

slide-64
SLIDE 64

64

Outline of the presentation

  • High level nuclear waste disposals
  • Microstructure issues in compacted bentonites

and sand bentonite mixtures:

  • Hydration of compacted bentonites
  • Nanostructure issues in compacted bentonites

during hydration

  • Consequences on water retention
  • Consequences on water transfer
  • Consequences on technological voids
  • Conclusions
slide-65
SLIDE 65

65

Conclusions

  • Smectites are very active materials/water
  • Microstructure examined at various levels:

µtomo MiP and SEM

  • Hydration mechanisms further understood

through nanostructure considerations

  • Generation and role of gel
  • Water retention and transfer illustrated through

adsorption of water layers

  • Swelling pressure always conditioned by final

saturated density

  • Bentonite based material are safe and reliable

with respect to water tightness
