Test Boards Design for LTDB

Xueye Hu, Hucheng Chen, Joe Mead USTC & BNL

06/20/2012

2

Outline

 LTDB Test Boards

LAr Trigger Digitizer Board

 ADC Mezzanine Card  FPGA Carrier Card  Test  Conclusion

3

Outline

 LTDB Test Boards

LAr Trigger Digitizer Board

 ADC Mezzanine Card  FPGA Carrier Card  Test  Conclusion

 LTDB Test Boards

• LTDB: Phase 1 Upgrade of LAr Front- End electronics

Setup irradiation test (Proton beam) LTDB Test boards: Three Steps Step 2 Modular design verify the functionalities 1：ADC Mezzanine Card 2: FPGA Carrier Card Step 1 3: Optical Mezzanine Card (SMU)

5 Re-integrate into ¼slice LTDB Digital Mezzanine Card & A LTDB MOTHER Board Step 3

Function of FPGA Carrier Card

Function of ADC Mezzanine Card Function of Optical Mezzanine Card

LTDB Digital Mezzanine Card

Liquid Argon Trigger Digitizer Board MOTHER Board Analog Interface Analog Mezzanine card

6

Outline

 LTDB Test Boards

LAr Trigger Digitizer Board

 ADC Mezzanine Card  FPGA Carrier Card  Test  Conclusion

7

 Key Features

• Input: SMA connectors
• Output: FMC HPC connector

 ADC Mezzanine Card

• ADC Sampling clock: SMA / OSC/

FPGA differential output

• ADC reference: internal / external
• Hardware
• ADC Driver: AD8138 /500krad
• Clock Driver: CDC1212 /1Mrad
• Power supply: external supply || on board POL converter

*3

SMA

POWER CONNECTOR POL CONVERTER

ADC

OSC FMC CONNECTOR ASP-134602-01 SMA SMA

...

CLK Driver

ADC DRIVER

Block Diagram of ADC Test Boards

8

 First ADC test board using TI ADS5263

– ADS5263: 4-ch, 16bit/14bit, 100MSPS – Board has been assembled

 Second ADC test board using TI ADS5294

– ADS5294: 8-ch, 14bit, 80MSPS – Board has been assembled

 Third ADC test board using TI ADS5272

– ADS5272: 8-ch, 12bit, 65MSPS – Survived more than 8Mrad so far – Simple architecture and small (6.5 clock cycle) latency – PCB design is ongoing

• ADC

ADC @Test Boards

TI ADS5263 Test Board TI ADS5294 Test Board

For irradiation test Clearance circle with 3inch diameter

10

Outline

 LTDB Test Boards

LAr Trigger Digitizer Board

 ADC Mezzanine Card  FPGA Carrier Card  Test  Conclusion

11

FMC CONNECTOR ASP-134602-01

OSCS XILINX Kintex-7 XC7K325T

POWER CONNECTOR POL CONVERTER LDO Regulators

FMC CONNECTOR ASP-134602-01

• Diff. pairs

Single ended USB

USB-UART Bridge Flash

DDR3 SO-DIMM

12*10Gbps SMAs

SFP

ADC DATA GTX DATA

Current Monitor

Block Diagram of FPGA Test Board

 FPGA Carrier Card

JTAG

12

 Key Features

• Hardware

 FPGA Carrier Card

• FMC HPC connectors

receive ADC differential data & transmit 10Gbps serial data

• Memory: DDR3
• Ethernet interface: SFP cage & RJ45
• RS232 port: Mini-USB & SiLabs CP2103
• Configuration: BPI flash & JTAG
• FPGA: XC7K325T-1FFG900

XADC: monitoring temperature and voltage

• Power: POL converter LTM4616

LTM4616 & Diode FDLL4148: FPGA power-on sequence

• Clock: ADC Mezzanine card & differential oscillator
• SMA: test GTX electrically

For irradiation test Clearance circle with 2.5inch diameter

FPGA @Test Board

14

Outline

 LTDB Test Boards

LAr Trigger Digitizer Board

 ADC Mezzanine Card  FPGA Carrier Card  Test  Conclusion

15

 Setup of Test

• Preparation

Make our ADC test boards more generic ML605, KC705, FPGA Carrier card

A mapping spreadsheet: Define the FMC HPC connector signals carefully

Two FPGA banks transfer differential signals two pairs for clock signals, up to 16 pairs for ADC DATA signals Third FPGA bank for ADC single ended signal

• Preparation
• ADC preliminary test
• Verify ADC functionalities
• FPGA preliminary test

16

FPGA

ML605

Board ADC Board

 Setup of Test

 Ongoing test

• ADS5263
• ADS5294
• FPGA Carrier card
• ADC preliminary test
• ADS5263: power supply, OSC, ADC Driver, Clock Driver work well
• ADS5294: work well

* DCLK, FCLK are not stable with missing cycles It turns out that the analog supply voltage threshold is 1.84V Adjust DC/DC Converters output voltage

17

 Setup of Test

• Verify ADC functionalities (VHDL code on ML605)

 ADC interface (S2P) : ADC serial LVDS output parallel data in FPGA  Control (SPI): control ADC serial register & configure ADC  ChipScope: capture the S2P and SPI data directly from FPGA hardware

• ADS5263 configuration: 2-wire, 16x serialization, 4 x bit

clock, 1 x frame clock, Bytewise mode

 ADC Sampling clock = 40MHz, FCLK= 40MHz, DCLK= 160MHz Configure ADC and sample ADC data properly  ADC Sampling clock = 80MHz, FCLK= 80MHz, DCLK= 320MHz * add clock adjustment module OK

• ADS5294 configuration: 2-wire, 14x serialization, 4 x bit

clock, 1 x frame clock, Wordwise mode

 SPI works fine & S2P debugging is ongoing

18

• FPGA preliminary test

@ power supply works well & power-on sequence has verified with ADM chip and FDLL4148 @ Kintex-7 FPGA is tested with a small LED blinking program JTAG configuration & power on sequence work properly @ MicroBlaze system built on FPGA carried card * DDR3 memory & USB--UART work well Data rate DDR3: 64 bit * 100MHz = 6.4 Gbps ADS5263: 4ch * 16bit * 80MHz = 5.12Gbps

• --- DDR3 can handle ADC data input easily

* Gigabit Ethernet test is ongoing

 Setup of Test

19

Outline

 LTDB Test Boards

LAr Trigger Digitizer Board

 ADC Mezzanine Card  FPGA Carrier Card  Test  Conclusion

 Conclusion

1.1: Two ADC (ADS2563, ADS5294) mezzanine cards (Done) 1.2: FPGA carrier card (Done) 1.3: The third ADC (ADS5272) layout (Ongoing) 2.1: ADC (ADS5263) mezzanine card function test (Done) 2.2: ADC (ADS5294) mezzanine card function test (Ongoing) 2.3: ADC Irradiation Test S2P & SPI integrated on ML605 MicroBlaze system (Ongoing)

21

Thank you !
