SLIDE 1
http://cs.mst.edu
http://cs.mst.edu
Syntax Rules
- The class definition must be labeled as a template
- Every member function must be templated
Template Classes http://cs.mst.edu Syntax Rules The class - - PowerPoint PPT Presentation
Template Classes http://cs.mst.edu Syntax Rules The class - - PowerPoint PPT Presentation
Template Classes http://cs.mst.edu Syntax Rules The class definition must be labeled as a template Every member function must be templated http://cs.mst.edu Stacks http://cs.mst.edu Push 25 12 http://cs.mst.edu Push 32 25 25
SLIDE 2
SLIDE 3
http://cs.mst.edu
Stacks
SLIDE 4
http://cs.mst.edu
Push 12 25
SLIDE 5
http://cs.mst.edu
Push 25 25 32
SLIDE 6
http://cs.mst.edu
Pop 25 25 32
SLIDE 7
http://cs.mst.edu
Pop 12 25
SLIDE 8
http://cs.mst.edu
Stack Example
template <class T_element> class stack { private: T_element m_data[MAX]; int m_numElements; public: stack():m_numElements(0){} stack(const stack<T_element>& source); bool push(const T_element elm); bool pop(T_element & elm); bool isFull()const {return m_numElements == MAX;} bool isEmpty()const {return m_numElements == 0;} };
SLIDE 9
http://cs.mst.edu
Push
// stack.hpp template <class T_element> bool stack<T_element>::push(const T_element elm) { if (!isFull()) { m_data[m_numElements] = elm; m_numElements++; return true; } return false; }
SLIDE 10
http://cs.mst.edu
Push
// stack.hpp template <class T_element> bool stack<T_element>::push(const T_element elm) { if (!isFull()) { m_data[m_numElements] = elm; m_numElements++; return true; } return false; }
SLIDE 11
http://cs.mst.edu
Pop
// stack.hpp template <class T_element> bool stack<T_element>::pop(T_element & elm) { if (!isEmpty()) { elm = m_data[m_numElements-1]; m_numElements--; return true; } return false; }
SLIDE 12
http://cs.mst.edu
Pop
// stack.hpp template <class T_element> bool stack<T_element>::pop(T_element & elm) { if (!isEmpty()) { elm = m_data[m_numElements-1]; m_numElements--; return true; } return false; }
SLIDE 13
http://cs.mst.edu
Copy Constructor
template <class T_element> stack<T_element>::stack(const stack<T_element>& source) { m_numElements = source.m_numElements; for (int i=0; i < m_numElements; i++) m_data[i] = source.m_data[i]; }
SLIDE 14
http://cs.mst.edu
Copy Constructor
template <class T_element> stack<T_element>::stack(const stack<T_element>& source) { m_numElements = source.m_numElements; for (int i=0; i < m_numElements; i++) m_data[i] = source.m_data[i]; }
SLIDE 15
http://cs.mst.edu
Copy Constructor
template <class T_element> stack<T_element>::stack(const stack<T_element>& source) { m_numElements = source.m_numElements; for (int i=0; i < m_numElements; i++) m_data[i] = source.m_data[i]; }
SLIDE 16
http://cs.mst.edu
Copy Constructor
template <class T_element> stack<T_element>::stack(const stack<T_element>& source) { m_numElements = source.m_numElements; for (int i=0; i < m_numElements; i++) m_data[i] = source.m_data[i]; }
SLIDE 17
http://cs.mst.edu
Example
stack<int> ant_hill; int a_value; ant_hill.pop(a_value); ant_hill.push(5); ant_hill.push(6); ant_hill.pop(a_value);
SLIDE 18
http://cs.mst.edu
Example
stack<int> ant_hill; int a_value; ant_hill.pop(a_value); ant_hill.push(5); ant_hill.push(6); ant_hill.pop(a_value); ? ? ? ? ? [0] [1] [2] [3] [4]
SLIDE 19
http://cs.mst.edu
Example
stack<int> ant_hill; int a_value; ant_hill.pop(a_value); ant_hill.push(5); ant_hill.push(6); ant_hill.pop(a_value); ? ? ? ? ? [0] [1] [2] [3] [4] ? a_value
SLIDE 20
http://cs.mst.edu
Example
stack<int> ant_hill; int a_value; ant_hill.pop(a_value); ant_hill.push(5); ant_hill.push(6); ant_hill.pop(a_value); ? ? ? ? ? [0] [1] [2] [3] [4] ??? a_value
SLIDE 21
http://cs.mst.edu
Example
stack<int> ant_hill; int a_value; ant_hill.pop(a_value); ant_hill.push(5); ant_hill.push(6); ant_hill.pop(a_value); 5 ? ? ? ? [0] [1] [2] [3] [4] ? a_value
SLIDE 22
http://cs.mst.edu
Example
stack<int> ant_hill; int a_value; ant_hill.pop(a_value); ant_hill.push(5); ant_hill.push(6); ant_hill.pop(a_value); 5 6 ? ? ? [0] [1] [2] [3] [4] ? a_value
SLIDE 23
http://cs.mst.edu
Example
stack<int> ant_hill; int a_value; ant_hill.pop(a_value); ant_hill.push(5); ant_hill.push(6); ant_hill.pop(a_value); 5 ? ? ? ? [0] [1] [2] [3] [4] 6 a_value
SLIDE 24
http://cs.mst.edu
Example 2
class elephant { private: float m_wt; string m_name; public: elephant(string name, float wt); void do_something(); }; stack<elephant> pack_o_derms;
SLIDE 25
http://cs.mst.edu
Example 2
template <class T_animal> class farm { public: farm():m_herdSize(0){} private: T_animal my_herd[MAX]; int m_herdSize; }; farm<elephant> large_animal_ranch;
SLIDE 26
