Tariff Design and Assessment Tool Workshop 3 Dec 2018, UNSW Sydney, Asia-Pacific Solar Research Conference (APSRC 2018) Welcome from the SPREE/CEEM Distributed Energy Modelling and Analysis Team Anna Bruce (a.bruce@unsw.edu.au) Jose Bilbao

slide-1
SLIDE 1

3 Dec 2018, UNSW Sydney, Asia-Pacific Solar Research Conference (APSRC 2018)

Tariff Design and Assessment Tool Workshop

slide-2
SLIDE 2

www.ceem.unsw.edu.au

facebook.com/ceem.unsw/ twitter.com/ceem_unsw linkedin.com/company/ceem.unsw/ github.com/unsw-ceem

Anna Bruce (a.bruce@unsw.edu.au) Jose Bilbao (j.bilbao@unsw.edu.au) Jessie Copper (j.copper@unsw.edu.au) Nicholas Gorman (n.Gorman@unsw.edu.au) Emi Gui (emi.gui@unsw.edu.au Navid Haghdadi n.haghdadi@unsw.edu.au Iain MacGill (i.macgill@unsw.edu.au) Luke Marshall (luke.marshall@unsw.edu.au) Rob Passey (r.passey@unsw.edu.au) Mike Roberts (m.roberts@unsw.edu.au) Alistair Sproul (a.sproul@unsw.edu.au) Naomi Stringer (n.stringer@unsw.edu.au) Sharon Young (Sharon.young@unsw.edu.au) Katelyn Purnell (k.purnell@unsw.edu.au)

Welcome from the SPREE/CEEM Distributed Energy Modelling and Analysis Team

slide-3
SLIDE 3

Electricity emissions intensity comparison

(shrink that footprint)

The challenge –

  • ur failure to serve the long-

term interests of consumers

3 Integrating demand response and energy efficiency into energy markets (ACCC, 2017) Australian residential energy prices index

(Australian Energy Statistics Update 2017)

International retail electricity price comparison

(ACCC Retail Price Competition Inquiry, 2017)

slide-4
SLIDE 4

The opportunity - a greater role for energy-users in our energy future

  • A growing appreciation of our diverse energy users and contexts
  • Citizens, consumers, customers…. now increasingly possible partners, competitors,

communities, collectives

  • Contexts – housing types, vulnerable consumers…
  • New opportunities for energy users to engage
  • PV, Storage, demand-side participation,

energy efficiency

  • Improving regulatory, market and policy efforts

to appropriately facilitate end-user engagement engage end users

  • From assumptions of rational, utility maximising

individual customers driven by prices… to a more complex appreciation of energy decision making, individual yet also collective goals and actions, and hence coordination, sharing

  • New ways to explore these challenges &
  • pportunities; learn, disseminate and broaden

the conversation

4 Integrating demand response and energy efficiency into energy markets

Australia’s residential PV penetration (Finkel Review into NEM Security, 2017)

slide-5
SLIDE 5

Open data, tools … and processes

5

slide-6
SLIDE 6

The Day

6

slide-7
SLIDE 7

Our collective task

  • Updating you on progress
  • Panel contributions from some

key stakeholders

  • Discussion
  • Your ideas, guidance, comments

and suggestions on how we can improve our analysis and tools and impact

7 UNSW CEEM / SPREE Dx Network Tariff Tool Workshop - Melbourne, December 2017

slide-8
SLIDE 8

Tariff Design and Assessment Tool: Progress and Next Steps

  • 10:15 – 11am Tool Introduction and plans for new functionality

Navid Haghdadi

  • 11:00 – 12pm Stakeholder Panel

Bob Telford, AER Craig Chambers, ARENA

Q&A and Discussion

8

slide-9
SLIDE 9
  • Introduction to the TDA tool
  • Aim
  • Quick tour
  • Status report
  • Development
  • Moving to Python
  • Moving to API
  • Adding new functionalities
  • Plans for improvement
  • Retail price and analysis
  • Distributed energy analysis
  • Demand response analysis
  • Feedback and Questions

9

Agenda

slide-10
SLIDE 10

Tariff Design and Analysis tool

The open source TDA tool aims to assist stakeholders to investigate how different tariff structures impact on the expected bills of different types of residential consumers, while also estimating how well the tariffs align these customer bills with their impact on longer-term and wider electricity industry costs.

10

slide-11
SLIDE 11

Tariff Design and Assessment (TDA) tool

Where to find it?

https://github.com/UNSW-CEEM/TDA_Matlab http://ceem.unsw.edu.au/open-source-tools https://www.researchgate.net/project/Tariff-Design-and-Analysis-TDA-Tool

11

slide-12
SLIDE 12

Tariff Design and Assessment (TDA) tool

How to install it?

https://github.com/UNSW-CEEM/TDA_Matlab/releases

12

slide-13
SLIDE 13

Tariff Design and Assessment (TDA) tool

How to find more information about it?

13

slide-14
SLIDE 14

Tariff Design and Assessment (TDA) tool

What does the previous version do?

14

slide-15
SLIDE 15

Tariff Design and Assessment (TDA) tool

Select load from a range of existing load profiles, or upload your own set of loads!

15

slide-16
SLIDE 16

Tariff Design and Assessment (TDA) tool

Filer the load profiles by the demographic information

16

slide-17
SLIDE 17

Tariff Design and Assessment (TDA) tool

Get quick analysis of the set of selected loads

17

slide-18
SLIDE 18

Tariff Design and Assessment (TDA) tool

Add a network tariff (and some limited retail tariffs) and optionally change any parameters

18

slide-19
SLIDE 19

Tariff Design and Assessment (TDA) tool

Visualize the results of the analysis by a range of different graphing options

19

slide-20
SLIDE 20

Tariff Design and Assessment (TDA) tool

Add up to 10 analysis case and compare the results

20

slide-21
SLIDE 21

Tariff Design and Assessment (TDA) tool

Add tariffs, loads and projects; exports the results to excel, and change the preferences in the context menu

21

slide-22
SLIDE 22

22

Use case example: Comparison of tariffs

slide-23
SLIDE 23

23

Use case example: Comparison of tariffs

Excluding summer peaks

Coincident peak User’s peak

slide-24
SLIDE 24

24

Unitised Standard Demand Charge vs Average Demand at Time of Eight Highest network Peaks. Unitised Demand Charge (applied to customer demand at time of 12 monthly network peaks) vs Average Demand at Time of Eight Highest Network Peaks.

Passey, R., Haghdadi, N., Bruce, A., & MacGill, I. (2017). Designing more cost reflective electricity network tariffs with demand charges. Energy Policy, 109, 642-649.

Use case example: Assessing tariffs

slide-25
SLIDE 25
  • Moving to Python
  • More Analyses and Visualisation features
  • Retail Tariffs (and Categorising them)
  • Network, Wholesale, Retail Tariff Combined Analysis
  • Distributed Resources/Response:
  • PV
  • Battery
  • Appliances
  • Demand response
  • Energy Efficiency
  • Load Clustering

25

New Developments

slide-26
SLIDE 26

New Development: Converting to Python

  • Even more open source!
  • Easier collaboration in non-academic environment
  • Reduced size

26

slide-27
SLIDE 27

27

  • 800
  • 600
  • 400
  • 200

200 400 0% 5% 10% 15% 20% 25% 30% 35% 40% 45% 50% 55% 60% 65% 70% 75% 80% 84% 89% 94% 99%

Difference in bill ($) Customers

Difference ($)

  • 40%
  • 30%
  • 20%
  • 10%

0% 10% 20% 30% 40% 0% 5% 10% 15% 20% 25% 30% 35% 40% 45% 51% 56% 61% 66% 71% 76% 81% 86% 91% 96%

Difference in bill (%) Customers

Difference (%)

New Developments: Comparison of tariffs

Going from Ausgrid Flat rate tariff (2017/18) to Time of use (2017/18)

slide-28
SLIDE 28

28

New Developments: Distributed resources

PV and battery impact on peak and other users

Preliminary results, using SAPN network tariffs for SGSC homes, 15% of customers having PV and battery

slide-29
SLIDE 29

WS price and SGSC load profile are for 2013, but retail tariff is for 2018

New Development: Comparison of the network, wholesale and retail revenue

29

slide-30
SLIDE 30

WS price and SGSC load profile are for 2013, but retail tariff is for 2018

$- $20 $40 $60 $80 $100 $120 $140 $160 $- $100 $200 $300 $400 $500 $600 $700 $800 $900 Network Market Retailer 15% Retailer 20% Retailer 25%

Per MWh

Per Customer per year

Benefit ($)

New Development: How about different discount levels?

30

slide-31
SLIDE 31

WS price and SGSC load profile are for 2013, but retail tariff is for 2018

New Development: How about different discount levels?

31

Distribution of bills Annual Bill ($) Annual Bill ($/MWh)

slide-32
SLIDE 32

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 0% 6% 11% 17% 22% 28% 33% 39% 45% 50% 56% 61% 67% 72% 78% 84% 89% 95% Energy Charge % % of customers

Energy share of Bill (%)

0% 10% 20% 30% 40% 50% 60% 0% 10% 20% 30% 40% 'Real' discount Energy discount Bill discount Retailer revenue loss

New Development: Bill Discount, Energy Discount, Retailer Discount?

32

30% Energy Discount means 23% Bill discount, but 45% less revenue for retailer!

8% 38% 31% 14% 9%

54% of customers have more than 30% of their bill from fixed charge

slide-33
SLIDE 33

New Development: Clustering load profiles

33

Generating groups of load profile based on daily pattern More load profiles are [very] welcome!

slide-34
SLIDE 34

New Development: Financial calculation of RE

Data: 300 solar homes Ausgrid, 6 retail tariffs in NSW, PV cost retrieved from SolarChoice

34

Annual saving of putting PV categorised by different size range

slide-35
SLIDE 35

New Development: Financial calculation of RE

35

Data: 300 solar homes Ausgrid, 6 retail tariffs in NSW, PV cost retrieved from SolarChoice

Payback period (years) of putting PV categorised by different size range

slide-36
SLIDE 36

36

1 2 3 4 5 6 7 8 Net PV Net PV Scaled Net PV Net PV Scaled Net PV Net PV Scaled 2010-11 2011-12 2012-13 FR TOU

New Development: Financial calculation of RE

Data: 300 solar homes Ausgrid, 6 retail tariffs in NSW, PV cost retrieved from SolarChoice

Payback period based on different years data and for scaling PV to 4 kW for flat rate and TOU tariffs

slide-37
SLIDE 37

New Development: Financial calculation of RE

Data: 300 solar homes Ausgrid, 6 retail tariffs in NSW 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 2 4 6 8 10 12 Annaul Export (% of PV Generation) PV Capacity (kW) 2010-11 2011-12 2012-13

37

Percentage of export (100% - self consumption %) for different PV and load profiles

slide-38
SLIDE 38

New Development: Online list of tariffs with continues update

38

slide-39
SLIDE 39

Q&A

39

Join the discussion group at: https://groups.google.com/forum/#!forum/ceem-tda Take the online survey here: https://www.surveymonkey.com/r/J5HH277
