TameTire 3.0 Page 1 Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de cration : 03/07/2014 Index The model : an overview Model validation TameTire 3.0 : novelties

slide-1
SLIDE 1

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014 Page 1

TameTire 3.0

slide-2
SLIDE 2

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014 Page 2

Index

The model : an overview Model validation TameTire 3.0 : novelties Michelin’s vision for TameTire

slide-3
SLIDE 3

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

TameTire : an overview

slide-4
SLIDE 4

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

TameTire : an overview

For handling purposes

Page 4

Perfomances (CPU) Realism

Real time threshold TMTE

FEM

MF

Easy to obtain Difficult to obtain

slide-5
SLIDE 5

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

TameTire: the model

Mechanical model Rubber properties Thermal models Adherent part Sliding part δ speed rim casing torsion δ’ Friction coefficient X Contact temperature contact patch tread pattern Rubber shear modulus G* Tread rigidity Internal temperature

  • f the tread

FX FY MZ Convection to air Internal heating due to tread shearing Belt bending thermal equation in the tread depth Heat generation due to friction Conduction to the track contact model O X Y Z

slide-6
SLIDE 6

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Model validation

slide-7
SLIDE 7

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Model validation

Application of the following procedure to validate

  • ur model:
  • 1. Verify that the TameTire testing procedure can be

applied successfully on a third party machine

  • 2. On vehicle testing:

Steady state Braking

Page 7

Visit to NTRC (USA) to perform the TameTire testing procedure on several passenger car tyres (Michelin & competitor tyres)

slide-8
SLIDE 8

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Test procedure on a third party machine

Results at the NTRC: TameTire vs Michelin’s measurement == TameTire vs NTRC measurement /!\

Page 8

Cornering Stiffness at cold temperatures Fy @ 80kph & Z=6700N at intemediate temperatures Transient @ 10kph at hot temperatures @ Michelin @ NTRC

  • 15
  • 10
  • 5
5 10 15
  • 8000
  • 6000
  • 4000
  • 2000
2000 4000 6000 Slip angle (°) Fy (N) load6677 speed80 km/h Fy Measurement Fy Model
  • 20
  • 15
  • 10
  • 5
5 10 15 20
  • 8000
  • 6000
  • 4000
  • 2000
2000 4000 6000 8000 Slip angle (°) Fy (N) load6724 speed80 km/h Fy Measurement Fy Model
slide-9
SLIDE 9

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Model validation

Pure tyre validation

  • successfully achieved

Page 9

On vehicle validation vs simulation

  • Braking:

No precise braking model at our disposal braking with a trailer

  • Steady state:

On vehicle testing vs total vehicle simulation on CarMaker

slide-10
SLIDE 10

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Braking tests with a trailer

Braking tests performed on Michelin’s test trailer on a 245 / 35 R 20 Pilot Alpin 4 The braking force Fx is controlled until the desired maximum slip ratio (~50%) is reached To increase the clarity of the following graphs a Pacejka fit is performed on the experimental data

Page 10

Tyre being tested Trailer with hydraulic brake discs

Test plan

Effect Range Inflation pressure {1.5 ; 2.5 ; 3.5} bar Tread thickness {1.6 ; 8} mm Tyre temperature 30 -> 125 °C

slide-11
SLIDE 11

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

5 10 15 20 25 30 0.5 1 1.5

Slip Ratio (%) Friction coefficient mu Winter tyre: temperature effect

115°C simu TMTE 35°C simu TMTE 115°C mesure 35°C mesure

Braking with TameTire

Temperature effect on braking

Page 11

Ti = 115°C Ti = 35°C

115°C simu TMTE 35°C simu TMTE 115°C mesure 35°C mesure

slide-12
SLIDE 12

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

5 10 15 20 25 30 0.5 1 1.5

Slip Ratio (%) Friction coefficient mu Winter tyre: tread depth effect

8mm TMTE 1,6mm TMTE 8mm mesure 1,6mm mesure

Braking with TameTire

Sculpture height on braking

Page 12

Hs = new tyre Hs = 1,6 mm

8mm TMTE 1,6mm TMTE 8mm mesure 1,6mm mesure

slide-13
SLIDE 13

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

5 10 15 20 25 30 0.5 1 1.5

Slip Ratio (%) Friction coefficient mu Winter tyre: inflation pressure effect

1.5bar simu TMTE 2.5 bar simu TMTE 3.5 bar simu TMTE 1.5bar mesure 2.5bar mesure 3.5bar mesure

Braking with TameTire

Pressure effect on braking

Page 13

P = 1,5b P = 2,5b P = 3,5b

1.5bar simu TMTE 2.5 bar simu TMTE 3.5 bar simu TMTE 1.5bar mesure 2.5bar mesure 3.5bar mesure

slide-14
SLIDE 14

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

On vehicle results versus TameTire predictions

A on-track testing test to validate TameTire against on vehicle measurement Equipement:

  • Vehicle : 308 110HP
  • 4 Kistler wheel force transducers
  • RT systems
  • 2 Lasers
  • GPS
  • Primacy 17”
  • Continental Sport Contact 17”

Manouevres:

  • Steady state manoeuvres
  • Several laps at different speeds (6585kph)

Simulation :

  • CarMaker 4.5 + MF5.2 (Primacy 17’’ & Sport Contact 17 ’’) vs
  • CarMaker 4.5 + TameTire (Primacy 17’’ & Sport Contact 17 ’’)
slide-15
SLIDE 15

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Yaw speed [° ° ° °] Rack displacement [mm] Slip angle @ CDG [° ° ° °] ContiSportContact Primacy 3

On vehicle results versus TameTire simulations on CarMaker Speed : 80 kph (Steady State)

0.2 0.4 0.6 0.8 1 5 10 15 20 25 Lateral acceleration [g] Yaw speed [°/s] 0.2 0.4 0.6 0.8 1

  • 3
  • 2.5
  • 2
  • 1.5
  • 1
  • 0.5

Lateral acceleration [g] Slip angle @ COM (offset SA(0g)=0) [°] 0.2 0.4 0.6 0.8 1 5 10 15 20 25 Lateral acceleration [g] Yaw speed [°/s] 0.2 0.4 0.6 0.8 1

  • 3
  • 2.5
  • 2
  • 1.5
  • 1
  • 0.5

Lateral acceleration [g] Slip angle @ COM (offset SA(0g)=0) [°] 0.2 0.4 0.6 0.8 1

  • 0.005

0.005 0.01 0.015 0.02 0.025 0.03 Lateral acceleration [g] Rack displacement [m] 0.2 0.4 0.6 0.8 1

  • 0.005

0.005 0.01 0.015 0.02 0.025 0.03 Lateral acceleration [g] Rack displacement [m]

slide-16
SLIDE 16

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Slip angle @ Front Right [° ° ° °] Slip angle @ Rear axle [° ° ° °] ContiSportContact Primacy 3

On vehicle results versus TameTire simulations on CarMaker Speed : 80 kph (Steady State)

0.2 0.4 0.6 0.8 1

  • 14
  • 12
  • 10
  • 8
  • 6
  • 4
  • 2

Lateral acceleration [g] Slip angle @ Front right (offset SA(0g)=0) [°] 0.2 0.4 0.6 0.8 1

  • 14
  • 12
  • 10
  • 8
  • 6
  • 4
  • 2

Lateral acceleration [g] Slip angle @ Front right (offset SA(0g)=0) [°] 0.2 0.4 0.6 0.8 1

  • 5
  • 4.5
  • 4
  • 3.5
  • 3
  • 2.5
  • 2
  • 1.5
  • 1
  • 0.5

Lateral acceleration [g] Slip angle at rear axle (offset SA(0g)=0) [°] 0.2 0.4 0.6 0.8 1

  • 5
  • 4.5
  • 4
  • 3.5
  • 3
  • 2.5
  • 2
  • 1.5
  • 1
  • 0.5

Lateral acceleration [g] Slip angle at rear axle (offset SA(0g)=0) [°]

TameTire is overall better correlated to measurement than MF5.2

slide-17
SLIDE 17

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

TameTire 3.0 : novelties

slide-18
SLIDE 18

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

TameTire 3.0 : a faster version

TameTire 3.0 has been successfully integrated into CarMaker 4.5 TameTire 3.0 is ~ 30% faster than TameTire 2.2

Page 18

slide-19
SLIDE 19

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

TameTire 3.0 : an improved RR model

Page 19

Integration of a new rolling resistance model based

  • n the ISO 28580 indoor test
slide-20
SLIDE 20

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

TameTire 3.0 : Increased database

Page 20

Brand Tyre Line Size

Michelin PSS 235/35 ZR19 Michelin PSS 295/30 ZR19 Michelin

  • P. Sport 2

235/35 ZR19 Michelin

  • P. Sport 2

295/30 ZR19 Michelin Lat. Tour HP 255/55 R18 Michelin

  • Lat. Sport

255/55 R18 Michelin

  • Lat. Alpin

255/55 R18 Michelin

  • Lat. Sport 3

255/55 R18

Brand Tyre Line Size

Michelin

  • P. Sport 3

225/45 R17 Michelin

  • P. Sport 2

225/45 R17 Michelin

  • P. HP

225/45 R17 BFGoodrich G Grip* 225/45 R17 Michelin Alpin 5 225/45 R17 Michelin

  • P. Alpin

225/45 R17 Michelin Primacy 3 ST (AS) 225/45 R17 Michelin Primacy 3 (EU) 225/45 R17 Continental Conti Sport Contact 225/45 R17 Bridgestone Turanza ER300 225/45 R17 Bridgestone Potenza S001 225/45 R17

Brand Tyre Line Size

Michelin Primacy HP 205/55 R16 Michelin

Energy Saver

205/55 R16 Michelin Energy Saver+ 205/55 R16 Michelin Primacy Alpin 205/55 R16 Michelin Alpin 5 205/55 R16 BFGoodrich G-grip* 205/55 R16 Michelin

  • E. Saver

195/65 R15 Michelin

  • E. Saver +

195/65 R15 Michelin Alpin 3 195/65 R15 Michelin Alpin 5 195/65 R15 Kleber Dynaxer HP3 195/65 R15 Michelin

  • E. Saver

175/65 R14 Michelin

  • E. Saver +

175/65 R14

Increased/upgraded database with competitor tyres

slide-21
SLIDE 21

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Michelin’s vision for TameTire

slide-22
SLIDE 22

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Michelin’s vision for TameTire

Our answer for Tire Modeling: TameTire

  • Employed internally by Michelin for Tire Development

For passenger cars and racing tires

  • Used outside Michelin

Vehicle dynamics simulations Virtual chassis design and set-up, virtual development loops HIL and Driving simulators (driver in the loop)

  • Key advantages

Thermal & real time abilities Representing real tire physics Competitive Tools for TameTire model feeding are available

  • Virtual Scaling Factors
  • Real Tire characterization process is robust
  • Representative tire database available

Page 22

slide-23
SLIDE 23

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Michelin’s vision for TameTire

TameTire is opened towards our customers

  • Our Strategy = being able to support a wide deployment
  • Efficient Customer Support

Powered by the IPG + Michelin partnership

  • Customer Oriented Model

Integration of customer needs for future developments Measurement process for tire characterization successfully tested on external machine (NTRC)

Continuous Improvement & Progress Strategy

  • A living model, periodically updated
  • Merging multiple tire performances models

XY-Forces and Torques, steady-state and transient Rolling Resistance TPMS (Rolling Radius, evtl. Eigenmodes in the future…)

  • New features added regularly (e.g. v3.0 recently released)
  • Continuously enhanced performances

precision, calculation time…

Page 23

slide-24
SLIDE 24

Apply & Innovate 2014 Auteur/Sce : F.SPETLER & O.BLANCO HAGUE Classification: D4 Conservation :YC+3 Date de création : 03/07/2014

Thank you for your attention!
