tabula rasa

Exploring sound/gesture typo-morphology for enactive computer music performance IRCAM Musical Research Residency 2011 Thomas Grill http://grrrr.org

Contents

• Introduction – concepts
• Implementation – current status
• Implications – outlook

Enactive musical performance with recorded sounds

• Make sampled sounds within a corpus

accessible in an intuitive manner, e.g. for live performance

• Resulting sound should preserve bonding to

source material

Enactive musical performance with recorded sounds

• Organization – by which criteria?
• Interfacing – visual, haptic, auditory?
• Controlling and synthesizing –

how to preserve qualities of corpus elements / achieve a predictable stream of sound?

Enactive musical performance with recorded sounds

• Design the interface in a way that it is

immediately self-explaining ➔ enactivity

• Use principles of cross-modality ➔ embodiment
• Associate perceptual characteristics in corpus

sounds to characteristics of interaction

In the mines of matter / 2ex (2010)

Enactive musical performance with recorded sounds

• Analyze hand gestures and surface interaction

sounds

• Associate interaction traces with elements in

sound corpus (spectral and temporal)

• Synthesize audio stream, corresponding to both

the corpus and the real-time gestures

• Expressive (sonic complexity)
• Withstand and process large dynamic range

(very soft to brute force)

• High resolution ("analog" feel)
• No obstruction between performer & audience
• Portable & stage compatible (lighting, beer)

Musical interface

• Use different (exchangeable / modular) surfaces
• Tile surfaces for larger area
• Augment interaction using preparation –
• bjects to interact with
• Use interaction position for selection of sound

material

Musical interface – bonus

Musical interface

30cm contact mics 40-50cm polyacrylic interaction surface flexible, microstructured (<1mm)

]

foam spacing (~10mm) foam rubber antislip (2mm) MDF base (3mm)

[

force sensitive sensors Arduino board (ADC) mic pre-amps and ADC

Musical interface – Sensorics –

• 4x pickup microphones provide rich sonic trace
• f surface interaction
• Matrix of force sensors provides additional data
• n interaction strength
• Combined: data on interaction position

Musical interface

Musical interface – Force sensors –

• 4x4 sensors – Arduino Mega has 16 ADCs

(10 bits @ max 10kHz)

• FSR sensor range ~100g – 10kg

(resolution 10g)

• 2D interpolation (e.g. with peak picking)

should allow position detection

Musical interface – Contact microphones –

• Piezo discs exhibit large tolerances in their

resonance modes

• Larger piezo discs have lower fundamental

resonances and are more sensitive

• Background noise / hum
• 2D position detection through amplitudes
• Alternative: more expensive contact mics

Gesture segmentation

• GestureFollower follows corpus phrases

always from the start

• Necessity for meaningful segmentation
• The interaction sound is very noisy

material + background noise / hum

• Use combination of onset detection and

statistical segmentation

Gesture segmentation

• Onset detection (Jean-Philippe Lambert):
• Statistical segmentation (~Arnaud Dessein):

DKL

past lookahead Gaussians (diagonal covariances) Kullback-Leibler divergence

• i

log(melbandi) − log(melbandi) ≥ threshold

Gesture segmentation

Gesture tracing

• GestureFollower can process ~100 parallel

phrases at a time

• A typical sound corpus consists of 1000s of

sample segments

• Phrase length of interaction data and

corpus don't match – what to do when corpus phrase ends before the interaction gesture is finished?

Anticipation

• We need heuristics to reduce the number of

parallel phrases taken into account by GF

• We need to be able to (reasonably) continue

a prematurely ended corpus phrase

• Employ classification of whole segments to

predict possibly following segments (Markov Model)

Analysis – interaction sound

Interaction sound Segmentation Feature analysis Whitening Transition probabilities Front GMM Posteriors Back GMM Posteriors

Segmented audio Features Posteriors Gaussian mixture model

Segment backs Transition probabilities

following preceding

Segment fronts

Analysis – sound corpus

Corpus sound Segmentation Feature analysis Whitening Front Posteriors Transition probabilities Front GMM Posteriors Back GMM Posteriors

Analysis – sound corpus

Corpus sound Segmentation Feature analysis Whitening Front Posteriors Gesture learning Downsampling Transition probabilities iors Back GMM Posteriors

Live – gesture following

Transition probabilities iors Back GMM Posteriors

Transition probabilities

* *

Candidate segments Gesture following Downsampling Interaction Sound Segmentation Feature analysis Whitening Back Posteriors Corpus posteriors

Live – sound synthesis

• Candidate segments come along with individual

probabilities

• List can be ordered resp. probabilities used to

seed GestureFollower

• Thresholds can be used for covered total

probability or maximum number of candidates

Live – gesture following

Transition probabilities

* *

Corpus sound Candidate segments Gesture following Gesture synthesis Downsampling Interaction Sound Segmentation Feature analysis Whitening Back Posteriors Corpus posteriors

Live – sound synthesis

• GestureFollower delivers (for each input frame)

individual phrase likelihoods, time positions and speed estimates

• We need to take into account varying tracing

speeds for synthesis

• Use some speed-variable (granular) synthesis

technique

Implementation

• Whole system based on Max
• Feature analysis and segmentation is done using FTM
• Model data (GMMs, transition matrix),

corpus data (segmentation and posteriors) and GestureFollower data is stored using mubu

• Clustering and anticipation is done using Python /

numpy / scikits.learn by means of py/pyext

What is missing?

• Speed-variable sample playing
• Integrate force sensor data

e.g. for material selection (position) and dynamics processing (strength)

• Finish interface hardware

Future improvements – software –

• Use higher-level (perceptual) features to describe

sound characteristics

• Tune segmentation algorithm
• Evaluate anticipation strategy (clustering method,

front/back model, probability thresholds)

• Find out feasible feature rate for GestureFollower
• Seed GestureFollower with candidate probabilities

Future improvements – hardware –

• Use clamp-frame mechanism to allow exchangeable

surfaces (if possible)

• Explore drum-skin-like surfaces (not damped)
• Tactile feedback (potential cooperation with ISIR

haptics lab at Paris 6)

• Visual feedback (projection on surface)

Artistic implications

• Staging / ways to interact (novel instrument)
• How to radiate sound?
• Linking performance concepts to sound, using

additional objects and respective sound corpus

Thanks!

See you!
