SLIDE 1

T1DM and DKA

Endocrinology series

Dr Azeem Alam, MBBS BSc (Hons) Surgical AFP Guy’s and St. Thomas’ Hospital

Content reviewed on the 28/04/2020.

Pathophysiology, differentials, investigations and management.

Cases Quiz

SLIDE 2

History An 11-year-old boy presents to the emergency department with abdominal pain and vomiting. He reports an ongoing history of frequent urination and extreme thirst. BM levels are unrecordable and ketones are 4 mmol/L. You notice a fruity smell on his breath. Observations HR 125, BP 92/65 mmHg, RR 28, SpO2 97%, Temp 38.0

2

Case 1

SLIDE 3

SLIDE 4

History An 11-year-old boy presents to the emergency department with abdominal pain and vomiting. He reports an ongoing history of frequent urination and extreme thirst. BM levels are unrecordable and ketones are 4 mmol/L. You notice a fruity smell on his breath. Observations HR 125, BP 92/65 mmHg, RR 28, SpO2 97%, Temp 38.0.

4

Case 1

SLIDE 5

Pathophysiology

5

Pathophysiology

(1)

SLIDE 6

Pathophysiology

6

SLIDE 7

SLIDE 8

SLIDE 9

Pathophysiology

9

Definition: a metabolic disorder characterised by high glucose levels due to absolute insulin deficiency. Epidemiology

10-20% of all diabetic patients
Most common form of diabetes in <20 years of age
Highest incidence at 10-14 years old

Risk factors

HLA risk profile: HLA-DR3 and HLA-DR4
Personal / family history of autoimmune disease: e.g Hashimoto’s

Pathophysiology

SLIDE 10

Pathophysiology

10

Clinical features

Symptoms Signs Polyuria Poor wound healing Polydipsia Polyphagia Weight loss Fatigue

SLIDE 11

Pathophysiology

11

T1DM vs. T2DM

T1DM T2DM Frequency 10-20% 80-90% Pathogenesis Absolute insulin deficiency Insulin resistance Genetics HLA association No HLA association; strong genetic predisposition Presentation Age < 20 years old and often acute with DKA Age > 40 years and gradual

nset

Acute manifestation DKA Usually HHS Management Insulin Lifestyle à oral medication à insulin

SLIDE 12

SLIDE 13

Pathophysiology

13

Primary investigations:

Random blood glucose: ≥11.1 mmol/L with clinical features à same-day referral
Fasting blood glucose: ≥7.0 mmol/L is typical
Oral glucose tolerance test: ≥11.1 mmol/L two hours after a 75g oral glucose load
HbA1c: >48 mmol/mol suggests hyperglycaemia over 3 months. Use for monitoring

Investigations to consider:

C-peptide: if atypical features are present e.g. age > 50, or BMI > 25kg/m2
Autoantibodies: if atypical features are present; e.g. anti-glutamic acid decarboxylase
VBG: if concerned about DKA

Investigations

SLIDE 14

SLIDE 15

15

Management

Urgent referral to diabetes specialist team Lifestyle

Diet high in fibre and low in fat, sugar, and salt
Educate regarding carbohydrate counting; allows insulin dose to be matched to intake

Insulin therapy

Basal-bolus: first-line, long-acting regularly (basal) with rapid-acting insulin before meals (bolus)
Basal: Levemir (Detemir) given twice daily. Lantus (Glargine) once-daily is an alternative
Bolus: Insulin Lispro (Humalog), Insulin Aspart (Novorapid)
Mixed insulin regimen: short/rapid-acting insulin analogue with intermediate-acting insulin
Used when unable to tolerate basal-bolus regime
Continuous insulin infusion: disabling hypoglycaemia or persistent hyperglycaemia (HbA1c

>69mmol/mol)

SLIDE 16

Pathophysiology

16

Glucose

HbA1c: measured every 3-6 months with a target of ≤48 mmol/mol
Self-monitoring: check blood glucose levels at least 4 times a day. Targets as follows:
On waking: 5-7 mmol/L
Before meals and other times of the day: 4-7 mmol/L

Retinopathy

Immediate ophthalmology referral upon diagnosis and annually thereafter
Arrange urgent review thereafter if:
Acute reduction in acuity
Pre proliferative or proliferative retinopathy
Diabetic maculopathy

Diabetic foot

Should be assessed at least annually; refer urgently to foot protection service if at risk (e.g. ulceration)

Diabetic nephropathy

Annual measurement of eGFR and urinary albumin:creatinine ratio

Monitoring

SLIDE 17

Pathophysiology

17

Complications

System Complication Cardiovascular

Ischaemic heart disease
Heart failure
PVD

Neurological

Stroke
Carpal tunnel syndrome
Neuropathy

Endocrine

DKA

Renal

Diabetic nephropathy and CKD

Ophthalmology

Diabetic retinopathy
Macular degeneration
Open-angle glaucoma
Cataracts

SLIDE 18

18

Metabolic state as a complication of T1DM (predominantly)
Medical emergency: dehydration and electrolyte imbalances
Triad: hyperglycaemia, acidosis and ketonaemia
Mortality rate < 1% in UK
May be a first presentation of T1DM
Often a precipitating factor: infection, trauma, surgery, corticosteroid use

Diabetic ketoacidosis

SLIDE 19

SLIDE 20

20

Diabetic ketoacidosis

SLIDE 21

21 Precipitating factor Net reduction in insulin Increase in counter hormones (e.g. cortisol) Reduced glucose entry into cells Metabolism of lipids as an alternative energy source ? FFA to liver ? Ketogenesis Acidosis ? Gluconeogenesis ? Glycogenolysis Hyperglycaemia Osmotic diuresis Dehydration and electrolyte abnormalities

SLIDE 22

SLIDE 23

23

SLIDE 24

Pathophysiology

24

Clinical features

Symptoms Signs Abdominal pain Fruity ‘pear drop’ smell of acetone on the breath Nausea and vomiting Dehydration:

Mild: only just detectable
Moderate: dry skin and mucus membranes; reduced skin

turgor

Shock: tachycardia, hypotension (late), drowsiness,

reduced urine output Polyuria and polydipsia Kussmaul respiration: deep, laboured breathing Weight loss Inability to tolerate oral fluids Lethargy and confusion

SLIDE 25

25

Bedside

Urine dip: glycosuria and ketonuria
Bedside ketone and capillary glucose

Bloods

ABG/VBG: quickest way to ascertain pH and HCO3 levels
U&Es: electrolyte derangement and acute kidney injury due to dehydration
FBC and CRP: raised inflammatory markers may suggest underlying infection as a precipitant
Infection screen: if an infection is the suspected trigger

Investigations

SLIDE 26

26

Triad: hyperglycaemia, acidosis and ketonaemia

Diagnostic criteria

Joint British Diabetes Societies Inpatient Care Group (2013) Glucose > 11 mmol/L

r

known DM HCO3 < 15 mmol/L and/or venous pH < 7.30 Ketonaemia (≥ 3 mmol/l)

r

2+ ketonuria

SLIDE 27

SLIDE 28

28

Management

Treatment Further information IV fluid SBP < 90 mmHg

1 litre 0.9% NaCl over 15 mins
Call for senior help as required

SBP > 90 mmHg: typical regimen

1 litre 0.9% NaCl over 1 hour
1 litre 0.9% NaCl with KCl over next 2 hours
1 litre 0.9% NaCl with KCl over next 2 hours
1 litre 0.9% NaCl with KCl over next 4 hours
1 litre 0.9% NaCl with KCl over next 4 hours
1 litre 0.9% NaCl with KCl over next 6 hours

Insulin Fixed-rate insulin infusion:

Commence at 0.1 U/kg/h
Add in 10% glucose once glucose levels drop below 14.0 mmol/L
Do not stop long-acting insulin

SLIDE 29

29

Management

Serum potassium concentration (mmol/L) Potassium replacement > 5.5 None 3.5-5.5 40 mmol/L < 3.5 Consider HDU/ITU for replacement via central line

Potassium replacement
Total body potassium is low and correction of acidosis causes further reduction in

potassium

Anticoagulation: patients are at increased risk of VTE
Glucose, pH, bicarbonate, ketone levels, and electrolytes should be closely monitored

throughout, 1-2 hourly

SLIDE 30

30

Complications

Hypokalaemia and hyperkalaemia

Potentially life-threatening
Hyperkalaemia: extracellular shift of K+ due to acidosis
Hypokalaemia: due to correction of acidosis

Hypoglycaemia

Due to rapid correction of ketoacidosis
May result in rebound ketosis

Cerebral oedema

More common in children (70-80% of diabetes-related deaths)
Likely to be iatrogenic

SLIDE 31
