Synchronization

CISC3595/5595 Fall 2015 Fordham Univ.

Synchronization Motivation

• When threads concurrently read/write

shared memory, program behavior is undefined

– Two threads write to the same variable; which

• ne should win?
• Thread schedule is non-deterministic

– Behavior changes when re-run program

• Compiler/hardware instruction reordering
• Multi-word operations are not atomic

Question: Can this panic?

Thread 1

• p = someComputation();

pInitialized = true; Thread 2

• while (!pInitialized)

; q = someFunction(p); if (q != someFunction(p)) panic

Why Reordering?

• Why do compilers reorder instructions?

– Efficient code generation requires analyzing control/data dependency – If variables can spontaneously change, most compiler optimizations become impossible

• Why do CPUs reorder instructions?

– Write buffering: allow next instruction to execute while write is being completed

Fix: memory barrier

– Instruction to compiler/CPU – All ops before barrier complete before barrier returns – No op after barrier starts until barrier returns

Too Much Milk Example

Person A Person B 12:30 Look in fridge. Out of milk. 12:35 Leave for store. 12:40 Arrive at store. Look in fridge. Out of milk. 12:45 Buy milk. Leave for store. 12:50 Arrive home, put milk away. Arrive at store. 12:55 Buy milk. 1:00 Arrive home, put milk away. Oh no!

Definitions

Race condition: output of a concurrent program depends

• n the order of operations between threads

Mutual exclusion: only one thread does a particular thing at a time

– Critical section: piece of code that only one thread can execute at once

Lock: prevent someone from doing something

– Lock before entering critical section, before accessing shared data – Unlock when leaving, after done accessing shared data – Wait if locked (all synchronization involves waiting!)

Too Much Milk, Try #1

• Correctness property

– Someone buys if needed (liveness) – At most one person buys (safety)

• Try #1: leave a note

if (!note) if (!milk) { leave note buy milk remove note }

Too Much Milk, Try #2

Thread A

• leave note A

if (!note B) { if (!milk) buy milk } remove note A Thread B

• leave note B

if (!noteA) { if (!milk) buy milk } remove note B

Too Much Milk, Try #3

Thread A

• leave note A

while (note B) // X do nothing; if (!milk) buy milk; remove note A Thread B

• leave note B

if (!noteA) { // Y if (!milk) buy milk } remove note B

Can guarantee at X and Y that either: (i) Safe for me to buy (ii)Other will buy, ok to quit

Lessons

• Solution is complicated

– “obvious” code often has bugs

• Modern compilers/architectures reorder

instructions

– Making reasoning even more difficult

• Generalizing to many threads/processors

– Even more complex: see Peterson’s algorithm

Structured Synchronization

11

Example: Shared Object

12

13

14

15

16

Roadmap: Layered View

17

Locks

• Lock::acquire

– wait until lock is free, then take it

• Lock::release

– release lock, waking up anyone waiting for it

• 1. At most one lock holder at a time (safety)
• 2. If no one holding, acquire gets lock (progress)
• 3. If all lock holders finish and no higher priority

waiters, waiter eventually gets lock (progress)

Question: Why only Acquire/Release

• Suppose we add a method to a lock, to

ask if the lock is free. Suppose it returns

• true. Is the lock:

– Free? – Busy? – Don’t know?

Too Much Milk, #4

Locks allow concurrent code to be much simpler:

• lock.acquire();

if (!milk) buy milk lock.release();

Lock Example: Malloc/Free

char *malloc (n) { heaplock.acquire(); p = allocate memory heaplock.release(); return p; } void free(char *p) { heaplock.acquire(); put p back on free list heaplock.release(); }

Rules for Using Locks

• Lock is initially free
• Always acquire before accessing shared data

structure

– Beginning of procedure!

• Always release after finishing with shared data

– End of procedure! – Only the lock holder can release – DO NOT throw lock for someone else to release

• Never access shared data without lock

– Danger!

Will this code work?

if (p == NULL) { lock.acquire(); if (p == NULL) { p = newP(); } lock.release(); } use p->field1 newP() { p = malloc(sizeof(p)); p->field1 = … p->field2 = … return p; }

Example: Bounded Buffer

tryget() { item = NULL; lock.acquire(); if (front < tail) { item = buf[front % MAX]; front++; } lock.release(); return item; }

tryput(item) { lock.acquire(); if ((tail – front) < size) { buf[tail % MAX] = item; tail++; } lock.release(); } Initially: front = tail = 0; lock = FREE; MAX is buffer capacity

• If tryget returns NULL, do we know the buffer is empty?
• If we poll tryget in a loop, what happens to a thread calling tryput

If tryget returns NULL, do we know the buffer is empty? If we poll tryget in a loop, what happens to a thread calling tryput?

Suppose we want to block?

25

Condition Variables

• Waiting inside a critical section

– Called only when holding a lock

• Wait: atomically release lock and

relinquish processor

– Reacquire the lock when wakened

• Signal: wake up a waiter, if any
• Broadcast: wake up all waiters, if any

Condition Variable Design Pattern

methodThatWaits() { lock.acquire(); // Read/write shared state

• while (!testSharedState()) {

cv.wait(&lock); }

• // Read/write shared state

lock.release(); } methodThatSignals() { lock.acquire(); // Read/write shared state // If testSharedState is now true cv.signal(&lock);

• // Read/write shared state

lock.release(); }

Example: Bounded Buffer

get() { lock.acquire(); while (front == tail) { empty.wait(lock); } item = buf[front % MAX]; front++; full.signal(lock); lock.release(); return item; } put(item) { lock.acquire(); while ((tail – front) == MAX) { full.wait(lock); } buf[tail % MAX] = item; tail++; empty.signal(lock); lock.release(); }

Initially: front = tail = 0; MAX is buffer capacity empty/full are condition variables

Pre/Post Conditions

• What is state of the bounded buffer at

lock acquire?

– front <= tail – front + MAX >= tail

• These are also true on return from wait
• And at lock release
• Allows for proof of correctness

Pre/Post Conditions

methodThatWaits() { lock.acquire(); // Pre-condition: State is consistent

• // Read/write shared state
• while (!testSharedState()) {

cv.wait(&lock); } // WARNING: shared state may // have changed! But // testSharedState is TRUE // and pre-condition is true

• // Read/write shared state

lock.release(); } methodThatSignals() { lock.acquire(); // Pre-condition: State is consistent

• // Read/write shared state

// If testSharedState is now true cv.signal(&lock);

• // NO WARNING: signal keeps lock
• // Read/write shared state

lock.release(); }

Condition Variables

• ALWAYS hold lock when calling wait, signal,

broadcast

– Condition variable is sync FOR shared state – ALWAYS hold lock when accessing shared state

• Condition variable is memoryless

– If signal when no one is waiting, no op – If wait before signal, waiter wakes up

• Wait atomically releases lock

– What if wait, then release? – What if release, then wait?

Condition Variables, cont’d

• When a thread is woken up from wait, it may

not run immediately

– Signal/broadcast put thread on ready list – When lock is released, anyone might acquire it

• Wait MUST be in a loop

while (needToWait()) { condition.Wait(lock); }

• Simplifies implementation

– Of condition variables and locks – Of code that uses condition variables and locks

Java Manual

When waiting upon a Condition, a “spurious wakeup” is permitted to occur, in general, as a concession to the underlying platform

• semantics. This has little practical impact
• n most application programs as a

Condition should always be waited upon in a loop, testing the state predicate that is being waited for.

Semaphores

• Semaphore has a non-negative integer value

– P() atomically waits for value to become > 0, then decrements – V() atomically increments value (waking up waiter if needed)

• Semaphores are like integers except:

– Only operations are P and V – Operations are atomic

• If value is 1, two P’s will result in value 0 and one

waiter

• Semaphores are useful for

– Unlocked wait: interrupt handler, fork/join

Semaphore Bounded Buffer

get() { fullSlots.P(); mutex.P(); item = buf[front % MAX]; front++; mutex.V(); emptySlots.V(); return item; } put(item) { emptySlots.P(); mutex.P(); buf[last % MAX] = item; last++; mutex.V(); fullSlots.V(); }

Initially: front = last = 0; MAX is buffer capacity mutex = 1; emptySlots = MAX; fullSlots = 0;

Implementing Condition Variables using Semaphores (Take 1)

wait(lock) { lock.release(); semaphore.P(); lock.acquire(); } signal() { semaphore.V(); }

Roadmap: Layered View

37

Structured Synchronization via Shared Objects

• Identify objects or data structures that can be accessed

by multiple threads concurrently

– In OS/161 kernel, everything!

• Add locks to object/module

– Grab lock on start to every method/procedure – Release lock on finish

• If need to wait

– while(needToWait()) { condition.Wait(lock); } – Do not assume when you wake up, signaller just ran

• If do something that might wake someone up

– Signal or Broadcast

• Always leave shared state variables in a consistent state

– When lock is released, or when waiting

Remember the rules

• Use consistent structure
• Always use locks and condition variables
• Always acquire lock at beginning of

procedure, release at end

• Always hold lock when using a condition

variable

• Always wait in while loop
• Never spin in sleep()

Condition Variables: Mesa vs. Hoare semantics

• Mesa

– Signal puts waiter on ready list – Signaller keeps lock and processor

• Hoare

– Signaller gives processor and lock to waiter – When waiter finishes, processor/lock given back to signaller – Nested signals possible!

FIFO Bounded Buffer
 (Hoare semantics)

get() { lock.acquire(); if (front == tail) { empty.wait(lock); } item = buf[front % MAX]; front++; full.signal(lock); lock.release(); return item; }

put(item) { lock.acquire(); if ((tail – front) == MAX) { full.wait(lock); } buf[last % MAX] = item; last++; empty.signal(lock); //CAREFUL: someone else ran lock.release(); }

Initially: front = tail = 0; MAX is buffer capacity empty/full are condition variables

FIFO Bounded Buffer
 (Mesa semantics)

• Create a condition variable for every waiter
• Queue condition variables (in FIFO order)
• Signal picks the front of the queue to wake up
• CAREFUL if spurious wakeups!
• Easily extends to case where queue is LIFO,

priority, priority donation, …

– With Hoare semantics, not as easy

FIFO Bounded Buffer
 (Mesa semantics, put() is similar)

get() { lock.acquire(); myPosition = numGets++; self = new Condition; nextGet.append(self); while (front < myPosition || front == tail) { self.wait(lock); } delete self; item = buf[front % MAX]; front++; if (next = nextPut.remove()) { next->signal(lock); } lock.release(); return item; }

Initially: front = tail = numGets = 0; MAX is buffer capacity nextGet, nextPut are queues of Condition Variables

Roadmap: Layered View

44

Implemente Synchronization Variable: Lock and Conditional Variable

Take 1: using memory load/store

– See too much milk solution/Peterson’s algorithm

Take 2:

Lock::acquire() { disable interrupts } Lock::release() { enable interrupts }

Lock Implementation, Uniprocessor

Lock::acquire() { disableInterrupts(); if (value == BUSY) { waiting.add(myTCB); myTCB->state = WAITING; next = readyList.remove(); switch(myTCB, next); myTCB->state = RUNNING; } else { value = BUSY; } enableInterrupts(); } Lock::release() { disableInterrupts(); if (!waiting.Empty()) { next = waiting.remove(); next->state = READY; readyList.add(next); } else {
 value = FREE; } enableInterrupts(); }

Multiprocessor

• Read-modify-write instructions

– Atomically read a value from memory, operate on it, and then write it back to memory – Intervening instructions prevented in hardware

• Examples

– Test and set – Intel: xchgb, lock prefix – Compare and swap

• Any of these can be used for implementing

locks and condition variables!

Spinlocks

A spinlock is a lock where the processor waits in a loop for the lock to become free

– Assumes lock will be held for a short time – Used to protect the CPU scheduler and to implement locks

Spinlock::acquire() { while (testAndSet(&lockValue) == BUSY) ; } Spinlock::release() { lockValue = FREE; memorybarrier(); }

How many spinlocks?

• Various data structures

– Queue of waiting threads on lock X – Queue of waiting threads on lock Y – List of threads ready to run

• One spinlock per kernel?

– Bottleneck!

• Instead:

– One spinlock per lock – One spinlock for the scheduler ready list

• Per-core ready list: one spinlock per core

What thread is currently running?

• Thread scheduler needs to find the TCB of the

currently running thread

– To suspend and switch to a new thread – To check if the current thread holds a lock before acquiring or releasing it

• On a uniprocessor, easy: just use a global
• On a multiprocessor, various methods:

– Compiler dedicates a register (e.g., r31 points to TCB running on the this CPU; each CPU has its own r31) – If hardware has a special per-processor register, use it – Fixed-size stacks: put a pointer to the TCB at the bottom of its stack

• Find it by masking the current stack pointer

Lock Implementation, Multiprocessor

Lock::acquire() { disableInterrupts(); spinLock.acquire(); if (value == BUSY) { waiting.add(myTCB); suspend(&spinlock); } else { value = BUSY; } spinLock.release(); enableInterrupts(); } Lock::release() { disableInterrupts(); spinLock.acquire(); if (!waiting.Empty()) { next = waiting.remove(); scheduler- >makeReady(next); } else {
 value = FREE; } spinLock.release(); enableInterrupts(); }

Compare Implementations

Semaphore::P() { disableInterrupts(); spinLock.acquire(); if (value == 0) { waiting.add(myTCB); suspend(&spinlock); } else { value--; } spinLock.release(); enableInterrupts(); } Semaphore::V() { disableInterrupts(); spinLock.acquire(); if (!waiting.Empty()) { next = waiting.remove(); scheduler- >makeReady(next); } else {
 value++; } spinLock.release(); enableInterrupts(); }

Lock Implementation, Multiprocessor

Sched::suspend(SpinLock ∗lock) { TCB ∗next;

• disableInterrupts();

schedSpinLock.acquire(); lock−>release(); myTCB−>state = WAITING; next = readyList.remove(); thread_switch(myTCB, next); myTCB−>state = RUNNING; schedSpinLock.release(); enableInterrupts(); } Sched::makeReady(TCB ∗thread) {

• disableInterrupts ();

schedSpinLock.acquire(); readyList.add(thread); thread−>state = READY; schedSpinLock.release(); enableInterrupts(); }

Lock Implementation, Linux

• Most locks are free most of the time

– Why? – Linux implementation takes advantage of this fact

• Fast path

– If lock is FREE, and no one is waiting, two instructions to acquire the lock – If no one is waiting, two instructions to release the lock

• Slow path

– If lock is BUSY or someone is waiting, use multiproc impl.

• User-level locks

– Fast path: acquire lock using test&set – Slow path: system call to kernel, use kernel lock

Lock Implementation, Linux

struct mutex { /∗ 1: unlocked ; 0: locked; negative : locked, possible waiters ∗/ atomic_t count; spinlock_t wait_lock; struct list_head wait_list; }; // atomic decrement // %eax is pointer to count lock decl (%eax) jns 1f // jump if not signed // (if value is now 0) call slowpath_acquire 1:

Implementing Condition Variables
 using Semaphores (Take 2)

wait(lock) { lock.release(); semaphore.P(); lock.acquire(); } signal() { if (semaphore is not empty) semaphore.V(); }

Implementing Condition Variables
 using Semaphores (Take 3)

wait(lock) { semaphore = new Semaphore; queue.Append(semaphore); // queue of waiting threads lock.release(); semaphore.P(); lock.acquire(); } signal() { if (!queue.Empty()) { semaphore = queue.Remove(); semaphore.V(); // wake up waiter } }

Example: Bounded Buffer

get() { lock.acquire(); while (front == tail) { empty.wait(lock); } item = buf[front % MAX]; front++; full.signal(lock); lock.release(); return item; } put(item) { lock.acquire(); while ((tail – front) == MAX) { full.wait(lock); } buf[tail % MAX] = item; tail++; empty.signal(lock); lock.release(); }

Initially: front = tail = 0; MAX is buffer capacity empty/full are condition variables

Remember the rules

• Use consistent structure
• Always use locks and condition variables
• Always acquire lock at beginning of

procedure, release at end

• Always hold lock when using a condition

variable

• Always wait in while loop
• Never spin in sleep()
