Synchronization

presented by Radu Teodorescu

CS533

Why we need it?

• Parallel programs share data!
• Consistency of shared data structures
• Access serialization
• Coordination between processors
• Allows queueing, ordering

2

For today

• How synchronization works
• Synchronization operations
• Hardware primitives
• Implementations

How it works

• Components of a synchronization event:
• ACQUIRE method - access right to the

synchronization

• WAITING algorithm - wait for

synchronization to become available

• RELEASE method - allow other processes

to proceed past synchronization

Waiting algorithms

• The process spins in a loop, repeatedly

testing for status change

• PROS: low latency
• CONS: blocks processor, higher traffic

(network, bus, cache)

Busy-waiting

Waiting algorithms

• The process suspends, releases the

processor, waits to be awakened

• PROS: releases the processor for other jobs
• CONS: higher overhead

Scheduling overhead < expected wait time

Blocking

Synch operations

• Locks: grant access to one process only
• Barriers: no process advances beyond it until

all have arrived

• Semaphores
• Monitors
• …

Some combination of hardware primitives and software

Hardware primitives

• Synchronization requires some ATOMIC
• peration
• Some flavor of atomic Read&Modify
• Atomic exchange
• Test & set
• Fetch & increment

Implement locks, barriers, etc.

Test & set

• Test a value and set it if test passed
• Also used to implement locks
• In cache coherent machines - lots of

invalidations

lock: ADD R2, R0, #1 T&S R2, (R1) BNEZ R2, lock

Test and test & set

• Take advantage of locality
• Test before write (to avoid an invalidation)

lock: LD R2, (R1) BNEZ R2, lock ADD R2, R0, #1 T&S R2, (R1) BNEZ R2, lock

Atomic exchange

• Exchange a value in a register with memory
• Can be used to implement a spin lock

lock: LD R2, (R1) BNEZ R2, lock ADD R2, R0, #1 EXCH R2, (R1) BNEZ R2, lock

EXCH Reg, Mem

Fetch and increment

• Reads a memory value and increments it

atomically

• Useful for barrier implementation
• Can be used to determine how many

processes are waiting for it

Performance

• How expensive is locking with test&set?
• N processors waiting
• No hold time

∑(2i+1) = N2+2N

lock: ADD R2, R0, #1 T&S R2, (R1) BNEZ R2, lock

Hardware complexity

• Single, atomic memory operation
• Hard to implement in hardware
• complicates the coherence protocol
• must be uninterrupted
• avoid deadlocks

Reducing complexity

• Maintain the atomicity requirement
• Have two linked instructions
• The second indicates if the pair executed

atomically

• MIPS/SGI: Load-linked (LL), Store-conditional (SC)

LL/SC

• LL returns value of memory location
• SC
• LL/SC not atomic - returns 0, doesn’t

update memory

• LL/SC is atomic - returns 1, updates

memory

LL/SC

• LL/SC also fails if processor context

switches between LL and SC

• Can implement other primitives: exchange,

fetch-and-add,...

lock: LL R2, (R1) BNEZ R2, lock ADD R2, R0, #1 SC R2, (R1) BEQZ R2, lock

Implementations

• HEP Multiprocessor
• NYU Ultracomputer
• IBM RP3
• Illinois Cedar

HEP multiprocessor

• Each word in memory has Full/Empty bit
• Bit is tested in hardware before a RD/WR
• The RD/WR blocks until the test succeeds:
• RD until full
• WR until empty
• When test succeeds, the bit is set to the
• pposite value

HEP multiprocessor

• PROS:
• Very efficient for low level dependences

(compare to locks)

• CONS:
• Requires complex hardware:
• F/E bits
• Support to queue a process if test fails
• Logic to implement indivisible ops

NYU ultracomputer

• Implements fetch-and-add
• PROS:
• Can use message combining, scales well
• Efficient barrier implementation
• CONS:
• Very complex network
• Adders in each memory module

Message combining

Switch Memory X Switch Memory X Switch Memory X Switch Memory X 5 F&A(X,3) F&A(X,1) 3 5 F&A(X,4) 9 5 5 8 3 9

IBM RP3

• Implements fetch-and-phi, where phi can be:
• Add, And, Or
• Min, Max, Store
• Store if zero
• PRO: generality
• CON: hardware complexity

Illinois Cedar

• General atomic instruction that operates on

synchronization variables

• Synch variable has 2 words: Key and

Value

• Synch instruction:
• F/E bit test for a read:
• Complex hardware, special processor for

each memory module

{addr;(cond);op on key;op on value} {X; (X.key==1)*; decrement; fetch}

That’s it for today!
